RKS MT8 User manual

MT8
USER MANUAL
www.rksmotor.eu

01
PREFACE
Dear Users;
Our company makes RKS brand electric scooter become a kind of environmental protection type leisure traffic tool
instead of walk with elegant, beautiful shape and modern luxurious feeling by virtue of novel management model,
abundant technical force, perfect quality system, first-class workmanship equipments and an excellent
professional team of technology.
This scooter has safe and reasonable structure and design, adopts high-efficient and superior-performance electric
hub, high-energy seal type free of maintenance jelly battery and front fork shock-preventing device to improve the
comfort of riding. It has three kinds of functions for riding including electric driving, pedal driving as well as both
electric and pedal driving. It is a kind of ideal traffic tool instead of walk.
In order that this scooter can offer better services for you, please read carefully this user's manual before use,
please make sure to follow the requirements of this user's manual in order to make your electric scooter in the best
status and make you to travel more safely, comfortably and successfully.
This product is designed for transportation and is environmental friendly. Below are the characteristics and
advantages of this electric scooter.
ŸHigh-efficient brushless DC motor.
ŸDigital controller with indicator and protection from over voltage and under voltage.
ŸBrake system with power cut-off ability to ensure safe riding.
ŸBattery with high performance offering stronger current and longer distance for drive
ŸFront and rear suspension system providing a smooth and comfortable riding.
MT8

02
CONTENTS
1. Matters Needing Attention to Users
2. Riding Safely
3. Check Before Driving
4. Structure and Technical Parameters of Complete Vehicle
5. Profile for Characteristic of Product
6. Method of Adjustment of All Parts
7. About Charging
8. About Riding
9. Maintenace and Service
10. Troubles and Solutions
11. Special Hints
MT8

03
MATTERS NEEDING ATTENTION TO USERS
Please note the following important safe matters in order to ensure your safe driving and use this scooter better.
1.Please read the user manual carefully and check whether all spare parts is perfect before driving in order to
ensure your safe driving.
2.Overloading is prohibited strictly.
3.It is recommended to carry out charging every day, to charge after electric quantity of battery exhausts is
prohibited strictly.
4.Inside the battery box of this scooter there is a safety power source, when battery box is taken out, both jacks in
lower end (namely positive pole + and negative pole - of battery) can't be touched by hand (particularly damp hands)
at the same time, and also be prohibited to touch metal body (like key, etc.) or else unlimited short-circuit current
produced will cause an accident and burn of human body. Please give a great attention to the above.
5.Please don't detach and disassemble spare parts or rebuild electric scooter by itself, please purchase standard
spare parts from the dealer of RKS brand electric scooter if to replace spare parts. Please repair timely if find power-
cut don't happen when do a front or rear brake.
6.This scooter can drive normally under the condition that depth of deposit water don't surpass center of electric hub
when driving on road surface with dropsy in rainy weather. Electric hub will be infiltrated by water and cause a
trouble from electric hub if dropsy of road surface surpass center of electric hub.
MT8

04
RIDING SAFETY
General Rules
ŸAlways wear an approved helmet when riding your scooter, and follow the helmet manufacturer's instructions for
fit, use and care of your helmet.
ŸWhen riding obey the same road laws as all other road vehicles, including giving way to pedestrians, and stopping
at red lights and stop signs.
ŸRide predictably and in a straight line. Never ride against traffic.
ŸUse correct signal lights to indicate turning or stopping.
ŸRide defensively. To other road users, you may be hard to see.
ŸConcentrate on the path ahead. Avoid potholes, gravel, wet road markings, oil, curbs, speed bumps, drain grates
and other obstacles.
ŸExpect the unexpected such as opening car doors or cars backing out of concealed driveways.
ŸBe very careful at intersections and when preparing to pass other vehicles.
ŸFamiliarize yourself with all the scooter's features. Practice signal lights, braking and the use of horns.
ŸDon't carry packages or passengers that will interfere with your visibility or control of the scooter. Don't use items
that may restrict your hearing.
ŸMaintain a comfortable stopping distance from all other riders, vehicles and objects. Safe braking distance and
forces are subject to the prevailing weather conditions.
Wet Weather
In wet weather you need to take extra care.
Brake earlier, you will take a longer distance to stop.
Decrease your riding speed, avoid sudden braking, and take corners with additional caution.
Be more visible on the road.
Wear reflective clothing and use safety lights.
Potholes and slippery surfaces such as line markings and train tracks all become more hazardous when wet.
MT8

