rionet Digitalian U Series Operating instructions

Earmold shown above are not included as standard ac-
cessories.
* The communication connector serves for adjustment of
the hearing aid by the hearing aid professional.
Battery Placement
1. Set the O-M2-M switch of the hearing aid to
"O" (power off).
2. Peel off the sticker on the positive side of
battery (PR48 or 13 zinc-air battery).
3. Open the battery holder with the tip of your
finger.
4. Insert the battery into the battery
holder. You do not have to worry
about the polarity.
5. Close the battery holder.
Battery life (PR48 or 13, for continuous use)
ANSI: Approx. 270 hours
IEC: Approx. 290 hours
- Battery life will change depending on the operat-
ing condition.
Putting on Hearing Aid
1. Place the hearing aid on the ear.
Earmold
HOW TO USE YOUR FIRST HEARING AID
Any hearing aid cannot return level of your hearing to normal or
halt further hearing deterioration, but proper use of your hearing
aid can help you hear what is going on around you and let you
get more enjoyment of life.
If this is your first hearing aid, you - like most new users - will
probably be surprised at the loudness of the sounds, and after
using it for a short while, you may even feel that it is too noisy. The
following three tips are important in overcoming your concerns.
1) Read this manual and become familiar with the hearing aid's
various mechanisms and how to use them correctly.
2) First, use your hearing aid in a quiet place and listen to quiet
sounds and give yourself sufficient time to get accustomed to
the sound of your hearing aid.
3) If any physical problems develop, consult your doctor.
FOR KEEPING YOUR HEARING AID LONGER
Always keep the hearing aid clean. Clean the hearing aid with dry
cloth periodically and also remove earwax plugged in the earpiece
or earmold using eyebrush or toothbrush.
Do not expose the hearing aid to the heat from stoves, etc. Also,
avoid leaving it in places with high humidity.
Operate the controls with care. Do not press hard.
If the hearing aid is dropped in water, wipe with dry cloth and ask
the dispenser for check.
Do not pick the microphone with nail, pin, etc., because this may
damage the microphone.
Do not disassemble or attempt any repairs by yourself. Ask the
dispenser for repair.
3-20-41 Higashimotomachi, Kokubunji, Tokyo 185-8533, Japan
HB-G2U
DIGITAL
HEARING AID
(off) (on) (on)
O M 2 M
or
(off) (on)
Select "M".
O M 2 M
Turn up to
increase volume.
Turn down to
decrease volume.
Wind cover
Volume control
*Communication
connector
O-M2-M switch
Battery holder
Earmold
"Either way"
circuit
Hook
Microphone
OPERATING INSTRUCTIONS
Parts and Controls
Earpiece
2. Turn the power on.
3. Adjust the volume control to a suitable level.
Volume control
Higher numbers mean louder sound.
* Adjust the volume according to the situation (volume of
other voices, ambient noise, etc.).

Memory selection (using selector switch)
If sounds are hard to hear depending
on the environment, such as in a noisy
or quiet environment, change the set-
ting of the memory selector to find the
position that yields best results.
* The memory selector switch (M2/M)
is programmed to match your hearing
pattern. Operate the switch to find the
position that yields best results in a
given situation.
Switch operation sound
Memory 1 Memory 2
M2 M: one short beep M M2: two short beeps
Removing Hearing Aid
1. Set the switch to "O" (power off) before re-
moving the hearing aid. If the switch is left in
the "M" or "M2" position, acoustic feedback
(high-pitched sounds) may occur.
Recycled papers are used for this manual. No. 51290 06-11
2. Be sure to set the switch to "O" and take out the battery, when
not using the hearing aid.
Turn-on precaution
If you switch the hearing aid off and then immediately on again,
there may be no sound, but this is not a defect. In such a case,
return the switch to "O" (Off), wait for at least 10 seconds, and
then set the switch to "M" or "M2" again.
Adjusting the Controls
This hearing aid is a digital type. Any adjustments must be done
at the dealer. For details, please contact the dealer.
