RKI Instruments 65-2391RK User manual

65-2391RK
CO2Transmitter
Operator’s Manual
Part Number: 71-0121RK
Revision: B
Released: 7/18/14
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter
WARNING
Read and understand this instruction manual before
operating transmitter. Improper use of the transmitter could
result in bodily harm or death.
Periodic calibration and maintenance of the transmitter is
essential for proper operation and correct readings. Please
calibrate and maintain this transmitter regularly! Frequency
of calibration depends upon the type of use you have and
the sensor types. Typical calibration frequencies for most
applications are between 6 and 12 months, but can be
required more often or less often based on your usage.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter
Product Warranty
RKI Instruments, Inc., warrants gas alarm equipment sold by us to be free from defects in
materials, workmanship, and performance for a period of one year from date of shipment
from RKI Instruments, Inc. Any parts found defective within that period will be repaired
or replaced, at our option, free of charge. This warranty does not apply to those items
which by their nature are subject to deterioration or consumption in normal service, and
which must be cleaned, repaired, or replaced on a routine basis. Examples of such items
are:
Warranty is voided by abuse including mechanical damage, alteration, rough handling, or
repair procedures not in accordance with the operator’s manual. This warranty indicates
the full extent of our liability, and we are not responsible for removal or replacement costs,
local repair costs, transportation costs, or contingent expenses incurred without our prior
approval.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER
WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED,
AND ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF
RKI INSTRUMENTS, INC. INCLUDING BUT NOT LIMITED TO, THE
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL RKI INSTRUMENTS,
INC. BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
LOSS OR DAMAGE OF ANY KIND CONNECTED WITH THE USE OF
ITS PRODUCTS OR FAILURE OF ITS PRODUCTS TO FUNCTION OR
OPERATE PROPERLY.
This warranty covers instruments and parts sold to users by authorized distributors,
dealers, and representatives as appointed by RKI Instruments, Inc.
We do not assume indemnification for any accident or damage caused by the operation of
this gas monitor, and our warranty is limited to the replacement of parts or our complete
goods.
a) Absorbent cartridges d) Batteries
b) Pump diaphragms and valves e) Filter elements
c) Fuses
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IR CO2Detector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Junction Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting the CO2Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Wiring the CO2Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Introducing Incoming Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting the Zero Signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacing Components of the CO2Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Preparing for Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting the Zero Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the Response Reading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Returning to Normal Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 1
Overview
This manual describes the 65-2391RK CO2transmitter. This manual also describes how to
install, start up, configure, maintain, and calibrate the transmitter when it is used with a
gas monitoring controller. A parts list at the end of this manual lists replacement parts and
accessories for the CO2 transmitter.
Specifications
Table 1 lists specifications for the CO2transmitter.
WARNING: When using the 65-2391RK, you must follow the instructions and warnings
in this manual to assure proper and safe operation of the 65-2391RK and to
minimize the risk of personal injury. Be sure to maintain and periodically
calibrate the 65-2391RK as described in this manual.
Table 1:Specifications
Target/Calibration Gas Carbon Dioxide (CO2)
Area Classification Explosionproof for Class I, Groups B, C, and D
Sampling Method Diffusion
Signal Output 4 to 20 mA
Detection Range 65-2391RK-02: 0 - 5,000 ppm
65-2391RK-03: 0 - 5% Volume
65-2391RK-05: 0 - 50% Volume
65-2391RK-10: 0 - 100% Volume
Response Time 90% in 45 seconds
Accuracy ± 5% of reading or ± 2% of full scale (whichever is greater)
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

2 • 65-2391RK CO2Transmitter
Description
This section describes the components of the CO2transmitter. The transmitter is a 4 - 20
mA type detector head. It consists of the infrared CO2detector, amplifier, and junction
box.
