RITM OKB ZAO SCENAR 1-NT User manual

SCENAR 1-NT
The first steps
RITM OKB ZAO

MENU
button
Amplitude setting / "O" state
2 sec
without
pressing
Basis states
DOSE
button
2 sec
without
pressing
buttons “+”, “-"
2 sec
without
pressing

The “O” state screen

Each step of amplitude setting is indexed
with click;
When min/max of the amplitude is reached
long signal sounds.
Sounds while amplitude setting

(dosing is off)
Every 30 sec (without button pressing) short
signal sounds.
Sounds during work
30 sec 30 sec 30 sec

The menu structure

“Dose mode”
Dose
1No 2
3
АМ
+/-
4
5
Gap

“Dose mode”
Working in dose mode (screen information and
sounds) will be observed later!

“Amplitude modulation mode”
АМ FМ
+/-
No 1:1
Bee 5:1 ... 2:1
Dose

No
1:1
2:1
3:1
4:1
5:1
Bee
Sounds in
“Amplitude modulation mode”

“Frequency modulation mode”
FМ Dmp
+/-
No On
Sw 4... Sw1
АМ

“Frequency modulation mode”

Sounds in
“Frequency modulation mode”
No
On
Sw1
Sw2
Sw3
Sw4

“Damping mode”
Dmp
No
F
+/-
FМ
Sc1
Var Sc4 ... Sc2

Sounds in “Damping mode”
No
Sc1
Sc2
Sc3
Sc4
Var

“Frequency mode”
F Int
15 ... 350
+/-
Dmp

15,3Hz
29,7Hz
59,3Hz
90,3Hz
121 Hz
180 Hz
351 Hz
Sounds in “Frequency mode”

“Intensity mode”
Int
21 3 ... 8
+/-
GapF

“Gap mode”
Gap Dose
10 ... 80
+/-
Int

Practice
Set max frequency
Switch on the combination “FМ-Var”
Switch on damping “Sc4”
Switch Dose mode “Dose=1”
Switch off the modulation
Set intensity 2, 3,...,8
While increasing Gap, watch the intensity
Switch the device off and switch it on again
