Rixen TX-60 Series User manual

Digital Thermometer TX-60 series
I. Introduction:
The TX-60 series Digital Thermometer accepts K.J.E.T.N.R.S.B. thermocouple types. It offer widest temperature range, highly accurate, high
performance and rugged.
The TX-60 series Digital Thermometer has a variety of useful functions. Available for hold, stored MAX/MIN values, ℃/℉switchable, auto-ranging
and automatic/manual power shutoff and RS-232 Data output.
The TX-60 series Digital Thermometer also features single point field calibration offset factory setting and power sources both
of DC 9V battery or AC adaptor.
II. Features:
High Accuracy, Fast response.
Auto-Ranging with 0.1/1Resolution
Data-Hold, Records MAX. MIN Values.
RS-232 Data Output, 9V AC Adaptor is available
Automatic/Manual power shut off function.
Rugged, drop-proof, dust-proof operating panel and case
℃/℉switchable
Wide measuring range (Thermocouple Type)
Self-diagnostics (Alarm): Low Battery, Open TCs and Over Range Alerts
III. Symbol definition and button location
IV. Specifications:
Model No.
Input Type
Measuring Range
RS-232 initial data
Resolution
Accuracy (at 25℃)
TK-60
K
- 200 ~ + 1372 ℃
(-200.0℃= 0 Bit)
0.1°Between -199.9 to + 199.9°
1°Above 200°(Auto Ranging)
± 0.1% of rdg +0.2℃
(Between -199.9 to +199.9℃)
± 0.1% of rdg+1℃(Above 200℃)
TJ-60
J
- 200 ~ + 1200 ℃
TE-60
E
- 200 ~ + 1000 ℃
TT-60
T
- 200~ + 400 ℃
TN-60
N
- 200 ~ + 1300 ℃
(-200.0℃= 0 Bit)
1℃(Full Range)
±0.1% of rdg +1℃
TR-60
R
- 20 ~ + 1768 ℃
(-20.0℃= 0 Bit)
TS-60
S
- 20 ~ + 1768 ℃
TB-60
B
+600 ~ + 1820 ℃
(+600.0℃= 0 Bit)
LCD display
Offset calibration screw
AC power adaptor
RS-232 Output
Memory function
Max/Min
Data Hold button
Power Switch

V. Common Specifications of TX-60 series
Sampling Rate : Approx. 0.4 sec/reading
Temp. Compensation : Auto. Temperature Compensation depends on T/C types
Display : Digital LCD display, Quick-type and Weatherablity.
Signal Output : RS-232, 0.1℃/1Bit
Main Functions : Auto power off, Records Max./Min. values, Data-hold, ℃/℉switchable, Low battery warning, RS-232 Signal output.
Power Supply : One 9V006P battery about 180 hours for continuing use. or AC Adaptor (option)
Dimension/Weight : 150 x 75 x 28 mm (L x W x D), approx. 160g (without battery).
Sensor connector : Miniature Connector for Thermocouple –Standard (Two pins)
※Above data of “Accuracy” and “Sampling rate” exclude the error of temperature probes.
※The specification of TK-60 series will be subject to change without notice.
VI. Operation Instructions:
A. Power Switch: Press the button turn the thermometer On or Off.
B. Manual Power off ( + ):
Keep the key pressed and press the key turn on the meter, the meter will change to manual power off, the “ M ” indication appears
on the display, denote the meter is manual power off mode.
C. Auto power off:
Press turn on the meter, it is under auto power off mode. The meter automatically turns itself off after about 7 minutes if no key is operated.
D. Data Hold Function:
The measured values can be held in the display by pressing the key, and a symbol HOLD will appear in the display. Operator may
press button again to exit the HOLD mode.
E. MAX/MIN Value Operations:
Press button, the meter will enter the memory function, the MAX symbol is on the display and the maximum value is shown on the display.
Press again, the MIN symbol is on the display, and show the minimum value on the display.
※Operator may press to circulate the display mode both options.
F. Low battery condition:
When the battery voltage is under proper operation requirement, the symbol “ “ will show on the LCD and the battery needs to be
replaced with new one.
G. ℃/℉Switch:
Keep the key pressed and press the key turn on the meter, the meter will change to ℃/℉, the “℃/℉” indication appears
on the display.
Precaution:
If operator would like to circumscribed power for long time measure record, please use the AC Adaptor. (This is chosen products, please contact
original company sales department).
Offset calibration screws offers temperature reparation or specialties calibration needed. Unless specialist please doesn’t random adjust.
When meter show the “ “, please check the thermocouple if well or not. Or your measure range is out of this meter that can accept the
measure temperature.
Please don’t put the meter in high temperature, humid or shaky place.
If have any problem of using; please don’t repair or instead mounting by yourself.
Warranty: Within one year from the date of original purchase.

RS-232 Transmission Functions
The RS-232 transmission port of TX-60 series is single side data transmission, it functions with 3 signal composed grounding wires to receive
and input. We suggest that you choose the original transmission cable or shorter than 10 meters cable to connect PC and instrument.
a. Transmission Status: 57600 / 8 / N / 1
b. Transmission Content (8-BIT):
START
TYPE
MOD
MSD
LSD
CHECK
END
A8H
HI-DATA
LO-DATA
FFH
8AH
BIT [7:0] = Instrument Model
TK-62 =>00H
TX-60 Series =>01H
BIT [7:4] = Thermocouple Type
BIT [3:2] = Instrument Status
BIT [1] = Power Model
Automatic Power Off = 0
Manual Power Off = 1
BIT [0] = Power
Enough Power = 0
Low Power = 1
c. Illustration of Connection:
Example 1: A8H,01H,11H,09H,23H,FFH,8AH
=>> TX-60 type, J-TYPE, NORMAL mode, Automatic Power Off, Low Power
09H,23H =>> (9 X 256) + (2 X 16 + 3) = 2339.BIT = + 33.9℃
Example 2: A8H,01H,6CH,32H,D4H,FFH,8AH
=>> TX-60 type, N-TYPE, MAX mode, Manual Power Off, Enough Power
32H,D4H =>> ((3 X 16 + 2) X 256) + (13 X 16 + 4) = 13012.BIT = + 1101.2℃
※Notice: RS-232 transmission can not configure a variety of instruments on the same port.
K
0000
R
0100
J
0001
S
0101
E
0010
N
0110
T
0011
B
0111
NORMAL
00
HOLD
01
MAX
10
MIN
11