Figure 1: CO2Transmitter Component Location
Infrared CO2Detector
The infrared CO2 detector is made up of a miniature infrared CO2detector housed and
encapsulated in a pipe nipple. The pipe nipple has 3/4 inch NPT threads on each end and
a 1 1/4 inch hex that allows removal or installation of the detector with a wrench. A
porous flame arrestor that is coated with a hydrophobic film that repels liquids is on one
end of the detector and allows sample gas to enter the detector. Four color coded leads,
red, white, green, and black, extend from the other end of the detector. The leads allow
you to connect the detector to the amplifier.
To distinguish the different ranges of CO2detectors from one another, a short length of
shrink tubing is applied to the wiring where it comes out of the nipple. The following
table indicates the color of the shrink tubing and the color of the wire to which it is
applied.
GND
24V
4-20
RED
WHT
GRN
BLK
SENSOR POWER/SIG
TP+
TP-
Amplifier
Interconnec
t
terminal str
ip
Test point (-)
S
ecuring screw (2)
Test point (+)
Zero potentiometer
Span potentiometer
Potentiometer
(factory set)
Potentiometer
(factory set)
Jumper pins
(factory use only)
IR CO Detector
2
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 3
Amplifier
The amplifier converts the electrical output from the detector to a 4 to 20 mA signal that
corresponds to the detection range and transmits the signal to a gas monitoring controller.
The amplifier includes the interconnect terminal strip, span potentiometer, zero
potentiometer, and test points (see Figure 1).
Interconnect Terminal Strip
The interconnect terminal strip is a seven-point terminal strip. Use the interconnect
terminal strip to connect the IR CO2detector to the amplifier and the amplifier to a
controller.
NOTE: The IR CO2 detector is factory-wired to the amplifier. See the Installation section
of this manual for all wiring procedures related to the transmitter.
Span Potentiometer
The span potentiometer is near the bottom of the amplifier (see Figure 1). Use the span
potentiometer to adjust the transmitter’s response output during the calibration
procedure. Turn the adjustment screw clockwise to increase the gas response and
counterclockwise to decrease the gas response.
Zero Potentiometer
The zero potentiometer is to the right of the span potentiometer (see Figure 1). Use the
zero potentiometer to adjust the transmitter’s target gas-free output during the start-up
and calibration procedures. Turn the adjustment screw clockwise to increase the zero
output and counterclockwise to decrease the zero output.
CAUTION: The amplifier includes two additional potentiometers. They are factory-set. Do not
adjust them.
Test Points
The test points (labeled TP+ and TP-) are to the left of the interconnect terminal strip
(see Figure 1). The test points produce a 100 to 500 mV output that corresponds to the
transmitter’s 4 to 20 mA output. Use the test points and a voltmeter to measure the
transmitter’s output during the start-up and calibration procedures.
Table 2: CO2Detector Color Designations
Detector Color Designations
0 - 5,000 ppm black shrink tubing on white wire
0 - 5% volume green shrink tubing on white wire
0 - 50% volume green shrink tubing on red wire
0 - 100% volume red shrink tubing on green wire
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

4 • 65-2391RK CO2Transmitter
Junction Box
Use the junction box to install the CO2transmitter at a mounting site that is remote from
the controller. The junction box also protects the amplifier and wiring connections made
to the amplifier. Use the two 3/4 in. conduit hubs to mount the detector to the junction
box (bottom hub) and connect wiring from the amplifier to the controller (top hub).
NOTE: The detector and amplifier are factory-mounted to the junction box.
Use the junction box’s two mounting holes to mount the CO2transmitter to a vertical
surface at the monitoring site. Use the cover on the front of the junction box to access the
interior of the junction box.
Installation
This section describes procedures to mount the CO2transmitter in the monitoring
environment and wire the transmitter to a controller.
Mounting the CO2 Transmitter
1. Select a mounting site that is representative of the monitoring environment. Consider
the following when you select the mounting site.
• Select a site where the transmitter is not likely to be bumped or disturbed.
• Select a site where there is sufficient room to perform start-up, maintenance, and
calibration procedures.
• Mount the transmitter at least six feet from the floor to minimize the possibility of
someone breathing on the unit. The exhaled CO2may cause an alarm.
