Rigol DM3063 User manual

User Manual
RIGOL
Publication number DM3-070314
March 2007
DM3000 Series Digital Multimeter
DM3061/2/3/4
DM3051/2/3/4
© Copyright RIGOL Technologies, Inc. 2007
All Rights Reserved

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. I
User Manual for DM3000 Series
zCopyright © RIGOL TECHNOLOGIES, INC. 2007 All Rights Reserved.
zRIGOL products are protected by patent law in and outside of P.R. China.
zInformation in this publication replaces that in all previously corresponding
material.
zRIGOL Technologies, Inc. reserves the right to modify or change pat of or all
the specifications and pricing policies at company’s sole decision.
NOTE: RIGOL is the registered trademark of RIGOL TECHNOLOGIES, INC.

RIGOL
II © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
Safety Notices
Review the following safety precautions carefully before operate the instrument
to avoid any personal injury or to damage the instrument and any products
connected to it.
To avoid potential hazards use the instrument in a manner only as specified by
this user’s guide.
The instrument should be serviced only by qualified personnel.
To Avoid Fire or Personal Injury
Use proper power cord Use only the power cord designed for your
oscilloscope and authorized in your country.
Connect and Disconnect accessories properly. Do not connect or
disconnect probes or test leads while they are connected to a voltage source
Ground the instrument This product is grounded through the protective terra
conductor of the power cord. To avoid electric shock the grounding conductor
must be connected to earth ground. Before making connections to the input or
output terminals of the oscilloscope ensure that the instrument is properly
grounded.
Connect the probe properly. The probes’ ground terminals are at the same
voltage level with earth terminal of the instrument. Do not connect the ground
terminals to a high voltage.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all
ratings and marks on the instrument. Follow the user’s manual for further ratings
information before making connections to the instrument.
Do not operate without Covers. Do not operate your oscilloscope with covers
or panels removed.

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. III
User Manual for DM3000 Series
Use Proper Fuse. Use only the fuse type and rating specified for this product.
Avoid Circuit or Wire Exposure. Do not touch exposed connections and
components when power is on.
Do not operate with suspected failures. If you suspect damage with this
product, have it inspected by qualified service personnel who were authorized by
RIGOL before further operations.
Provide Proper Ventilation. Refer to the manual’s installation instructions for
details as to the oscilloscope has proper ventilation.
Do not operate in wet/damp conditions
Do not operate in an explosive atmosphere
Keep product surfaces clean and dry
The disturbance test of all the models can meet the limit values of A in
the standard of EN 61326: 1997+A1+A2+A3, but can't meet the limit
values of B.

RIGOL
IV © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
Safety Terms and Symbols
Terms in This Manual. These terms may appear in this manual:
WARNING: Warning statements identify conditions or practices that
could result in injury or loss of life.
CAUTION: Caution statements identify conditions or practices that
could result in damage to this product or other property.
CAT II (1000V): IEC Measurement Category II. Inputs may be
connected to mains (up to 1000 VAC) under Category II overvoltage
conditions.
Terms on the Product: These terms may appear on the product:
DANGER indicates an injury hazard may happen immediately.
WARNING indicates an injury hazard may not happen immediately.
CAUTION indicates that a potential damage to the instrument or other property
might occur.
Symbols on the Product: These symbols may appear on the Instrument:
!
Hazardous
Voltage Refer to Instructions Protective earth terminal Test
Grounding
Terminal
Grounding
Terminal
of Chassis
!
!
!

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. V
User Manual for DM3000 Series
General-Purpose Multimeter
The book covers the following description and eight models DM3000 Series
Digital Multimeter:
DM3061、DM3062、DM3063、DM3064;
DM3051、DM3052、DM3053、DM3054.
DM3000 Series Digital Multimeter desktop naming rules:
Prefix desktop Digital Multimeter
Serial Number
6－62
1
，5－54
3
digit
No.
1－Basic, 2－Interface models with expansion board,
3－Inspection plate with the model,
4－Inspection plate with the model and interface extended board
Application examples:
DM3061－62
1
DM3000 series. Basic type
DM3062－62
1
DM3000 series. Basic type. Increasing the interface board with
LAN/GPIB.
DM3063－62
1
DM3000 Series, Basic type. Increasing the inspection board
DM3064－62
1
DM3000 series, Basic type. Increasing the interface board with
LAN/GPIB and inspection board.
30 61
DM

