Rival Drivetech 4x4 DT-2D18121 User manual

FITTING INSTRUCTIONS Australia
www.drivetech4x4.com.au
New Zealand
www.drivetech4x4.co.nz
Information on this sheet is prepared as a customer aid, from reliable information, with the utmost care and should not be used for any other purpose.
Motospecs reserves the right to make product or publication changes at any time without notice. © Copyright Motospecs, all rights reserved.
Installation Manual
Product:
Model:
Suits Bumper:
CAUTION!
To reduce the risk of serious injury or damage, please read and understand all
instructions and procedures before attempting to install or use this product.
Safety glasses should be worn at all times during installation or maintenance of this
product.
Ensure all mounting bolts are tensioned after 1,000kms and periodically there-after.
PXIII Radar Adapter (DT-2D18121)
Ford Ranger (2018-On)
DT-2D18081
ИНСТРУКЦИЯ ПО УСТАНОВКЕ
ПРОДУКТ:
МАРКА:
АРТИКУЛ:
ОСТОРОЖНО!
Чтобы уменьшить риск серьезных травм или повреждения имущества: До начала установки и использования данного
продукта, прочитайте всю инструкцию, особое внимание обратите на условия безопасного использования и
рекомендации по установке! При установке или обслуживании данного изделия, необходимо использовать защитные
очки. Проверяйте целостность конструкции и момент затяжки крепежа через каждые 1000км пробега. Не используйте
данный продукт если имеются повреждения конструкции либо крепежа!
D.1812.1
Конверсионный пакет
Ford Ranger (2017-)
INSTALLATION MANUAL
PRODUCT: PX 3 ADAPTER
MODEL: FORD RANGER ( 2018- )
PART NO: DT-2D18121
To reduce the risk of serious injury or damage, please read and understand all instructions and
procedures before attempting to install or use this product.
Safety glasses must be worn at all times during installation or maintenance of this product.
Ensure all mounting bolts are tensioned after 1000 kms and periodically there after.
CAUTION!
www.drivetech4x4.com.au

FITTING INSTRUCTIONS Australia
www.drivetech4x4.com.au
New Zealand
www.drivetech4x4.co.nz
Information on this sheet is prepared as a customer aid, from reliable information, with the utmost care and should not be used for any other purpose.
Motospecs reserves the right to make product or publication changes at any time without notice. © Copyright Motospecs, all rights reserved.
PXIII Radar Adapter
Installation Notice
Required Tools
Torque Setting
• M6 - 9 N.M
• M10 - 44N.M
• Basic tool kit
• Electric drill
• Drill set
• Angle grinder (or other appropriate cutting tool)
• Torque wrench
• Marker
DT-2D18121
Ford Ranger PXIII 2018-On
Aluminium
392 x 193 x 57mm
760gm
Drivetech 4x4 Bumper by Rival DT-2D18081B
• The PXIII Radar Adapter must be mounted and secured to the vehicle
according to this instruction manual
• Personal safety during the installation process must be adhered to at all times
and the use of personal safety equipment is highly recommended.
• It is strongly recommended that you install PXIII Radar Adapter on specified
vehicle model only
Part No:
Suited to vehicle:
Material:
Dimensions:
Weight:
Compatibility:
МОМЕНТ ЗАТЯЖКИ
НЕОБХОДИМЫЙ ИНСТРУМЕНТ
* Basic tool kit
* Electric drill
* Angle grinder
* Torque wrench
* Drill set
* Marker
* М6 - 9 Н·м,
* М10 - 44 Н·м.
Date: 18.06.2019
REQUIRED TOOLS
TORQUE SETTING
DT-2D18121
Ford Ranger 2018-
Aluminum
392 х 193 х 57 mm
0.76 kg
DT-2D18081BNL-1 Front bumper
Part Number:
Suited to vehicle:
Material:
Dimensions:
Weight:
Compatibility:
PX3 ADAPTER
of personal safety equipment is highly recommended.
* The PX3 Adapter must be mounted and affixed to the vehicle according to this installation
manual.
* Personal safety during the installation process must be adhered to at all times and the use
* It is strongly recommended to instal PX3 Adapter on specified vehicle model.
INSTALLATION NOTICE
Installation manual DT-2D18121
< Page 1 of 4 >
www.drivetech4x4.com.au

