RKC INSTRUMENT HA430 User manual

Resin Pressure Digital Controller
IMR01N11-E4
Thank you for purchasing this RKC product. In order to achieve maximum
performance and ensure proper operation of your new instrument, carefully read all
the instructions in this manual. Please place this manual in a convenient location for
easy reference.
 This product is intended for use with industrial machines, test and measuring
equipment. (It is not designed for use with medical equipment and nuclear
energy.)
 This is a Class A instrument. In a domestic environment, this instrument may
cause radio interference, in which case the user may be required to take
adequate measures.
 This instrument is protected from electric shock by reinforced insulation.
Provide reinforced insulation between the wire for the input signal and the
wires for instrument power supply, source of power and loads.
 Be sure to provide an appropriate surge control circuit respectively for the
following:
− If input/output or signal lines within the building are longer than 30 meters.
− If input/output or signal lines leave the building, regardless the length.
 This instrument is designed for installation in an enclosed instrumentation
panel. All high-voltage connections such as power supply terminals must be
enclosed in the instrumentation panel to avoid electric shock by operating
personnel.
 All precautions described in this manual should be taken to avoid damage to
the instrument or equipment.
 All wiring must be in accordance with local codes and regulations.
 To prevent instrument damage or failure, protect the power line and the
input/output lines from high currents with a protection device such as fuse,
circuit breaker, etc.
 Prevent metal fragments or lead wire scraps from falling inside instrument
case to avoid electric shock, fire or malfunction.
 Tighten each terminal screw to the specified torque found in the manual to
avoid electric shock, fire or malfunction.
 For proper operation of this instrument, provide adequate ventilation for heat
dispensation.
 Do not connect wires to unused terminals as this will interfere with proper
operation of the instrument.
 Turn off the power supply before cleaning the instrument.
 Do not use a volatile solvent such as paint thinner to clean the instrument.
Deformation or discoloration will occur. Use a soft, dry cloth to remove stains
from the instrument.
 To avoid damage to instrument display, do not rub with an abrasive material
or push front panel with a hard object.
NOTICE
 This manual assumes that the reader has a fundamental knowledge of the
principles of electricity, process control, computer technology and communications.
 The figures, diagrams and numeric values used in this manual are only for purpose
of illustration.
 RKC is not responsible for any damage or injury that is caused as a result of using
this instrument, instrument failure or indirect damage.
 RKC is not responsible for any damage and/or injury resulting from the use of
instruments made by imitating this instrument.
 Periodic maintenance is required for safe and proper operation of this instrument.
Some components have a limited service life, or characteristics that change over
time.
 Every effort has been made to ensure accuracy of all information contained herein.
RKC makes no warranty expressed or implied, with respect to the accuracy of the
information. The information in this manual is subject to change without prior
notice.
 No portion of this document may be reprinted, modified, copied, transmitted,
digitized, stored, processed or retrieved through any mechanical, electronic, optical
or other means without prior written approval from RKC.
1. MOUNTING
 Mounting Cautions
(1) This instrument is intended to be used under the following environmental
conditions. (IEC61010-1) [OVERVOLTAGE CATEGORY II, POLLUTION DEGREE 2]
(2) Use this instrument within the following environment conditions.
• Allowable ambient temperature: −10 to +50 °C
• Allowable ambient humidity: 5 to 95 %RH
(Absolute humidity: MAX. W. C 29.3 g/m3dry air at 101.3 kPa)
• Installation environment conditions: Indoor use, Altitude up to 2000 m
(3) Avoid the following conditions when selecting the mounting location:
• Rapid changes in ambient temperature which may cause condensation.
• Corrosive or inflammable gases.
• Direct vibration or shock to the mainframe.
• Water, oil, chemicals, vapor or steam splashes.
• Excessive dust, salt or iron particles.
• Excessive induction noise, static electricity, magnetic fields or noise.
• Direct air flow from an air conditioner.
• Exposure to direct sunlight.
• Excessive heat accumulation.
(4) If this instrument is permanently connected to equipment, it is important to include
a switch or circuit-breaker into the installation. This should be in close proximity to
the equipment and within easy reach of the operator. It should be marked as the
disconnecting device for the equipment.
