RIKA induo II User manual

INDUO II
Operating Manual

2
TABLE OF CONTENTS
Spare part overview exploded diagram .....................................................................................................................................................4
Spare part overview article numbers.........................................................................................................................................................6
1. PREFACE 7
Explanations to symbols...........................................................................................................................................................................7
Dimensions ..............................................................................................................................................................................................8
Amount of fuel .........................................................................................................................................................................................8
Technical data...........................................................................................................................................................................................8
Packaging .................................................................................................................................................................................................8
Electrical connection ................................................................................................................................................................................8
2. IMPORTANT INFORMATION 9
General warning and safety information ..................................................................................................................................................9
First heating..............................................................................................................................................................................................9
Safety distances ........................................................................................................................................................................................9
Prior to set up.........................................................................................................................................................................................10
Convection air conduction......................................................................................................................................................................10
Stoves type 1 (BA 1):..............................................................................................................................................................................10
3. INSTALLING THE STOVE 11
General information...............................................................................................................................................................................11
Connection to the chimney ....................................................................................................................................................................11
Connecting to a steel chimney ...............................................................................................................................................................11
Combustion air.......................................................................................................................................................................................11
Feeding in external combustion air.........................................................................................................................................................11
4. BRIEF INFORMATION ON FUEL - PELLETS 12
What are pellets?....................................................................................................................................................................................12
Wood pellet specification according to ENplus – A1 .............................................................................................................................12
Pellet container refilling during operation ..............................................................................................................................................12
Pellet storage ..........................................................................................................................................................................................12
5. BRIEF INFORMATION ON COMBUSTIBLE - LOGS 13
Suitable fuels and fuel amounts ..............................................................................................................................................................13
Wood types.............................................................................................................................................................................................13
Output controlling .................................................................................................................................................................................13
Clean combustion...................................................................................................................................................................................13
6. TECHNOLOGY AND SAFETY FUNCTIONS 14
Operating comfort..................................................................................................................................................................................14
Top efficiency - lowest emissions............................................................................................................................................................14
Burnback and flue gas flaps ....................................................................................................................................................................14
Overheating............................................................................................................................................................................................14
Low-temperature shutdown...................................................................................................................................................................14
Electrical excess current protection.........................................................................................................................................................14
Automatic cleaning cycle........................................................................................................................................................................14
Component monitoring .........................................................................................................................................................................14
Auger motor monitoring ........................................................................................................................................................................14
7. ASSEMBLY/DISMANTLING STONE AND OPTIONS 15
Dismantling stone ..................................................................................................................................................................................15
Conversion to flue pipe connection rear .................................................................................................................................................16
8. BURNBACK AND FLUE GAS FLAP 17
Start of operation....................................................................................................................................................................................17
Refilling logs - opening flue gas flap.......................................................................................................................................................17
9. FLOW DIAGRAM PELLET - LOG OPERATION 18

|
3
EN
2
10. MAINTENANCE 19
Cleaning the fire trough - daily ..............................................................................................................................................................19
Cleaning the flame temperature sensor ..................................................................................................................................................19
Empty the ash drawer.............................................................................................................................................................................19
Cleaning the door glass ..........................................................................................................................................................................19
Cleaning painted surfaces.......................................................................................................................................................................19
11. CLEANING 20
Cleaning the convection air openings.....................................................................................................................................................20
Combustion air - intake .........................................................................................................................................................................20
Cleaning the pellet container..................................................................................................................................................................20
Bearings..................................................................................................................................................................................................20
Checking door seal .................................................................................................................................................................................20
Cleaning flue pipes .................................................................................................................................................................................20
Cleaning flue gas deflector section..........................................................................................................................................................21
Cleaning the flue pipes...........................................................................................................................................................................21
12. PROBLEMS - POSSIBLE SOLUTIONS 22
Problem 1 ...............................................................................................................................................................................................22
Problem 2 ...............................................................................................................................................................................................22
Problem 3 ...............................................................................................................................................................................................22
13. INSTRUCTIONS FOR COMMISSIONING PROTOCOL 23
14. WARRANTY 26

4
Spare part overview exploded diagram
7
8
9
16
15
11
11
11
12
12
13
13
5
5
18
4
4
20
19
17
10
14
14
6
1
1
2
2
3
3
21
66
28
27
29
33
25
34
24
35
32
26
30
31
39
42
37
36
38
22
23
48
47
45
46
50
53
51
52
54
57
67
68
69
55
56
49
64
65
52
51
58
43
44
40
41
62
61
63
59
60
60

|
5
EN
4
70
71
73
72
75
74
76
77
81
84
89
82
79
85
83
78
88
80
87
86
119
113
120
118
117
116
115
113
98
112
107
105
104
103
99
92
94
97
95
110
109
96
108
114
111
93
90
91
102
101
100
106
132
139
141
142
143
135
136
137
135
144
137
145
138
126
127
146
134
133
150
147
123
121
122
128
130
155
154
129
153
152
151
149
148
129
131
128
130
129
129
140
124
125
160
128
130
165
156
157
158
164
163
162
161
159

