Robe ANOLiS ArcSource Submersible II User manual

1
Version 1.4

2
ArcSource Submersible II
Table of contents
1. Introduction .................................................................................................................... 3
2. Safety information.......................................................................................................... 3
3. Mounting ......................................................................................................................... 3
4. ArcSource Submersible II connection with a control unit.......................................... 4
5. Technical specications ................................................................................................ 5
6. Mounting the ArcSource Submersible II into the installation sleeve ........................ 7
7. Cleaning and maintenance ........................................................................................... 7

3
1. Introduction
The ArcSource Submersible II has a housing crafted from the highest quality marine grade bronze meaning its
is capable to withstand the very harshest environmental conditions. The ArcSource Submersible II can easily
operate constantly submersed up to 10 m and o󰀨ers more than 10 di󰀨erent beam options for positioning free-
dom.
2. Safety information
The unit must be installed by a qualied electrician in accordance with all national
and local electrical and construction codes and regulations.
The persons who are in charge of installation should have the required qualications for this
type of work
Avoid using the unit in locations subject to possible impacts.
The unit is intended only for permanent underwater installation up to depth of 10 m.
Do not let the unit in frozen water.
All service works have to be done in a dry environment (e.g. in a workshop).
Avoid looking directly into the LED light beam at close range.
Immunity of the equipment is designed for electromagnetic environments E1, E2, E3 according to
the standard EN55103-2 ed.2 Electromagnetic compatibility. Product family standard for audio, video,
audiovisual and entertainment lighting control apparatus for professional use. Part 2: Immunity.
The product (covers and cables) must not be exposed to a high frequency electromagnetic eld higher
than 3V/m.
The installation company should check levels of possible interferences above the tested levels E1,E2,E3 given
by this standard (e.g. transmitters in surrounding area) before installing the equipment.
Emission of the equipment complies with the standard EN55032 Electromagnetic compatibility of multimedia
equipment – Emission Requirements according to class B.
3. Mounting
The ArcSource Submersible II can be arranged in any position orientation. The LED module body is mounted
on a bronze bracket for tilt adjustment . Use the Allen key no.6 to adjust desired tilt position of the LED module
by means of two tilt locks (1). For fastening the ArcSource Submersible II to the at surface use either three
holes or two semicircle slots which allows ne adjusting the xture in a pan direction.

4
Wiring of the ArcSource Submersible II:
Wire Red wire Blue wire Orange wire
Function +24V Ground Communication
4. ArcSource Submersible II connection with a control unit
Maximum cable length between the ArcSource Submersible II and the SubDrive 1
(Subdrive 4) depends on the operating mode:
Minimum mode: 100 m
Medium mode: 50 m
Maximum mode: 25 m
Example of connection:

5
5. Technical specications
ELECTRICAL
Input voltage :24 V DC
Typical Power Consumption: 35 W (@ 350 mA), 70 W (@ 700 mA), 100 W (@ 1000 mA)
Max. Input Current: 1000 mA (max. per channel)
OPTICAL
Light Source: 6 x 15 W Multichip LED
Colour Variants: RGBW (W - 6500 K), RGBA, PW (W - 3000 K)
Beam Angle:
Symmetrical: 7°, 13°, 20°, 30°, 40°, 60°, 90°
Bi-symmetrical: 7° x 30°, 30° x 7°, 7° x 60°, 60° x 7°, 35° x 70°, 70° x 35°, 10° x 90°, 90° x 10°
Projected Lumen Maintenance: 60.000 hrs (L70 @ 25 °C / 77 °F)
CONTROL
Compatible drivers: SubDrive 1, SubDrive 4
PHYSICAL
Weight: 9.5 kg / 20.9 lbs
Housing: Marine Bronze, Tempered Glass
Connection: Cable Submersible PBS-USE 3x1.5 mm2 (CE), Cable Submersible L0390 (US)
Mounting Method: Yoke, Floor Stand (optional)
Adjustability: +35°/ -90°
Protection factor: IP68 10m rating (CE), maximum depth of 10 m (US)
IK Rating: IK10
Cooling System: Convection
Operating Ambient Temperature: +1 °C / +45 °C (34 °F / +113 °F )
Operating Temperature: +55 °C @ Ambient +45 °C (+131 °F @ Ambient +113 °F )
OPTIONAL ACCESSORIES
SubDrive 1
SubDrive 4
Wallmount installation sleeve (P/N 10980285)
Floor Stand ArcSource 24 MC Submersible 5mm (P/N10980315)
INCLUDED ITEMS
ArcSource Submersible II
User manual

6
DIMENSIONS
mm [inch]
ArcSource Submersible II
Installation sleeve

7
6. Mounting the ArcSource Submersible II into the wallmount
installation sleeve
1. Unscrew the bracket from the ArcSource Submersible II.
2. Insert the ArcSource Submersible II (4) into chassis (5) and fasten it on both sides it by means of two
bolts (7) with rubber washers (6), 6 mm long spacers ( 10) and nuts M8 (9). These parts (6,7,9,10) are
components of the wallmount installation sleeve (8).
3. Insert Allen bolts M5x45 (1) with spring washers (2) to the 30mm spacers (3) and used them to screw
the chassis (5) to the installation sleeve (8) (before inserting chassis, pull the ArcSource Submersible II´s
cable through the aperture in the wallmount installation sleeve.
4. Screw the metal collar (13) to the chassis (5) with two Allen keys M4x12 (11) and washers (12).
5. Insert the at rubber gasket (14) into metal collar (13).
6. Put the glass (15) on the rubber gasket (14).
7. Put the shaped rubber gasket (16) on the glass (15).
8. Screw the top metal ange (17) by means of the six at head screws M6x30 (18) to the wallmount installation
sleeve.
9. Connect the ArcSource Submersible II to the SubDrive 1 (SubDrive 4).
7. Cleaning and maintenance
Disconnect from the mains before starting any maintenance work
Maintenance and service operations are only to be carried out by a qualied person.
Should you need any spare parts, please use genuine parts.
June 14, 2021
Copyright © 2021 Robe Lighting - All rights reserved
All Specications subject to change without notice
Made in CZECH REPUBLIC by ROBE LIGHTING s.r.o. Palackeho 416/20 CZ 75701 Valasske Mezirici