 Dimensions
 Mounting Procedures
1. Prepare the panel cutout as specified in Dimensions.
2. Insert the instrument through the panel cutout.
3. Insert the mounting bracket into the mounting groove of the instrument. (Fig. 1)
4. Pull till click sounds to the direction shown by the arrow. (Fig. 2)
5. Tighten up the screw. (Fig.3)
6. The other mounting bracket should be installed the same way described in 3. to 5.
When the instrument is mounted, always secure with two mounting brackets so
that upper and lower mounting brackets are positioned diagonally.
The waterproof/dustproof option on the front of the instrument conforms to IP65
when mounted on the panel. For effective waterproof/dustproof, the gasket
must be securely placed between instrument and panel without any gap. If
gasket is damaged, please contact RKC sales office or the agent.
2. WIRING
 Wiring Cautions
• For thermocouple input, use the appropriate compensation wire.
• For RTD input, use low resistance lead wire with no difference in resistance between
the three lead wires.
• Use a special shielded cable for connection with the pressure sensor.
When using our CZ-100P or CZ-200P:
The rated output (mV/V) of pressure sensor is when the cable is at a length of 5 m.
If the cable is extended, correct the rated output using the following equation. Set the
correction value thus calculated to “Gain setting.”
For the Gain setting screen, refer to Operation Manual (IMR01N12-E).
e1: Rated output in standard-cable length 5 m (mV/V is described on the nameplate of the sensor)
e2: Rated output after extension
K: Correction factor* 1.96
×10−4/m [Non-explosionproof specification type],
1.40 ×10−4/m [Explosionproof specification type]
* When using 0.5 mm2 ×4-core shielded cable (standard-cable) or equal.
L: Extended cable length (m)
e1 =e2 (1+K L) e2 =1+K L
e1
Correction equation:
• To avoid noise induction, keep input signal wire away from instrument power line,
load lines and power lines of other electric equipment.
• If there is electrical noise in the vicinity of the instrument that could affect operation,
use a noise filter.
− Shorten the distance between the twisted power supply wire pitches to achieve
the most effective noise reduction.
 Terminal Configuration (All the terminal configuration of HA430 and HA930 is the same.)
1 OUT1 and OUT2 are not isolated from each other
except for relay or triac output.
2 Remote input is not isolated from pressure sensor input (strain gauge
input).
3 If the sensor power supply (optional) is specified, OUT3 to OUT5 cannot
be used.
4 When using our pressure sensor CZ-GP100 (with amplifier), as power
supply to the amplifier, specify the sensor power supply and use sensor
signal input terminal Nos.20 and 21.
 Specifications
Power supply voltage:
90 to 264 V AC [Power supply voltage range], 50/60 Hz (Rating: 100 to 240 V AC)
21.6 to 26.4 V AC [Power supply voltage range], 50/60 Hz (Rating: 24 V AC)
21.6 to 26.4 V DC [Power supply voltage range] (Rating: 24 V DC)
Power consumption:
HA430: 16.5 VA max. (at 100 V AC) 22.5 VA max. (at 240 V AC)
15.0 VA max. (at 24 V AC) 430 mA max. (at 24 V DC)
HA930: 17.5 VA max. (at 100 V AC) 24.0 VA max. (at 240 V AC)
16.0 VA max. (at 24 V AC) 470 mA max. (at 24 V DC)
Input 1: Pressure sensor input
Relevant sensor: Strain gauge type pressure sensor
Input 2: TC input, RTD input, Voltage input, Current input
Option input: Remote input (Not isolation type), Event input
Power supply for strain gauge type of pressure sensor:
Rated voltage (EXC): 8 V DC ±3 %
Temperature drift: 80 ppm/°C
Rated current 30 mA max.
Sensor power supply (optional): OUT3 is used
Rated voltage: 24 V DC ±5 %
Rated current: 24 mA max.
*1 Rubber
*2 If the HA430s or HA930s have waterproof/dustproof options, protection will be compromised
and not meet IP65 by close mounting.
*3 When controllers are closely mounted, ambient temperature must not exceed 50 °C.
For mounting of the HA430 or HA930, panel thickness must be between 1 to 10 mm. When
mounting multiple HA430s or HA930s close together, the panel strength should be checked t
o
ensure proper support.
To prevent electric shock or instrument failure, do not turn on the power until all the wiring is completed. Make sure that the wiring has been properly
made before applying power to the instrument.