6
Spare part overview article numbers
Nr. Art.Nr. Description
1 L02007 Guide stone
2 N111965 Washer D05
3 N111866 Hexagonal screw
4 N111856 Hexagonal countersunk screw M04x12
5 L01957 Closure plate
6 L02010 Door lock
7 B16564 Door metallic assy
B16972 Door compleet, black
8 N103693 Flat seal black 8x2
9 Z34303 Door glass (ceramic glass)
10 N100485 Round sealing strip black D12
11 Z34472 Hinge plate
12 N112175 Washer
13 N103964 Hexagonal screw M06x16
14 Z34457 Hinge
15 N112075 Allen screw
16 L02574 Glass holder
17 N100485 Round sealing strip black D12
18 N111637 Setscrew Door opener
19 N111798 Cylindrical pin Door opener
20 B16565 Door opener assy
21 N112065 Cylinder screw
22 Z34554 Wood retainer metallic
Z36928 Wood retainer black
23 N111947 Self-tapping screw
24 Z34412 Firebrick lining front left
25 Z34411 Firebrick lining rear left
26 Z34553 Air scoop metallic
Z36252 Air scoop black
27 Z35555 Angle bracket and allen screw
28 Z37040 Convection cover metallic
Z34243 Convection cover black
29 N111320 Sealing cord grey Ø14mm
30 B16682 Flue gas chute lid
31 N103066 Round sealing strip black D06
32 Z36658 Baffle plate
33 Z34409 Firebrick lining rear
34 Z34410 Firebrick lining rear right
35 Z34413 Firebrick lining front right
36 N103560 Hexagonal screw
37 L02008 Fire trough tray
38 N111846 Hexagon socket 06x12
39 Z36643 Recess
40 Z34468 Sealing
41 Z36935 Seal
42 Z34244 Dumping grate
43 L02044 Dumping grate support
44 N112148 Hexagonal screw
45 L01875 Driving plate Dumping grate
46 N112470 Spring clip
47 N108131 Pressure spring
48 Z33924 Intermediate shaft Dumping grate
49 N107521 Hexagonal screw M05x12
50 Z34824 Bearing clamping plate metallic
Z34965 Bearing clamping plate black
51 N104718 Circlips
52 N108310 Sinter bearing ID10
53 Z34757 Bearing plate top metallic
Z34966 Bearing plate top black
54 B16553 Sprocket top
55 N100172 Washer
56 N110928 Screw
Nr. Art.Nr. Description
57 Z34557 Chain Dumping grate
58 B16559 Actuating cam dumping grate
59 N111825 Door contact switch
60 Z34461 Bearing plate bottom metallic
Z34964 Bearing plate bottom black
61 N111631 Round sealing cord grey Ø6mm
62 B16680 Cleaning cover
63 N112093 Milled nut (cleaning cover)
64 B16957 Sprocket bottom
65 Z34555 Sinter bearing ID 10,2 sprocket out
66 L02952 Ash drawer
67 Z35158 Spacer chain guide / clamping plate
68 Z35302 Chain guide
69 Z35303 Clamping plate
70 B16675 Flap lever flue gas flap
71 N112283 Hexagonal screw
72 N111058 Setscrew with pin
73 Z36535 Shaft of fluegas flap
74 N103560 Hexagonal screw
75 Z36925 Bearing
76 Z36926 Shaft of fluegas flap
77 B18135 Lever fluegas flap
78 Z18997 Rubber buffer
79 N112321 Pressure spring
80 Z34471 Tension spring flue gas flap
81 B18087 Hinge shaft
82 N112120 O-ring
83 L02954 Holder plate
84 N111732 Magnetic switch top part
85 N111733 Solenoid switch bottom part
86 N112409 Hexagon socket screw
87 B17925 Flap handle
88 N112315 Cylindrical pin
89 B17340 Fluegas flap assy
90 Z34565 Soapstone option side
91 B18082 Stone retainer
92 B16576 Cover metallic assy
B16965 Cover assy, black
93 E15143 Cover AH metallic
E15356 Cover AH black
94 B16577 Flue pipe cover metallic
B16966 Flue pipe cover black
95 N111631 Round sealing cord grey Ø6mm
96 Z21690 Blind cover metallic
97 Z30137 Flue pipe attachments (without seal) metallic grey
150mm
Z20556 Flue pipe connection black 150mm
98 B17100 Stone retainer
99 N112143 Hexagonal nut M03
100 N111842 Hexagon socket M03x10
101 N111733 Solenoid switch bottom part
102 L01445 Switch spacer
103 N112144 Washer
104 N111732 Magnetic switch top part
105 N110461 Double ball catch
106 N111731 Container seal
107 B16578 Container lid metallic grey assy
B16971 Container lid black assy
108 Z34994 Cleaning opening metallic
Z34995 Cleaning opening black
109 Z36659 Rear wall right metallic grey
Z36661 Rear panel right, black
110 Z34486 Rear wall left metallic grey

