Robam CXW-200-A861 User manual

A861
CXW-200-
Range Hood
Operation Manual

CONTENTS
1.Important Information.........................1
2.Product Overview...............................1
3.Installation..........................................2
4.Use Instruction..................................5
5.Maintenance and Services...............6
6.Circuit Diagram..................................9
7.General Troubleshooting....................10

Technical Datas
1
Improper operation may cause hazardous effect.
Picture 1
Decorative tube
Switch
Oil cup
CXW -200-8312
Dear Users
Thank for your buying our range hood. Please accept our best regards.
Please read this operation manual carefully before installation and operation.
Important Information
Product Overview
New Package of Range Hood
Please settle those packages carefully in order to protect environment.
Don’t allow children to play plastic film and package, it may cause asphyxia. Please avoid children near package
material.
Dispose Old Range Hood
If the old range hood can’t work, we suggest users to dispose them after confirming without any usage.
There are something useful material inside of old range hood, please assist us to dispose so as to protect environment.
Before use new range hood
This range hood exhaust fume outside.
Please read this manual and all information carefully before installation and operation. Please comply with our
suggestion. If it’s necessary, please read manual for gas hob. And please keep these manual carefully for future reference.
This manual is available for different models. So you may find different description with your own range hood.
If range hood has obvious damage, please don’t electrify and contact operator.
Children and disability are not allowed to use range hood independently in order to avoid accident.
≥230
895×463×856(mm)
15 m/min
3
+1
-2
CXW-200-A861
≤4W
≥22%
22kg
Size( L x W x H)
Model
Power Supply
Total Pressure Efficiency
Nominal Wind Pressure
Air Flow Rate
a.c 220-240V 50Hz
Pa
Noise
Rated Main Motor Input Power
Lighting Power
Net Weight
200W
Non-Disassembly and W Free ash
≤57dB

Installation
Preparation
Size & Dimension
325
463
2
386
895
856( )430
Picture 2
CXW-200-8 312
Note:The lenghth is only for reference，in the brackets of the size is high of draw tube .（size：mm）
Ambient environment
Packing List
Packing List
No.Item Name Quantity No.Item Name Quantity
1
12
11
6
5
4
3
2Plastic expansion tube
1 unit
4 pcs
1 piece
Check Valve
1 piece
9ST 4x18 tapping screw 8 pcs
ST 3x10 tapping screw 4 pcs
13
14
ST 4.8x50 wooden screw 4 pcs
10
Stop block for bracket 1 unit
M6metal expansion tube 1 unit
7
Stainless steel oil cup
Hanging feet 1 unit
8
Φ175 aluminum foil's duct(2m)
Φ175 air duct’s interface
Fixed bar of air duct
Adhesive tape 1 set
Range Hood
Warning
Range hood shall be installed away from positions with too many windows or doors, which will lead
to strong air convection and thus reduce the effect of fume removal.
Tools
Note: This product must be used in the daily life. Don't use it under special situation(for example:
outside ),Meanwhile ,don't use this product to exhaust dangerous explosive material or gas . This
product must be placed under safe circumstance before installation. ( dry, good ventilation,non-
corrosive and innoxious ,etc)
!
Installing range hood requires the following tools:1.impact electric drill(with drill bit); 2.Wrench;
3.Screwdriver;4.Ruler
1.The range hood is prohibited from exhausting fume into hot flue ,which is used for exhausting gas fuel or
other fuel fume.
2 In installing metal expansion tube ensure perfect match of tube diameter with hole diameter to prevent
accidental falling off loosened expansion tube due to excessive hole expansion
3 Use range hood in case of gas or other fuel combustion and ensure ventilation in the room
4 Flue opening smaller than that of the air duct or excessively long air duct will affect the fume removal
. ,
from .
. good .
. .
Non-Disassembly and ree Wash F

Keep hood horizontal when installing.
Picture 7
Please use the single-phase grounding socket,
and good.
3
Picture 3Picture 4
Picture 5Picture 6
!
Installation Precautions
Don't install the range hood too high and
keep it free from external airflow to prevent
reduced the effect of fume removal.
Please reserve sufficient space when
making cabinet in order to maintain
Tap water pipe
improperly earthed.
It's dangerous of fire
and explosion to earth
gas pipe.
Picture 8
explosive
Raw water pipe
gas pipe
Please pay much attention to following:
If your kitchen is under installation, please don’t divulge range hood outside, because the smell from building material,
dust, painting, coating material may cause rust. We suggest users to install range hood after decoration.
Don’t allow to install range hood on the wall which is easy to fire, for instance, wooden wall. Please install range hood
on the wall where has enough space and strength for noncombustible material.
Range hood and electricity must be installed by specific operation. Don’t allow to install, disassembly and maintenance
range hood by non-professionable person.
Please ware glove when moving, installing, cleaning or repairing range hood.
Please be care of electricity inside of wall when operator digging holes on the wall. It may cause fire.
Warning:Don't allow to contact fire with range hood
directly. Forbid gas stove from getting fire to prevent
damage of range hood or happening of accident.
Non-Disassembly and W Free ash

