RIKA E16705 User manual

CONNECT WOOD
Operating manual
E16705 / E16709 / E16726 / E16727

2
TABLE OF CONTENTS
1. EXPLANATIONS TO SYMBOLS 3
2. TECHNICAL DOCUMENTATION  ECODESIGN 4
3. TECHNICAL DATA 8
Spare part overview exploded diagram............................................................................................................................................................ 8
Spare part overview - article numbers .............................................................................................................................................................10
Dimensions ...................................................................................................................................................................................................................................11
Amount of fuel ...........................................................................................................................................................................................................................11
Technical data...........................................................................................................................................................................................................................11
Packaging......................................................................................................................................................................................................................................11
4. IMPORTANT INFORMATION 12
General warning and safety information ........................................................................................................................................................12
First heating................................................................................................................................................................................................................................12
Safety distances .....................................................................................................................................................................................................................12
Prior to set up........................................................................................................................................................................................................................... 13
5. BRIEF INFORMATION ON COMBUSTIBLE  LOGS 14
Suitable fuels and fuel amounts ............................................................................................................................................................................. 14
Wood types................................................................................................................................................................................................................................. 14
Output controlling................................................................................................................................................................................................................ 14
Clean combustion................................................................................................................................................................................................................ 14
6. INSTALLING THE STOVE 15
Connection to the chimney..........................................................................................................................................................................................15
Connecting to a steel chimney .................................................................................................................................................................................15
Combustion air........................................................................................................................................................................................................................15
Feeding in external combustion air......................................................................................................................................................................15
7. MANUAL OPERATION 16
RIKA firelighter......................................................................................................................................................................................................................... 16
Combustion air regulation........................................................................................................................................................................................... 16
Correct heating up...............................................................................................................................................................................................................17
Refilling............................................................................................................................................................................................................................................17

|3
2
EN
1. EXPLANATIONS TO SYMBOLS
...important
Note
...useful
Tip ...manually ...fragile
8. CLEANING AND MAINTENANCE 18
Basic information ................................................................................................................................................................................................................. 18
Cleaning the door glass.................................................................................................................................................................................................. 18
Clean combustion chamber....................................................................................................................................................................................... 18
Empty ash drawer................................................................................................................................................................................................................ 18
Clean painted surfaces................................................................................................................................................................................................... 18
Clean convection air openings ................................................................................................................................................................................ 18
Clean flue gas outlet.......................................................................................................................................................................................................... 19
Check seals................................................................................................................................................................................................................................ 19
9. PROBLEMS  POSSIBLE SOLUTIONS 20
Problem 1......................................................................................................................................................................................................................................20
Problem 2.....................................................................................................................................................................................................................................20
Problem 3 ....................................................................................................................................................................................................................................20
10. GUARANTEE CONDITIONS 21
11. WARRANTY CONDITIONS 21
12. DISPOSAL INFORMATION 22
Information on the individual components of the device ...............................................................................................................22
Extract from the waste code of the European Waste List Regulation.................................................................................22
Electronic Waste....................................................................................................................................................................................................................22
13. COMPLIANCE WITH EU REGULATIONS 22

2. TECHNICAL DOCUMENTATION  ECODESIGN
Contact details of the manufacturer
Manufacturer:
Contact:
Address:
Details of the device
Characteristics when operating with the preferred fuel
Special precautions for assembly, installation or maintenance
Characteristics when operating exclusively with the preferred fuel
Pnom 8kW
Pmin 4kW
ηth,nom >=80 %
ηth,min >=80 %
elmax n.A. kW
elmin n.A. kW
elSB n.A. kW
Ppilot n.A. kW
*RIKATRONIC
Notified body:
Pilot flame power requirement
Notified body no.:
Technische Universität Wien, Getreidemarkt 9/166, 1060
Wien, Austria
1746
Fire protection and safety distances such as distances to combustible building materials must be observed!
Direct heat output:
n.A.
EN13240:2001/A2:2004/AC:2007
-
Nein
TECHNICAL DOCUMENTATION
according to commission regulation
(EU) 2015/1185 und 2015/1186
Ecodesign
Model Identifier:
Equivalent models:
CONNECT WOOD
-
RIKA Innovative Ofentechnik GmbH
Andreas Bloderer
Müllerviertel 20
4563 Micheldorf
Austria
Test report no.:
Applied harmonised standards:
Other applied standards/technical specifications:
Indirect heating functionality:
An adequate supply of combustion air for the appliance must be guaranteed at all times. Air-suction systems can interfere with the combustion air supply!
The flue gas values of the appliance must be observed for the chimney dimensioning!
Auxiliary electricity consumption*
At nominal heat output
At minimum heat output
Heat output
Nominal heat output
Minimum heat output
Useful efficiency
Useful efficiency at nominal heat output
8 kW
Indirect heat output:
Useful efficiency at minimum heat output
In standby mode
Permanent pilot flame power requirement
Energy Efficiency Index: >=107 - <130
-Seasonal space heating energy efficiency RIKATRONIC ηs :
-
Seasonal space heating energy efficiency ηs :
Energy Efficiency Index RIKATRONIC:
>=70 %
-
4