FITTING INSTRUCTIONS Australia
www.drivetech4x4.com.au
New Zealand
www.drivetech4x4.co.nz
Information on this sheet is prepared as a customer aid, from reliable information, with the utmost care and should not be used for any other purpose.
Motospecs reserves the right to make product or publication changes at any time without notice. © Copyright Motospecs, all rights reserved.
Parts Listing
8. Screw М6х20 black...........................
10. Nut М8............................................
6. Bolt 8х20...........................................
11. Nut М10..........................................
1. Template...........................................
12. Washer М6.....................................
5. License plate.....................................
14. Washer М10...................................
9. Nut М6..............................................
13. Washer М8.....................................
4. Bracket №2.......................................
7. Bolt 10х20.........................................
3. Bracket №1.......................................
2. Decoration pad..................................
2 pc.
8 pc.
1 pc.
8 pc.
2 pc.
1 pc.
10 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
3
1
5
2
4
Date: 18.06.2019 Installation manual DT-2D18121
< Page 2 of 4 >
PARTS LISTING
www.drivetech4x4.com.au
1. Template
2. Fascia Plate
3. Bracket No1
4. Bracket No2
5. License plate
6. M8x20 Bolt
7. M10x20 Bolt
8. M6x20(black) Screw
9. M6 Nut
10. M8 Nut
11. M10 Nut
12. M6 Washer
13. M8 Washer
14. M10 Washer
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
8 pc.
8 pc.
1 pc.
1 pc.
10 pc.
2 pc.
2 pc.

FITTING INSTRUCTIONS Australia
www.drivetech4x4.com.au
New Zealand
www.drivetech4x4.co.nz
Information on this sheet is prepared as a customer aid, from reliable information, with the utmost care and should not be used for any other purpose.
Motospecs reserves the right to make product or publication changes at any time without notice. © Copyright Motospecs, all rights reserved.
Инструкция по установкеИнструкция по установке
Drill 6 pricked holes up to 8mm
2.Cut the hole in bumper out, by follow
the marked line
1. Install template (pos. 1), as shown.
Mark the shape of cut out and prick 6
holes.
3. Install the radar and bracket №2 in
bumper, using screws M6x20, washers
M6, nuts M6, bolt M8x20, washers
M8,nut M8, as shown.
4. Fix the bottom part of radar using
bracket №1, bolt M10x20, washers 10
and nuts M10, as shown.
Date: 18.06.2019 Installation manual DT-2D18121
< Page 3 of 4 >
www.drivetech4x4.com.au
INSTALLATION PROCEDURE
Installation Procedure
1. Position template plate between upright
supports on the centre of the Bumper
2. Drill pilot holes using a 5mm drill bit
3. Mark the required area on the inside edge
of the template plate
6. Install the factory radar and bracket
No2 in Bumper, using M6x20 screws,
M6 washers, M6 nuts, M8x20 bolt, M8
washers, M8 nut as shown
7. Fix the bottom of the radar using bracket
No1, M10x20 bolt, M10 washers and
M10 nuts as shown
4. Remove marked sections of the Bumper
with an angle grinder or appropriate cutting
tool
5. Re-drill pilot holes using an 8mm drill bit

FITTING INSTRUCTIONS Australia
www.drivetech4x4.com.au
New Zealand
www.drivetech4x4.co.nz
Information on this sheet is prepared as a customer aid, from reliable information, with the utmost care and should not be used for any other purpose.
Motospecs reserves the right to make product or publication changes at any time without notice. © Copyright Motospecs, all rights reserved.
Installation Procedure
5. Install decorative pad (pos.2), using
screws M6x20 (pos.8), washers M6
(pos. 12), nuts M6 (pos 9), as shown.
Before operating a vehicle fitted with RIVAL PX3 Adapter:
- make sure all fittings are tightened
- check adapter and brackets operation
6. Install universal license plate (pos. 5)
using screwsM6x20 (pos. 8), nuts M6
(pos. 9) and washers M6 (pos. 12).
Tighten all connectors after that.
7. Adjust the angle of license plate.
Date: 18.06.2019 Installation manual DT-2D18121
< Page 4 of 4 >
www.drivetech4x4.com.au
INSTALLATION PROCEDURE
Before operating a vehicle fitted with the PXIII Radar Adapter:
• Make sure all fittings are tightened
• Check the operation of adapter and brackets
8. Install Fascia plate, using M6x20 screws,
M6 washers and M6 nuts as shown
9. Install universal license plate using M6x20
screws, M6 nuts and M6 washers, ensure
number plate mount is behind fascia plate
10. Adjust the angle of the license plate
11. Recheck all nuts and bolts to ensure that
they are fastened tightly
