RIKA TURA User manual

Operating Manual
TURA
TURA

2
CONTENTS
1. PREFACE 3
Explanations to symbols...........................................................................................................................................................................3
Spare part overview exploded diagram .....................................................................................................................................................4
Spare part overview article numbers.........................................................................................................................................................6
Dimensions ..............................................................................................................................................................................................7
Amount of fuel .........................................................................................................................................................................................7
Technical data...........................................................................................................................................................................................7
Packaging .................................................................................................................................................................................................7
Electrical connection ................................................................................................................................................................................7
2. IMPORTANT INFORMATION 8
General warning and safety information ..................................................................................................................................................8
Safety distances ........................................................................................................................................................................................8
Prior to set up...........................................................................................................................................................................................9
3. BRIEF INFORMATION ON FUEL - LOGS 10
Suitable fuels and fuel amounts ..............................................................................................................................................................10
Wood types.............................................................................................................................................................................................10
Fuel amounts with nominal heat output.................................................................................................................................................10
Clean combustion...................................................................................................................................................................................10
4. INSTALLING THE STOVE 11
General information...............................................................................................................................................................................11
Connection to the chimney ....................................................................................................................................................................11
Connecting to a steel chimney ..............................................................................................................................................................11
Combustion air.......................................................................................................................................................................................11
Feeding in external combustion air.........................................................................................................................................................11
5. ASSEMBLY/ DISASSEMBLY STONE AND OPTIONS 12
Retrofitting to flue pipe connection rear.................................................................................................................................................12
6. OPERATION - RIKATRONIC³ 13
Heating instructions...............................................................................................................................................................................13
Correct heating up..................................................................................................................................................................................13
Heating up .............................................................................................................................................................................................13
Adding wood..........................................................................................................................................................................................13
Burn out .................................................................................................................................................................................................13
ECO operation.......................................................................................................................................................................................13
Complete closing of the air flaps ............................................................................................................................................................14
Operating the riddle grate......................................................................................................................................................................14
Power failure...........................................................................................................................................................................................14
Manual regulation ..................................................................................................................................................................................14
7. STATUS DISPLAYS 15
8. WARNINGS AND MALFUNCTION MESSAGES 16

|3
EN
2
9. OPERATION – MANUAL REAR WALL 17
Correct heating up..................................................................................................................................................................................17
Operating the riddle grate......................................................................................................................................................................17
Control knob rear wall............................................................................................................................................................................17
10. CLEANING AND MAINTENANCE 18
Basic information ...................................................................................................................................................................................18
Ampty the ash drawer ............................................................................................................................................................................18
Cleaning the door glass ..........................................................................................................................................................................18
Cleaning the convection air openings.....................................................................................................................................................18
Cleaning the flame temperature sensor ..................................................................................................................................................18
Checking door seal .................................................................................................................................................................................18
Checking chimneay connection..............................................................................................................................................................18
11. PROBLEMS - POSSIBLE SOLUTIONS 19
Problem 1 ...............................................................................................................................................................................................19
Problem 2 ...............................................................................................................................................................................................19
Problem 3 ...............................................................................................................................................................................................19
12. GUARANTEE 21
1. PREFACE
Explanations to symbols
...important
note #10
...hex #10
(M6 winding)
...useful
tip ...manually

Spare part overview exploded diagram
5 4
5 2
4 9
4 8
5 0
4 7
5 1
5 3
4 2
4 1
4 1
4 3
4 0
4 6
4 6
4 4
4 5
7 8
7 5
7 6
7 5
7 4
81
7 9
80
7 7
7 3
7 2
82
7 9
80
7 7
83
3
15
16
17
12
11
10
14
3 5
1
2
3 9
3 7
3 8
3 6
4
5
7
6
1
9
8
3 2
2 6
2 8
2 9
2 3
2 5
3 0
2 7
2 1
3 1
3 3
2 4
2 1
2 0
2 0
2 2
3 4
13
16
19
18
4

7 8
7 5
7 6
7 5
7 4
81
7 9
80
7 7
7 3
7 2
82
7 9
80
7 7
83
8 5
113
8 4
10 7
10 8
8 9
9 0
9 1
9 2
10 3
10 2
10 6
10 4
10 5
8 6
8 7
8 8
9 7
9 8
9 4
9 6
9 9
10 0
9 5
10 1
9 3
111
112
7 1
6 4
6 3
5 9
6 2
6 1
6 9
7 0
5 8
6 7
6 8
5 7
6 7
6 8
6 6
6 6
5 6
5 6
6 5
5 5
6 0
10 9
110
|5
EN
4