05
RIDING SAFETY
Night Riding
ŸEnsure that the front lights are on.
ŸWear reflective and light coloured clothing.
ŸRide at night only if necessary. Slow down and use familiar roads with street lighting, if possible.
WARNING!
The product is not allowed to use by handicapped people!
Check Before Driving
Please do a check before driving in order to ensure your safety of driving.
ŸOpen power lock, check whether all indication of scooter head is normal, brake power cut is effective?
ŸWhether tyre pressure is normal?(Short inflation will influence running speed or continual mileage.)
ŸWhether nut of front and rear wheel is locked
ŸWhere electric energy is enough?
ŸWhether braking system is adjusted suitably and reliably?
ŸWhether handgrip and saddle is adjusted well and tightened?
Structure and Technical Parameters of Complete Vehicle
There can be differences between the illustrated vehicles and the vehicles in real.
MT8

06
STRUCTURE AND TECHNICAL PARAMETERS
OF COMPLETE VEHICLE
Standart
Engne Type
Maxmum Motor Rated Power
Motor Rated Voltage
Maxmum Speed
Maxmum Range
Load Capacty
Front Brake
Rear Brake
Wheel & Tyre Size
Battery Type
Battery Capacty
Battery Voltage
Battery Chargng Tme
Scooter Sze
Dry Weght
EN15194:2017
Brushless Engne
250W
36V
25 km/h
35-40 km
130 kg
Tektro Mechancal Dsc Brake
Tektro Mechancal Dsc Brake
26"x4.0
Li-ion Powerpack
10.4Ah
23V
3-4 hours
1500x250x800 mm
32 kg
* Informatve Values
MT8

07
MODEL VIEW MT8

08
PROFILE FOR CHARACTERISTIC OF PRODUCT
ŸTri-dimensional design body is carried out a scientific design to get the best riding effect according to body
engineering and esthetics.
ŸLight, simple and elegant shape, exquisite selection of parts and materials make you get more comfortable driving
effect.
ŸOperation of driving is simple, pedal design to get more comfortable effect.
ŸBe equipped with head light, it is safe and convenient for driving in the dark.
ŸIn order to ensure your safety during driving, electric safety system will power cut automatically when brake.
ŸIts rated vehicle speed is 25km/h, that make driver secure and family relieved.
ŸIt has 3 kinds of different driving methods including electric driving, both electric and pedal driving, and pedal
driving.
ŸIn order to ensure life of battery, please charge timely when indicating point of electric quantity is closing red area.
Part of electric quantity will be consumed if turn on headlight when drive in the dark, therefore that will cause
continual mileage is reduced correspondently. Please note that the lighting time of headlight in the dark should be
controlled suitably.
In order to ensure the life of battery, the users with enough conditions should keep charging as soon as possible
anytime after use to make the battery keeping in full status. You have to charge timely when indication of electric
quantity is only at a red light.
ADJUSTMENT OF PARTS
Adjustment of Steering Wheel
ŸInserted depth of vertical tube of wheel should be not lower than minimum depth (red safety mark); safety mark
must be inserted into below hexagonal nut. (See fig. 1)
ŸLoosen the clamping screw of saddle and put into saddle tube, tighten the screw suitably, and then insert saddle
tube into vertical tube of frame; put your both legs on the saddle to adjust the position of saddle tightly in order to
ensure you can drive comfortably. (See fig. 2)
MT8

