Robam CXW-220-A817 User manual

A817
CXW-220-A817
CXW-220-A815
Range Hood
User Manual
Before operating this unit, please read the ser manual completely and keep it. u

Safety Precaution.......................................................................................... ....1
Important Information....................................................................................... .............3
Product Overview................................................................................................. ........4
Packing List......................................................................................................... .... ....4
Installation Instructions...................................................................................... ....5
User Manual......................................................................................................... 8
Maintenance.......................................................................................... 10
Removal of Components........................................................................................... 10
Circuit Diagram....................................................................................................... .. 12
Troubleshooting of General faults........................................................................................ 13
......................
..........
...........
........... .
.................
..................
...............................
............
........... .
..
CONTENTS

Prohibit water on motor, switches or
other electric parts; Prohibit wash range
hood by water spray. Don’t use range
hood if wet or it may cause electric
leakage or shock.
Don’t touch plug, electric parts or
button by wet hands, or it may cause
electric shock.
Safety Precaution
Subject to harmful or destruct degree
In order to avoid harm or property damage to the users or other person, the following distinction and marks
are stipulated. They are important safety precaution, please comply strictly based on the full understanding.
Danger If ignore this sign and operate product improperly, it’s highly possible to cause danger,
serious injury or fire.
If ignore this sign and operate product improperly, it’s possible to cause danger, serious
injury or fire.
If ignore this sign and operate product improperly, it’s possible to cause injury or loss.
Please use this product according to manual strictly, or ROBAM shall not take any
responsible caused by improper operation.
Don't allow children or weakling to use
range hood separately, or it may cause
electric shock or other accident.
The electric wire must be cut off before
clean, install or maintain range hood
avoiding from electric shock.
Don’t change, stretch, bind or press
electric wire, or it’s possible to cause
electric shock or fire because of broken
wire.
Prohibit any change of interior circuit,
or it may cause injury or other danger,
for example, electric shock or fire.
Please turn off range hood immediately
if pan got fire (range hood shall
aggravate fire if it’s working) and
extinguish fire by effective action. For
example, cover flame by metal cover, turn
off gas valve immediately and remove
inflammable things.
Any abnormal, please turn off power,
take off plug or cut off electric source,
and contact service. It’s possible to
cause electric shock or fire if using
range hood under abnormal situation.
Notice and Prohibit Mark
1
Warning
Notice
Danger
Prohibit Prohibit
Flame
Prohibit
Touch
Prohibit Touch
by Wet Hand
Prohibit
Disassembly
Strict
Execution
Neccessary
Earthed
Caution
Electric Shock
Caution Scald
Warning
Prohibit
Prohibit Prohibit
Prohibit Strict
Execution
Strict
Execution
Strict
Execution
Prohibit Touch
by Wet Hand
Dear users:
Range Hood
Thank for your buying our range hood. Please accept our best regards.Please read this user manual
carefully before installation and operation.
*The pictures in this manual only for your reference. If the picture isn’t accord with object, subject to object. We
keep to right to update appearance, structure or products without notice.

Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
In order to ensure safety, range hood
must be installed by specific accessory (
especially expansion pipe and wooden
screws, or it may cause accidental drop
of range hood). The pipe bore and hole
must fit tightly during the installation of
metal expansion pipe. It is prohibited to
make excessively large hole to prevent
accidental drop of loosening expansion
pipe.
The range hood must be used by
specific plug and properly ground it. It’s
possible to cause electric shock, hot
plug or fire because of improper
electric wire. Installation must be
executed by professional person based
on local electrical regulations. Before
connect electricity, power must be
turned off.
If electric a l wir e is broke n , onl y
professional engineer can replace it.
If the range hood will be used with the
kitchen range burning gas or other
fuels, the room must be well ventilated.
The range hood and electric circuit must be
installed by skilled and trained personnel
wi t h required qualification. When
installation, the related regulation, standard
or instruction on fire must be complied. It
may cause danger because of improper
installation, for example, electric shock,
drop or fire accident.
Range hood must be i n stalled ,
d i s a s s e m b l e d or m a i n t a i n e d b y
professional person.
Put out the stove fire in time when it
is not used. That the stove fire bakes
the range hood directly is prohibited.
Do not barbecue food directly under
the range hood lest the range hood is
damaged and an accident should
occur.
All operation must comply with our
safety guidelines as well as local safety
regulations.
The range hood is used only daily life not
special environment ( for example, outside).
And it’s not allowed to exhaust dangerous or
explosive matter or air. It should be put
under dry and ventilation environment
without dangerous air.
The outlet must be connect with outside. In
order to ensure safety and fresh air, waste
gas should be exhaust to outside. Don’t
exhaust waste gas to the wall, loft or garage.
Don’t touch bulb if it’s on or just close in
short time, or it may cause scald.
It may get fire if cleaning range hood not in
accordance with manual.
Keep a good habit to turn off gas hob and gas valve if go outside, sleep or finish operation. Replace or
check gas pipe regularly, since gas alarm device can’t completely avoid accident caused by gas
leakage.
2
Warning
Prohibit
Prohibit
Disassembly
Prohibit
Touch
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Range Hood

3
Because the installation is difficult and
hood is heavy, the installation shall be
executed by professional person based
on manul.
Be fo re re mo vi n g range h ood f o r
installation, clean or maintainance ,
power must be cut off avoiding from
electric shock. When installation, clean
or maintainance, protective gloove
must be wear avoiding from injury.
Don't break electric wire or other
in v is ibl e equ i pm ent wh en cut t in g
something or drilling holes on ceiling.
When the oil exceeds 2/3 or near tick
mark in the oil cup, clean it in time. Don't
eat waste oil from oil cup.
The gas from range hood shall not be
exhausted to hot flue used for burning gas or
other fuels.
When range hood is using in well
sealed building, it should have air inlet
or open door to ensure good ventilation.
Th e te m per a tur e for ra nge ho od
working can’t exceed 40℃.
The wall of installing range hood needs
enough strength. For hollow walls, the
thickness of solid layer of hollow wall must
be more than 30mm, but for concrete walls,
it can be drill holes directly. The range hood
must be fixed on the wall firmly.
重要信息
Notice
Prohibit
Important Information
Package of Range Hood
Before use Range hood
Please settle those packages carefully in order to protect environment.
Don’t allow children to play plastic film and package, it may cause asphyxia. Please avoid children near package
material.
This range hood exhaust fume outside.
Please read this manual and all information carefully before installation and operation. Please comply with our
suggestion. If it’s necessary, please read manual for gas hob. And please keep these manual carefully for future
reference.
This manual is available for different models. So you may find different description with your own range hood.
If range hood has obvious damage, please don’t electrify and contact operator.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Strict
Execution
Range Hood

4
322
500(505)
359
895
537
The marked sizes are for reference only. The height of drawing panel is 430, and the size in brackets is specific
to A815 hood. (Unit: mm）
70
220Pa
A817:895×500×
A815:895×505×537
537
Rated Input Power of the Main Motor
≤58dB
≥23%
22kg
Dimensions (L×W×H)（mm）
Odour Decrease Rate (Normal)
Odour Decrease Rate (Instantaneous) ≥76%
340Pa
≥98%
Rated Input Power of the Hood
A817:222W A815:224
220W
Grease Separation Rate ≥92%
Noise
Maximum Input Power of the Light
Net Weight of the Host
220-240V~ 50Hz
Body Size
3
18m /min
CXW-220-A817
CXW-220-A815
Note: 1.The deviation between the expressed value and measured value of air flow rate, maximum static pressure
and nominal wind pressure shall not exceed -10% of the expressed value.
3
2. When stir-frying function is enabled, the air flow rate is 19m /min.
A817:
A815:≤
≤2W
2W×2
Maximum Static Pressure
Model
Power Supply
Total Pressure Efficiency
Nominal Pressure
Air Flow Rate
Technical Specification
Product Overview
Range Hood
Packing List
Please check lists if open the package.
Packing List
No.Name Quantity
No.Name Quantity
1
12
11
6
5
4
3
2
Range hood
Plastic expansion pipe
1 piece
4 pieces
1 piece
1 set
S T4x18 self-tapping screw 10 piece
13
S 4× wooden screw T 60 4 pieces
10
Hitching foot stopper 1 piece
1 pair
7
8
Hitching foot 1 piece
9
1 set
Φ185 (OD)
aluminum exhaust pipe
Exhaust pipe connection
Exhaust pipe tape
Exhaust pipe fixed strip
User manual
Check valve
M6 metal expansion pipe
Oil cup 1piece
14

