Rinstrum M4202 User manual

004M-610-110
ModuleDescription:
General 1xisolated duplexRS-232withDTR
1xisolated TX-only2RS-485
Isolation >500Vfromindicatortomodule
PowerSupply Internal
Baudrate1 2400,4800,9600, 19200, 38400, 57600
Paritybit1None, Even, Odd
Databits17,8
StopBits11,2
DTR1,3 OFF, ON
Termination1,4 OFF, ON(Internal)
Note1:Instrument maynotsupport all options.
Note2:TX-onlytransmitterisalways active.
Note3:RS-232 only.
Note4:RS-485 only.
Interface Diagram: ExampleUse:
ExampleUse:
ModuleConnections
M4
20
2
RS-232/485Comms

004M-610-110
M4202SETUP
TheindicatorshouldbeswitchedOFF beforeinstalling orremoving thisdevice.
Modulesareconfigured usingtheindicatorsetup.Setupcanbe doneviatheindicatorkeypad
ortheviewerprogram. Anoverviewof the setupisgivenbelow; seetheindicatorQuick Startor
Referencemanualsfordetailed setupinformation.
The indicatorprovidesconfigurationcheckingcapabilitiesfortheM4202. Thisisfoundinthe
H.WAREsetupmenu. SeetheindicatorQuick Start orReferencemanuals.
K402 SOFTWARESETUP
Thismoduleisconfiguredasserialport2ontheindicator.
Network
(i)Setup.. . .
SER.NET. . . .
(Refertoquick start manualforsettings)
AutomaticOutput
(i)Setup.. . .
SER.AUT
. .. . (Refertoquick start manualforsettings)
Print
(i)Setup.. . .
PRINT
. . . .. ..
(Refertoquick start manualforsettings)
PortConfiguration (i.e. Baud, etc)
(i)Setup.. . .
H.WARE. .. .
. SER2.HW.. . . (Refertoquick start manualforsettings)
M4202TROUBLESHOOTING
The M4202 has4annunciatorswhichhelpwithtroubleshooting.Theseannunciatorsare
shownasyellowonthe ModuleConnectionsfigureabove.
Problem Possiblesolutions
Receivenot working.
M4202 receiveannunciatornot lit. Check wiring.
Receivenot working.
M4202 receiveannunciatorlit. Check indicatorsetup(H.WARE:ALLOC).
Transmitnotworking.
M4202 transmitannunciatornot lit. Check indicatorsetup(H.WARE:ALLOC). When printing: Check DTRannunciatorandindicator
setup.
Transmitnotworking.
M4202 transmitannunciatorlit. Check wiring.