Figure 2: Mounting the CO2Transmitter
3.94
6.10
1
.10
.25 Dia. Mountin
g
Hole, 2X
3/4 NPT Condu
it
Hu
b
7.3 Max
2.75
5.20
3/4 NPT For
Calibration Cup
1.9
Max
5.46
NOTE: All Dimensions in Inches
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 5
If the detector is mounted to the junction box, skip to step 5. If not, continue with step 2.
2. Remove the junction box cover.
3. Guide the four wires that extend from the top of the detector through the bottom
conduit hub of the junction box.
4. Screw the detector into the bottom conduit hub of the junction box.
5. At the monitoring site, use #10 screws through the junction box’s two mounting holes
to secure the junction box to a vertical surface.
CAUTION: Mount the CO2transmitter with the detector facing down (see Figure 2.)
Wiring the CO2Transmitter to a Controller
WARNING: Always verify that the power to the controller is off before you make
wiring connections.
1. Turn off power to the controller.
2. Place the controller’s power switch in the OFF position.
3. Remove the junction box cover.
4. Verify that the detector leads are wired to the amplifier’s interconnect terminal strip.
If necessary, connect the detector leads to the interconnect terminal strip as shown in
Figure 3.
5. Guide a three-conductor, shielded cable or three wires in conduit through the top
conduit hub of the junction box.
6. Connect the three wires to the interconnect terminal strip as follows (see Figure 3).
• Connect the positive wire to the 24VDC terminal.
• Connect the feedback wire to the 4-20 (FB) terminal.
• Connect the negative wire to the GND (DC -) terminal.
CAUTION: If shielded cable is used, leave the cable shield’s drain wire insulated and
disconnected at the transmitter. You will connect the opposite end of the cable’s drain
wire at the controller to chassis ground.
7. Secure the junction box cover to the junction box.
8. Route the cable or wires leading from the CO2 transmitter through one of the conduit
hubs at the controller housing.
CAUTION: Do not route power and transmitter wiring through the same conduit hub. The
power cable may disrupt the transmission of the transmitter signal to the
controller.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

6 • 65-2391RK CO2Transmitter
9. Connect the wires to the applicable transmitter terminal strip at the controller as
shown in Figure 3 below.
Figure 3: Wiring the CO2Transmitter to a Controller
10. If shielded cable is used, connect the cable’s drain wire to an available chassis ground
at the controller.
Start Up
This section describes procedures to start up the CO2transmitter and place the transmitter
into normal operation.
Introducing Incoming Power
1. Complete the installation procedures described earlier in this manual.
2. Verify that the power wiring to the controller is correct and secure. Refer to the
controller operator’s manual.
3. Turn on or plug in power to the controller, then place the controller’s power switch in
the ON position.
4. Verify that the controller is on and operating properly. Refer to the controller
operator’s manual.
GND
24V
4-20
RED
WHT
GRN
BLK
SENSOR POWER/SIG
TP+
TP-
Black
Green White Red
Controller Transmitte
r
Terminals,Typical
- (DC -)
+ 24 VDC
4 - 20 mA In (FB or S
)
Cable Shield
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 7
NOTE: When first powered up, the transmitter will enter about a one minute period
when the 4-20 mA output is stabilizing and may be above the controller alarm
points or well below zero momentarily. RKI controllers have a one minute
warmup period when the controller does not display any gas reading or give any
alarm indication. The CO2transmitter’s 4-20 mA signal should be stable by the
time the controller’s warmup period is over.
CAUTION: Allow the detector to warm up for 5 minutes before you continue with the next
section, “Setting the Zero Signal”.
Setting the Zero Signal
Since there is a background of CO2in air of typically 300 - 600 ppm (0.03 - 0.06 %volume),
it is necessary to use a calibration kit with a 100% nitrogen cylinder to set the zero signal of
a CO2transmitter with a low range detector. Fresh air can be used to zero the transmitter
if a 0-50 %volume or 0-100 %volume detector is being used.