Output 1 to 3 (OUT1 to OUT3):
Relay contact output: 250 V AC, 3A (Resistive load), 1a contact
Electrical life 300,000 times or more (Rated load)
Voltage pulse output: 0/12 V DC (Load resistance 600 Ωor more)
Current output: 0 to 20 mA DC, 4 to 20 mA DC
(Load resistance 600 Ωor less)
Voltage output: 0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC
(Load resistance 1 kΩor more)
Triac output: Rated current 0.4 A
Output 4 (OUT4), Output 5 (OUT5):
Relay contact output: 250 V AC, 1 A (Resistive load), 1a contact
Electrical life 300,000 times or more (Rated load)
Control method: Brilliant PID control
(Direct action or Reverse action is available)
A
llowable ambient temperature: −10 to +50 °C
A
llowable ambient humidity: 5 to 95 %RH
Absolute humidity: MAX. W.C 29.3 g/m
3
dry air at 101.3 kPa
Operating environment: There should be neither corrosive gases nor much dust.
Weight: HA430: Approx. 360 g HA930: Approx. 460 g
 An external protection device must be installed if failure of this instrument
could result in damage to the instrument, equipment or injury to personnel.
 All wiring must be completed before power is turned on to prevent electric
shock, fire or damage to instrument and equipment.
 This instrument must be used in accordance with the specifications to
prevent fire or damage to instrument and equipment.
 This instrument is not intended for use in locations subject to flammable or
explosive gases.
 Do not touch high-voltage connections such as power supply terminals,
etc. to avoid electric shock.
 RKC is not responsible if this instrument is repaired, modified or
disassembled by other than factory-approved personnel. Malfunction can
occur and warranty is void under these conditions.
!WARNING
CAUTION
To prevent electric shock or instrument failure, always turn off the
power before mounting or removing the instrument.
!WARNING
44.8
11.1
10.1 100
(1)
*1
91.8
110.8
48
96
25 45
+
0.6
+
0
30 +0.8
+0
92
Individual mounting
HA430
(Unit: mm)
L = 48×n－3 n: Number of units (2 to 6)
+0.8 +0
92
L
+
0.6
+
0
Close mounting *2, *3
96
96
11.1
10.1 100
(1)
*1
91.8
110.8
91.8
HA930
(Unit: mm) 92
+
0.8
+
0
25
30 +0.8
+0
92
Individual mounting
L = 96×n－4 n: Number of units (2 to 6)
+0.8 +0
92
L
+
0.8
+
0
Close mounting *2, *3
!WARNING
Mounting brackets: 2 [HA430], 4 [HA930]
Instruction Manual: 1 (IMR01N11-E4)
Accessories
Instruction
Manual
HA430/HA93
0
(9) Input
36
35
DI5
Contact
(Optional)
Remote
20
19
RS
+
−
(11) Input (Input 2) 2, 4
RTD
RTD2
B
B
A
21
20
19
TC
21
20
TC2
+
−
Voltage/Current
IN2
+
−
21
20
(2) Output 5 3
Terminal numbers 13, 22: Unused
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
1
2
3
4
5
6
7
8
9
10
11
12
(1)
(2)
(3)
(4)
(5)
(6)
(8)(7) (9)
(10)
(11)
Contact
(8) Input
(Optional)
31
30
DI2
DI1
DI3
33
32
34
DI4
(7) Communication 2 (Optional)
RS-422A
R (A)
T (A)
SG
28
26
25
R (B)
29
T (B)
27
PROFIBUS
DGND
RxD/TxD-P
VP
28
26
25
27
RxD/TxD-N
RS-232C
RD
SD
SG
27
26
25
RS-485
T/R (B)
T/R (A)
SG
27
26
25
DeviceNet
CAN-L
V+
28
26
25
V−
29
27
CAN-H
Drain
NO
OUT5
4
3
Relay contact
(3) Output 4 3
Relay contact
5
6
OUT4
NO
L
(1) Power supply
+
−
24 V
DC
2
1
N
100-240 V
A
C
2
1L
N
24 V
A
C
2
1
(4) Output 3 3, 4
Triac
OUT3
8
7
NO
OUT3
8
7
Relay contact Sensor
power supply
24 V DC
+
−
8
7
(Optional)
Voltage pulse/
Voltage/Current
OUT3
+
−
8
7
(6) Output 1 1
Voltage pulse/
Voltage/Current
OUT1
+
−
12
11
Triac
OUT1
12
11
NO
OUT1
12
11
Relay contact
(5) Output 2 1
Voltage pulse/
Voltage/Current
OUT2
+
−
10
9
NO
OUT2
10
9
Relay contact Triac
OUT2
10
9
− Always install the noise filter on a grounded panel. Minimize the wiring distance
between the noise filter output and the instrument power supply terminals to
achieve the most effective noise reduction.