09
METHOD OF ADJUSTMENT OF ALL PARTS
Adjustment of Saddle
ŸInserted depth of saddle tube should be more than minimum depth of insert (safety mark is for reference of
minimum depth) to ensure the safety.
ŸLoosen the clamping screw of saddle and put into saddle tube, tighten the screw suitably, and then insert saddle
tube into vertical tube of frame; put your both legs on the saddle to adjust the position of saddle tightly in order to
ensure you can drive comfortably. (See fig. 4)
ŸScrew down clamping screw of saddle and saddle tube, recommended torque should be not less than 18N.m.
(See fig 3)
Adjustment of Drum Brake (Front Brake)
ŸIf the brake power is not enough, screw in the brakebowden's screw in the brake handle.The barke works well, if
the wheel round easily and when you pull the brake, the wheel stops immediately. See Pic. 3）
Adjustment of Drum-Brake (Rear Brake)
ŸWhen rear brake is at non-normal touch, loosen the locking screw of brake wire and turn adjusting screw, adjust
the interval of brake disc at status without resistance, and then tighten the screw rope tightening. The former
drum brake, See Pic. 4. In order:/draw plate /adjusting screw /brake line /rope fastening screw/fixed screw/rear
side wire.
MT8
Fig 1 Fig 2 Fig 3 Fig 4

10
METHOD OF ADJUSTMENT OF ALL PARTS
Adjustment on Tghtness of the Chan
ŸWhen adjustng the chan, please first loose the nut of back shaft and then adjust the screw of chan-
adjustng screw, makng the tghtness of the chan n a proper degree and agle drvng moton. Back
wheel should be placed n the poston of central symmetry. As soon as the chan droops 10-15mm, tght
the nut of back shaft at once. The recommended tghtenng torque should not be less than 30N.m.(See
Pc. 5)
Adjustment on Wheels
ŸFore wheel should be put n front fork, requrng the equal clearance from left and rght, clearance s
≤3mm. (See Pc. 6)
ŸBack wheel should be put n fork of scooter frame, requrng the equal clearance from left and rght,
clearance s ≤3.5mm.
ŸWhen tghtenng of nuts of fore wheel and back wheel s carred out, the tghtenng torque of fore wheel
should not be less than 22N.m whereas that of back wheel should not be less than 30N.m.
Pc 5 Pc 6
MT8

11
ABOUT CHARGING
Before rdng the electrc scooter for the first tme, you must charge the batteres for 4-6 hours usng the
suppled charger. To charge, remove the protectve cover from the chargng socket. Then plug n the
charger nto the chargng socket, before pluggng the charger nto a wall outlet.
IMPORTANT CHARGING INSTRUCTION
The Power Swtch Lock must be n the off poston when the electrc scooter s beng charged.
All batteres charge smultaneously. You should charge your electrc scooter after each rde. You must
charge your electrc scooter f t has not been used for 30 days or more. Rechargng tme s between 4-6
hours.
WARNING
Do not place the battery near heat or fire. Do not expose the charger near water.
MT8

12
ABOUT CHARGING
MT8

13
ABOUT CHARGING
Removng the Battery
Open the battery lock, move it to the side
Take out the battery
After charging put the battery back and close the lock
When the Battery s Beng Removed for Chargng
After the battery box s removed, as we menton before, please notce that the electrode “+” “-”can never be touched
by hands especally wet hands and the electrodes are also prohbted to be touched by other metal conductor!
Do not charge the battery up-sde down, otherwse the lfe tme of the battery wll be severely affected.
Put the battery charger n a flat level, and first plug n the output plug to the chargng socket of the battery box.
Then, plug n the nput plug (230V) to the power socket and chargng s started. (See Pc. 7)
After chargng s finshed, first pull out the power nput plug (230V) and then pull out the output plug.
MT8
Battery
Charger
Battery
Connector

