Rigol DS1000Z Series Operating instructions

RIGOL
Programming Guide
DS1000Z Series Digital Oscilloscope
Dec. 2013
RIGOL Technologies, Inc.

RIGOL
DS1000Z Programming Guide I
Guaranty and Declaration
Copyright
© 2013 RIGOL Technologies, Inc. All Rights Reserved.
Trademark Information
RIGOLis a registered trademark of RIGOL Technologies, Inc.
Publication Number
PGA17104-1110
Notices
RIGOL products are protected by patent law in and outside of P.R.C.
RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at
company’s sole decision.
Information in this publication replaces all previously corresponding material.
RIGOL shall not be liable for losses caused by either incidental or consequential in connection with
the furnishing, use or performance of this manual as well as any information contained.
Any part of this document is forbidden to be copied or photocopied or rearranged without prior written
approval of RIGOL.
Product Certification
RIGOL guarantees this product conforms to the national and industrial standards in China as well as the
ISO9001:2008 standard and the ISO14001:2004 standard. Other international standard conformance
certification is in progress.
Contact Us
If you have any problem or requirement when using our products or this manual, please contact RIGOL.
E-mail: servi[email protected]
Website: www.rigol.com

RIGOL
II DS1000Z Programming Guide
Document Overview
This manual guides users to control RIGOL DS1000Z series digital oscilloscope remotely by programming
using SCPI commands through the remote interface. DS1000Z can build communication with the PC
through the USB, LAN or GPIB (option) interface.
Main Topics in this Manual:
Chapter 1 Programming Overview
This chapter introduces how to build the remote communication between DS1000Z series digital
oscilloscope and the PC. It also introduces the remote control method and the SCPI commands.
Chapter 2 Command System
This chapter introduces the syntax, function, parameter and using instruction of each command.
Chapter 3 Programming Demos
This chapter lists some programming demos to illustrate how to use commands to realize the common
functions of the oscilloscope in the development environments of Excel, LabVIEW, Matlab, Visual Basic 6.0
and Visual C++ 6.0.
Tip
For the newest version of this manual, please download it from www.rigol.com.
Format Conventions in this Manual:
1. Button
The function key at the front panel is denoted by the format of “Button Name (Bold) + Text Box” in the
manual, for example, Utility denotes the “Utility” key.
2. Menu
The menu item is denoted by the format of “Menu Word (Bold) + Character Shading” in the manual,
for example, System denotes the “System” item under Utility.
3. Operation Step
The next step of the operation is denoted by an arrow “” in the manual. For example, Utility 
System denotes pressing Utility at the front panel and then pressing System.
Content Conventions in this Manual:
DS1000Z series includes the following models. Unless otherwise noted, this manual takes DS1104Z-S as an
example to illustrate the command system of DS1000Z series.
Model
Analog Bandwidth
Channel
Source Channel
DS1104Z
100 MHz
4
None
DS1074Z
70 MHz
4
None
DS1104Z-S
100 MHz
4
2
DS1074Z-S
70 MHz
4
2