− Do not connect fuses or switches to the noise filter output wiring as this will
reduce the effectiveness of the noise filter.
• About five seconds are required as preparation time for contact output every time
the instrument is turned on. Use a delay relay when the output line is used for an
external interlock circuit.
• Power supply wiring must be twisted and have a low voltage drop.
• This instrument is not furnished with a power supply switch or fuse. Therefore, if a
fuse or power supply switch is required, install close to the instrument.
Recommended fuse rating: Rated voltage 250 V, Rated current 1 A
Fuse type: Time-lag fuse
• For an instrument with 24 V power supply, supply power from a SELV circuit.
• A suitable power supply should be considered in the end-use equipment. The powe
r
supply must be in compliance with a limited-energy circuits (maximum available
current of 8 A).
• Use the solderless terminal appropriate to the screw size.
Screw size: M3×6 (With 5.8×8 square washer)
Recommended tightening torque: 0.4 N･m (4 kgf･cm)
• Make sure that the any wiring such as solderless terminal is not in contact with the
adjoining terminals.
HA930 is used in the above figures for explanation,
but the same mounting procedures also apply t
o
HA430.
Fig. 2Fig. 1
When using the mounting screws,
only turn one full revolution after
the screw touches the panel.
Fig. 3
Mounting
bracke
t
Strain gauge input
(10) Pressure sensor input (Input 1)
15
CAL
−
CAL
+
SHD (E)
16
EXC
+
(A)
EXC
−
(C)
14
17
18
SIG
+
(D)
SIG
−
(B)
24
23

3. PARTS DESCRIPTION
(1) Area display
Area (AREA) lamp [Green] Lights when memory area number is displayed.
Memory area display Displays memory area number (1 to 16).
(2) Upper display
Measured value 1 (PV1) lamp [Green] Lights when measured value 1 is displayed on the PV1/PV2
display unit.
Measured value 2 (PV2) lamp * [Green] Lights when measured value 2 is displayed on the PV1/PV2
display unit.
Manual (MAN) mode lamp [Green] Lights when operated in manual mode.
Remote (REM) mode lamp [Green] Lights when remote setting function is activated.
Autotuning (AT) lamp [Green] Flashes when autotuning is activated.
(After autotuning is completed: AT lamp will go out)
Measured value (PV1/PV2) display Displays PV1, PV2 or various parameter symbols.
* This lamp is activated only with 2-input controller.
(3) Lower display
Measured value 2 (PV2) lamp * [Green] Lights when measured value 2 is displayed on the SV display unit.
Set value (SV) lamp [Green] Lights when set value (SV) is displayed on the SV display unit.
Manual (MAN) mode lamp * [Green] Lights when operated in manual mode.
Autotuning (AT) lamp * [Green] Flashes when autotuning is activated.
(After autotuning is completed: AT lamp will become OFF)
Set value (SV) display Displays SV, PV2 or various parameter set values.
* This lamp is activated only with 2-input controller.
(4) Output/Alarm lamp
Output (OUT1 to OUT5) lamp [Green] Lights when the output corresponding to each lamp is ON.
Alarm (ALM) lamp [Red] Lights when alarm (Event function) is turned on.
The type of alarm which is on can be checked on the event
monitor display.
(5) Bar graph display *
One of the displays shown in the table below can be selected for the bar-graph.
Manipulated output value (MV)
display
Displays the manipulated output value (MV). When manipulated output
value (MV) is at 0 % or less, the left-end dot of the bar-graph flashes.
When MV exceeds 100 %, the right-end dot flashes.
Deviation display Displays the deviation between the measured value (PV) and the set
value (SV). When the Deviation display is selected, the dots at both
ends of bar-graph light.
