RKI Instruments GX-2009 User manual

www.rkiinstruments.com
RKI Instruments, Inc. •33248 Central Ave. Union City, CA 94587 •Phone (800) 754-5165 •(510) 441-5656 •Fax (510) 441-5650
Confirm CAL C--LIMIT
If the LCD display reads CAL C--LIMIT,
press the Power/Mode button on the gas
monitor to continue to TRANSMIT.
If CAL C--LIMIT is not displayed continue to
the next step.
Calibration Results
Once calibration is complete, the display either shows a “P” for pass or an “F” for fail for each
sensor. The display will alternate between the gas concentration and the letter “P” when the
monitor passes calibration. The “CAL” LED lights in green when calibration is passed. “CAL”
LED lights in red if there is a failure.
Instrument Connected
Once on, the display will show gas channels
and a transmit message. The gas monitor is
ready for a Bump Test or Calibration.
Bump Test
Press the “Bump” button to start bump test.
Note: Ensure calibration gas cylinder is connected
to a demand flow regulator and then to the back
of the cal station. Make sure calibration gas
concentrations match values shown on display.
Bump Gas Reading
During Bump test, the display
shows current gas reading.
Bump Results
The BUMP LED will stop blinking and be on
steadily green if the bump test passed or
steadily red if the bump test failed. Display
will show “P” for pass or “F” for fail for each
sensor. The display will alternate between
the gas concentration and the letter “P”
when the monitor passes bump test.
Return to Transmit Screen
Press the “EDIT/ENTER” button.
See step “E” below for turning off
instrument after completion of
bump test.
Calibrate
Press the “CAL” button to start calibration.
Note: Ensure calibration gas cylinder is connected
to a demand flow regulator and then to the back
of the cal station. Make sure calibration gas
concentrations match values shown on display.
Removing from SDM-2009U
After a successful bump test or calibration,
the GX-2009 will automatically turn off within
15 seconds. To turn off manually, press
the SDM-2009 “Edit Enter” and “Power”
buttons simultaneously.
Warning: Do not remove the GX-2009
before turning it off, and do not use the
GX-2009’s power button to power it down.
Turn Cal Station On
1. Press the “POWER” button on the cal
station.
2. Seat the GX-2009 into the cal station.
Then turn on the GX-2009 by pressing
the “POWER/MODE” button on the gas
monitor.
Calibration Gas Readings
During calibration, the display shows
current gas readings. Typical calibration
will take 3 minutes.
A
B C
B
D
C
AE
BUMP TEST
CALIBRATION
DATA TRANSFER
TURN ON
C
A B
A
D
Data Transfer To USB Flash Drive
With USB flash drive installed and unit powered on,
press and release the COPY button. The COPY LED will
become solid red while the records in the calibration
station’s memory are copied to the flash drive. In
addition, the flash drive’s LED will begin to blink.
When the LED stops blinking, the copy operation is
complete. Remove the flash drive from the USB port.
Transfer data to PC with Calibration Station software,
following the instructions in the Operator’s Manual.
GX-2009 Calibration Station
User Guide
Model SDM-2009U
PN 71-0264RK