Contents RIGOL
DS1000Z Programming Guide III
Contents
Guaranty and Declaration ......................................................................................................... I
Document Overview .................................................................................................................II
Chapter 1 Programming Overview......................................................................................1-1
To Build Remote Communication ...............................................................................................1-2
Remote Control Methods...........................................................................................................1-4
SCPI Command Overview..........................................................................................................1-5
Syntax...............................................................................................................................1-5
Symbol Description ............................................................................................................1-5
Parameter Type..................................................................................................................1-6
Command Abbreviation ......................................................................................................1-6
Chapter 2 Command System...............................................................................................2-1
:AUToscale...............................................................................................................................2-2
:CLEar......................................................................................................................................2-2
:RUN........................................................................................................................................2-2
:STOP ......................................................................................................................................2-2
:SINGle....................................................................................................................................2-3
:TFORce...................................................................................................................................2-3
:ACQuire Commands.................................................................................................................2-4
:ACQuire:AVERages............................................................................................................2-4
:ACQuire:MDEPth...............................................................................................................2-5
:ACQuire:TYPE...................................................................................................................2-6
:ACQuire:SRATe?................................................................................................................2-7
:CALibrate Commands...............................................................................................................2-8
:CALibrate:QUIT ................................................................................................................2-8
:CALibrate:STARt ...............................................................................................................2-8
:CHANnel<n> Commands.........................................................................................................2-9
:CHANnel<n>:BWLimit.......................................................................................................2-9
:CHANnel<n>:COUPling................................................................................................... 2-10
:CHANnel<n>:DISPlay ..................................................................................................... 2-10
:CHANnel<n>:INVert ....................................................................................................... 2-10
:CHANnel<n>:OFFSet...................................................................................................... 2-11
:CHANnel<n>:RANGe ...................................................................................................... 2-11
:CHANnel<n>:TCAL......................................................................................................... 2-12
:CHANnel<n>:SCALe ....................................................................................................... 2-13
:CHANnel<n>:PROBe....................................................................................................... 2-13
:CHANnel<n>:UNITs........................................................................................................ 2-14
:CHANnel<n>:VERNier..................................................................................................... 2-14
:CURSor Commands ............................................................................................................... 2-15
:CURSor:MODE................................................................................................................ 2-15
:CURSor:MANual.............................................................................................................. 2-16
:CURSor:TRACk ............................................................................................................... 2-21
:CURSor:AUTO:ITEM........................................................................................................ 2-25
:CURSor:XY ..................................................................................................................... 2-26
:DISPlay Commands ............................................................................................................... 2-29
:DISPlay:CLEar ................................................................................................................ 2-29
:DISPlay:DATA? ............................................................................................................... 2-30
:DISPlay:TYPE ................................................................................................................. 2-31
:DISPlay:GRADing:TIME................................................................................................... 2-31
:DISPlay:WBRightness...................................................................................................... 2-31
:DISPlay:GRID................................................................................................................. 2-32
:DISPlay:GBRightness ...................................................................................................... 2-32
IEEE488.2 Common Commands............................................................................................... 2-33
*CLS ............................................................................................................................... 2-33
*ESE ............................................................................................................................... 2-33

