RIKA ALUMO User manual

ALUMO
Operating manual

2
TABLE OF CONTENTS
1. EXPLANATIONS TO SYMBOLS 3
2. TECHNICAL DOCUMENTATION  ECODESIGN 4
3. TECHNICAL DATA 8
Dimensions ................................................................................................................................................................................................................................... 8
Amount of fuel ........................................................................................................................................................................................................................... 8
Technical data........................................................................................................................................................................................................................... 8
Packaging...................................................................................................................................................................................................................................... 8
Spare part overview - exploded diagram ........................................................................................................................................................9
Spare part overview - article numbers...............................................................................................................................................................11
4. IMPORTANT INFORMATION 12
General warning and safety information ........................................................................................................................................................12
First heating................................................................................................................................................................................................................................12
Safety distances .....................................................................................................................................................................................................................12
Prior to set up........................................................................................................................................................................................................................... 13
5. BRIEF INFORMATION ON COMBUSTIBLE  LOGS 14
Suitable fuels and fuel amounts ............................................................................................................................................................................. 14
Wood types................................................................................................................................................................................................................................. 14
Output controlling................................................................................................................................................................................................................ 14
Clean combustion................................................................................................................................................................................................................ 14
6. INSTALLING THE STOVE 15
Connection to the chimney..........................................................................................................................................................................................15
Connecting to a steel chimney .................................................................................................................................................................................15
Combustion air........................................................................................................................................................................................................................15
Feeding in external combustion air......................................................................................................................................................................15
7. ASSEMBLY  DISMANTLING STONE 16
Assembly / disassembly stone.................................................................................................................................................................................. 16
8. MANUAL OPERATION 17
Operating the riddle grate ............................................................................................................................................................................................17
Combustion air regulation............................................................................................................................................................................................17
RIKA firelighter..........................................................................................................................................................................................................................17
Correct heating up...............................................................................................................................................................................................................17
Refilling............................................................................................................................................................................................................................................17

|3
2
EN
1. EXPLANATIONS TO SYMBOLS
...Important
Note
...Useful
Tip ...Manually
9. CLEANING AND MAINTENANCE 18
Basic information ................................................................................................................................................................................................................. 18
Cleaning the combustion chamber..................................................................................................................................................................... 18
Empty the ash drawer...................................................................................................................................................................................................... 18
Cleaning the door glass.................................................................................................................................................................................................. 19
Cleaning painted surfaces ......................................................................................................................................................................................... 19
Checking seals........................................................................................................................................................................................................................ 19
Cleaning the convection air openings.............................................................................................................................................................. 19
Combustion air - intake.................................................................................................................................................................................................. 19
Cleaning the flue pipes ................................................................................................................................................................................................... 19
10. PROBLEMS  POSSIBLE SOLUTIONS 20
Problem 1......................................................................................................................................................................................................................................20
Problem 2.....................................................................................................................................................................................................................................20
Problem 3 ....................................................................................................................................................................................................................................20
11. GUARANTEE CONDITIONS 21
12. WARRANTY CONDITIONS 21
13. DISPOSAL INFORMATION 22
Information on the individual components of the device ...............................................................................................................22
Extract from the waste code of the European Waste List Regulation.................................................................................22
Electronic Waste....................................................................................................................................................................................................................22

4
2. TECHNICAL DOCUMENTATION  ECODESIGN
Contact details of the manufacturer
Manufacturer:
Contact:
Address:
Details of the device
Characteristics when operating with the preferred fuel
Special precautions for assembly, installation or maintenance
Characteristics when operating exclusively with the preferred fuel
Pnom 8kW
Pmin 4kW
ηth,nom 85,7 %
ηth,min 86 %
elmax n.A. kW
elmin n.A. kW
elSB n.A. kW
Ppilot n.A. kW
*RIKATRONIC
Notified body:
Pilot flame power requirement
Notified body no.:
Technische Universität Wien, Getreidemarkt 9/166, 1060
Wien, Austria
1746
Fire protection and safety distances such as distances to combustible building materials must be observed!
Direct heat output:
PL-12095-P
EN13240:2001/A2:2004/AC:2007
-
Nein
TECHNICAL DOCUMENTATION
according to commission regulation
(EU) 2015/1185 und 2015/1186
Ecodesign
Model Identifier:
Equivalent models:
ALUMO
-
RIKA Innovative Ofentechnik GmbH
Andreas Bloderer
Müllerviertel 20
4563 Micheldorf
Austria
Test report no.:
Applied harmonised standards:
Other applied standards/technical specifications:
Indirect heating functionality:
An adequate supply of combustion air for the appliance must be guaranteed at all times. Air-suction systems can interfere with the combustion air supply!
The flue gas values of the appliance must be observed for the chimney dimensioning!
Auxiliary electricity consumption*
At nominal heat output
At minimum heat output
Heat output
Nominal heat output
Minimum heat output
Useful efficiency
Useful efficiency at nominal heat output
8 kW
Indirect heat output:
Useful efficiency at minimum heat output
In standby mode
Permanent pilot flame power requirement
Energy Efficiency Index: 114
-Seasonal space heating energy efficiency RIKATRONIC ηs :
-
Seasonal space heating energy efficiency ηs :
Energy Efficiency Index RIKATRONIC:
75,7 %
-

