Roberts CR9953 User manual

ROBERTS
Sound for Generations
CR9953
2 Band Auto Set Dual Alarm
Clock Radio
Please read this manual before use

Contents .................................................................................. 1
Controls ................................................................................2-4
Switching on ............................................................................ 5
Setting the time ....................................................................... 5
Setting the date ....................................................................... 6
Setting alarm times ................................................................. 6
Setting Alarm 1........................................................................7
Setting Alarm 2........................................................................7
Alarm modes ........................................................................... 8
Weekday alarm ....................................................................... 8
Weekend alarm ....................................................................... 9
Everyday alarm ....................................................................... 9
Setting the alarms to wake to buzzer ................................... 10
Setting the alarms to wake to radio ......................................10
Checking the alarm times .....................................................11
1
Contents Listening to the radio............................................................. 11
Snooze control ......................................................................12
Sleep timer ............................................................................ 12
Dimmer switch ....................................................................... 13
Back-up battery ..................................................................... 13
Changing the back-up battery ..............................................14
Time zones ............................................................................15
Specifications ........................................................................16
General ..................................................................................17
Guarantee..............................................................................18

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
Time Zone
Year
Date
Time
Up
Down Radio On/Off
Sleep Week Mode
1
2
1. Time button
2. Sleep button
3. Week Mode button
4. Up button
5. Radio On/Off button
6. Down button
7. Alarm 1 button
8. Snooze button
9. Alarm 2 button
10. Date button
11. Time Zone button
Controls (top)
2
976
5
4
3
2
1
10 8
11

3
12. Day of week indicators
13. AM indicator
14. Alarm indicator
15. Clock display
16. Low battery indicator
17. Tuning dial
Controls (front)
1513 16
14
12
17

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
MW
FM
VOLUME
Buzz
Buzz
Off
Off
1
2
Radio
Radio
Low
High
Dimmer
18
19
20 23
22
21
18. Alarm 1 switch
19. Alarm 2 switch
20. Dimmer switch
21. Tuning control
22. Waveband switch
23. Volume control
Controls (left and right side)
4

Up
Down
Time
5
Switching on
1. Placeyourclock radioon aflatsurface. Plugthe powercordintothewall
socket and switch on.
2. After a few seconds the time, day and date will set automatically. Your
clock radio is fitted with a long life back-up battery to maintain the
factory set time, day and date. The built in calendar function will
automatically adjust for summer/winter time.
See section on Backup battery on page 13.
Should the time require adjustment follow the procedure shown in the
next section.
Setting the time
1. Press and hold down the Time button.
2. Whilst holding down the Time button press the Up or Down buttons
to set the time. Release the buttons when the correct time is reached.
The clock uses a 12 hour display with an AM indicator. Ensure that the
correct 12 hour cycle is selected.
1
22
Date Month
Low
Batt
AM
Sun
Mon
Tue
Wed
Thu
Fri
Sat
TUNING
with Instant Time Set
Computerised Time Control System
CR 9953
CALENDAR CLOCK RADIO
FM
MW
AUTOSET
2
1
C H R O N O L O G I C
IV
92
MHz
600
540
88
Date
Month
Low
Batt
AM

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
Up
Down
Date
Up
Down
Year
Date
Time
6
Setting the date
1. To set the year hold down both Time and Date buttons. The display
will change to show year.
2. Whilst holding down Time and Date buttons set correct year using
Up or Down buttons. When the Time and Date buttons are released
the display will revert to showing the time.
3. To set date hold down the Date button.
4. Whilst holding down the Date button set correct dateusing Up or Down
buttons.
12
1
34
Setting alarm times
Your alarm clock radio has 2 separate alarms which can be set to activate
at different times. The alarms can be set to wake you by either the buzzer
or the radio.
Date
Month
Low
Batt
AM
Date
Month
Low
Batt
AM

Up
Down
Up
Down
7
Setting alarm 1
1. Press and hold down the Alarm 1 button.
2. Whilst holding down the Alarm 1 button press the Up or Downbuttons
to set the alarm time. Release the buttons when the correct alarm time
is reached. The clock uses a 12 hour display with an AM indicator.
Ensure that the correct 12 hour cycle is selected.
3. Set the Alarm 1 switch to the Buzz or Radio position.
2
1
3
2
12
23
Setting alarm 2
1. Press and hold down the Alarm 2 button.
2. Whilst holding down the Alarm 2 button press the Up or Down buttons
to set the alarm time. Release the buttons when the correct alarm time
is reached. The clock uses a 12 hour display with an AM indicator.
Ensure that the correct 12 hour cycle is selected.
3. Set the Alarm 2 switch to the Buzz or Radio position.