6
Spare part overview article numbers
# Art.Nr.: Description
1 Z34377 hinge
2 N111780 Hexagonal nut
3 L01909 Door adjustment plate
4 Z34319 door glas
5 L00475 glass holder
6 L01413 door hinge ring
7 N104060 allen screw
8 N111780 Hexagonal nut
9 N111700 Headless screw
10 Z34342 wire cable
11 N111863 Door spring
12 L01982 spring tensioner
13 Z34516 cable cover
14 N111943 wire cable stop
15 L01526 Locking plate
16 Z10709 distance
17 Z33895 cable sheave
18 N110017 allen screw
19 N100169 washer
20 Z26185 distance
21 N111749 Headless screw
22 B16634 pressure piston
23 Z33959 Driving rod guide bolt
24 N109185 shaft securing device
25 Z34526 Driving rod upper
26 B16976 door handle complete
27 N111854 allen screw
28 N111810 allen screw
29 N108203 Door handle fillister head screw
30 Z33772 distance
31 Z28059 distance
32 N111860 Cylinder screw
33 L01641 Handle lock
34 N100172 washer
35 B12322 door lock
36 N103693 culimeta flat packing black 8x2
37 Z34524 combustion chamber door
38 N100485 Round sealing strip D12
39 L01800 hinge plate
40 Z32591 Fire brick front right
41 Z32593 Fire brick rear left/right
42 Z32590 Fire brick rear
43 Z32592 Fire brick front left
44 Z33588 Deflector plate bottom
45 Z32596 Deflector plate bottom Rikatronic³
46 Z33323 Deflector plate top
47 N100061 allen screw
48 Z25948 Shaker disk
49 Z25946 grate
50 L00616 Grate arm
51 L00618 ash drawer
52 L00617 ash drawer support
53 Z32940 wood retainer
54 Z35058 cover secondary air
55 Z34991 soapstone cover
56 Z34990 soapstone inlay
57 Z34989 soapstone side right
58 Z34988 soapstone side left
59 B17052 rear wall manual
60 B17012 rear wall Rikatonic³
61 Z10022 cover
62 L01947 mark plate
# Art.Nr.: Description
63 Z10021 cooking cover
64 Z10020 flue pipe attachments
65 Z32643 bolt
66 L02171 mounting plate
67 L02251 stone clip top
68 L02065 stone clip bottom
69 Z34843 cast cover
70 Z34764 cork disk
71 Z34366 bolt stone
72 Z34343 regulator knob
73 L02275 regulator handle
74 N108131 pressure spring rotating grid
75 Z34373 spring plate
76 L01912 slider
77 N111974 self-locking nut
78 Z34317 sliding lever
79 Z33758 distance
80 N108231 allen screw
81 L01913 driving plate
82 B16501 air regulator control top
83 Z34385 regulator cover
84 B16645 board Rikatronic³ cpl.
85 Z34418 bottom cover panel Rikatronic³
86 B15248 sensor tube
87 B15671 flame temperatur probe
88 L00433 Pressure bracket
89 Z33278 power supply holder
90 N110696 fuse 2,5A
91 B15754 main switch on/off
92 B15680 Cabletree
93 N104060 allen screw
94 B16464 transmission air regulator
95 N111817 air regulator motor
96 B16422 mainboard Rikatronic³
97 B16017 airbox with intake pipe socket
98 L02024 gear holder
99 N111815 elect. Lift magnet Rikatronic³
100 Z28501 distance
101 N111784 allen screw
102 N111825 door contact switch
103 L01992 contact switch support
104 Z34533 switching rod
105 N104971 Hexagonal nut
106 Z34535 contact switch rod plate
107 B16977 cover
108 N102647 allen screwdriver
109 Z34986 lid
110 Z33276 closure plate
111 N108131 pressure spring rotating grid
112 N111872 self-locking nut
113 Z34538 cable cover