RIGOL Contents
IV DS1000Z Programming Guide
*ESR?..............................................................................................................................2-34
*IDN?..............................................................................................................................2-34
*OPC...............................................................................................................................2-34
*RST ...............................................................................................................................2-34
*SRE ...............................................................................................................................2-34
*STB?..............................................................................................................................2-35
*TST?..............................................................................................................................2-35
*WAI...............................................................................................................................2-35
:MATH Commands ..................................................................................................................2-36
:MATH:DISPlay.................................................................................................................2-37
:MATH:OPERator..............................................................................................................2-37
:MATH:SOURce1 ..............................................................................................................2-37
:MATH:SOURce2 ..............................................................................................................2-38
:MATH:SCALe...................................................................................................................2-38
:MATH:OFFSet .................................................................................................................2-39
:MATH:INVert...................................................................................................................2-39
:MATH:RESet ...................................................................................................................2-39
:MATH:FFT:WINDow.........................................................................................................2-40
:MATH:FFT:SPLit ..............................................................................................................2-40
:MATH:FFT:UNIT..............................................................................................................2-41
:MATH:FFT:HSCale ...........................................................................................................2-41
:MATH:FFT:HCENter .........................................................................................................2-42
:MATH:OPTion:STARt........................................................................................................2-42
:MATH:OPTion:END..........................................................................................................2-43
:MATH:OPTion:INVert.......................................................................................................2-43
:MATH:OPTion:SENSitivity.................................................................................................2-44
:MATH:OPTion:DIStance...................................................................................................2-44
:MATH:OPTion:ASCale ......................................................................................................2-44
:MATH:OPTion:THReshold1...............................................................................................2-45
:MATH:OPTion:THReshold2...............................................................................................2-45
:MASK Commands...................................................................................................................2-46
:MASK:ENABle..................................................................................................................2-46
:MASK:SOURce.................................................................................................................2-47
:MASK:OPERate................................................................................................................2-47
:MASK:MDISplay ..............................................................................................................2-48
:MASK:SOOutput..............................................................................................................2-48
:MASK:OUTPut.................................................................................................................2-49
:MASK:X ..........................................................................................................................2-49
:MASK:Y ..........................................................................................................................2-49
:MASK:CREate..................................................................................................................2-50
:MASK:PASSed?................................................................................................................2-50
:MASK:FAILed?.................................................................................................................2-50
:MASK:TOTal? ..................................................................................................................2-50
:MASK:RESet....................................................................................................................2-50
:MEASure Commands..............................................................................................................2-51
:MEASure:SOURce............................................................................................................2-54
:MEASure:COUNter:SOURce..............................................................................................2-54
:MEASure:COUNter:VALue?...............................................................................................2-54
:MEASure:CLEar...............................................................................................................2-55
:MEASure:RECover ...........................................................................................................2-55
:MEASure:ADISplay ..........................................................................................................2-56
:MEASure:AMSource.........................................................................................................2-56
:MEASure:SETup:MAX.......................................................................................................2-57
:MEASure:SETup:MID .......................................................................................................2-57
:MEASure:SETup:MIN .......................................................................................................2-58
:MEASure:SETup:PSA........................................................................................................2-58
:MEASure:SETup:PSB........................................................................................................2-59
:MEASure:SETup:DSA .......................................................................................................2-59