NOTE: The following procedure assumes the use of a calibration kit which includes a
100% nitrogen calibration gas cylinder, a 0.5 LPM fixed flow regulator with an
on/off knob, a calibration cup for the detector, and a short piece of sample tubing
to connect the regulator to the calibration cup.
1. Place the controller into its calibration program or disable external alarms to avoid
accidental alarms during the zero setting procedure.
2. Screw the calibration cup onto the bottom of the detector.
3. Use the sample tubing that comes with the calibration kit to connect the regulator to
the calibration cup.
4. Set a voltmeter to measure in the millivolt (mV) range.
5. Remove the junction box cover, then plug the voltmeter leads into the test points on
the amplifier.
Plug the positive lead into the test point labeled TP+; plug the negative lead into the
test point labeled TP-.
6. Screw the regulator into the 100% nitrogen calibration cylinder.
7. Turn the regulator knob counterclockwise to open the regulator.
8. Allow the gas to flow for one minute and verify a reading of 100 mV (±2 mV). If
necessary, use the zero potentiometer on the amplifier to adjust the reading to 100 mV
(±2 mV).
9. Turn the regulator knob clockwise to close the regulator.
10. Unscrew the regulator from the 100% nitrogen calibration cylinder.
11. Unscrew the calibration cup from the detector.
12. Reinstall the junction box cover.
13. Return the controller to normal operation or enable external alarms.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

8 • 65-2391RK CO2Transmitter
Maintenance
This section describes maintenance procedures. It includes preventive maintenance,
troubleshooting, and component replacement procedures.
Preventive Maintenance
This section describes a preventive maintenance schedule to ensure the optimum
performance of the CO2 transmitter. It includes daily, monthly, and biannual procedures.
Daily
Verify a display reading at the controller of the background concentration of CO2. Typical
background concentrations of CO2vary from about 300 to 600 ppm (0.03 to 0.06 %volume)
depending on location. The 0-5,000 ppm and 0-5 %volume detectors will displaya reading
in a fresh air environment because they have low ranges. The 0-50 %volume and 0-100%
volume detectors will not display a reading in fresh air because their ranges are too large.
Investigate significant changes in the display reading.
Monthly
This procedure describes a test to verify that the CO2transmitter responds properly to the
target gas.
WARNING: The controller is not an active gas monitoring device during the response
test procedure.
NOTE: Performing a response test on the CO2transmitter may cause alarms. Be sure to
put the controller into its calibration program or disable external alarms before
performing this test.
NOTE: The following procedure assumes the use of a calibration kit which includes a
calibration gas cylinder, a 0.5 LPM fixed flow regulator with an on/off knob, a
calibration cup for the detector, and a short piece of sample tubing to connect the
regulator to the calibration cup.
Preparing for the response test
1. Place the controller into its calibration program or disable external alarms.
2. Verify that the controller display reading for the channel you are testing is consistent
with typical background levels of CO2.
If the display reading is not consistent with typical background levels of CO2, set the
zero reading of the transmitter as described in “Start Up” on page 6 of this manual,
then continue this procedure.
3. Screw the calibration cup onto the bottom of the detector.
4. Use the calibration kit sample tubing to connect the regulator to the calibration cup.
5. Set a voltmeter to measure in the millivolt (mV) range.
6. Remove the junction box cover, then plug the voltmeter leads into the test points on
the amplifier.
Plug the positive lead into the test point labeled TP+; plug the negative lead into the
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 9
test point labeled TP-.
7. Use the following formula to determine the correct test points output for the test
sample.
Output (mV) = (calibrating sample/fullscale) X 400 + 100
For example, with a test sample of 2.5% CO2and a fullscale setting of 5% CO2, the
correct output is 300 mV.
300 (mV) = (2.5/5) X 400 +100
Performing the response test
1. Screw the regulator into the calibration cylinder.
2. Turn the regulator knob counterclockwise to open the regulator.
3. Allow the gas to flow for one minute.
4. Verify that the reading is within ± 20% of the response reading you determined earlier.
NOTE: If the reading is not within ± 20% of the correct response reading, calibrate the
transmitter as described in “Calibration” on page 13 of this manual.