5
Installation
Notice
●
Keep the hood away from too many doors and windows, so as to avoid air convection affecting the efficiency.
●Tools preparation
The hood will be installed with the following tools:1. an impact drill (with drill bit) 2. a wrench 3. a screwdriver; and
4. a ruler.
Surrounding
Preparation for installation
●Installation and circuit setting must be done by experienced professionals. Only a professionally trained
person with an installation qualification can install the hood. Non-professionals are not allowed to install,
dismantle and repair the hood.
●Please do not power on the hood before installation to avoid electric shock.
●Do not expose the hood if your kitchen is under renovation, because construction materials, dusts, paint,
coatings, and emitted gases will corrode and tarnish the hood surface. Therefore, it is recommended to install
it after the renovation is completed.
●Don't install the hood on wood and other combustible walls. The wall shall be made of noncombustible
materials with enough strength and the surface shall be flat.
●The hood may have very sharp edges. So, please wear protective gloves during hood installation, cleaning
or repair.
●When drilling on the wall or ceiling board, keep away from embedded wires and other concealed devices to
avoid electric shock and fire.
●Do not install the hood at a too high position as well as keep the hood free from disturbance of ambient
airflow lest the reduction of smoke pumping effect shall occur.
●When making cabinet, please leave space for installation and disassembly of the hood in order to maintain
and overhaul the hood.
●When installing, please keep the machine body remain horizontal.
●Please use single phase grounded socket and the hood shall be well grounded (water pipe grounding is not
reliable and gas pipeline grounding has risks of causing fire disaster and explosion).
●In order to ensure safety and successful installation, please use standard accessories provided with the
hood for installation, otherwise the hood may be at risk of falling down.
●If the power cord is damaged, in order to avoid danger, it must be replaced by manufacturer, professionals
of its maintenance department or similar departments. Please do not carry out restructuring, stretching,
knotting and squeezing or apply heavy objects to the power cord, etc., otherwise it may cause power cord
damage easily, leading to accidents such as electric shock and fire disaster, etc.
●After installation, please clean the surface of the hood, and then supply power for test run.
Warning
1.The air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or
other fuels,the discharge of air must fulfill the requirements of local regulations.
2.Note that when installing the metal expansion pipe, the pipe shall match with the hole in size. Overlarge hole is
prohibited, as it will result in loose pipe and accidental drops.
3.There shall be adequate ventilation of the room when the range hood is used at the same time as appliances
burning gas or other fuels.
4.If the flue aperture is less than air duct aperture, it will influence the fume suction effect and the too long air
duct will influence the fume suction effect, too.
5.This product is only for daily use and please do not use it under special environment (e.g. outdoor); nor can it
be used to exhaust hazardous or explosive substance or gas. Before assembly, the product shall be placed
in environment which is dry, ventilated without corrosive and harmful gas in the surrounding.
Range Hood