Measured value display Displays the measured value (PV). Scaling is available within the input
range.
Set value display Displays the set value (SV). Scaling is available within the input range.
* The number of dots: 10 dots (HA430), 20 dots (HA930)
(6) Direct key
Auto/Manual transfer key Switching the Auto/Manual control mode between Auto (PI control)
mode and Manual mode.
Remote/Local transfer key Switching the Remote/Local control mode between Remote control and
Local control.
RUN/STOP transfer key Switching the RUN/STOP mode between RUN and STOP.
(7) Operation key
Set (SET) key Used for parameter calling up and set value registration.
Shift key Shift digits when settings are changed. Used to selection operation
between modes.
Down key Decrease numerals.
Up key Increase numerals.
(8) Infrared port
Used when sending and receiving data between this controller and the PDA installed with the RKCIR software.
To avoid damage to the instrument, never use a sharp object to press keys.
4. OPERATION FLOW OF EACH MODE
In order to make this instrument operable after being mounted on equipment and then wired, it needs to be set with operating conditions such as the set value (SV), input/output function, control function, etc. specific to each customer. In addition, the following
operational flowchart illustrates key operation in each mode or each setting item. When actually setting these operating conditions specific to the customer, see the HA430/HA930 Operation Manual (IMR01N12-E).
(2)
(3)
(1)
(4)
(5)
(6)
(8)
HA430
OUT1 OUT2 OUT3 OUT4 OUT5 ALM
A
RE
A
PV2 MAN REM
AT
S
V
PV1 PV2 MAN REM
AT
MODE
SET
A/M R/L R/S
(7)
(2)
(1)
(8)
(3)
(4)
(5)
(7)
HA930
AREA PV2 MAN REM ATSV
PV1 PV2 MAN REM
A
T
SE
T
MODE
OUT1 OUT2 OUT3 OUT4 OUT5 ALM
A
/M R/L R/S (6)
A
/M
SE
T
MODE
R/L
R/S
[Example] 0 50
100
−0 +
[Example]
Power ON Input type/Input range Display
Press the
shift key while
pressing the
SET key
Engineering Mode
In this mode, it is possible to set operating conditions such as the input/output
function, control function, etc. specific to each customer. For details, HA430/HA930
Operation Manual (IMR01N12-E).
Press the shift key while pressing the SET key
Return to PV1/SV1 monitor of SV setting & Monitor mode
Press the shift key for 1 second
Press the shift key while
pressing the SET key
Press the shift key whil
e
pressing the SET key fo
r
2 seconds
The first edition: AUG. 2003 [IMQ00]
The fourth edition: SEP. 2008 [IMQ00]
HEADQUARTERS: 16-6, KUGAHARA 5-CHOME, OHTA-KU TOKYO 146-8515 JAPAN
PHONE: [phone] ([phone])
E-mail: [email protected]
FAX: [phone] ([phone]) SEP. 2008
®
RKC INSTRUMENT INC.
Turn off the power at once. If an error occurs
after the power is turned on again, please
contact RKC sales office or the agent.
A
/D conversion error
EEPROM error
A
djusted data erro
r
Upper display
RAM check error
Watchdog timer error
Hardware configuration error
Software configuration error
Program busy
Lower display
Overscale
Underscale
Input error
Displays when the measured value (PV)
exceeds the input error determination poin
t
(high or low limit) or display range limi
t
(−19999 to +99999). Check the sensor o
r
input lead.
*Input error determination point (high limit):
Input scale high +(5 %of input span)
Input error determination point (low limit):
In
p
ut scale low
−
(
5
%
of in
p
ut s
p
an
)
Measured
value (PV)
[Flashing]
[Flashing]
[Flashing]
Description Solution
Display of self-diagnostic error and overscale/underscale
Operation of various functions
• For the operation of various functions, see the HA430/HA930 Operation Manual (IMR01N12-E).
• For the communication function, see the following manuals.
HA430/HA930 Communication Instruction Manual [RKC communication/Modbus]
(IMR01N13-E)
HA430/HA930 Communication Instruction Manual [PROFIBUS] (IMR01N14-E)
HA430/HA930 Communication Instruction Manual [DeviceNet] (IMR01N15-E)
This instrument returns to the PV1/SV1 monitor screen if no key operation is performed fo
r
more than 1 minute.