Contents RIGOL
DS1000Z Programming Guide V
:MEASure:SETup:DSB....................................................................................................... 2-59
:MEASure:STATistic:DISPlay.............................................................................................. 2-60
:MEASure:STATistic:MODE................................................................................................ 2-60
:MEASure:STATistic:RESet ................................................................................................ 2-61
:MEASure:STATistic:ITEM ................................................................................................. 2-61
:MEASure:ITEM ............................................................................................................... 2-62
:REFerence Commands ........................................................................................................... 2-63
:REFerence:DISPlay ......................................................................................................... 2-63
:REFerence<n>:ENABle ................................................................................................... 2-63
:REFerence<n>:SOURce .................................................................................................. 2-64
:REFerence<n>:VSCale.................................................................................................... 2-64
:REFerence<n>:VOFFset.................................................................................................. 2-65
:REFerence<n>:RESet ..................................................................................................... 2-65
[:SOURce[<n>]] Commands (DS1000Z-S Only)........................................................................ 2-66
[:SOURce[<n>]]:OUTPut[<n>][:STATe]............................................................................ 2-67
[:SOURce[<n>]]:OUTPut[<n>]:IMPedance....................................................................... 2-67
[:SOURce[<n>]]:FREQuency[:FIXed]................................................................................ 2-68
[:SOURce[<n>]]:PHASe[:ADJust]..................................................................................... 2-68
[:SOURce[<n>]]:PHASe:INITiate...................................................................................... 2-69
[:SOURce[<n>]]:FUNCtion[:SHAPe].................................................................................. 2-69
[:SOURce[<n>]]:FUNCtion:RAMP:SYMMetry ..................................................................... 2-70
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate][:AMPLitude].............................................. 2-70
[:SOURce[<n>]]:VOLTage[:LEVel][:IMMediate]:OFFSet...................................................... 2-71
[:SOURce[<n>]]:PULSe:DCYCle ....................................................................................... 2-71
[:SOURce[<n>]]:MOD[:STATe]......................................................................................... 2-72
[:SOURce[<n>]]:MOD:TYPe............................................................................................. 2-72
[:SOURce[<n>]]:MOD:AM[:DEPTh].................................................................................. 2-73
[:SOURce[<n>]]:MOD:AM:INTernal:FREQuency ................................................................ 2-73
[:SOURce[<n>]]:MOD:FM:INTernal:FREQuency ................................................................ 2-73
[:SOURce[<n>]]:MOD:AM:INTernal:FUNCtion ................................................................... 2-74
[:SOURce[<n>]]:MOD:FM:INTernal:FUNCtion ................................................................... 2-74
[:SOURce[<n>]]:MOD:FM[:DEVIation].............................................................................. 2-74
[:SOURce[<n>]]:APPLy? .................................................................................................. 2-75
[:SOURce[<n>]]:APPLy:NOISe ......................................................................................... 2-75
[:SOURce[<n>]]:APPLy:PULSe ......................................................................................... 2-75
[:SOURce[<n>]]:APPLy:RAMP.......................................................................................... 2-75
[:SOURce[<n>]]:APPLy:SINusoid...................................................................................... 2-75
[:SOURce[<n>]]:APPLy:SQUare........................................................................................ 2-75
[:SOURce[<n>]]:APPLy:USER........................................................................................... 2-75
:SYSTem Commands............................................................................................................... 2-77
:SYSTem:AUToscale.......................................................................................................... 2-77
:SYSTem:BEEPer.............................................................................................................. 2-77
:SYSTem:ERRor[:NEXT]?.................................................................................................. 2-78
:SYSTem:GPIB ................................................................................................................. 2-78
:SYSTem:LANGuage ......................................................................................................... 2-78
:SYSTem:LOCKed............................................................................................................. 2-78
:SYSTem:PON.................................................................................................................. 2-79
:SYSTem:OPTion:INSTall .................................................................................................. 2-79
:SYSTem:OPTion:UNINSTall.............................................................................................. 2-79
:TIMebase Commands ............................................................................................................ 2-80
:TIMebase:DELay:ENABle................................................................................................. 2-80
:TIMebase:DELay:OFFSet................................................................................................. 2-80
:TIMebase:DELay:SCALe .................................................................................................. 2-81
:TIMebase[:MAIN]:OFFSet................................................................................................ 2-81
:TIMebase[:MAIN]:SCALe................................................................................................. 2-82
:TIMebase:MODE............................................................................................................. 2-82
:TRIGger Commands .............................................................................................................. 2-83
:TRIGger:MODE............................................................................................................... 2-83

RIGOL Contents
VI DS1000Z Programming Guide
:TRIGger:COUPling...........................................................................................................2-84
:TRIGger:STATus? ............................................................................................................2-84
:TRIGger:SWEep..............................................................................................................2-84
:TRIGger:HOLDoff............................................................................................................2-85
:TRIGger:NREJect ............................................................................................................2-85
:TRIGger:EDGe ................................................................................................................2-86
:TRIGger:PULSe...............................................................................................................2-88
:TRIGger:SLOPe...............................................................................................................2-91
:TRIGger:VIDeo ...............................................................................................................2-96
:TRIGger:PATTern.............................................................................................................2-99
:TRIGger:DURATion........................................................................................................2-101
:TRIGger:TIMeout (Option).............................................................................................2-104
:TRIGger:RUNT (Option).................................................................................................2-106
:TRIGger:WINDows (Option)...........................................................................................2-110
:TRIGger:DELay (Option)................................................................................................2-113
:TRIGger:SHOLd (Option)...............................................................................................2-116
:TRIGger:NEDGe (Option)...............................................................................................2-119
:TRIGger:RS232 (Option)................................................................................................2-121
:TRIGger:IIC (Option).....................................................................................................2-125
:TRIGger:SPI (Option)....................................................................................................2-129
:WAVeform Commands..........................................................................................................2-133
:WAVeform:SOURce........................................................................................................2-134
:WAVeform:MODE ..........................................................................................................2-135
:WAVeform:FORMat........................................................................................................2-135
:WAVeform:DATA?..........................................................................................................2-136
:WAVeform:XINCrement?................................................................................................2-137
:WAVeform:XORigin? ......................................................................................................2-137
:WAVeform:XREFerence? ................................................................................................2-137
:WAVeform:YINCrement?................................................................................................2-138
:WAVeform:YORigin? ......................................................................................................2-138
:WAVeform:YREFerence? ................................................................................................2-138
:WAVeform:STARt...........................................................................................................2-139
:WAVeform:STOP ...........................................................................................................2-139
:WAVeform:PREamble?...................................................................................................2-140
Chapter 3 Programming Demos......................................................................................... 3-1
Programming Preparations.........................................................................................................3-2
Excel Programming Demo..........................................................................................................3-3
Matlab Programming Demo........................................................................................................3-7
LabVIEW Programming Demo....................................................................................................3-9
Visual Basic Programming Demo..............................................................................................3-13
Visual C++ Programming Demo...............................................................................................3-15