Yes
No
No
No
No
No
No
No
No
Details of the fuel
PM OGC CO NO
x
PM OGC CO NO
x
Yes No >=70 <=40 <=120 <=1250 <=200 - - - -
No No - - - - - - - - -
Compressed wood, moisture content < 12 % No No - - - - - - - - -
Other woody biomass No No - - - - - - - - -
Non-woody biomass No No - - - - - - - - -
Anthracite and dry steam coal No No - - - - - - - - -
Hard coke No No - - - - - - - - -
Low temperature coke No No - - - - - - - - -
Bituminous coal No No - - - - - - - - -
Lignite briquettes No No - - - - - - - - -
Peat briquettes No No - - - - - - - - -
Blended fossil fuel briquettes No No - - - - - - - - -
Other fossil fuel No No - - - - - - - - -
Blended biomass and fossil fuel briquettes No No - - - - - - - - -
Other blend of biomass and solid fuel No No - - - - - - - - -
(*) PM = dust, OGC = gaseous organic compounds, CO = carbon monoxide, NOx = nitrous gases
(**) Only required when applying correction factors F(2) or F(3)
Signed for and on behalf of the manufacturer by:
Micheldorf, 25.04.2022
In case of doubt as well as missing or incorrect translations, the German version is the only valid one.
Subject to technical and visual changes as well as layout and printing errors.
© 2021 | RIKA Innovative Ofentechnik GmbH
with electronic room temperature control plus day timer (**)
Type of heat output/room temperature control
two or more manual stages, no room temperature control (**)
with mechanic thermostat room temperature control (**)
with electronic room temperature control (**)
Room temperature control with presence detection (**)
single stage heat output, no room temperature control
with electronic room temperature control plus week timer (**)
Andreas Bloderer / product management
Room temperature control with open window detection (**)
Space heating emissions
at nominal heat output
(*)
Space heating emissions
at minimum heat output
(*)(**)
mg/Nm
3
(13% O
2
)mg/Nm
3
(13% O
2
)
with remote control options (**)
Fuel Preferred
fuel:
Other
suitable fuel:
ηs[%]
|5
4
EN

Contact details of the manufacturer
Manufacturer:
Contact:
Address:
Details of the device
Characteristics when operating with the preferred fuel
Special precautions for assembly, installation or maintenance
Characteristics when operating exclusively with the preferred fuel
Pnom 6kW
Pmin 4kW
ηth,nom >=80 %
ηth,min >=80 %
elmax n.A. kW
elmin n.A. kW
elSB n.A. kW
Ppilot n.A. kW
*RIKATRONIC
Notified body:
Pilot flame power requirement
Notified body no.:
Technische Universität Wien, Getreidemarkt 9/166, 1060
Wien, Austria
1746
Fire protection and safety distances such as distances to combustible building materials must be observed!
Direct heat output:
n.A.
EN13240:2001/A2:2004/AC:2007
-
Nein
TECHNICAL DOCUMENTATION
according to commission regulation
(EU) 2015/1185 und 2015/1186
Ecodesign
Model Identifier:
Equivalent models:
CONNECT WOOD 6 kW
-
RIKA Innovative Ofentechnik GmbH
Andreas Bloderer
Müllerviertel 20
4563 Micheldorf
Austria
Test report no.:
Applied harmonised standards:
Other applied standards/technical specifications:
Indirect heating functionality:
An adequate supply of combustion air for the appliance must be guaranteed at all times. Air-suction systems can interfere with the combustion air supply!
The flue gas values of the appliance must be observed for the chimney dimensioning!
Auxiliary electricity consumption*
At nominal heat output
At minimum heat output
Heat output
Nominal heat output
Minimum heat output
Useful efficiency
Useful efficiency at nominal heat output
6 kW
Indirect heat output:
Useful efficiency at minimum heat output
In standby mode
Permanent pilot flame power requirement
Energy Efficiency Index: >=107 - <130
-Seasonal space heating energy efficiency RIKATRONIC ηs :
-
Seasonal space heating energy efficiency ηs :
Energy Efficiency Index RIKATRONIC:
>=70 %
-
6