|
7
EN
6
Note: Please consider the powdercoated parts can differ slightly in colour and colour effects though they are elaborated in high quality.
1. PREFACE
Explanations to symbols
...Important
note #8
...Hex #8
#6
...Allen key #6 ...Scrawl with
copper paste
...Useful
tip #10
...Hex #10 ...Manually ...Hacksaw
Nr. Art.Nr. Description
Z34971 Rear panel left black
111 B17925 Flap handle
112 B16574 Touch-Display plug-in
113 N111730 Grommet
114 N111993 Levelling screw
115 B17924 Right side panel metallic
B17931 Right side panel black
116 Z34483 Soapstone front
Z35078 Sandstone front
Z36340 Quartz front anthracite grey
Z36545 Frontstone white
117 B16570 Cover panel, bottom metallic
B16960 Casing panel bottom black
118 Z34479 Cable cover metallic grey
Z34967 Cable cover black
119 B16566 Side panels steel metallic grey left
B16964 Side casing panel, left black
120 B16568 Front top metallic
B16961 Front top black
121 B17923 Ceramic ignition
122 Z36293 Seal for ignition
123 Z34464 Insertion screw
124 B15248 Sensor tube
125 B16676 Flame temperatur sensor
126 L01954 Pressure bracket
127 N111862 Screw motor, stepless
128 Z11915 Lock ring conveyer screw
129 Z35182 Friction bearing Di16
130 N111058 Setscrew with pin
131 Z34463 Discharge auger
132 B16798 Handle burnback flap
133 B16030 Add. board motor
134 Z34790 Electromagnet
Nr. Art.Nr. Description
135 L01445 Switch spacer
136 N111732 Magnetic switch top part
137 L02310 Guard plate
138 N111942 Self-locking nut
139 Z34885 Activator security flap
140 Z34529 Torsion spring
141 Z35524 Spacer
142 N104195 Washer
143 N112299 Hexagonal screw
144 N111733 Solenoid switch bottom part
145 N112044 Hexagon socket screw
146 L02012 Magnet plate
147 B16561 Mainboard USB11
148 B16672 Add. Board
149 B16671 Add. Board
150 N111862 Screw motor, stepless
151 L02250 Bearing holding plate
152 L02605 Bearing collar plate
153 L02604 Motor plate
154 N111967 Allen screw M06x10
155 Z35752 Bearing retaining ring
156 B16547 Air regulator assy
157 B18088 Extension of actuator
158 N112220 Circlips
159 N111817 Air regulator motor
160 N111880 Dumping grate motor
161 Z34467 Coupling Dumping grate motor
162 N111825 Door contact switch
163 N112309 Pressure spring door contact
164 Z35156 Stop bar
165 N111581 Induced draft fan motor
N111604 Fuse 2,5A