Chapter 1 Programming Overview RIGOL
DS1000Z Programming Guide 1-1
Chapter 1 Programming Overview
This chapter introduces how to build the remote communication between the PC and instrument and
provides an overview of the syntax, symbol, parameter type and abbreviation rules of the SCPI commands.
Main topics of this chapter:
To Build Remote Communication
Remote Control Methods
SCPI Command Overview

RIGOL Chapter 1 Programming Overview
1-2 DS1000Z Programming Guide
To Build Remote Communication
This oscilloscope can build communication with the PC through the USB, LAN or GPIB (option) interface.
This section introduces how to control the oscilloscope remotely through the USB interface using Ultra
Sigma in details.
Operation Steps:
1. Install the Ultra Sigma common PC software
Download the Ultra Sigma common PC software from www.rigol.com or acquire it from the resource
CD supplied with the accessories and install it according to the instructions.
2. Connect the instrument and PC and configure the interface parameters of the instrument
DS1000Z can build communication with the PC through the USB, LAN or GPIB (option) interface. This
manual takes the USB interface as an example.
(1) Connect the devices
Connect the USB DEVICE interface at the real panel of the oscilloscope and the USB Host interface
of the PC using a USB cable.
(2) Install the USB driver
This oscilloscope is a USBTMC device. Assuming that your PC has already been installed with
Ultra Sigma, after you connect the oscilloscope to the PC and turn both on for the first time (the
oscilloscope is automatically configured to the USB interface), the New Hardware Wizard as
shown in the figure below is displayed on the PC. Please install the “USB Test and Measurement
Device” driver following the directions in the wizard. The steps are as follows.
1
2
3
4

Chapter 1 Programming Overview RIGOL
DS1000Z Programming Guide 1-3
(3) Search for device resource
Start up the Ultra Sigma and the software will automatically search for the oscilloscope
resources currently connected to the PC. You can also click to search for the
resources. During the search, the status bar of the software is as shown in the figure below.
5
6
7

RIGOL Chapter 1 Programming Overview
1-4 DS1000Z Programming Guide
(4) View the device resources
The resources found will appear under the “RIGOL Online Resource” directory and the model
number and USB interface information of the instrument will also be displayed as shown in the
figure below.
(5) Communication test
Right click the resource name “DS1104Z (USB0::0x1AB1::0x04CE::DS1T0000000006::INSTR)”
and select “SCPI Panel Control” to turn on the remote command control panel (as shown in the
figure below) through which you can send commands and read data.
Remote Control Methods
1. User-defined Programming
Users can use the SCPI (Standard Commands for Programmable Instruments) commands to program
and control the oscilloscope. For details, refer to the introductions in Chapter 3 Programming
Demos.
2. Send SCPI Commands via the PC Software
You can control the oscilloscope remotely by sending SCPI commands via the PC software (Ultra Sigma)
provided by RIGOL.Besides, you can also control the instrument using the “Measurement &
Automation Explorer” of NI (National Instruments Corporation) or the “Agilent IO Libraries Suite” of
Agilent (Agilent Technologies, Inc.).