Yes
No
No
No
No
No
No
No
No
Details of the fuel
PM OGC CO NO
x
PM OGC CO NO
x
Yes No >=70 <=40 <=120 <=1250 <=200 - - - -
No No - - - - - - - - -
Compressed wood, moisture content < 12 % No No - - - - - - - - -
Other woody biomass No No - - - - - - - - -
Non-woody biomass No No - - - - - - - - -
Anthracite and dry steam coal No No - - - - - - - - -
Hard coke No No - - - - - - - - -
Low temperature coke No No - - - - - - - - -
Bituminous coal No No - - - - - - - - -
Lignite briquettes No No - - - - - - - - -
Peat briquettes No No - - - - - - - - -
Blended fossil fuel briquettes No No - - - - - - - - -
Other fossil fuel No No - - - - - - - - -
Blended biomass and fossil fuel briquettes No No - - - - - - - - -
Other blend of biomass and solid fuel No No - - - - - - - - -
(*) PM = dust, OGC = gaseous organic compounds, CO = carbon monoxide, NOx = nitrous gases
(**) Only required when applying correction factors F(2) or F(3)
Signed for and on behalf of the manufacturer by:
Micheldorf, 25.04.2022
In case of doubt as well as missing or incorrect translations, the German version is the only valid one.
Subject to technical and visual changes as well as layout and printing errors.
© 2021 | RIKA Innovative Ofentechnik GmbH
with electronic room temperature control plus day timer (**)
Type of heat output/room temperature control
two or more manual stages, no room temperature control (**)
with mechanic thermostat room temperature control (**)
with electronic room temperature control (**)
Room temperature control with presence detection (**)
single stage heat output, no room temperature control
with electronic room temperature control plus week timer (**)
Andreas Bloderer / product management
Room temperature control with open window detection (**)
Space heating emissions
at nominal heat output
(*)
Space heating emissions
at minimum heat output
(*)(**)
mg/Nm
3
(13% O
2
)mg/Nm
3
(13% O
2
)
with remote control options (**)
Fuel Preferred
fuel:
Other
suitable fuel:
ηs[%]
|7
6
EN

3. TECHNICAL DATA
Spare part overview exploded diagram
51
52
55
54
53
50
50
64
64
63
63
63
65
65
66
67
53
50
72
69
69
71
71
68
68
70
70
69
69
61
62
60
59
57
58
56
21
21
22
22
14
16
13
12
32
31
34
35
7
7
7
7
7
15
15
15
15
15
15
36
37
18
37
11
10
9
8
7
7
7
1
1
1
7
20
20
19
19
18
17
18
17
33
4
6
3
5
2
1
1
29
30
27
26
25
18
23
24
38
28
39
8

102
100
100
101
101
101
101
99
80
81
85
87
87
87
87
82
82
90
89
89
89
88
88
88
88
91
83
83
84
84
86
86
92
93
94
96
96
95
95
88
97
97
98
82
89
89
117
120
120
119
119
118
118
112
112
111
110
110
116
124
121
123
122
114
115
113
RAO
|9
8
EN

