RIKA DOMO Back User manual

DOMO BACK
Operating manual

2
TABLE OF CONTENTS
1. PREFACE 3
Explanations to symbols.................................................................................................................................................................................................. 3
Spare part overview exploded diagram............................................................................................................................................................4
Spare part overview article numbers................................................................................................................................................................... 8
Spare part overview article numbers...................................................................................................................................................................9
Dimensions .................................................................................................................................................................................................................................10
Amount of Fuel........................................................................................................................................................................................................................10
Technical data.........................................................................................................................................................................................................................10
Packaging....................................................................................................................................................................................................................................10
Electrical connection.........................................................................................................................................................................................................10
2. INSTALLING THE STOVE 11
General information.............................................................................................................................................................................................................11
Connection to the chimney...........................................................................................................................................................................................11
Connecting to a steel chimney ..................................................................................................................................................................................11
Combustion air.........................................................................................................................................................................................................................11
Feeding in external combustion air.......................................................................................................................................................................11
3. IMPORTANT INFORMATION 12
General warning and safety information ........................................................................................................................................................12
First heating................................................................................................................................................................................................................................12
Safety distances .....................................................................................................................................................................................................................12
Prior to set up........................................................................................................................................................................................................................... 13
The correct chimney connection ........................................................................................................................................................................... 13
4. BRIEF INFORMATION ON FUEL  PELLETS 14
What are pellets?................................................................................................................................................................................................................... 14
Wood pellet specification according to ENplus – A1 ............................................................................................................................ 14
Pellet container refilling during operation..................................................................................................................................................... 14
Pellet storage............................................................................................................................................................................................................................ 14
5. TECHNOLOGY AND SAFETY FUNCTIONS 15
Operating comfort................................................................................................................................................................................................................15
Top efficiency - lowest emissions............................................................................................................................................................................15
DAR - Dynamic Air Regulation...................................................................................................................................................................................15
Pressure monitoring............................................................................................................................................................................................................15
Low-temperature shutdown ........................................................................................................................................................................................15
Electrical excess current protection ....................................................................................................................................................................15
Automatic cleaning cycle...............................................................................................................................................................................................15
Component monitoring ...................................................................................................................................................................................................15
Auger motor monitoring..................................................................................................................................................................................................15
Power failure (during heating)...................................................................................................................................................................................15
Power failure (during the initial stage)...............................................................................................................................................................15
6. ASSEMBLYDISMANTLING STONE AND OPTIONS 16
Dismantling stone ................................................................................................................................................................................................................ 16
Dismantling rear panels ................................................................................................................................................................................................. 16
Dismantling side panels ..................................................................................................................................................................................................17
Options for DOMO BACK............................................................................................................................................................................................... 18
Left side connection R2................................................................................................................................................................................................... 18
Right side connection R3............................................................................................................................................................................................... 19
Rear top connection R4 .................................................................................................................................................................................................. 19

|3
EN
2
7. COMFORT OPTIONS 21
Room sensor, Radio room sensor............................................................................................................................................................................21
GSM Control ...............................................................................................................................................................................................................................21
Interface for various options.......................................................................................................................................................................................21
External room thermostat .............................................................................................................................................................................................21
External connection cable bridge..........................................................................................................................................................................21
Option firenet ............................................................................................................................................................................................................................21
RIKA VOICE ..................................................................................................................................................................................................................................21
8. MAINTENANCE 22
Open combustion chamber door ..........................................................................................................................................................................22
Clean fire trough ...................................................................................................................................................................................................................22
Clean flame temperature sensor...........................................................................................................................................................................22
Empty ash drawer................................................................................................................................................................................................................22
Clean door glass....................................................................................................................................................................................................................22
Clean painted surfaces...................................................................................................................................................................................................22
9. CLEANING 23
Clean convection air openings ............................................................................................................................................................................... 23
Clean combustion air intake..................................................................................................................................................................................... 23
Clean pellet container..................................................................................................................................................................................................... 23
Clean flue gas channels and flue gas collecting duct ...................................................................................................................... 23
Clean flue pipes .................................................................................................................................................................................................................... 24
Check bearings ..................................................................................................................................................................................................................... 24
Check seals............................................................................................................................................................................................................................... 24
Changing the baking compartment lighting............................................................................................................................................. 24
10. PROBLEMS  POSSIBLE SOLUTIONS 25
Problem 1.......................................................................................................................................................................................................................................25
Problem 2......................................................................................................................................................................................................................................25
Problem 3 .....................................................................................................................................................................................................................................25
11. INSTRUCTIONS FOR COMMISSIONING PROTOCOL 26
12. GUARANTEE CONDITIONS 28
13. WARRANTY CONDITIONS 28
1. PREFACE
Explanations to symbols
...Important
note #8
...Hex #8
#3
...Allen key #3
#5
...Allen key #5
...Useful
tip
#25
...Hexalobular T25 ...Manually ...Hacksaw