Chapter 1 Programming Overview RIGOL
DS1000Z Programming Guide 1-5
SCPI Command Overview
SCPI (Standard Commands for Programmable Instruments) is a standardized instrument programming
language that is built upon the standard IEEE488.1 and IEEE 488.2 and conforms to various standards
(such as the floating point operation rule in IEEE754 standard, ISO646 7-bit coded character for
information interchange (equivalent to ASCll programming)). The SCPI commands provide a hierarchical
tree structure. Each command subsystem consists of a root keyword and on or more sub-keywords.
Syntax
The command string usually starts with ":"; the keywords are separated by ":" and are followed by the
parameter settings available; "?" is added at the end of the command string to indicate query; the
command and parameter are separated by space.
For example,
:ACQuire:TYPE <type>
:ACQuire:TYPE?
ACQuire is the root keyword of the command. TYPE is the second-level keyword. The command string starts
with ":" which is also used to separate the multiple-level keywords. <type> represents the parameters
available for setting. "?" represents query. The command :ACQuire:TYPE and parameter <type> are
separated by space.
"," is generally used for separating multiple parameters contained in the same command, for example,
:TRIGger:PATTern:PATTern <pattern1>,<pattern2>,<pattern3>,<pattern4>
Symbol Description
The following symbols will not be sent with the commands.
1. Braces {}
The parameters enclosed in the braces are optional and are usually separated by the vertical bar "|".
When using the command, one of the parameters must be selected.
2. Vertical Bar |
The vertical bar is used to separate multiple parameters and one of the parameters must be selected
when using the command.
3. Square Brackets []
The content in the square brackets can be omitted.
4. Triangle Brackets <>
The parameter enclosed in the triangle brackets must be replaced by an effective value.

RIGOL Chapter 1 Programming Overview
1-6 DS1000Z Programming Guide
Parameter Type
1. Bool
The parameter could be OFF, ON, 0 or 1. For example,
:MEASure:ADISplay <bool>
:MEASure:ADISplay?
Wherein,
<bool> can be set to {{0|OFF}|{1|ON}}.
The query returns 0 or 1.
2. Discrete
The parameter could be any of the values listed. For example,
:ACQuire:TYPE <type>
:ACQuire:TYPE?
Wherein,
<type> can be set to NORMal|AVERages|PEAK|HRESolution.
The query returns the abbreviations (NORM, AVER, PEAK or HRES).
3. Integer
Unless otherwise noted, the parameter can be any integer (NR1 format) within the effective value
range. Note that do not set the parameter to a decimal, otherwise errors will occur. For example,
:DISPlay:GBRightness <brightness>
:DISPlay:GBRightness?
Wherein,
<brightness> can be set to any integer between 0 and 100.
The query returns an integer between 0 and 100.
4. Real
The parameter can be any real number within the effective value range and this command accepts
decimal (NR2 format) and scientific notation (NR3 format) parameter input. For example,
:TRIGger:TIMeout:TIMe <NR3>
:TRIGger:TIMeout:TIMe?
Wherein,
<NR3> can be set to any real number between 1.600000e-08 (namely 16ns) to 0.1e+02 (namely 10s).
The query returns a real number in scientific notation.
5. ASCII String
The parameter should be the combinations of ASCII characters.
For example,
:SYSTem:OPTion:INSTall <license>
Wherein,
<license> can be set to PDUY9N9QTS9PQSWPLAETRD3UJHYA.
Command Abbreviation
All the commands are case-insensitive and you can use any of them. If abbreviation is used, all the capital
letters in the command must be written completely. For example, the :MEASure:ADISplay? command can
be abbreviated to :MEAS:ADIS?.