5. Turn the regulator knob clockwise to close the regulator.
6. Unscrew the regulator from the calibration cylinder.
7. Unscrew the calibration cup from the detector.
8. Remove the voltmeter leads from the amplifier test points.
9. Reinstall the junction box cover.
10. When the controller display reading falls below the alarm setpoints, return the
controller to normal operation.
11. Store the components of the calibration kit in a safe place.
Biannually
Calibrate the CO2transmitter as described in “Calibration” on page 13 of this manual.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

10 • 65-2391RK CO2Transmitter
Troubleshooting
The troubleshooting guide describes symptoms, probable causes, and recommended
action for problems you may encounter with the CO2transmitter.
NOTE: This troubleshooting guide describes transmitter problems only. See the
controller operator’s manual for problems you may encounter with the
controller.
Table 3:Troubleshooting the CO2Transmitter
Condition Symptom(s) Probable Causes Recommended Action
Fail Condition • Controller indicates a
fail condition. • The transmitter wiring is disconnected or
misconnected.
• The transmitter’s
reading in air is low
enough to cause a fail
condition.
• The transmitter is
malfunctioning.
1. Verify that the transmitter wiring is
correct and secure.
2. Calibrate the transmitter.
3. If the fail condition continues, replace
the detector.
4. If the fail condition continues, contact
RKI for further instruction.
Slow or No
Response/
Difficult or
Unable to
Calibrate
• Transmitterresponds
slowly or does not
respond to response
test.
• Unable to accurately
set the zero or
response reading
during calibration.
• Transmitter requires
frequent calibration.
Note: Under “normal”
circumstances, the
transmitter requires
calibration once every
six months.
Some applications
may require a more
frequent calibration
schedule.
• Thecalibrationcylinder
is low, out-dated, or
defective.
• The transmitter is
malfunctioning.
1. Verify that the calibration cylinder
contains an adequate supply of a
fresh test sample.
2. Verify that the regulator used for
calibration is a 0.5 LPM regulator.
3. If the calibration/response difficulties
continue, replace the detector.
4. If the calibration/response difficulties
continue, contact RKI for further
instruction.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 11
Replacing Components of the CO2Transmitter
This section includes procedures to replace the IR CO2detector and amplifier.
Replacing the IR CO2Detector
1. Turn off power to the controller.
2. Place the controller’s power switch in the OFF position.
3. Remove the junction box cover.
4. Disconnect the detector leads from the interconnect terminal strip. Note the position
of the color-coded leads as you remove them.
5. Unscrew the detector from the junction box.
6. Guide the detector leads of the replacement detector through the bottom conduit hub
of the junction box, then screw the mounting threads of the detector into the conduit
hub.
7. Connect the detector leads to the interconnect terminal strip as shown in Table 4
below and Figure 3 on page 6 of this manual.
8. Turn on power to the controller.
9. Place the controller’s power switch in the ON position.
NOTE: When first powered up, the transmitter will enter about a one minute period
when the 4-20 mA output is stabilizing and may be above the controller alarm
points or well below zero momentarily. RKI controllers have a one minute
warmup period when the controller does not display any gas reading or give any
alarm indication. The CO2transmitter’s 4-20 mA signal should be stable by the
time the controller’s warmup period is over.
CAUTION: Allow the replacement detector to warm up for 5 minutes before you continue with
the next step.
10. Calibrate the replacement detector as described in “Calibration” on page 13 of this
manual.
Replacing the Amplifier
1. Turn off power to the controller
2. Place the controller’s power switch in the OFF position.
Table 4: Reconnecting the CO2
Detector to the Amplifier
Detector Lead Amplifier Interconnect
Terminal Strip
Red RED
White WHT
Green GRN
Black BLK
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

12 • 65-2391RK CO2Transmitter
3. Remove the junction box cover.
4. Disconnect the detector leads from the interconnect terminal strip.
5. Disconnect the wiring that connects the CO2transmitter to the controller from the
amplifier’s interconnect terminal strip.