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
Alarm modes
Your clock radio has three alarm modes for each of the alarms. The alarm
modes are Weekdays only - the alarm will switch on Monday to Friday.
Weekends only - the alarm will switch on Saturday and Sunday only.
Everyday - the alarm will switch on everyday.
Weekday alarm
1. Press and hold down the Alarm 1 or Alarm 2 buttons (depending on
which alarm you wish to set mode for).
2. Whilst holding down Alarm 1 or Alarm 2 buttons repeatedly press and
release the Week Mode button until Mon to Fri indicators are lit.
3. Set the Alarm 1 or Alarm 2 switch to the Buzz or Radio position.
8
1
3
2

9
Weekend alarm
1. Press and hold down the Alarm 1 or Alarm 2 buttons (depending on
which alarm you wish to set mode for).
2. Whilst holding down Alarm 1 or Alarm 2 buttons repeatedly press and
release the Week Mode button until Sat and Sun indicators are lit.
3. Set the Alarm 1 or Alarm 2 switch to the Buzz or Radio position.
Everyday alarm
1. Press and hold down the Alarm 1 or Alarm 2 buttons (depending on
which alarm you wish to set mode for).
2. Whilst holding down Alarm 1 or Alarm 2 buttons repeatedly press and
release the Week Mode button until all the days of the week indicators
are lit.
3. Set the Alarm 1 or Alarm 2 switch to the Buzz or Radio position.
2
13
3
12

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 10
Setting the alarms to wake to buzzer
1. Set the alarm time as previously described. Set the Alarm 1 or Alarm
2 switch to the “Buzz” position. The Alarm indicator will light.
2. The buzzer alarm will sound every day at the preset time for 1 hour. To
switch off the alarm until the next day press the Alarm 1 or Alarm 2
button.
3. To turn off the alarms permanently set the Alarm 1 or Alarm 2 switch
to the 'Off' position.
Setting the alarms to wake to radio
1. Set the alarm time as previously described. Set the Alarm 1 or Alarm
2 switch to the “Radio” position. The Alarm indicator will light.
2. Ensure that the volume is set to the correct level and the desired station
is tuned in.
3. The radio alarm will sound every day at the preset time for 1 hour. To
switch off the alarm until the next day press the Radio On/Off button.
To turn off the alarms permanently set the Alarm 1 or Alarm 2 switch
to the “Off” position.
12
1
33
11
33
2
3

11
Checking alarm times
1. Press and hold down either Alarm 1 or Alarm 2 buttons. The display
will change from normal time to alarm time - days of the week indicators
will show days of the week on which alarm will activate. Release the
Alarm button to return to normal time.
Listening to the radio
1. Switch on the radio by pressing the Radio On/Off button. Select the
required waveband using the Waveband switch.
2. Tune in to the desired station using the Tuning control. Adjust volume
using the Volume control.
3. The Wire aerial located on the rear of your clock radio is for FM
reception.Thewireshouldbefullyextendedandpositioned foroptimum
reception.
For MW reception there is a built in ferrite aerial. Rotate your clock radio
to the position giving best reception.
22
11
1

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
Up
Down
Snooze control
The radio or buzzer alarm can be silenced for 9 minutes by pressing the
Snooze button. This sequence can be repeated whilst the alarm is
sounding.
Sleep timer
You can program you clock radio to play the radio for up to 90 minutes and
then switch off.
1. Press the Sleep button. The display will show the sleep time.
2. To increase or decrease the amount of time the radio will play before
switching off, hold down the sleep button and increase or decrease the
sleep time using the Up or Down buttons (maximum 90 minutes -
minimum 2 minutes).
3. To cancel the sleep timer before the sleep time has elapsed press the
Snooze button.
12
2
1
3
2

13
Dimmer Switch
The Dimmer switch locatedon theleft side ofyour clockradiowill allowyou
to adjust the intensity of the clock display to suit room brightness.
Backup battery
As with all batteries, eventually the built in lithium battery will need to be
replaced.Anumberoffactors,suchas thelength oftime betweenthedateyour
clock radio was manufactured and the date you plugged it in for the first time,
determine the amount of time before replacement. During this initial storage
period the lithium backup battery is supplying power to your clock radios
computer memory. Once you connect your clock radio to the household AC
mains supply the battery no longer supplies power to your clock radio. A fresh
backup battery can supply power to your clock radio’s computer memory for 2
years even if it is never connected to a mains supply. If your clock radio was
connectedtotheACmainssupplywithinafewmonthsafteritwasmanufactured
and you experience only short interruptions to the mains supply, your battery
may last for up to 2-3 years or even longer.
When the power drops below a certain level the Low battery indicator will
light. When you see this indicator you should change the battery as soon as it
is convenient to do so.
See following page for details on battery replacement.
Date
Month
Low
Batt
AM