4
Spare part overview exploded diagram
34
36
37
27
31
27
24
24
24
33
33
33
35
40
41
42
51
10
19
10
13
6
20
6
18
10
10
12
19
20
6
13
6
9
8
11
10
14
17
15
16
7
6
5
2
3
4
21
22
24
24
25
25
23
23
23
26
26
53
52
16
54
31
45
43
27
27
40
41
42
44
38
38
39
39
4
4
29
29
29
29
32
32
32
28
30
30
6
6
46
47
48
50
49
6
1
55
58
61
60
59
57
56
70
70
72
71

|5
EN
4
101
99
100
99
98
103
86
81
80
84
84
83
83
85
87
81
80
8484
83
83
85
87
81
80
85
82
82
82
91
92
90
89
88
138
137
136
82
135
134
133
140
131
132
132
96
96
141
139
115
130
128
129
127
126
125
123
124
119
122
120
121
118
117
116
115
115
114
113
85
114
113
85
114
113
85
111
112
110
85
105
106
97
96
107
97
96
95
95
94
94
93
102
104
108
109

6
162
163
164
165
166
150
151
156
158
159
155
155
157
152
154
153
168
161
169
160
161
155
170
161
171
154
153
154
154
172
161
154
173
174
154
167
194
194
189
189
191
191
190
190
193
193
177
183
187
176
176
176
185
188
178
175
180
192
192
179
181
182
185
186
181
182

|7
EN
6
200
212
213
211
214
205
203
202
204
201
206
207
209
208
210
224
238
240
241
215
239
247
259
249
250
243
242
242
248
253
252
245
246
256
244
246
246
254
210
255
244
233
230
235
236
237
229
227
226
228
227
226
225
234
232
231
257
258
226
222
221
219
223
220
218
216
215
217
260

8
Spare part overview article numbers
Nr. Art.Nr. Description
1 B18905 Oven decorative door
2 Z38543 Magnet shell
3 N112758 Magnet
4 N108485 Allen screw
5 N111973 Hexagonal nut
6 N111950 Hexagonal screw M05x10
7 L03825 Magnet holder plate
8 Z38463 Wooden handle
9 L03823 Mounting bracket for handle
10 N110032 Hexagonal screw
11 N107134 Hexagonal countersunk screw
12 L03822 Door mounting plate
13 Z35996 Hanger plate
14 Z38464 Teflon washer
15 Z33758 Spacer
16 N108121 Self-tapping screw
17 L03824 Door stop
18 Z38462 Teflon washer
19 Z35995 Door mounting plate
20 Z35992 Hinge
21 Z38066 Cast frame black
22 Z37460 Door glass oven
23 N111789 Grub screw
24 L00475 Glass holder
25 N112177 Hexagon socket screw
26 N108395 Hexagon socket screw
27 B17524 Hinge black
28 B17405 Hinge
29 N111780 Hexagonal nut
30 L02645 Door stop base plate
31 N105049 Flat washer black
32 B16814 Hinge
33 N112201 Hexagon socket screw
34 Z35464 Combustion chamber door black
35 N112551 Round sealing strip grey D11
36 N103693 Flat seal black 8x2
37 Z35856 Front door glass
38 B12322 Closure plate
39 N100170 Washer
40 B17407 Shutter
41 L02647 Closure plate
42 N112190 Hexagon socket screw
43 N112551 Round sealing strip grey D11
44 N112603 Glass fabric tape adhesive
45 Z35465 Front door black assy
46 N112240 Self-tapping screw
47 Z38461 Cover plate
48 B17521 Pressure spring
49 N111990 Hexagon socket
50 Z36171 Electromagnet
51 Z35993 Door mounting plate
52 Z27866 Spacer
53 L03831 Door stop
54 N112728 Edge guard
55 B18804 Decorative door
56 N112382 Hexagonal countersunk screw
57 L02714 Magnet washer
58 N112111 Rubber buffer
Nr. Art.Nr. Description
59 N112175 Washer
60 N112729 Spacer
61 N109233 Hexagonal nut
70 Z32838 Shelf support
71 Z37435 Grill
72 E16210 Baking tray
80 N112716 Sealing cord D08
81 Z38451 Cleaning opening
82 N112414 Wing nut
83 N103988 Hexagonal nut M06
84 N112734 Grub screw
85 N112240 Self-tapping screw
86 Z38577 Mounting bracket for cleaning opening
87 Z38484 Mounting bracket for cleaning opening
88 Z38454 Baffle plate left
89 Z37455 Baffle plate right
90 Z38453 Firebrick lining right
91 Z36576 Cast rear panel black
92 Z36601 Firebrick lining left
93 N112726 Cap nut
94 N112487 Washer
95 Z38467 Seal plate
96 N112415 Hexagonal screw
97 N112269 Washer
98 Z37386 Actuator
99 Z37387 Silicone ring
100 Z37388 Wooden handle
101 Z37390 Handle sleeve
102 Z38090 Intermediate shaft
103 N111723 Hexagon socket screw
104 N111864 Grub screw
105 Z38466 Axis fluegas flap
106 L03827 Rear flapsheet
107 L03828 Front flapsheet
108 B18809 Forkhead complete
109 N112760 Pressure spring
110 N100475 Flat packing white 8x2
111 Z38465 Bearing plate
112 Z18997 Rubber buffer
113 Z36778 Blind cover
114 N100475 Flat packing white 8x2
115 N110833 Self-tapping screw
116 Z37844 Pipe adapter
117 Z37830 Pipe adapter seal
118 Z37832 Intermediary
119 N108485 Allen screw
120 N111058 Setscrew with pin
121 N112125 Circlips
122 Z35853 Drive shaft
123 N102688 Sinter bearing ID16
124 Z35852 Bearing clamping plate
125 Z35851 Bearing plate
126 Z36167 Ceramic seal
127 N112470 Spring clip
128 Z35854 Intermediate shaft dumping grate
129 N108131 Pressure spring
130 L01875 Driving plate dumping grate
131 Z35808 Grid