6. Unscrew and remove the two screws that secure the amplifier to the junction box.
The screws are at the top left and bottom right of the amplifier.
7. Remove the amplifier.
8. Place the new amplifier in the same position as the amplifier you removed in the
previous step.
9. Use the two screws you removed in step 6 to secure the amplifier to the junction box.
10. Reconnect the wiring that connects the controller to the CO2transmitter at the
amplifier’s interconnect terminal strip as shown in Table 5 below and Figure 3 on
page 6 of this manual.
11. Reconnect the detector leads to the amplifier’s interconnect terminal strip as shown in
Table 6 below and Figure 3 on page 6 of this manual.
12. Turn on power to the controller.
13. Turn on the controller and place it into normal operation.
Table 5: Reconnecting the CO2Amplifier
to the Controller
Amplifier Interconnect
Terminal Strip
Controller
Transmitter Terminal
Strip (typical)
GND - (DC -)
4-20 4 - 20 mA (FB or S)
24V + 24V
Table 6: Reconnecting the CO2
Detector to the Amplifier
Detector Lead Amplifier Interconnect
Terminal Strip
Red RED
White WHT
Green GRN
Black BLK
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 13
NOTE: When first powered up, the transmitter will enter about a one minute period
when the 4-20 mA output is stabilizing and may be above the controller alarm
points or well below zero momentarily. RKI controllers have a one minute
warmup period when the controller does not display any gas reading or give any
alarm indication. The CO2transmitter’s 4-20 mA signal should be stable by the
time the controller’s warmup period is over.
CAUTION: Allow the detector to warm up for 5 minutes before you continue with the next step.
14. Calibrate the CO2transmitter as described in “Calibration” on page 13 of this manual.
Calibration Frequency
Although there is no particular calibration frequency that is correct for all applications, a
calibration frequency of every 6 months is adequate for most infrared CO2transmitter
applications. Unless experience in a particular application dictates otherwise, RKI
Instruments, Inc. recommends a calibration frequency of every 6 months for the infrared
CO2transmitter.
If an application is not very demanding, for example detection in a clean, temperature
controlled environment where calibration adjustments are minimal at calibration, then a
calibration frequency of every 9 to 12 months is adequate.
If an application is very demanding, for example if the environment is not well controlled,
then more frequent calibration than every 6 months may be necessary.
Calibration
This section describes how to calibrate the CO2transmitter. It includes procedures to
prepare for calibration, set the zero reading, set the response reading, and return to
normal operation.
WARNING: The controller is not an active gas monitoring device during the calibration
procedure.
NOTE: The following procedure assumes the use of a calibration kit which includes a
CO2 calibration gas cylinder, a 100% nitrogen cylinder, a 0.5 LPM fixed flow
regulator with an on/off knob, a calibration cup for the detector, and a short
piece of sample tubing to connect the regulator to the calibration cup.
Preparing for Calibration
1. Screw the calibration cup onto the bottom of the CO2detector.
2. Use the sample tubing that comes with the calibration kit to connect the regulator to
the calibration cup.
3. Set a voltmeter to measure in the millivolt (mV) range.
4. Remove the junction box cover, then plug the voltmeter leads into the test points on
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

14 • 65-2391RK CO2Transmitter
the amplifier.
Plug the positive lead into the test point labeled TP+; plug the negative lead into the
test point labeled TP-.
5. Use the following formula to determine the correct test points output for the
calibrating sample.
Output (mV) = (calibrating sample/fullscale) X 400 + 100
For example, with a calibrating sample of 2.5% CO2and a fullscale setting of
5% CO2, the correct output is 300 mV.
300 (mV) = (2.5/5) X 400 +100
6. Place the controller into its calibration program or disable external alarms.
NOTE: Calibrating the CO2transmitter may cause alarms. Be sure to put the controller
into its calibration program or disable external alarms before continuing.