8
Dimensions
R - H
F - S R - S
R O - S
H
B
T
R O - H
R O - T 1
F - H
R O - T 2
R O - T 3
F -
R -
~20cm
Dimensions
Height [mm] 1132
Width [mm] 882
Corpus depth [mm] 515
Weight
Weight without shell [kg] 305
Weight with shell [kg] 345
Weight with soap stone sideways (optional) [kg] 385
Flue Pipe Connection
R - Ø Flue pipe outlet [mm] 150
RO - H Original angle pipe connection height [cm] 165
RO - T1 Original angle pipe total depth [cm] 71
RO - T2 Original angle pipe distance to rear wall [cm] 20
RO - T3 Deapth from rear wall to middle of flue
pipe [cm] 18
RO - S Original angle pipe side distance [cm] 45
R - H Rear connection height [cm] 93
R - S Rear connection side distance [cm] 40
Fresh Air Connection
F - Ø Diameter [mm] 125
F - H Connection height [cm] 22
F - S Side distance [cm] 21
Amount of fuel
Nominal Load Part Load
Log operation 2,8 kg 1,4 kg
Pellet operation ~2,2 kg* ~0,7 kg*
Burn time at full pellet
hopper ~14 h* ~53 h*
*Practical values may vary depending on pellet quality.
Note
Pellet consumption depends on the size of the pellets. The larger the pellet,
the slower the feed and vice versa.
Technical data
Description Measure Data
Heating capacity range [kW] 3 - 10
Room heating capacity depending on house
coating [m³] 70 - 260
Pellet consumption [kg/h] till 2,4
Pellet container capacity* [l/kg] 51/~33
Electric supply [V] 230V/50Hz
Average electrical input [W] ~ 20
Fuse [A] 2,5 T
Pellet Operation Measure Data
Heating capacity range [kW] 3 - 10
Efficiency in pellet mode [%] 91
CO2[%] 13,3
CO-emission on 13% O2[mg/mN3] 42
Dust emission [mg/mN3] 10
Exhaust [g/s] 5,4
Exhaust temperature [°C] 178,9
Chimney draft requirement [Pa] 3
Log Operation Measure Data
Heating capacity range [kW] 5 - 10
Efficiency in log mode [%] 86
CO2[%] 9,7
CO-emission on 13% O2[mg/mN3] 792
Dust emission [mg/mN3] 27
Exhaust [g/s] 10,1
Exhaust temperature [°C] 180,2
Chimney draft requirement [Pa] 12
*e capacity in kg may deviate due to different pellet bulk densities.
The owner of small firing systems or the person authorised for the small
firing system is to keep the technical documentation and is to submit it to the
authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as local
regulations concerning the installation and operation of firing installations!
Packaging
Your first impression is important to us!
The packaging of your new stove provides excellent protection against damage.
However damage to the stove and accessories may still occur during transport.
Note
Therefore please check your stove on receipt for damage and completeness!
Report any deficiencies to your dealer immediately! Pay particular attention
during unpacking that the stone panels remain intact. Scratches to the
material can easily occur. Stone panels are excluded from the warranty
The packaging of your new stove is environmentally neutral to a great extent.
Tip
The wood used in the packaging has not been surface treated and may
therefore be burnt in your stove. The cardboard and film (PE) can be disposed
of via the municipal waste collection for recycling.
Electrical connection
The stove is supplied with an approx. 2m long connecting cable with a Euro-plug.
This cable is to be connected to a 230Volt/50Hz socket. The average electrical
power consumption is about 20 Watt in heating operation. And approx. 150
Watt during automatic ignition. The connection cable must be laid so that there
is no contact to any sharp edges or hot surfaces of the stove.

|
9
EN
8
2. IMPORTANT INFORMATION
General warning and safety information
Observance of the introductory general warning information is imperative.
QRead the entire manual thoroughly before installing and putting the stove into
service. Observe the national provisions and laws as well as the regulations
and rules applicable locally.
QRIKA stoves should only be installed in rooms with normal humidity (dry
areas according to VDE 0100 Part 200). The furnaces are not splash water
protected and may not be installed in wet areas.
QOnly approved transport equipment with sufficient load carrying capacity
may be used with your heating appliance.
QYour heating appliance is not suitable for use as a ladder or stationary
scaffolding.
QThe burning of fuel releases heat energy that lead to extensive heating of
the stove surfaces, doors, door and operating handles, glass, flue pipes
and possibly the front wall. Refrain from touching these parts without
appropriate protective clothing or equipment e.g. heat-resistant gloves or
means of operation (operating handle).
QMake your children aware of this particular danger and keep them away from
the stove during heating.
QOnly burn approved heating materials.
QThe combustion or introduction of highly flammable or explosive materials
such as empty spray cans etc. in the combustion chamber and storing them
near the stove is strictly prohibited due to the danger of explosion.
QNo light or inflammable clothing is to be worn when post-heating.
QUse the heat-resistant gloves supplied to open the doors of your stove.
QOnly use suitable tools from our range of accessories when handling embers
and make sure that no embers fall out of the combustion chamber onto
inflammable material.
QPush the embers together to form a firebed when you add new fuel (logs).
QPlacing non-heat resistant objects on the stove or near it is prohibited.
QDo not place clothing on the stove to dry.
QLaundry racks etc. must be placed at a sufficient distance to the stove –
ACUTE DANGER OF FIRE!
QWhen your stove is burning, the use of highly inflammable and explosive
materials in the same or adjacent rooms is prohibited.
QIf the stove is heated in continuous operation, the cleaning intervals are
shorter. Increased wear, especially of the thermally stressed parts, is the
result. Please therefore strictly follow the requirements for cleaning and
maintenance!
Note
Waste and liquids may not be burnt in the stove!
Note
To prevent your stove from overheating of the internal components,
do never cover the convection fins!
Note
CAUTION when filling the pellet container. The opening of the pellet container
is sufficiently dimensioned to ensure easy filling. Take great care that no
pellets drop to the convection fins and the hot stove body. This can cause a
lot of smoke.
Tip
Therefore we recommend refilling the pellet container at a cold stove.
Note
Your stove will expand and contract during the heating and cooling phase.
This can sometimes lead to slight bending or cracking noises. This is normal
and is no reason for a complaint.
First heating
The stove body, just as various steel parts, cast iron parts and the flue pipes
are painted with a heat resistant paint. During the first heating the paint dries
out completely. This may cause a slight smell. Touching or cleaning the painted
surfaces during the curing should be avoided. The hardening of the paint is
finished after the first heating with high power.
Safety distances
Note
1. To non-combustible objects
a > 40 cm, b > 10 cm
2. To combustible objects and reinforced concrete load-bearing walls
a > 80 cm, b > 20 cm
Tip
Please observe a minimum distance of 20 cm behind and sideways the stove
for maintenance.