Parameters which are not related to existing functions on the controller are not displayed.
(Except engineering mode)
If two or more errors occur simultaneously, the error code numbers are totaled and displayed
as one number.
Modbus is a registered trademark of Schneider Electric.
DeviceNet is a registered trademark of Open DeviceNet Vender Association, Inc.
Company names and product names used in this manual are the trademarks or registered trademarks of the respective companies.
Press the SET key for 2 seconds Press the shift key while pressing the SET key
Press the SET key for 2 seconds
Parameter Setting Mode
In this mode, it is possible to set parameters relating to control such as PID constants, event set values, etc. Up to
16 individual sets of SVs and parameters in Parameter Setting Mode can be stored and used in Multi-memory Area
function.
: Parameters related to
multi-memory area function
Event 1 set value
LBA1 time
LBA1 deadband
Input 1_proportional
band for PI/PID
control
Input 1_integral time
for PI/PID control
Input 1_derivative
t
ime for PID control
Input 1_control
response parameter
Return to first parameter setting
item of parameter setting mode
Event 2 set value
Event 3 set value
LBA2 time
LBA2 deadband
Event 4 set value
Input 2_control
response parameter
Input 1_setting change
rate limiter (up)
Input 1_setting change
rate limiter (down)
Input 2_setting change
rate limiter (up)
Input 2_setting change
rate limiter (down)
A
rea soak time
Link area number
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
Input 2_proportional
band for PI/PID
control
Input 2_integral time
for PI/PID control
Input 2_derivative
time for PID control
SV Setting & Monitor Mode
In this mode, it is possible to set SV which is the desired value for control and also to monitor PV, SV, MV, etc.
PV1/SV1 monitor 1, 2
PV2/SV2 monitor 3
PV1/PV2 monitor
SET key
Input 1_SV setting
Input 2_SV setting
PV1 peak hold
value monitor Input 2_MV monitor
Event monitor
Memory area
selection
Return to PV1/SV1 monitor
Memory area soak
time monitor
SET key
SET key
SET key
SET key
PV1 value
SV1 value
SET key
SET key
SET key
SET key
SET key
SET key
Remote input value
monitor
PV1 bottom hold
value monitor
SET key
PV1 hold reset
PV2 peak hold
value monitor
SET key
SET key
PV2 bottom hold
value monitor
SET key
PV2 hold reset
PV2 value
SV2 value
PV1 value
PV2 value
SET key
Interlock release
SET key
SET key
Input 1_MV monitor
: Parameters related to
multi-memory area function
1 Remote input: Displays the remote set value.
2 Manual operation: Manipulated output value (MV1) of Input 1 can be set.
In the monitoring status, MV scaling value is displayed on the SV display.
3 Manual operation: Manipulated output value (MV2) of Input 2 can be set.
*Relevant sensor:
Our CZ-GP100 (without amplifier), or
the other strain gauge type sensors
Setup Setting Mode
Input 2_digital filter
Input 2_PV ratio
Input 2_proportional
cycle time
Data bit configuration
Set lock level
Interval time
Return to first parameter setting
item of setup setting mode
In this mode, it is possible to set setting items not corresponding to the memory area, setting lock levels, etc.
SET key
SET key
Device address
(Slave address)
Communication
speed
Input 2_PV low input
cut-off
Input 1_digital filter
Input 1_PV ratio
Input 1_PV bias
Input 2_PV bias
Input 1_proportional
cycle time
Input 1_PV low input
cut-off
SET key SET key
Infrared communication
address
Infrared communication
speed
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
SET key
A
uto-zero
(Pressure sensor)
A
uto calibration
(Pressure sensor)*
Operation Mode
Input 1_PID/AT transfer *
Input 2_PID/AT transfer *
Input 1_Auto/Manual
transfer
Remote/Local transfer
RUN/STOP transfer
Return to Input 1_PID/AT transfer
In this mode, it is possible to selects the operation modes of the instrument.
SET key or Shift key
SET key or Shift key
SET key or Shift key
SET key or Shift key
SET key or Shift key
SET key or Shift key
Input 2_Auto/Manual
transfer
* Factory shipment: No transfer from PID to AT can be made (PID only)