|7
EN
6
Dimensions
B
R O - H
T
H
R O - T 1
R O - T 2 R O - T 3
F - S
F - H
R - H
R O - S
R - SR -
F -
Dimensions
height [mm] 1256
width [mm] 590
corpus depth [mm] 495
Weight
weight without stone [kg] 149
weight with stone [kg] 366
Flue pipe connection
R - Ø flue pipe outlet [mm] 130
RO - H original angle pipe connection height [cm] 175
RO - T1 original angle pipe total depth [cm] 74
RO - T2 original angle pipe distance to rear wall [cm] 25
RO - T3 deapth from rear wall to middle of flue
pipe [cm] 14
RO - S original angle pipe side distance [cm] 30
R - H rear connection height [cm] 89
R - S rear connection side distance [cm] 30
Fresh air connection
F - Ø diameter [mm] 125
F - H connection height [cm] 21
F - S side distance [cm] 30
Convection air connection
K - Ø diameter [mm] -
K - H connection height [cm] -
K - S side distance [cm] -
Amount of fuel
nominal load part load
Amount of fuel ~2,2kg* ~1,1kg*
*Practical values may vary depending on pellet quality.
Technical data
description measure data
heating capacity range [kW] 4 - 8
room heating capacity depending on house
coating [m³] 90 - 210
fuel consumption [kg/h] bis 2,2
electric supply [V]/[Hz] 230/50
average electrical input [W] ~ 4
fuse [A] 2,5 AT
efficiency [%] 85,7
CO2[%] 8,9
CO-emission on 13% O [mg/Nm3] 851
dust emission [mg/Nm3] 19
exhaust [g/s] 7,2
exhaust temperature [°C] 180
chimney draft requirement [Pa] 12
The owner of small firing systems or the person authorised for
the small firing system is to keep the technical documentation
and is to submit it to the authorities or the chimney sweep on
request.
Note
Please observe the national and European standards as well as local
regulations concerning the installation and operation of firing installations!
Packaging
Your first impression is important to us!!
The packaging of your new stove provides excellent protection against damage.
However damage to the stove and accessories may still occur during transport.
Note
Therefore please check your stove on receipt for damage and completeness!
Report any deficiencies to your dealer immediately! Pay particular attention
during unpacking that the stone panels remain intact. Scratches to the
material can easily occur. Stone panels are excluded from the warranty
The packaging of your new stove is environmentally neutral to a great extent
Tip
The wood used in the packaging has not been surface treated and may
therefore be burnt in your stove. The cardboard and film (PE) can be disposed
of via the municipal waste collection for recycling.
Electrical connection
The stove is supplied with an approx. 2m long connecting cable with a Euro-plug.
This cable is to be connected to a 230Volt/50Hz socket. The average electrical
power consumption is some 4 Watt in regular operation. The connection cable
must be laid so that there is no contact to any sharp edges or hot surfaces of
the stove.

8
2. IMPORTANT INFORMATION
General warning and safety information
Observance of the introductory general warning information is imperative.
QRead the entire manual thoroughly before installing and putting the stove into
service. Observe the national provisions and laws as well as the regulations
and rules applicable locally.
QRIKA stoves should only be installed in rooms with normal humidity (dry
areas according to VDE 0100 Part 200). The furnaces are not splash water
protected and may not be installed in wet areas.
QOnly approved transport equipment with sufficient load carrying capacity
may be used with your heating appliance.
QYour heating appliance is not suitable for use as a ladder or stationary
scaffolding.
QThe burning of fuel releases heat energy that lead to extensive heating of
the stove surfaces, doors, door and operating handles, glass, flue pipes
and possibly the front wall. Refrain from touching these parts without
appropriate protective clothing or equipment e.g. heat-resistant gloves or
means of operation (operating handle).
QMake your children aware of this particular danger and keep them away from
the stove during heating.
QOnly burn approved heating materials
QThe combustion or introduction of highly flammable or explosive materials
such as empty spray cans etc. in the combustion chamber and storing them
near the stove is strictly prohibited due to the danger of explosion.
QNo light or inflammable clothing is to be worn when post-heating.
QPlacing non-heat resistant objects on the stove or near it is prohibited.
QDo not place clothing on the stove to dry.
QStands for drying clothes etc. must be placed at a sufficient distance to the
stove – ACUTE DANGER OF FIRE!
QWhen your stove is burning, the use of highly inflammable and explosive
materials in the same or adjacent rooms is prohibited
Note
Waste and liquids may not be burnt in the stove!
Safety distances
Note
1. To non-combustible objects
a > 40 cm b > 10 cm
2. To combustible objects and reinforced concrete load-bearing walls
a > 80 cm b > 20 cm
Tip
please observe a minimum distance of 20 cm behind and sideways the stove
for maintenance.

