PT2E-1582
Gas detector head
70D Series Ethernet Model
Communication Function Manual

Preface
Thank you for choosing our 70D Series Ethernet model (GD-70D-EA/SD-70SC-ET, hereafter GD-70D-EA
is described as a representative of both).
This communication function manual explains how to use the Ethernet communication function of
GD-70D-EA. Not only the first-time users but also the users who have already used the product must read
and understand the operating manual to enhance the knowledge and experience before using the product.
Note that the communication function of GD-70D-EA is part of communication devices forming the network
system on the field.
Please be sure to read the operating manuals of related equipment.
Limitation of Responsibilities
We shall not take any responsibilities of the results caused by the program of other devices that
communicates with this product.
Notation of numerical number
Decimal number: Numerical value only (1 100 1000, etc.)
Hexadecimal number: With“0x” in front of the value (0x00 0x64 0x3EB, etc.)
Definition of DANGER, WARNING, CAUTION and NOTE
Definition of DANGER, WARNING, CAUTION and NOTE
DANGER This message indicates that improper handling may cause serious damage on
life, health or assets.
WARNING This message indicates that improper handling may cause serious damage on
health or assets.
CAUTION This message indicates that improper handling may cause minor damage on
health or assets.
NOTE This message indicates advice on handling.

Contents
1. Start-up ........................................................................................................................................................... 1
1-1. Connecting devices................................................................................................................................ 1
1-1-1. Connection with a PoE switching hub ........................................................................................... 1
1-1-2. Connection with a non-PoE switching hub.................................................................................... 2
1-2. Setting .................................................................................................................................................... 3
1-2-1. Setting the IP address of GD-70D-EA........................................................................................... 3
1-2-2. Setting the IP address of the PC ................................................................................................... 4
1-2-3. Communication test ....................................................................................................................... 5
1-3. Web functions ........................................................................................................................................ 6
1-3-1. Setting the browser........................................................................................................................ 6
1-3-2. Logging in to the user mode.......................................................................................................... 7
1-3-3. Logging in to the authorized user mode........................................................................................ 8
1-4. PLC communication functions (OMRON CJ/CS Series) ....................................................................... 9
1-4-1. Connection with the PLC .............................................................................................................10
1-4-2. Setting the communication with PLC through the Web function................................................. 11
1-4-3. Setting the communication with PLC through the GD-70D-EA main unit operation...................12
1-5. PLC communication functions (MELSEC Q Series)............................................................................ 14
1-5-1. Connection with the PLC .............................................................................................................14
1-5-2. Setting the communication with PLC through the Web function................................................. 15
1-5-3. Setting the communication with PLC through the GD-70D-EA main unit operation...................16
2. Web Functions.............................................................................................................................................. 18
2-1. Precautions on operating environment................................................................................................18
2-2. List of functions ....................................................................................................................................20
2-3. Web screen components .....................................................................................................................21
2-3-1. User screen (User) ......................................................................................................................21
2-3-2. Authorized user screen (Authorized Users) ................................................................................ 24
2-4. Auto mailing function (gas alarm/fault alarm) ......................................................................................36
3. Modbus/TCP Communication Functions...................................................................................................... 38
3-1. Communication specifications .............................................................................................................38
3-2. Register map........................................................................................................................................38
3-3. Command............................................................................................................................................. 43
3-4. Exceptional response...........................................................................................................................44
3-4-1. When non-supported function is specified ..................................................................................44
3-4-2. When the specified address is out of the range..........................................................................44
3-4-3. When access to the address not within the range is specified ................................................... 44
3-4-4. When writing to the unwritable address is specified ................................................................... 44
4. PLC Communication Functions....................................................................................................................45
4-1. Communication specifications .............................................................................................................45
4-2. Data type ..............................................................................................................................................46
4-2-1. Basic Data: Small ........................................................................................................................46
4-2-2. Basic Data: Large ........................................................................................................................ 47
4-2-3. Basic Data: Small + Optional Data .............................................................................................. 48
4-2-4. Basic Data: Large + Optional Data.............................................................................................. 49
4-3. Communication settings.......................................................................................................................50
4-4. Data map..............................................................................................................................................52
4-4-1. Basic Data: Small ........................................................................................................................52
4-4-2. Basic Data: Large ........................................................................................................................ 54
4-4-3. Optional Data...............................................................................................................................56
4-5. Command............................................................................................................................................. 57
4-5-1. Issuing Command 1 (setting alteration) ......................................................................................57
4-5-2. Issuing Commands 2 to 9 (Basic Data: Large only).................................................................... 57
4-5-3. Issuing Command 10 (alarm test concentration setting) (Basic Data: Large only) ....................58
4-5-4. Data relative to Basic Data: Large commands............................................................................59
4-5-5. Data relative to Optional Data commands ..................................................................................61
4-5-6. Altering alarm setpoint setting ..................................................................................................... 62
4-5-7. Inhibit operation ........................................................................................................................... 63
4-6. Specifications for communication setting through GD-70D-EA main unit operation........................... 64

1. Start-up 1-4. PLC communication functions (OMRON CJ/CS Series)
- 9 -
1-4. PLC communication functions (OMRON CJ/CS
Series)
Configure the PLC communication settings of GD-70D-EA.
The settings can be configured by the following methods:
To flexibly set the small number of devices:
Use the Web screen of the authorized user mode.
Multiple items can flexibly be set through the Network screen of the Web function.
If not [PLC MODE] = 1, it is not possible to change all the items.
See 1-4-2, “Setting the communication with PLC through the Web function” for details of the setting
method.
To quickly set a large number of devices through the operation on the gas detector:
Use the GD-70D-EA front panel.
The setting can be easily configured using front panel keys in the following two items: [PLC MODE]
and [PLC AREA].
PLC IP address XXX. XXX. XXX.251 and NODE251 are fixed.
([xxx] is the same as the IP address of GD-70D-EA.)
See 1-4-3, “Setting the communication with PLC through the GD-70D-EA main unit” for details of the
setting method.