182mm
wall
Wind pipe hole sizeφ200mm
Ceiling hole size chart
463mm
895mm
Hood top projection size
508mm
(Don’t require to adjust and install draw tube in Picture9-2)
Installation:
1、Location: The dimension of mounting of removable baffle is decided according to actual situations. The range
hood shall be centered vertically and kept horizontally. ( picture 10-2).Note:this only applies to the installation
of electric induction cooker,if installed the gas hob,the installation height should according to the gas hob
installation requirements.
Picture 10-1
（Picture 9-1 mounting without removable baffle）
Picture 9
Draw tube
Decorative tube
1000-1100mm 65±2mm
Hanging plate
235mm
55mm 55mm
ST4X18 tapping screw
10mm
top Plate
300-400mm
800-900mm
installation-hole for
draw tube
4
（Picture 9-2 mounting with removable baffle）
removable plate
300-400mm
top plate
removable plate
10mm
800-900mm300-400mm
463
35±2mm
stop block for hanging plate
Picture 10-2
2.Installing hanging plate: Drill four 50-60mm-deep holes by Ф8mm drill bit at positions corresponding to the
hanging plate dimension. Force the expansion tube into the holes and fasten firmly the hanging plate by the
supplied four 4.8x50 wooden screw. Drill a 40-50mm-deep Ф10mm hole at position 65mm high from the four
holes and force the M6 metal expansion tube into the hole(picture 10).
Installing hood body: F as shown in Picture 10, align the hanging holes
at back of the hood body to the hooks on the hanging plate and slide the body in by pressing and shake by
hands the body to see if it is firmly hang. When the body is ready in place, install safety stop block and gasket
on the M6 metal expansion tube and fasten firmly the nuts to prevent the hood body from running out of the
hooks under external force.
5.
3.Adjust draw tube:Pull up two brackets of the draw tube to proper level, then forced pull out the draw tube, ear off
the protective film. And then insert into between decorative tube and shell body to adjust the proper level.
4.irst fix the check valve as picture 11-1
Install draw tube:Following picture 9-1, a gap is about 3cm between draw tube and top plate, push the draw tube, so
that the draw tube can touch the top plate, and then fix the draw tube on the top plate with ST 4x18 tapping screw.
Non-Disassembly and ree Wash F

Use Instruction
5
Control panel
Insert power plug, the buzzer sound 3
times, prompt installation qualification,
enter into the standby state.
Picture 12
Picture 13 Picture 14
High
After ensuring power is on, lightly press power key
by finger and the embedded lamp light. Then lightly
press "High" key by finger, motor runs in high speed
to exhaust fume (High mode is on) .Lightly press
"Low"key , hood changes to low mode.
check valve
body of machine
seal ring of check valve
ST3X10 screw
fixed bar of air duct
ST4X18 screw
Picture11-1
6.Installation of aluminum foil's air duct:Firstly,insert the aluminum foil's air duct with fixed bar between the inner and
external rings of check valve vent, fasten it by ST3x10 tapping screw. Then fasten another side of aluminum foil's air
duct with adhesive tap outside of room.When the wall's hole is bigger than air duct, the air duct can be pulled out of
room directly;when the wall's pipe is smaller than air duct, there are four specifications for the interface of air duct,such
as 140mm,150mm,160mm and 170mm.The operator can select reasonable specification according to wall's hole. The
additional part can be cut with forfex.（The detail as following picture）:
7. Installing other end of exhaust duct (for reference)
●
eplace a piece of window glass with plywood with ventilation holes or drill holes directly on the glass.
● In case range hood kept away from the window:
Choose the window nearest to the hood and with outdoor access for installing the exhaust tube; or dril holes
on the wall nearest to the hood and with outdoor access to install the exhaust tube through the wall.
● Drilling holes through wall:
Align properly the positions of exhaust tube against the wall and scribe the holes on the wall (circles slightly
larger than the exhaust tube diameter),then drill the wall by long drill bit.please take care of the wall structure
and materials to prevent damage of wall other than the wall holes.
The hole diameter on the wall shall be near to that of the exhaust tube and shall not be too small. Otherwise,
it will lead to obstructed exhaust, higher noise and lower air flow rate.
Installing with exhaust tube and range hood against the window:
R
Pciture 15 Picture 16
Low Light
After ensuring power is on, lightly press power key
by finger and the embedded lamp light. Then lightly
press "Low" key by finger, motor runs in low speed
to exhaust fume (Low mode is on) .Lightly press
"High"key , hood changes to high mode.
Press “Lighting” switch, the lamp shall be turned
on, press it again, lamp shall be turned off.
Non-Disassembly and W Free ash
Φ175 aluminum foil's air duct
Adhesive tape
Φ175 air duct's interface
cut additional part which smaller than wall's hole
Notice: Please straighten the aluminum foil's air duct when installing
this product to avoid noise under incompletely straight condition. The
additional air duct can be cut by wire-cutter.
Φ180 Φ170 Φ160 Φ150
Φ140
Picture11-2