Factory Default Setting
O - M2 - M switch: "O"
Volume control (1 to 4): "1"
120 0dB=20µPa 1600 2500
110
100
90
80
70
100 200 500 1000 2000 5000 10000
Frequency (Hz)
Output SPL (dB)
Input SPL 60dB
130 0dB=20µPa 1600 2500
120
110
100
90
80
100 200 500 1000 2000 5000 10000
Frequency (Hz)
Output SPL (dB)
Input SPL 90dB
0 dB
-20 dB
70 1600 2500
60
50
40
30
20
100 200 500 1000 2000 5000 10000
Input SPL 50dB
(0dB=20µPa)
Frequency (Hz)
Acoustic Gain (dB)
120 0dB=20µPa 1600 2500
110
100
90
80
70
100 200 500 1000 2000 5000 10000
Frequency (Hz)
Output SPL (dB)
Input SPL 60dB
140 0dB=20µPa 1600 2500
130
120
110
100
90
100 200 500 1000 2000 5000 10000
Frequency (Hz)
Output SPL (dB)
Input SPL 90dB
0 dB
-20 dB
80 1600 2500
70
60
50
40
30
100 200 500 1000 2000 5000 10000
Input SPL 50dB
(0dB=20µPa)
Frequency (Hz)
Acoustic Gain (dB)
(off) (on) (on)
O M 2 M
Full-on gain curve
Frequency response curve OSPL90 curve and effect of
output limiting control
Full-on acoustic gain frequency response curve
Basic frequency response
curve
OSPL90 curve and effect
of output limiting control
Memory 2
(switch position "M2")
Memory 1
(switch position "M")
(off) (on)
O M 2 M
(off) (on)
O M 2 M
Note:
(1) Production number (se-
rial number) is indicated at
the upper rear side of the
unit.
(2) Manufacturer's name is
imprinted at the lower rear
side of the unit.
TECHNICAL DATA (According to ANSI standard S3.22 2003)
Maximum-OSPL90 125 dB (1100 Hz)
HFA-OSPL90 121 dB
HFA-full-on Acoustic Gain 54 dB
Reference Test Gain 44 dB
Frequency Range 100 Hz to 6500 Hz
Equivalent Input Noise Level 24 dB
Total Harmonic Distor tion 500 Hz: 7% 800 Hz: 7% 1600 Hz: 5%
AGC Input AGC / OPC (Output AGC)
Attack /
Recovery
Time
Input AGC Single Mode
Attack: 3 msec
Recovery: 120 msec
Double Mode
Attack: 3 msec or 100 msec
Recovery: 100 msec or 2 sec
Triple Mode
Attack: 3 msec or 400 msec
Recovery: 100 msec or 600 msec or 15 sec
Output AGC Attack: 3 msec
Recovery: 50 msec
Operating Switch O-M2-M
Output Limiting Control OPC (range: 20 dB)
Gain Control Main VR (range: 23 dB)
GAIN (range: 19 dB)
Battery Type/Supply Voltage 13/1.3 V
Battery Current 0.98 mA
Battery Life Approx. 270 hours
Dimensions/Weight 3.80 × 1.34 × 0.88 cm /
3.6 g (excluding battery)
(Typical value with E1 hook)
TECHNICAL DATA ( )
Reference Test Frequency 1600 Hz
OSPL90 126 dB
500 Hz 124 dB
Peak 131 dB
Full-on Acoustic Gain 58 dB
Equivalent Input Noise Level 32 dB
Total Harmonic Distortion 500 Hz: 7% 800 Hz: 7% 1600 Hz: 5%
AGC Input AGC / OPC (Output AGC)
Attack /
Recovery
Time
Input AGC Single Mode
Attack: 3 msec
Recovery: 120 msec
Double Mode
Attack: 3 msec or 100 msec
Recovery: 100 msec or 2 sec
Triple Mode
Attack: 3 msec or 400 msec
Recovery:
100 msec or 600 msec or 15 sec
Output AGC Attack: 3 msec
Recovery: 50 msec
Operating Switch O-M2-M
Output Limiting Control OPC (range: 20 dB)
Gain Control Main VR (range: 23 dB)
GAIN (range: 19 dB)
Battery Type/Supply Voltage PR48/1.3 V
Battery Current 0.9 mA
Battery Life Approx. 290 hours
Dimensions/Weight 3.80 × 1.34 × 0.88 cm /
3.6 g (excluding battery)
(Typical value with E1 hook)
According to IEC standard Pub. 60118-0-1983
Amendment 1-1994