Setting the Zero Reading
Since there is a background of CO2in air of typically 300 - 600 ppm (0.03 - 0.06 %volume),
it is necessary to use a calibration kit with a 100% nitrogen cylinder to set the zero signal of
a CO2transmitter with a low range detector. Fresh air can be used to zero the transmitter
if a 0-50 %volume or 0-100 %volume detector is being used.
1. Screw the regulator into the 100% nitrogen cylinder.
2. Turn the regulator knob counterclockwise to open the regulator.
3. Allow the gas to flow for one minute and verify a reading of 100 mV (±2 mV). If
necessary, use the zero potentiometer on the amplifier to adjust the reading to 100 mV
(±2 mV).
4. Turn the regulator knob clockwise to close the regulator.
5. Unscrew the regulator from the 100% nitrogen cylinder. Leave the sample tubing
connected to the regulator and the calibration cup.
Setting the Response Reading
1. Screw the regulator into the calibration cylinder. Verify that the calibration gas is
representative of the transmitter’s target gas.
2. Turn the regulator knob counterclockwise to open the regulator.
3. Allow the calibration gas to flow for one minute and verify that the reading matches
the response reading (±2 mV) you determined earlier. If necessary, use the span
potentiometer on the amplifier to adjust the reading to match the correct response
reading.
4. Turn the regulator knob clockwise to close the regulator.
5. Unscrew the regulator from the calibration cylinder.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

65-2391RK CO2Transmitter • 15
Returning to Normal Operation
1. Remove the voltmeter leads from the amplifier test points.
2. Unscrew the calibration cup from the detector.
NOTE: For convenience, leave the regulator and calibration cup connected by the
sample tubing.
3. Secure the junction box cover to the junction box.
4. When the display reading falls below the alarm setpoints, return the controller to
normal operation.
5. Verify that the controller display reading decreases and stabilizes at a typical
background CO2level. The 0-5,000 ppm and 0-5 %volume detectors will display a
reading in a fresh air environment because they have low ranges. The 0-50 %volume
and 0-100 %volume detectors will not display a reading in fresh air because their
ranges are too large.
6. Store the components of the calibration kit in a safe and convenient place.
Parts List
Table 7 lists replacement parts and accessories for the CO2transmitter.
Table 7:Parts List
Part Number Description
06-1248RK Sample tubing (3/16 in. x 5/16 in.; specify length when ordering)
18-0405RK-01 Junction box (without cover; pre-drilled for amplifier)
18-0406RK Junction box cover (cover only)
57-1050RK Amplifier (specify detector part number when ordering)
61-0191RK-02 Infrared CO2detector, 0 - 5,000 ppm
61-0191RK-03 Infrared CO2detector, 0 - 5% Volume
61-0191RK-05 Infrared CO2detector, 0 - 50% Volume
61-0191RK-10 Infrared CO2detector, 0 - 100% Volume
65-2391RK-02 CO2transmitter, 0 - 5,000 ppm (includes detector, junction box, and amplifier)
65-2391RK-03 CO2transmitter, 0 - 5% Volume (includes detector, junction box, and amplifier)
65-2391RK-05 CO2transmitter, 0 - 50% Volume (includes detector, junction box, and amplifier)
65-2391RK-10 CO2transmitter, 0 - 100% Volume (includes detector, junction box, and amplifier)
71-0121RK 65-2391RK CO2 Transmitter Operator’s Manual (this document)
81-0070RK-01 Steel calibration cylinder, 2,000 ppm CO2, 34-liter
81-0072RK-01 Steel calibration cylinder, 2.5% CO2, 34-liter
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

16 • 65-2391RK CO2Transmitter
81-0073RK-01 Steel calibration cylinder, 15% CO2, 34-liter
81-0076RK-01 Zero air calibration cylinder (34-liter)
81-1050RK Regulator, 0.5 liter/minute, with gauge and knob, for 17- and 34-liter calibration
cylinders
81-1103RK Calibration cup
82-0006RK Pot adjust screwdriver, for calibration
Table 7:Parts List
Part Number Description
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30