10
Prior to set up
Floor bearing capacity
Ensure that the substructure is capable of bearing the weight of the stove prior
to set-up.
Note
No modifications may be made to the firing installation. This also leads to loss
of warranty and guarantee.
Floor protection
A base is required (glass, sheet steel or ceramic) if the floor is combustible
(wood, carpet, etc.).
Flue pipe connection
QFlue pipes pose a particular source of hazard regarding gas leaks and
fire. Get the advice of an authorised specialist company for the layout and
assembly.
QPlease observe the corresponding installation guidelines for walls panelled
with wood when connecting your flue pipes to the stove,
QObserve the formation of flue gas (atmospheric inversion) and draughts
when the weather is unfavourable.
QInfeed of too little combustion air can lead to smoke in the rooms or to flue
gas leaks. Hazardous deposits in the stove and chimney may also occur.
QIf flue gas escapes, let the fire burn out and check whether all the air inlet
openings are free and the flue gas pipes and the stove pipe are clean. If in
doubt notify the master chimney sweep since draught malfunctions may be
connected to your chimney.
Convection air conduction
only for stoves with MultiAir
The MultiAir equipped stove is delivered with a cover on the convection air outlet
to prevent direct heat to the wall.
Operation without this cover or without attached convection pipes is not
allowed. If you do though no warranty and no liability is accepted for damage.
QThe amount of air and temperature of one fan is designed to heat one
additional room.
QNote the regional specific fire safety regulations and clarify the connection
situation with the competent authority
QThe max. temperature of the convection air is 180° C at the air outlet.
QThe convection air canal should be as short as possible.
QKeep the number of deflections as small as possible.
Note
Please pay attention to the national and country-specific building and fire
regulations when connecting the convection air pipes. Installation and
assembly must be performed by a trained specialist only.
Stoves type 1 (BA 1):
QThese may only be operated with the combustion chamber door closed.
QSuitable for multiple occupancy. (note the different country regulations)
QThe combustion chamber door may only be opened to add fuel and must
then be closed again otherwise other firing installations connected to the
chimney may be endangered.
QThe combustion chamber door is to be kept closed when the stove is not
in operation.
QFouling of the chimney i.e. deposits of highly inflammable materials such as
soot and tar and subsequently fire in the chimney may occur if the chimney
is miscalculated and dimensioned wrong and if wet wood is used.
If fire in the chimney occurs, disconnect the mains plug of the stove. Phone the
fire brigade and get yourself and other residents out of harm’s way.
Note
Due to the size of the combustion chamber door it is necessary not to
open the door abruptly, to prevent the flames coming out. Especially when
reheating into blazing flames.
Note
on ROOM-AIR DEPENDENT and
ROOM-AIR INDEPENDENT OPERATION:
Your stove has been tested as a room-air independent stove according to
EN13240 and to EN14785 and can be installed as well room-air dependent
and independent. In Germany it does not conform to the requirements for
room-air independent operation.
When installed room-air dependent in combination with room-air installations
(e.g. controlled ventilation and venting systems (extractors etc.) it must
be ensured that the stove and the room air system are monitored and
safeguarded mutually (e.g. via a differential pressure controller etc.).
The combustion air infeed of approx. 20 m3/h must be ensured.
Please observe the respective local regulations and rules in consultation with
your master chimney sweep. For changes after the printing of this manual, we
can not assume any liability. We reserve the right to change without notice.