Spare part overview - article numbers
Note: Please consider the powdercoated parts can differ slightly in colour and colour effects though they are elaborated in high quality.
Minor damage to the trim parts can be repaired with our special Senotherm paint spray. There is no matching RAL colour for the painted
fairing parts.
10
NR. ART.NR. DESCRIPTION
1 N112142 Flange nut
2 L03954 Holder plate
3 B18879 Magnet
4 Z38953 Door opener
B19077 Door opener compl. right for door stop left
B19084 Door opener compl. left for door stop right
5 N112166 Headless screw M04X16
6 N112829 Setscrew door opener M06X20
7 N112009 Flat washer
8 LB00922 Decorative door left door stop
B19075 Decorative door compl. left door stop
LB00927 Decorative door right door stop
B19083 Decorative door compl. right door stop
9 N103693 Flat seal black 8x2
10 Z38645 Door glass
11 N103693 Flat seal black 8x2
12 N111970 Hexagonal nut M08
13 N112214 Hexagonal bolt M08X40
14 Z38643 Front door right
15 N112138 Hexagonal screw M05X12
16 Z38644 Front door left
17 N111866 Hexagonal screw M05X20
18*1 N111965 Washer M05
19 L04096 Hinge plate top
20 L03951 Hinge plate below
21 B16814 Hinge
22 N111780 Hexagonal nut
23*1 N111950 Hexagonal screw M05x10
24*1 N112148 Hexagonal screw M04X10
25*1 L04099 Lock
26*1 L04098 Locking plate
27 Z39437 Angle support
28 Z39435 Spring tensioner
29 Z39780 Torsion spring left
Z39547 Torsion spring right
30 Z39436 Pipe
31 N103693 Flat seal black 8x2
32 Z38646 Front door glass
33 N112828 Double sealing cord
34 L03756 Glass holder
35 N111964 Hexagonal screw M05X08
36 Z38649 Bolt
37 N112140 Hexagonal screw M05X16
38 B19073 Shutter left
B19310 Shutter right
50 N112274 Hexagonal nut M05
51 Z37407 Seal
52 B19070 Airbox compl.
53 N112476 Adjusting screw
54 N104718 Circlips D08
55 B18557 Pulley with steel cable
56 E16728 Option air supply adapter
57 N100169 Washer M05
58 N112051 Hexagonal screw M05X25
59 L03956 Cover
60 N111974 Self-locking nut M05
NR. ART.NR. DESCRIPTION
61 LB00925 Front cover, bottom, actuator right
LB00928 Front cover, bottom, actuator left
62 Z38957 Actuator
63 N111990 Hexagon socket M04X06
64 N112471 Slide
65 N104477 Allen screw M04X06
66 L03937 Hinge plate, actuator
67 N111964 Hexagonal screw M05X08
68 Z33895 Cable roll
69 N103988 Hexagonal nut M06
70 Z10709 Spacer
71 N112175 Washer
72 N112422 Hexagonal screw M06X30
80 LB00974 Side panel for flue pipe connection right
LB00976 Side panel for flue pipe connection left
81 LB00975 Rear wall for flue pipe connection right
LB00977 Rear wall for flue pipe connection left
82 Z36001 Snap spring
83 L02751 Adjusting plate below
84 B17565 Adjusting plate
85 Z38956 Holder plate
86 N112694 Hexagon socket screw M05X12
87 N108121 Self-tapping screw M05X08
88 Z36997 Bushing
89 N111965 Washer M05
90 B19081 Cover assy, top flue outlet
91 B19085 Cover assy, rear flue outlet
92 Z39612 Blind cover
93 N100475 Flat packing white 8x2
94 LB00946 Power stone cover RAO
LB00947 Power stone cover flue pipe connection right
LB00948 Power stone cover flue pipe connection left
95 N106175 Hexagonal nut M05
96 N112944 Spacer
97 Z38336 Power stone
98 Z38337 Power stone AH
99 LB00923 Cover
100 Z38941 Bracket
101 N110833 Self-tapping screw M05X16
102 N112495 Levelling screw black
110 Z38658 Firebrick lining
111 Z38657 Firebrick lining rear
112 Z38656 Baffle plate cover
113 N112305 Self-tapping screw M05x30
114 Z36906 Flue pipe attachment D130 metallic
115 N111631 Round sealing cord grey D06
116 Z38655 Baffle plate
117 Z38905 Wood retainer
118 N111974 Self-locking nut M05
119 N100169 Washer M05
120 N108231 Allen screw M05x16
121 Z38659 Firebrick lining
122 Z10350 Grate hook
123 Z38927 Grate
124 L03930 Ash drawer
*1 up to serial number 221524898 articles Z35847 +
Z35848 must be supplied as well