RIGOL
VI © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
RIGOL DM3000-Series Digital Multimeter is a high-precision, multifunction,
multi-automatic measurement for users designment of products, including 6 2
1
digits multimeter, high-speed data acquisition, automatic measurement and
inspection, many mathematical transform, in one of sensor measurements and
other functions. In support RS-232, USB, LAN and GPIB interface. It supports U
disk storage and print.
In performance, the DM3000 has high-resolution monochrome LCD display
system, supports a simple waveform display and data recording waveform
display; clear and easy to operate the button backlight keyboard layout and
operation make it more flexible, user-friendly operating features;50k/S high data
sampling rate, can be used, such as the rapidly changing high-precision audio
waveform data; depth 2Mbyte of internal storage, external storage can be
arbitrary depth; adopt true RMS AC voltage and current measurement; virtual
terminal display and control, and remote network access.
From the performance and characteristics are given below, you will Understand
how can DM3000 satisfy your measurement requirements.
z50k/s data sampling rate, can be used, such as the rapidly changing
high-precision audio waveform data. Meanwhile waveform can be displayed
on LCD Screen
zMeasurement accuracy: more than 6 1/2 and 2,400,000 Count
z26 measurement functions
DC voltage and current, AC voltage and current, two-wire and four-wire
resistance, capacitance, continuity test, diode test, frequency, cycle
ratio measurements, arbitrary sensor measurement, And so on.
Upper limit and lower limit on the threshold measurement
Arithmetic include: maximum, minimum, average, dBm, dB
Data acquisition functions include : data records, inspection, automatic
measurement
zTrue RMS AC voltage and current measurement
z16- Road inspection functional measurement and control software (optional)
zDC voltage >10GΩinput impedance to achieve the scope of 48V (±24V)
zWith data acquisition function, the maximum sampling rate support to
50kSPs

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. VII
User Manual for DM3000 Series
z10 groups measuring set-up storage and embedded PC measuring set up
unlimited storage
zSaturat-ing responses of 256 x 64 pixel monochrome LCD
zI/O: RS-232, USB, LAN and GPIB
zBuilt-in USB Host to support USB disk and USB printer
zSimple, convenient, flexible control software: Ultralogger, Supports for
Microsoft® Windows 98/2000/Me/XP

RIGOL
VIII © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
Content
Safety Notices ......................................................................................................................II
General-Purpose Multimeter ..............................................................................................V
CHAPTER 1 : BASIC MULTIMETER OPERATIONS................................... 1-1
General Inspection ........................................................................................................... 1-2
Handle Adjustment........................................................................................................... 1-3
The Front/Rear Panel and User Interface..................................................................... 1-4
To Measure DC Voltage................................................................................................... 1-7
To Measure AC Voltage ................................................................................................... 1-9
To Measure DC Current................................................................................................. 1-11
To Measure AC Current ................................................................................................. 1-13
To Measure Resistance.................................................................................................. 1-15
To Measure Capacitance ............................................................................................... 1-19
To Test Continuity.......................................................................................................... 1-21
To Check Diodes............................................................................................................. 1-23
To Measure Frequency and Period .............................................................................. 1-25
To Measure Arbitrary Sensor........................................................................................ 1-29
To Choice Digits resolving index.................................................................................. 1-33
To Choose Data Digit Display....................................................................................... 1-34
To Choose Range Options............................................................................................. 1-35
To Control Trigger Options ........................................................................................... 1-37
CHAPTER 2 : OPERATING YOUR MULTIMETER...................................... 2-1
To Set up Measurement Parameters............................................................................. 2-2
Math Functions ............................................................................................................... 2-12
To Set Up Triggering Parameter Function.................................................................. 2-19
Store and Recall.............................................................................................................. 2-27
To Set Up the Utility....................................................................................................... 2-32
High-speed Data Logger ............................................................................................... 2-46
Multi-route Scanning...................................................................................................... 2-53
How to Use the Built-in Help System .......................................................................... 2-61
CHAPTER 3 : APPLICATION & EXAMPLES............................................... 3-1
Example 1: Reading Statistic Functions ........................................................................ 3-1
Example 2: Elimination Test Leads Resistance Error................................................... 3-3
Example 3: dB Measurement.......................................................................................... 3-4
Example 4: dBm Measurement ...................................................................................... 3-5

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. IX
User Manual for DM3000 Series
Example 5: Limit Test.......................................................................................................3-6
Example 6: Temperature Sensor ....................................................................................3-7
Example 7: Reading Hold ..............................................................................................3-11
CHAPTER 4 : PROMPT MESSAGES& TROUBLESHOOTING ....................4-1
Prompting Message..........................................................................................................4-1
Troubleshooting ................................................................................................................4-3
CHAPTER 5 : SUPPORT & SERVICE...........................................................5-1
CHAPTER 6 : APPENDIX .............................................................................6-4
Appendix A: Specifications ..............................................................................................6-4
Appendix B: DM3000 Series Accessories ......................................................................6-7
Appendix C: General Care and Cleaning .......................................................................6-8

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 1-1
User Manual for DM3000 Series
Chapter 1 : Basic Multimeter Operations
This chapter covers the following topics:
General Inspection
Handle Adjustment
The Front Panel and User Interface
To Measure DC Voltage
To Measure AC Voltage
To Measure DC Current
To Measure AC Current
To Measure Resistance
To Measu re Capac itance
To Test Continuity
To Check Diodes
To Measure Frequency and Period
To Make an Arbitrary Sensor measurement
To Choice Digits resolving index
To Choose Data Digit Display
To Choose Range Options
To Control Trigger Options