8328
Installation
6
500(505)
600-800
650-750
800-900
10
Ceiling
Removable panel
Removal baffle
(Figure Installation method of
hood without removable baffle)
1-1
CXW-200 -8312
Figure 2 Figure 3
100
468
Ceiling hole sizes(Figures in brackets
are specific to the A815 hood)
500(505)
895
Projection size
of the hood top
Walls
Hole size of the exhaust pipeφ200
●Install hitching feet
According to the dimension of hitching feet, drill four 60-70mm deep holes (overlarge holes are prohibited)
accordingly with an 8mm diameter drill bit. Press the expansion pipe into the holes, and then fix the hitching feet
reliably with 4 provided ST4×60 wood screws. Drill a hole with diameter of 10mm and depth of 50-55mm at the position
65mm above the four holes and insert the M6 metal expansion pipe into the hole. (See Figure 2)
A817
8328
600-800
650-750
800-900
10
35±2
Hitching foot stopper
Hitching foot
235
110
55 55
495 65±2
Range Hood
(Figure Installation method of hood with removable baffle)
(Figures in brackets are specific to the A815 hood)
1-2
●Determine the position
Ceiling
Drawing panel
Mounting hole of
the drawing panel
Main hood panel
ST4X18
self-tapping
The hood shall be installed right above the hob. The minimum distance between the bearing surface of
cooking appliance and the lowest part of hood is 650mm (larger space specified in the installation instruction of
gas hob shall be considered. The distance for electric cooker may be reduced appropriately, depending on the
actual situations)
The size of removable baffle (reference: 430mm) can be adjusted according to the actual situations. The
installation pitch of holes is shown in Figure 2. The hood body shall be centered vertically and kept level. Ceiling
hole size is shown in Figure 3.

●Drilling position of the aluminum foil exhaust pipe (public flues do not require drilling)
a. Aluminum foil exhaust pipe and hob facing the window: Remove one of the glasses and install a plywood with
ventilation holes or punch directly on the glass.
b. Hob away from the window: Install the aluminum foil exhaust pipe through the window that is close to the hob
and connected outside; or install it by punching on the wall that is close to the hob and connected outside.
c. Drill hole through the wall: Determine the location of the aluminum foil exhaust pipe against the wall and draw
the drilling range (i.e. a circle slightly larger than the pipe OD). Then use a long drill bit to drill through the wall. Pay
attention to the wall structure and material, so as not to destroy other parts of the wall.
●Link the aluminum foil exhaust pipe
Insert the end of aluminum foil exhaust pipe without fixed strip to the pipe connection and stick with tapes.
Straighten the aluminum foil exhaust pipe and then connect the pipe to the connection of public flue outlet
(straighten the pipe directly to the outdoor if there is no public flue). This can be done directly when the public flue
connection or wall hole is larger than the pipe. Otherwise, there are five types of pipe connection small ends (OD:
140, 150, 160, 170 and 180 respectively) to be chosen from according to the hole size. Then cut the excess part
with scissors.
Then insert the end of the aluminum foil exhaust pipe with fixed strip in the outer ring of the check valve connection
and seal with exhaust pipe tapes. At last, put four snaps of the check valve connection in corresponding slots, and
rotate them clockwise to fix the exhaust pipe to the check valve.
Install the aluminum foil exhaust pipe
7
●Adjust drawing panel
Pull the two brackets of the drawing panel upwards to an appropriate height and then pull out the drawing
panel by holding both sides. Remove the protective film (excluding cold plate materials) on the drawing panel and
insert it along the gap between the main hood panel and the housing. Then adjust it to the proper height.
●Install hood body
Fix the check valve as shown in Figure 5. Then align the hanging holes in the back of hood with the hooks of
hitching feet according to Figure 2 and press them together. Shake the body to check if it’s hung securely.
After the body is mounted, install the hitching foot stopper and gaskets to the M6 metal expansion pipe, and then
tighten the nuts (to prevent accidental decoupling of the body under external force).
●Install drawing panel
As shown in Figure 1-1, there is certain gap between the drawing panel and the top plate. Push the panel
against the top plate and then fix it to the top plate with ST4×18 screws.
(If installation method in Figure 1-2 is adopted there’s no need to adjust and install the drawing panel)
,
,
Figure 5
Figure 4
Φ190
Φ180 Φ170 Φ160
Φ150
Φ140
Range Hood
The exhaust wall hole diameter shall be close to that of the exhaust pipe, which shall not be too small. Otherwise, it
will cause poor exhaust efficiency, more noises and lower airflow, etc. The connection between the pipe and the
hole or the public flue must be sealed tightly to ensure that, the pipe and the check valve or public flue are
connected securely. The blades at the check valve connection or public flue connection must be flexible.
Note: During installation, straighten the aluminum foil
exhaust pipe to avoid noises in semi-stretched state.
Excess part may be cut with a wire cutter.
Φ185 aluminum foil exhaust pipe
Exhaust
pipe tape
Exhaust pipe
connection
Cut the excess part smaller than the wall hole
Exhaust pipe tape
Body
Check valve
Check valve connector
ST4X18 screw
Check valve seal
Buckle
Slot