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-1
Chapter 2 Command System
This chapter introduces the syntax, function, parameter and using instruction of each DS1000Z command.
Main topics of this chapter:
:AUToscale
:CLEar
:RUN
:STOP
:SINGle
:TFORce
:ACQuire Commands
:CALibrate Commands
:CHANnel<n> Commands
:CURSor Commands
:DISPlay Commands
IEEE488.2 Common Commands
:MATH Commands
:MASK Commands
:MEASure Commands
:REFerence Commands
[:SOURce[<n>]] Commands (DS1000Z-S Only)
:SYSTem Commands
:TIMebase Commands
:TRIGger Commands
:WAVeform Commands
Note:
1. Unless otherwise noted, this manual takes DS1104Z-S as an example to introduce the commands.
2. For parameter setting commands (for example, the time, frequency and amplitude), the oscilloscope
can only accept numbers and set the parameters using the default units; it cannot recognize the units
sent with the parameters. For the default unit of each parameter, please refer to the description in each
command in the following introductions.

RIGOL Chapter 2 Command System
2-2 DS1000Z Programming Guide
:AUToscale
Syntax
:AUToscale
Description Enable the waveform auto setting function. The oscilloscope will automatically adjust the
vertical scale, horizontal timebase and trigger mode according to the input signal to
realize optimum waveform display. This command is equivalent to pressing the AUTO key
at the front panel.
Explanation Theoretically, waveform auto setting function requires that the frequency of sine is no
lower than 41Hz; the duty cycle should be greater than 1% and the amplitude must
be at least 20mVpp for square.
When the pass/fail function is enabled (see the :MASK:ENABle command), if you sent
this command, the oscilloscope will disable the pass/fail function firstly and then
execute the waveform auto setting function.
When the waveform record function is enabled or during the playback of the
recorded waveform, this command is invalid.
:CLEar
Syntax
:CLEar
Description Clear all the waveforms on the screen. If the oscilloscope is in the RUN state, waveform
will still be displayed. This command is equivalent to pressing the CLEAR key at the front
panel.
Related
Command
:DISPlay:CLEar
:RUN
:STOP
Syntax :RUN
:STOP
Description The :RUN command makes the oscilloscope start running and the :STOP command makes
the oscilloscope stop running. These commands are equivalent to pressing the
RUN/STOP key at the front panel.
Explanation When the waveform record function is enabled or during the playback of the recorded
waveform, this command is invalid.

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-3
:SINGle
Syntax
:SINGle
Description Set the oscilloscope to the single trigger mode. This command is equivalent to the
following two operations: pressing the SINGLE key at the front panel and sending
the :TRIGger:SWEep SINGle command.
Explanation In the single trigger mode, the oscilloscope triggers once when the trigger conditions
are met and then stops.
When the waveform record function is enabled or during the playback of the
recorded waveform, this command is invalid.
Related
Commands :TFORce
:RUN
:STOP
:TFORce
Syntax
:TFORce
Description Generate a trigger signal forcefully. This command is only applicable to the normal and
single trigger modes (see the :TRIGger:SWEep command) and is equivalent to pressing
the FORCE key at the front panel.
Related
Command
:TRIGger:SWEep