|9
EN
8
Prior to set up
Floor bearing capacity
Ensure that the substructure is capable of bearing the weight of the stove prior
to set-up.
Note
No modifications may be made to the firing installation. This also leads to loss
of warranty and guarantee.
Floor protection
A base is required (glass, sheet steel or ceramic) if the floor is combustible
(wood, carpet, etc.).
Flue pipe connection
QFlue pipes pose a particular source of hazard regarding gas leaks and
fire. Get the advice of an authorised specialist company for the layout and
assembly.
QPlease observe the corresponding installation guidelines for walls panelled
with wood when connecting your flue pipes to the stove,
QObserve the formation of flue gas (atmospheric inversion) and draughts
when the weather is unfavourable.
QInfeed of too little combustion air can lead to smoke in the rooms or to flue
gas leaks. Hazardous deposits in the stove and chimney may also occur.
QIf flue gas escapes, let the fire burn out and check whether all the air inlet
openings are free and the flue gas pipes and the stove pipe are clean. If in
doubt notify the master chimney sweep since draught malfunctions may be
connected to your chimney.
QPush the embers together to form a firebed when you add new fuel (logs).
QOnly use suitable tools from our range of accessories when handling embers
and make sure that no embers fall out of the combustion chamber onto
inflammable material.
QUse the heat-resistant gloves supplied to open the doors of your stove.
Stoves type 1 (BA 1):
QThese may only be operated with the combustion chamber door closed.
QThe combustion chamber door may only be opened to add fuel and must
then be closed again otherwise other firing installations connected to the
chimney may be endangered.
QThe combustion chamber door is to be kept closed when the stove is not
in operation.
QFouling of the chimney i.e. deposits of highly inflammable materials such as
soot and tar and subsequently fire in the chimney may occur if wet fuel is
used and operation is damped too much.
QIf this occurs phone the fire brigade and get yourself and other residents
out of harm’s way.
Note
The size of the combustion chamber door makes it necessary, particularly
with post-heating when ablaze, not to open the door too abruptly to prevent
the tips of the flames reaching out.
Note
on ROOM-AIR DEPENDENT and
ROOM-AIR INDEPENDENT OPERATION:
Your stove has been tested as a room-air dependent stove according to EN
13240 and does not conform in Germany to the requirements for room-
air independent operation. In combination with room-air installations (e.g.
controlled ventilation and venting systems (extractors etc.) it must be ensured
that the stove and the room air system are monitored and safeguarded
mutually (e.g. via a differential pressure controller etc.). The combustion air
infeed of approx. 40 m3/h must be ensured. Please observe the respective
local regulations and rules in consultation with your master chimney sweep

10
3. BRIEF INFORMATION ON FUEL - LOGS
Suitable fuels and fuel amounts
Your stove is generally suitable for burning dry firewood. You can also burn fuels
such as wood briquettes.
Note
A stove is not a waste incinerator. The warranty lapses if waste or non-
approved materials such as plastic, treated wood etc. are burnt! This leads to
damage to the stove and chimney and environmental pollution!
Note
FUEL AMOUNTS
The stove is fitted with a construction-specific flat firebox. This means only
one layer of fuel may be laid on the base embers.
Please observe that adding greater quantities of fuel leads to emission of
more heat and greater heating of the stove than it is designed for. This may
cause damage to your stove.
Wood types
Different types of wood have different fuel values. Deciduous wood is
particularly suitable. It burns with a constant flame and forms long-lasting
embers. Coniferous wood has higher levels of resin and burns off faster as do
all softwoods and tends to spray sparks.
wood type fuel value
kWh/m3
fuel value
kWh/kg
maple 1900 4,1
birch 1900 4,3
beech 2100 4,2
oak 2100 4,2
alder 1500 4,1
ash 2100 4,2
spruce 1700 4,4
larch 1700 4,4
poplar 1200 4,1
robinia 2100 4,1
fir 1400 4,5
elm 1900 4,1
willow 1400 4,1
Fuel amounts with nominal heat output
Logs - wood briquettes (broken)
3 logs or pieces approx. 0.8kg each
The output of your stove is regulated via the Rikatronic³, however please
observe that the output of your stove also depends on the chimney draught and
the amount of fuel added.
Clean combustion
1. The firewood must be dry and untreated.
Guideline between 14% and 18% relative wood moisture.
Wood stored dry and ventilated for 2 – 3 years.
2. Correct firewood amount and size
QToo much firewood leads to overheating. This stresses the material too
much and leads to poor flue gas values.
QToo little firewood or logs being too large means the stove does not reach
optimum operating temperature. The flue gas values are also poor in this
case.
QFor right quantity of firewood (see AMOUNT OF FUEL)