User Manual
8
Plug in and 3 ticks from the buzzer will indicate qualified installation. Now the hood is in standby.
Light
Weak
Power
Switch Control Panel
Stir-frying/Strong
Maintenance
Press Power button, the icon is on and the hood is powered on waiting for
operation directions. When the Power icon is lit up and only the spotlight is on,
press the power button gently and the spotlight will be turned off directly; if the
fan is working under power-on mode, press the Power button, the power icon will
flash and the hood will enter delayed working state, and all working state will be
disabled after 1min (under delayed working state, all Stir-frying/Strong , Weak
and Light buttons will be disabled);When the Power button and all functions
are shut down.
“ ”
“ ”
“ ”
“ ” “ ”
“ ” “ ”
Under power-on mode, press “Stir-frying/Strong” button to enable the stir-frying
function. When the icon twinkles, press the button again to switch to strong level. In
case no operation is taken after enabling the stir-frying function, it will switch to
strong level automatically after 3 minutes and the icon will stay on under strong level.
Under standby mode, press the “Light” button once to turn on the light and repress to turn
off. Each press will trigger a tick from the buzzer. The “Light”button only controls the light.
Under power-on mode, press the “weak” button and the impellers will rotate at low speed
to inhale smoke (which shows the weak level is switched on). Repress the button to turn
off.
Range Hood
Warning
1.There is a fire risk if cleaning is not carried out in accordance with the instructions.
2.Cleaning and maintenance shall be conducted under outage. Electrical components such as motor,
switch, and connector shall not be spoiled by water so as to prevent from accidents.
3.It's prohibited to wash with water so as to prevent accidents.
4.Stove fire shall be extinguished timely when it is not used; do not flambe under the range hood and it's
prohibited to bake food under range hood directly to prevent range hood from damaging and causing
accidents.
5.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
6.Accessible parts may become hot when used with cooking appliances.

9
Removal of light
Raise the spotlight outward forcibly to remove it from
the hood. Pull out the connector to replace the spotlight.
Insert a small flat head screwdriver or something
sharp in the gap between the light cover and hood.
Insert a small flat head screwdriver or something
sharp in the gap between the light cover and hood.
●Removal of A817 light
●Removal of A815 light
Range Hood
Notice
Removal of Components
●The hood shall be cleaned and maintained regularly depending on the surroundings, so as to keep its cleanness
& efficiency and extend its service life. We recommend that:
Clean the exhaust fume collecting hood and hood body after each cooking.
To ensure smooth discharge of fumes, the filter screen shall be cleaned regularly according to actual situations.
Be careful to avoid damage when cleaning.
●It is recommended to use a neutral detergent to clean instead of strong detergents, and dry with a soft cloth, and
should avoid the contact between detergent and control buttons.
●Do not allow stains to stay on the surface of the hood for too long.
●Please do not use cleaning balls, brushes and other rough objects to clean the hood to prevent the body surface
from scratching.
●When cleaning or maintaining the hood, please wear protective gloves to prevent
wounding during wiping.
●Please check and clean the oil cup at regular basis. When the oil reaches above 2/3
of the cup, rotate the cup rightwards with a hand to toss away the oil, as shown in right.
●Do not touch the light bulb that has been turned on or just been turned off to avoid burns.
●Please unplug it during long-term shutdown, but please do not pull hard.
1.The machine body needs not to be disassembled in ordinary conditions. Disassembly shall be operated by
professional serviceman.
2. The electricity must be cut off before clean, installation or maintenance of range hood.
Note: The installation procedures are in reverse with the removal. Please wear protective gloves during operation
to prevent the sharp edge of metal from hurting your hands.
Warning
Raise the spotlight outward forcibly to remove it from
the hood. Pull out the connector to replace the spotlight.