|5
4
EN
Yes
No
No
No
No
No
No
No
No
Details of the fuel
PM OGC CO NO
x
PM OGC CO NO
x
Yes No 75,7 19 49 851 109 - - - -
No No - - - - - - - - -
Compressed wood, moisture content < 12 % No No - - - - - - - - -
Other woody biomass No No - - - - - - - - -
Non-woody biomass No No - - - - - - - - -
Anthracite and dry steam coal No No - - - - - - - - -
Hard coke No No - - - - - - - - -
Low temperature coke No No - - - - - - - - -
Bituminous coal No No - - - - - - - - -
Lignite briquettes No No - - - - - - - - -
Peat briquettes No No - - - - - - - - -
Blended fossil fuel briquettes No No - - - - - - - - -
Other fossil fuel No No - - - - - - - - -
Blended biomass and fossil fuel briquettes No No - - - - - - - - -
Other blend of biomass and solid fuel No No - - - - - - - - -
(*) PM = dust, OGC = gaseous organic compounds, CO = carbon monoxide, NOx = nitrous gases
(**) Only required when applying correction factors F(2) or F(3)
Signed for and on behalf of the manufacturer by:
Micheldorf, 21.12.2021
In case of doubt as well as missing or incorrect translations, the German version is the only valid one.
Subject to technical and visual changes as well as layout and printing errors.
© 2021 | RIKA Innovative Ofentechnik GmbH
with electronic room temperature control plus day timer (**)
Type of heat output/room temperature control
two or more manual stages, no room temperature control (**)
with mechanic thermostat room temperature control (**)
with electronic room temperature control (**)
Room temperature control with presence detection (**)
single stage heat output, no room temperature control
with electronic room temperature control plus week timer (**)
Andreas Bloderer / product management
Room temperature control with open window detection (**)
Space heating emissions
at nominal heat output (*)
Space heating emissions
at minimum heat output
(*)(**)
mg/Nm
3
(13% O
2
)mg/Nm
3
(13% O
2
)
with remote control options (**)
Fuel Preferred
fuel:
Other
suitable fuel:
ηs[%]

6
Contact details of the manufacturer
Manufacturer:
Contact:
Address:
Details of the device
Characteristics when operating with the preferred fuel
Special precautions for assembly, installation or maintenance
Characteristics when operating exclusively with the preferred fuel
Pnom 6kW
Pmin -kW
ηth,nom 82 %
ηth,min - %
elmax n.A. kW
elmin n.A. kW
elSB n.A. kW
Ppilot n.A. kW
*RIKATRONIC
Notified body:
Pilot flame power requirement
Notified body no.:
Technische Universität Wien, Getreidemarkt 9/166, 1060
Wien, Austria
1746
Fire protection and safety distances such as distances to combustible building materials must be observed!
Direct heat output:
PL-20064-2-P
EN13240:2001/A2:2004/AC:2007
-
Nein
TECHNICAL DOCUMENTATION
according to commission regulation
(EU) 2015/1185 und 2015/1186
Ecodesign
Model Identifier:
Equivalent models:
ALUMO 6 kW
-
RIKA Innovative Ofentechnik GmbH
Andreas Bloderer
Müllerviertel 20
4563 Micheldorf
Austria
Test report no.:
Applied harmonised standards:
Other applied standards/technical specifications:
Indirect heating functionality:
An adequate supply of combustion air for the appliance must be guaranteed at all times. Air-suction systems can interfere with the combustion air supply!
The flue gas values of the appliance must be observed for the chimney dimensioning!
Auxiliary electricity consumption*
At nominal heat output
At minimum heat output
Heat output
Nominal heat output
Minimum heat output
Useful efficiency
Useful efficiency at nominal heat output
6 kW
Indirect heat output:
Useful efficiency at minimum heat output
In standby mode
Permanent pilot flame power requirement
Energy Efficiency Index: 109
-Seasonal space heating energy efficiency RIKATRONIC ηs :
-
Seasonal space heating energy efficiency ηs :
Energy Efficiency Index RIKATRONIC:
72,0%
-