RIGOL
1-2 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
General Inspection
After you get a new DM3000 Digital Multimeter, you are suggested the following
steps to inspect the instrument.
1. Inspect the shipping container for damage.
Keep a damaged shipping container or cushioning material until the contents of
the shipment have been checked for completeness and the instrument has been
checked mechanically and electrically.
2. Check the accessories.
Accessories supplied with the instrument are listed in "Accessories" in front of
this manual.
If the contents are incomplete or damaged, please notify your RIGOL Sales
Representative.
3. Inspect the instrument.
In case any mechanical damage or defect, or if the instrument does not operate
properly or pass performance tests, notify your RIGOL Sales Representative.
If the shipping container is damaged, or the cushioning materials show signs of
stress, notify the carrier as well as your RIGOL sales office. Keep the shipping
materials for the carrier’s inspection.
RIGOL offices will arrange for reparation or replacement at RIGOL’s option without
waiting for claim settlement.

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 1-3
User Manual for DM3000 Series
Handle Adjustment
To adjust the handle position of DM3000 Digital Multimeter, please grip the handle by
the sides and pull it outward. Then, make the handle rotate to the desired position.
The operation methods are shown in the graphs 1-1, 1-2, 1-3.
Figure 1-1
Figure 1-2 Figure 1-3
Viewing Positions Carrying Position

RIGOL
1-4 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
The Front/Rear Panel and User Interface
After you get a new DM3000 Digital Multimeter, first, you need to clear how to
operate the front panel of the DM3000 correctly. This chapter will make a brief
introduction and description for the operation and functions of the Front Panel.
The front panel of the DM3000 is very simple and clear for users operation. The front
panel include direction buttons and functions buttons.
Figure 1-4
USB Host
District Purple:
Measurement Function
Ke
y
s
Menu Operation
Keys Blue Direction:
Function Selective
Keys
Current Input Terminal
Direction Keys
LCD Display
District Yellow:
Trigger Control Keys
On/Off Switch

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 1-5
User Manual for DM3000 Series
Figure 1-5
Figure 1-6
The interface explanation
VMC
10/100
Ethernet GPIB
(IEEE--488)
USB Device RS--232 Power FuseAC Voltage
Selector
Current Input Fuse Power Socket
Differential
Multiplexer Interface
Ext Trigger
Measurement
Data Display
Digits
resolving
index
Range
Current Measurement
Function
Local/Remote
Operation
Parameters
Display
Operation
Menu
Parameters
Name

RIGOL
1-6 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
How the definitions express in this book
In this book, the regarding keys writing expression has the same log with the keys on
the front panel. It is noteworthy that the menu operates keys, marking with the belt
shadow. For example, Conti , it means in menu short circuit option.

RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 1-7
User Manual for DM3000 Series
To Measure DC Voltage
In view of DC voltage measurement function, the following part demonstrated how
to link the measurement connection and how to choose measurement functions. The
following practice will gradually guide you to be familiar with the DC Voltage
measurement technique.
Figure 1-7
DC Voltage measurement data interface
Table 1-1 DC Voltage measurement characteristics
Five Range 200mV, 2V, 20V, 200V, 1000V
Max Resolution 100nV
Import Protection 1000V on all ranges (HI Termin al)
Configurable
Parameters Range, DC impedance, Null value
Basic measurement:
1. Connect test leads as Figure 1-8 shown. Red test lead connects the HI Terminal,
Black test lead connects the LO Terminal.
2. Press to select the DC Voltage measurement function.
3. According to the voltage measuring scope, choose the correct range.
4. Setup the DC impedance.
Press ÆRes , to setup the DC input impedance. Default value of the DC
input impedance will be 10MΩ, this parameter had been setup, and users may carry
on the DC Voltage measurement directly without modification.
5. Set the Null value
Null computing will be an option operation, it could be setup in accordance with
user demand. If user does not implement Null computing, this parameter is not

RIGOL
1-8 © Copyright RIGOL Technologies, Inc. 2007.
User Manual for DM3000 Series
required, direct implementation of the next step.
(To know the specific setting methods of the Null value setting, please refer to
Chapter 2 “To Set Up Measurement Parameters”, Null computing)
6. Lead test leads into circuit, starts to measurement.
Figure 1-8
DC Voltage measurement instruction chart
7. Measurement history data processing
Press History , enter the menu shown below:
Figure 1-9
To check or save the data that has measured by current measurement function,
you can use the history function. In this function you can get the “Info” (information),
“List” and “Graph” of this measurement. Also, you can save this information data
with press Save softkey.
Note
If the users can not predict the scope of the measurement, please choose Auto
range to obtain more accurate measurement data.
DC Voltage