Note: In case of installing the filer mesh, face the side with screw holes inwards.
Removal of filter mesh
Align the cross screwdriver with the screw hole and
raise it upward forcibly meanwhile rotating it counter-
clockwise about 120°,so as to remove the screw out
of the cross slot of the exhaust fume collecting hood.
Hold the bottom of the mesh with one hand, and
remove the screw on the other side with the other
hand by the cross screwdriver.
Hold the two screws on the filter mesh with both
hands and pull it down to detach the two prongs
inside from the filer mesh. Then pull the filter out as
per the arrow direction to remove it.
Note: Installation steps of the lights and switches
are opposite to the removal steps.
CXW- 20 0- 83 01CXW- 20 0- 83 01
8321
CXW- 20 0- 83 01
CXW- 20 0- 83 01CXW- 20 0- 83 01
8321
Removal of switch
Switch
●Removal of A817 switch
Removal steps
1. Pull out the plug;
2. Unscrew the four screws from the back of the main hood panel. Tilt the panel forward to a certain angle, and
then pull it up forcibly;
3. Remove the drawing panel from the main hood panel;
4. Use a cross screwdriver to unscrew the fastening screws on the cover to remove the cover;
5. Unscrew the fastening screws on the retaining ring to remove the retaining ring;
6. Unscrew the cap clockwise and take out the impeller vertically;
7. Remove the oil cup and the filter mesh by means of removing the fastening screws with a cross screwdriver.
Installation steps are opposite to the removal steps.
(When you install the impeller, please add some lubricating oil on the shaft hole of it. ）
Note: Step 3 is unnecessary if no drawing panel is installed.
Removal steps of the whole range hood
10
Range Hood
●Removal of A815 switch
After removing the spotlight, remove the two screws
on the switch with a cross screwdriver and move the
switch assembly diagonally upward to take it out
from the lamp hole for repair and replacement.
Untighten two screws on the small plate to remove
the plate.
Remove the two screws on the switch cover plate
and then rotate the cover plate to pull out the switch
assembly for maintenance and replacement.

11
Air passage
Electric motor
Housing
Mai n hood panel
Drawing panel
Oil cup
Retaining ring
Impeller
Cap
Cover plate
Filter mesh
Filter screen
Switch
Top cover plate
A817
Circuit diagram
220-240V~
LED
L
N
Function circuit
C
K4
K3
K2
K1
A817 Circuit Diagram
M
XP
Range Hood
yellow
orange
gray
black
blue
blue
red
Yellow/Green
blue
red
brown
brown
blue
Yellow/Green E
Terminal box
Control circuit

220-240V~ L
N
EL
EL
C
K4
K3
K2
K1
12
M
XP
Range Hood
A815 Circuit Diagram
Yellow/Green
blue
red
yellow
gray
black
blue
brown
brown
blue
Yellow/Green E
Function circuit
Terminal box
Control circuit
orange
blue
red
blue
red
Troubleshooting of General faults
The light is damaged or poorly
connected.
The impeller is loose, and the cap
is not tightened.
The power socket is not
grounded well.
Cause
No response after pressing any button
(e.g. the impeller does not rotate, or
the light is off)
Pressing the light switch, the light is
not lit.
Induced current exists on the hood
body may paralyze hands
Abnormal sound during impeller
running
FaultNo.
1
2
3
4
No oil in the oil cup after a period of time The body is tilt
5
Warning
The power plug is not connected
properly or there is power failure
1. When connecting or
replacing the plug, please
unplug the power plug.
2. If the range hood's
power cords are damaged,
it must be replaced by our
company's professional
maintenance staff.
3. The flame is strictly
prohibited being sucked
into the machine in case
of the accidents.

:
Edition: A/0
Publication Date：
Model A817、A815
August,1,2017