14
ABOUT CHARGING
When the Battery s Chargng on the Bke
ŸPlease swtch off power and remove the key.
ŸRemove (rotate to open) rubber stopper n the chargng hole and the stopper should be kept well. Then, first plug n
output plug of charger to the socket of battery box, after that, plug n power nput plug (230V) to household power
socket to start chargng.
ŸAfter chargng s finshed, first pull out the power nput plug (230V) and then pull out the output plug.
Duraton of Chargng
ŸWhen the nput and output termnal are connected, the red ndcaton lght of the charger wll be turned on, showng
that the power s beng connected.
ŸWhen the battery s charged for the first tme, 8-10 hours should be spent for chargng. When the green ndcaton
lght of the charger s turned on, showng that the battery s bascally full and t wll swtch to trckle charge mode to
ensure that over-chargng wll not occur. It takes 2-8 hours for normal chargng.
ŸThs charger has the protecton devce for over-chargng. Long-tme chargng should not be more than 24 hours
wthout affectng the lfe tme of the battery.
Matters Need Attenton for Chargng
ŸThe charge doesn’t need to be grounded.
ŸDurng chargng, please place the charger n safety locaton whch s beyond the reach of chldren.
ŸThe battery should not be used when t s not full, otherwse the lfe tme of the battery wll be affected.
ŸDo not charge wth charger from other brands and the charger s also not for other storage battery.
ŸThe charger has 230V crcut; please do not dsmantle.
ŸWhen the charger s beng used or stored, lquor and metal charge should be prevented from gong nto the nsde
of the charger, and t also should be free from fallng and bumpness to avod njury.
MT8

15
ABOUT CHARGING
ŸThe charger s the type of ndoor use. Please keep t n a dry, well-ventlated crcumstance when t s under use.
ŸDurng chargng, f pecular smell s smelt or the temperature s too hgh, please stop chargng mmedately and
send t back to sales department of mantenance department.
WARNING!
The attached cables of the battery charger can be used for the battery-charger only!
MT8

16
ABOUT RIDING
1.Power swtch. Pushng for short tme the bke s turned on, pushng for long tme the bke s turned off.
2.Adjusts the amount of pedelec assstans. Low s slow, Hge s fast speed. Can be changed by pushng the button
for short tme.
3.ndcator of battery. If all four leds are on the battery s fully charged. f only one led s on the battery needs to be
charged.
Once you have completed the ntal charge you are ready to rde. You must be aware of all local laws and ordnances
that govern and/or restrct the use of electrc bcycle. The laws and ordnances vary greatly from muncpalty to
muncpalty. It s your responsblty to know and abde by your local restrctons.
To rde, turn the power swtch lock to the “on” poston. The power swtch s located on the front bottom of the seat. The
battery gauge and the power ndcator located at the panel wll llumnate when the power s on.
Hold onto the handlebars wth both hands. Assume a well-balanced poston on the scooter and push off wth your
foot. Your rght hand wll control the accelerator. Twst the accelerator slowly to avod a sudden rush of speed forward.
MT8
Controller Dashboard Shfter

17
The speed of the bke wll ncrease as you twst the accelerator more. Release the accelerator and apply the brakes
to stop your bke. You wll control the speed of the bke by usng both the accelerator and the brakes. When the
brake handle s squeezed t cuts power to the accelerator.
Used for changng gears, n need, accordng to the envronment.
Matters Need Attenton Durng Journey
ŸFor economc use of battery and motor, please use your feet to assst drvng when the bke s started or clmbng,
prolongng the lfe tme effectvely.
ŸWhen the bke s started just now, the bke should be accelerated slowly to avod wastng power durng
nstantaneous speed-up or damagng electrcal parts. It s better to drve wth assstance of feet.
ŸOn the precondton of safety, he should try hs best not to brake or start too much n order to save power.
ŸThe controller of the bke has the functon of over-load protecton. If t s over-loaded, the power wll be cut
automatcally, when everythng goes back to normal, the power wll be connected automatcally.
ŸDurng drvng, t should be avoded that holdng the speed-adjustng handle after brakng, to prevent damagng
the machne part or motor by over-load (stuck rotaton) of electrcal motor.
ŸThe maxmum carryng capacty s 110kg, t s better to rde under the rated carryng capacty 110kg (ncludng the
drver). Do not drve overspeed.
Matters Need Attenton for Parkng
ŸWhen you get off the bke and push t forward, the power swtch should be shut off to avod unntentonal turnng
on the handle and the accdent can be avoded by sudden start-up of the bke.
ŸIt s suggested that the bke should be parked ndoor or wthn carport. Don’t forget to shut off power and take off
the key.
ABOUT RIDING MT8