|9
EN
8
Note: Please consider the powdercoated parts can differ slightly in colour and colour effects though they are elaborated in high quality.
Nr. Art.Nr. Description
132 L02726 Small plate
133 N112391 Wing screw
134 Z36000 Cleaning cover
135 Z36566 Sealing
136 Z35999 Cleaning cover
137 Z36567 Sealing
138 L02658 Ash drawer
139 N112197 Hexagon socket screw
140 Z38486 Fire trough
141 N111631 Round sealing cord grey D06
150 LB00802 Convection cover
151 Z36001 Snap spring
152 L03879 Rear wall top
153 L03667 Cover plate sensor
154 N112185 Self-tapping screw
155 N112240 Self-tapping screw
156 LB00898 Side panels top right
157 N108121 Self-tapping screw
158 N112432 Hexagonal nut
159 Z38088 Stop bolt for magnet
160 L03663 Side casing panel, right
161 N111730 Grommet
162 Z37809 Support pad, silicone
163 Z37463 Front soap stone
164 B17390 Stone retainer assy
165 L02239 Cover plate
166 N111970 Hexagonal nut M08
167 N112490 Levelling screw black
168 L03664 Side casing panel, left
169 N112419 Wing screw
170 L03878 Rear wall left
171 L02653 Rear wall cover black
172 L03665 Rear wall right
173 N112018 Key
174 Z35691 Spring plug
175 Z38576 Protective plate
176 N112240 Self-tapping screw
177 LB00801 Container lid
178 N112600 Container seal
179 L02349 Lock washer
180 N110461 Double ball catch
181 N112144 Washer
182 N112143 Hexagonal nut M03
183 N112446 Hexagonal countersunk screw
185 L01445 Switch spacer
186 N111732 Magnetic switch top part
187 N111842 Hexagon socket M03x10
188 N111733 Magnetic switch bottom part
189 L02243 Hinge lid
190 N110501 Circlips
191 Z34854 Hinge shaft
192 N112142 Flange nut
193 N111956 Grub screw
194 L02244 Hinge stove
200 B17289 Touch-display
201 N112769 Halogen lamp
202 N112759 Cross-head screw
Nr. Art.Nr. Description
203 B18907 Oven lighting complete
204 Z38547 Sealing internal
205 L03868 Holder for lighting
206 N111975 Hexagonal nut
207 Z38548 Sealing central
208 Z38550 Sealing external
209 Z38549 Cover
210 N108121 Self-tapping screw
211 B18619 Sensor tube
212 Z38094 Washer
213 L03830 Washer hot zinc dipped
214 N112768 Temperature sensor
215 N111793 Self-tapping screw
216 N112487 Washer
217 Z36290 Seal for ignition
218 B17166 Ceramic ignition
219 Z35183 Friction bearing Di10
220 B12301 Auger
221 Z35182 Friction bearing Di16
222 Z11915 Lock ring conveyer screw
223 N111058 Setscrew with pin
224 N112030 Screw motor, stepless
225 N111825 Contact switch
226 N112274 Hexagonal nut
227 N100170 Washer
228 L02646 Actuating cam dumping grate
229 L02644 Retaining plate
230 N112014 Turning grid motor assy
231 N112146 Hexagon socket screw
232 N111843 Washer M08
233 L02643 Motor plate
234 Z18105 Hose
235 L03484 Heat protection
236 N111806 Hexagonal screw
237 N101570 Hexagonal screw
238 B16951 Induced draft fan housing
239 N112305 Self-tapping screw
240 N111581 Induced draft fan motor
241 N106989 Hexagonal screw
242 N111551 Silicon hose
243 N112316 T-Joint
244 Z35943 Cable channel
245 N112240 Self-tapping screw
246 N100169 Washer
247 N111989 USB cable
248 N112703 Self-tapping screw
249 Z38387 IEC mains socket
250 B16561 Mainboard USB11
252 B18868 Aditional motherboard for lighting
253 B16030 Additional motherboard for motor, incl. cable
254 L03638 Holder plate
255 N112473 Differential pressure sensor
256 N112102 Differential pressure switch
257 Z36760 Pressure Pipe
258 N109185 Circlips D04
259 B16053 Sensor tube
260 B16114 Temperature sensor
Spare part overview article numbers