RIGOL Chapter 2 Command System
2-4 DS1000Z Programming Guide
:ACQuire Commands
The :ACQuire commands are used to set and query the memory depth, acquisition mode and the current
sample rate of the oscilloscope as well as to set the number of averages under the average acquisition
mode.
Command List [1] :
:ACQuire:AVERages
:ACQuire:MDEPth
:ACQuire:TYPE
:ACQuire:SRATe?
Note[1]:In the “Command List” in this manual, the parameters in the setting commands and the query
commands are not included and you can refer to the complete introductions of the commands in the text
according to the keyword.
:ACQuire:AVERages
Syntax :ACQuire:AVERages <count>
:ACQuire:AVERages?
Description
Set or query the number of averages under the average acquisition mode.
Parameter
Name
Type
Range
Default
<count>
Integer
2
n
(n is an integer from 1 to 10)
2
Explanation You can sent the :ACQuire:TYPE command to set the acquisition mode.
In the average acquisition mode, the greater the number of averages is, the lower
the noise will be and the higher the vertical resolution will be but the slower the
response of the displayed waveform to the waveform changes will be.
Return
Format
The query returns an integer between 2 and 1024.
Example :ACQuire:AVERages 128 /*Set the number of averages to 128*/
:ACQuire:AVERages? /*The query returns 128*/
Related
Command :ACQuire:TYPE

Chapter 2 Command System RIGOL
DS1000Z Programming Guide 2-5
:ACQuire:MDEPth
Syntax :ACQuire:MDEPth <mdep>
:ACQuire:MDEPth?
Description Set or query the memory depth of the oscilloscope namely the number of waveform
points that can be stored in a single trigger sample. The default unit is pts (points).
Parameter
Name
Type
Range
Default
<mdep> Discrete Refer to the Explanation AUTO
Explanation When a single channel is on: {AUTO|12000|120000|1200000|12000000|24000000}
When dual channels are on: {AUTO|6000|60000|600000|6000000|12000000}
When four channels are on: {AUTO|3000|30000|300000|3000000|6000000}
Wherein, 24000000, 12000000 and 6000000 are options.
The relationship among the memory depth, sample rate and waveform length
satisfies the following equation:
Memory Depth ＝Sample Rate × Waveform Length
Wherein, the Waveform Length is the product of the horizontal timebase (set by
the :TIMebase[:MAIN]:SCALe command) times the number of the horizontal scales
(12 for DS1000Z).
When AUTO is selected, the oscilloscope will select the memory depth automatically
according to the current sample rate.
Return
Format
The query returns the actual number of points (integer) or AUTO.
Example :ACQuire:MDEPth 12000 /*Set the memory depth to 12000*/
:ACQuire:MDEPth? /*The query returns 12000*/
Related
Commands :ACQuire:SRATe?
:TIMebase[:MAIN]:SCALe

RIGOL Chapter 2 Command System
2-6 DS1000Z Programming Guide
:ACQuire:TYPE
Syntax :ACQuire:TYPE <type>
:ACQuire:TYPE?
Description
Set or query the acquisition mode when the oscilloscope samples.
Parameter
Name
Type
Range
Default
<type>
Discrete
{NORMal|AVERages|PEAK|HRESolution}
NORMal
Explanation NORMal: in this mode, the oscilloscope samples the signal at equal time interval to
rebuild the waveform. For most of the waveforms, the best display effect can be
obtained using this mode.
AVERages: in this mode, the oscilloscope averages the waveforms from multiple
samples to reduce the random noise of the input signal and improve the vertical
resolution. The number of averages can be set by the:ACQuire:AVERages command.
The greater the number of averages is, the lower the noise will be and the higher the
vertical resolution will be but the slower the response of the displayed waveform to
the waveform changes will be.
PEAK (Peak Detect): in this mode, the oscilloscope acquires the maximum and
minimum values of the signal within the sample interval to get the envelope of the
signal or the narrow pulse of the signal that might be lost. In this mode, signal
confusion can be prevented but the noise displayed would be larger.
HRESolution (High Resolution): this mode uses a kind of ultra-sample technique to
average the neighboring points of the sample waveform to reduce the random noise
on the input signal and generate much smoother waveforms on the screen. This is
generally used when the sample rate of the digital converter is higher than the
storage rate of the acquisition memory.
Return
Format
The query returns NORM, AVER, PEAK or HRES.
Example
:ACQuire:TYPE AVERages /*Select the average acquisition mode*/
Related
Command
:ACQuire:AVERages