18
MAINTENCE AND SERVICE
ŸIn publc places, the bke should be parked n the regulated spot accordng to traffic regulatons. Don’t forget to shut
off power and take off the key.
MAINTENANCE AND SERVICE
For the safety of drvng, please keep your bke n optmal condton at the same tme and carry out perodcal
mantenance and washng.
Items for Perodcal Mantenance and Self-checkng
ŸCheck whether the nuts of fore wheel and back wheel are tght or not. Check whether the fore fork and the bke
frame work well wth devaton.
ŸCheck whether the groove pattern of cover tyre s worn or splts and f ar pressure of fore tyre and back tyre s
normal or not.
ŸCheck whether the gear system s workng smoothly or not.
ŸCheck whether the horn and back reflector are ntact or not.
ŸCheck whether the brakng thread s workng under lubrcaton and there s no clampng stagnaton.
ŸIf the bke has not been used for long, please notce that chargng should be executed perodcally (normally, one
tme n a month to mantan lfe tme of the battery)
ŸIn the wnter, place the battery at a warm place.
Explanaton on Mantenance and Washng
Do not wash wth hgh pressure water column to avod accdents caused by wet nner electrcal parts.
The drt on pant surface or the surface of plastc parts should be cleaned wth cloth, neutral agent should be used, and
then clean wth dry cloth.
Please use lubrcaton ol to mantan metal parts of the bke.
Ol should not be appled to fore brake rubber and back brake rubber, hold brake, rm, tre battery and controller.
MT8

19
TROUBLES AND SOLUTIONS
No Descrpton of Malfuncton Analyss of Malfuncton Way of Elmnatng
2Fal to adjust the speed or
max speed s relatvely slow
(1) Low voltage of battery
(2) Magnetc steel n the speed-
adjustng handle s loose
(3) Sprng n the speed-adjustng
handle fals to work or damage
(1) Charge the battery
(2) Clamp after weldng (*)
(3) Look for projectonsts or
mantenance staton.
3Motor doesn’t work after
swtchng on
(1) Wre connecton s loose
(2) Magnetc steel n the speed-
adjustng handle s loose
(3) Connectors of motor wre
connecton loose or damage
(1) Connect after repar (*)
(2) Clamp after weldng (*)
(3) Look for projectonsts or
mantenance staton.
4Drvng mles s not enough
after one charge
(1) Ar pressure low n the tyre
(2) Not enough chargng or charger
fault
(3) Too much upslope, heavy dead
wnd, brake qute often, bg load
(4) Dscharge battery completely for
long tme, and not charge n tme
the battery s agng or damaged
(5) Low temperature n wnter
affects drvng mles obvously
(1) Charge ar
(2) Fully charge or check the
touchng of connectors (*)
(3) Suggest use feet under these
stuatons
(4) Change the battery
(5) Suggest charge longer ndoor
MT8
1Fal to adjust the speed or
max speed s relatvely slow
(1) low voltage of battery
(2) bad touchng between battery box and
socket
(3) power lock swtch s not n correct poston
(1) charge the battery
(2) clean the drt on the touchng pece (*)
(3) turn to correct poston