Picture 19
Picture 18
Pull out power plug in case not being used
for a long time.
After ensur ing power is on , if onl y the light is on, light ly pr ess power key to tur n
off the light . If the motor is wor king when the power is on , press “power ” swi tch
by finger , its lamp twinkl es and range hood shal l be tur n off al l funct ions after 1 minut e.
Under “Delay” condi tion, it’s inval id to pr ess “ High” or “ Low” swi tch; Press "power ”
agai n, it will stop al l oper ations of range hood .
Pow er
Picture 17
Maintenance and Services
If not washed per the specified methods in the instruction, range hood may be liable of fire.
extend service life
To ensure smooth fume removal use warm water and detergent to clean oil guide mesh depending on the use
conditions
Range hood shall be cleaned at regular intervals depending on the environmental conditions to keep clean an d
good effect,it's helpful to .Our suggestion:
Please clean the range hood after every cooking.
,
. Be careful to wash oil guide mesh preventing from damage.
Pull out of oil cup discharge the waste oil.
Please check and clean oil cup regularly.
Warning:Maintenance and cleaning shall be carried out after unplug the plug.And the electric parts must avoid water.
For safety concern , do not wash the range.
Wipe with wet cloth soaked in neutral detergent.
Picture 20 Picture 21
Dismounting of lamp
Pull out power plug and the insert parts of the light,
remove glass components.
Picture 22 Picture 23
Remove the 9 screws of front ,behind cover
and top surface.
6
Non-Disassembly and ree Wash F

Picture 25Picture 24
7
Dismounting of switch
Picture 26
Remove two pieces of fastening screws on switch by
screwdriver. Dismount the switch cover.
Note: mounting of lamp and switch is just opposite to dismounting them.
Pull out of switch parts from LED hole to
maintenance or replace.
Remove the 2 screws on lamp shade plate
by screwdriver.
Picture 27
Pull out of LED light is just
Dismounting of impeller.
Picture 28 impeller baffle ring
cap
back cover plate
Dismounting steps:
1.Pull out of power plug.
2.Remove fastening screws by screwdriver
and pull out of back plate.
3、Remove fastening screws on baffle ring
and pull out of baffle ring.
4.Remove cap deasil and pull out of impeller
vertically.Mounting and dismounting steps are
opposite. (Please add some lube on the hole of
axes when installing impeller)
Dismounting of front plate
1、Take out of oil cup.
2.Hold front panel by hands, revolve it outside
and make it off from magnetic bottom as picture.
Then lift it upward, When pothook is left stands
of pothook, the dismounting steps are end.
Picture 29 Picture 30
Magnetic bottom
front panel
Revolve
lift upward
Non-Disassembly and W Free ash

8
Dismounting of oil mesh
Picture 32
oil mesh panel
1. Take two pieces of magnetic caps out by sharp
tools, then revolve screws right 2-3 rings by
screwdriver, and loose oil mesh panel.
2. Move 2pcs of oil mesh panel until it’s end.
3.Pull out oil mesh by hands.
Put pothook into stands.
Press it
Hold panel by hands, put pothook in stands,
then press it to right place.
magnetic cap
Picture 31
Dismounting of decorative tube
Dismounting Steps:
1.Pull out power plugs and take down the hood;
2.Screw off 4 screws behind the decorative
tube and incline the decorative tube forward to
certain angle and pull it out by force with hands;
3.Take out draw tube from the decorative tube;
Notice: Don't follow with step 3 without draw
tube.
Switch
Oil cup
Front plate
Decorative tube
Draw tube
Oil guide mesh
图31
Pull out of Direction
for decorative tube
LED lamp
Non-Disassembly and ree Wash F

Circuit Diagram
9
EL: Lighting lamp
M: Motor
XP:
K2:
K1:
K3:
C: Capacitor 500VAC 5
Lighting Switch
Power Plug
E: Earthing Terminal M
Low Switch
High Switch
Yellow/Green
Brown
Blue
Blue
Black
Orange
Brown
Blue
Red
Red
Yellow
Blue
Red
Connection Box
Control Circuit
Operating Circuit
220-240V
General Troubleshooting
Warning
Lamp damaged or improperly contacted
Loose impeller,cap not properly fastened
Plugs improperly plugged or
power off
Plug improperly earthed
Reasons
No reaction in pressing any switch(such as
impeller does not run and lamp does not light)
Lamp fails in pressing lighting switch
Induction current on hood surface
Abnormal impeller sound
Problem
1
2
3
4
No oil in oil cup after some time Inclined installation of hood body
5
No.
1.When connecting accessory or
replacing bulb, please pull out
power plug;
2.If power wires of range hood
damaged, replace them by
professionals;
3.Don't allow to exhaust flame
through range hood.
Warning
There shall be adequate ventilation of the room when the range hood is used at the same time as appliances
burning gas or other fuels .
- Do not flambe under the range hood.
- Regulations concerning the discharge of air have to be fulfilled.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory, or
mental capacities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Accessible parts may become hot when used with cooking appliances
The minimum distance between the supporting surface for the cooking vessels on the hob and the lowest
part of the range hood. When the range hood is located above a gas appliance, this distance shall be at least
65 cm. If the instructions for installation for the gas hob specify a greater distance, this has to be taken into
account.
-
-
Non-Disassembly and W Free ash