10
Dimensions
772
1370
428
375
177
297
289
492
813
122
148
60
100
100
Dimensions
Height [mm] 1370
Width [mm] 772
Corpus depth [mm] 428
Weight
Weight without shell [kg] ca. 
Weight with aluminium shell [kg] ca. 
Flue pipe connection
Ø Flue pipe outlet [mm] 
Connection height [mm]
Original angle pipe total depth [mm]
Original angle pipe distance to rear wall [mm]
Depth from rear wall to middle of flue
pipe [mm]
Original angle pipe side distance [mm]
Rear connection height [mm] 
Rear connection side distance [mm] 
Fresh air connection
Ø Diameter [mm] 
Connection height [mm] 
Side distance [mm] 
Convection Air Connection
Ø Diameter [mm] 
Connection Height [mm] 
Side Distance [mm] 
Connection Height [mm] 
Side Distance [mm] 
Amount of Fuel
Nominal load Part load
Amount of fuel ~, kg* ~, kg*
Burn time at full
pellet hopper up to ca.  h* up to ca.  h*
*Practical values may vary depending on pellet quality.
Note
Pellet consumption depends on the size of the pellets. The larger
the pellets, the slower the feed and vice versa.
Technical data
Technical data
Heating power range [kW]  - 
Room heating capacity
(depending on house insulation) [m]  - 
Fuel consumption [kg/h] , up to ,
Pellet container capacity [l]/[kg] /~
Electric supply [V]/[Hz] /
Average electrical input [W] ~ 
Fuse [A] , AT
Efficiency [%] 
CO2[%] ,
CO-emission on 13% O2[mg/mN
],
Dust emission [mg/mN
]
Exhaust [g/s] ,
Exhaust temperature [°C] ,
Chimney draft requirement [Pa] 
The owner of small firing systems or the person authorised for the
small firing system is to keep the technical documentation and is to
submit it to the authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as
local regulations concerning the installation and operation of
firing installations!
Packaging
Your first impression is important to us!
The packaging of your new stove provides excellent protection
against damage. However damage to the stove and accessories
may still occur during transport.
Note
Therefore please check your stove on receipt for damage and
completeness! Report any deficiencies to your dealer immediately!
Pay particular attention during unpacking that the stone panels
remain intact. Scratches to the material can easily occur. Stone
panels are excluded from the warrant.
The packaging of your new stove is environmentally neutral to a
great extent.
Tip
The wood used in the packaging has not been surface treated.
The cardboard and film (PE) can be disposed of via the municipal
waste collection for recycling.
Electrical connection
The stove is supplied with an approx. 2 m long connecting cable with
shock-proof plug. This cable is to be connected to a 230 Volt/50 Hz
socket. The average electrical power consumption is some 20 Watt in
heating operation, and approx. 150 Watt during automatic ignition.
The connection cable must be laid so that there is no contact to any
sharp edges or hot surfaces of the stove.