|7
6
EN
Yes
No
No
No
No
No
No
No
No
Details of the fuel
PM OGC CO NO
x
PM OGC CO NO
x
Yes No 72,0 17 37 901 107 - - - -
No No - - - - - - - - -
Compressed wood, moisture content < 12 % No No - - - - - - - - -
Other woody biomass No No - - - - - - - - -
Non-woody biomass No No - - - - - - - - -
Anthracite and dry steam coal No No - - - - - - - - -
Hard coke No No - - - - - - - - -
Low temperature coke No No - - - - - - - - -
Bituminous coal No No - - - - - - - - -
Lignite briquettes No No - - - - - - - - -
Peat briquettes No No - - - - - - - - -
Blended fossil fuel briquettes No No - - - - - - - - -
Other fossil fuel No No - - - - - - - - -
Blended biomass and fossil fuel briquettes No No - - - - - - - - -
Other blend of biomass and solid fuel No No - - - - - - - - -
(*) PM = dust, OGC = gaseous organic compounds, CO = carbon monoxide, NOx = nitrous gases
(**) Only required when applying correction factors F(2) or F(3)
Signed for and on behalf of the manufacturer by:
Micheldorf, 16.12.2021
In case of doubt as well as missing or incorrect translations, the German version is the only valid one.
Subject to technical and visual changes as well as layout and printing errors.
© 2021 | RIKA Innovative Ofentechnik GmbH
with electronic room temperature control plus day timer (**)
Type of heat output/room temperature control
two or more manual stages, no room temperature control (**)
with mechanic thermostat room temperature control (**)
with electronic room temperature control (**)
Room temperature control with presence detection (**)
single stage heat output, no room temperature control
with electronic room temperature control plus week timer (**)
Andreas Bloderer / product management
Room temperature control with open window detection (**)
Space heating emissions
at nominal heat output (*)
Space heating emissions
at minimum heat output
(*)(**)
mg/Nm
3
(13% O
2
)mg/Nm
3
(13% O
2
)
with remote control options (**)
Fuel Preferred
fuel:
Other
suitable fuel:
ηs[%]

8
3. TECHNICAL DATA
Dimensions
530
1070
475
672
1614
197
186
217
892
265
265
265
130
125
Dimensions
Height [mm] 
Width [mm] 
Corpus depth [mm] 
Weight
Weight without shell [kg] ~
Weight with shell in soapstone [kg] ~
Heat storage mass (i.e. soapstone) [kg] ~
Flue pipe connection
Flue pipe outlet [mm] 
Original angle pipe connection height [mm] 
Original angle pipe total depth [mm] 
Original angle pipe distance to rear wall [mm] 
Deapth from rear wall to middle of flue
pipe [mm] 
Original angle pipe side distance [mm] 
Rear connection height [mm] 
Rear connection side distance [mm] 
Fresh air connection
Diameter [mm] 
Connection height [mm] 
Side distance [mm] 
Amount of fuel
Nominal load Part load
Amount of fuel ~, kg* ~, kg*
*Practical values may vary depending on wood quality.
Technical data
Technical data
Heating power range [kW]  - 
Room heating capacity (depending on
house insulation) [m] -
Fuel consumption [kg/h] ~,
Electric supply [V]/[Hz] /
Average electrical input [W] ~ 
Fuse [A] , AT
Efficiency [%] ,
CO2[%] ,
CO-emission on 13% O2[mg/mN
] 
Dust emission [mg/mN
] 
Exhaust [g/s] ,
Exhaust temperature [°C] 
Chimney draft requirement [Pa] 
The owner of small firing systems or the person authorised for the
small firing system is to keep the technical documentation and is to
submit it to the authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as
local regulations concerning the installation and operation of
firing installations!
Packaging
Your first impression is important to us!
The packaging of your new stove provides excellent protection
against damage. However damage to the stove and accessories
may still occur during transport.
Note
Therefore please check your stove on receipt for damage and
completeness! Report any deficiencies to your dealer immediately!
Pay particular attention during unpacking that the stone panels
remain intact. Scratches to the material can easily occur. Stone
panels are excluded from the warrant.
The packaging of your new stove is environmentally neutral to a
great extent.
Tip
The wood used in the packaging has not been surface treated
and may therefore be burnt in your woodburning stove (not in a
pelletstove!). The cardboard and film (PE) can be depolluted via
the municipal waste collection for recycling.

|9
8
EN
Spare part overview - exploded diagram
36
34
38
37
33
35
40
32
32
41
31
30
39
10
16
23
19
22
28
8
9
5
6
7
17
18
19
20
21
8
1
2
3
4
11
12
13
14
15
9
27
25
26
24

10
63
63
52
65
64
62
62
59
60
61
58
57
57
67
60
61
66
54
51
56
56
53
50
55
75
76
74
72
70
71
73
77