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
Changing the backup battery
1. Purchase a replacement lithium backup battery type CR2032 or
equivalent.
2. Remove the fresh battery from its packaging so that it is ready to install.
3. Important. Maintain connection to AC mains supply during battery
replacement. This will provide power whilst the original battery is
removed.
4. Use a small screwdriver to remove the two small screws securing the
battery holder on cabinet back.
5. Remove the battery holder from cabinet.
6. Remove old battery from holder noting polarity. Replace new battery
with same polarity.
7. Replace the holder into cabinet back.
14
8. Refit two small screws to secure holder and confirm that the “Low Batt”
indicator is not lit.

15
Time Zones
Your clock radio is set up to UK time zone 00 GMT(UTC). Should you
wish to take your clock radio to other countries the time zone will need to
be reset.
1. Press and hold down the Time Zone button - the display will show the
time zone e.g 00.
2. Whilst holding down the Time Zone button adjust the time zone using
the Up or Down buttons. See the following table for details of time
zones and their offsets relative to GMT.
Zone Offset (Hours)
12 GMT +/-12
13 GMT +11
14 GMT +10
15 GMT +9
16 GMT +8
16 GMT +7
18 GMT +6
19 GMT +5
20 GMT +4
21 GMT +3
22 GMT +2
23 GMT +1
Zone Offset (Hours)
00 GMT
01 GMT -1
02 GMT -2
03 GMT -3
04 GMT -4
05 GMT -5
06 GMT -6
07 GMT -7
08 GMT -8
09 GMT -9
10 GMT -10
11 GMT -11

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 16
Specifications
Power Requirements
Mains AC 230 volts, 50Hz only
Back-up Battery 1 x CR2032 Lithium (2-3 year life)
Frequency Coverage
FM 87.5 - 108MHz
MW 522 - 1610kHz
Circuit Features
Loudspeaker 8 ohms
Output power 250mW
Aerial System FM Wire Aerial
MW Built-in Ferrite aerial
The Company reserves the right to amend the specification without notice.

Fuse
This apparatus must be protected by a 3A fuse (BS1362) in a 13A plug
(BS1363). If another type of plug is used a 5A fuse should be fitted in the
plug, adaptor or distribution board.
IF IN DOUBT - CONSULT A QUALIFIED ELECTRICIAN.
General
Do not allow this unit to be exposed to water or steam. It is recommended
that the FM band be used wherever possible as better results in terms of
quality and freedom from interference will usually be obtained than on the
MW band.
Mains supply
The CR9953 will operate from a supply of AC 230volts, 50Hz only.
For your convenience this product is supplied with a plug which is fitted with
a fuse of the appropriate rating. If the plug supplied is not suitable for your
socket outlet, it should be removed by unscrewing the plug top, the terminal
screws and removing the cable.
The correct style of plug to suit your household together with a correctly
rated fuse should be fitted.
IF IN DOUBT - CONSULT A QUALIFIED ELECTRICIAN
As these colours may not correspond
with the coloured markings identifying
the terminals in your plug, proceed as
follows:-The wire coloured BLUE must
be connected to the terminal marked N
or coloured BLACK.
The wire coloured BROWN must be
connected to the terminal marked L or
coloured RED.
IMPORTANT. DO NOT make any connection to the larger terminal which
is marked with the letter E or by the safety earth symbol or
coloured Green or Green-and-yellow.
The wires in the mains lead are coloured in accordance with the following
codes :- BLUE - NEUTRAL BROWN - LIVE
17
3 amp
(Earth)
E
(Live)
Brown
Blue
(Neutral)
L
N
Mains Lead

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 18
This radio is guaranteed for twelve months from the date of delivery to the original owner against failure due to faulty workmanship or component
breakdown, subject to the procedure stated below. Should any component or part fail during this guarantee period it will be repaired or replaced free of
charge.
The guarantee does not cover: 1. Damage resulting from incorrect use.
2. Consequential damage.
3. Product with removed or defaced serial numbers.
Procedure:
Any claim under this guarantee should be made through the dealer from whom the instrument was purchased. It is likely that your Roberts' dealer will be
able to attend to any defect quickly and efficiently but should it be necessary the dealer will return the instrument to the company’s service department
for attention. In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio
service department at the address shown on the rear of this manual before taking further action.
Guarantee
These statements do not affect the statutory rights of a consumer.

Issue 1
ROBERTS RADIO TECHNICAL SERVICES
97-99 Worton Road
Isleworth Middlesex
TW7 6EG
Technical Helpline :- 020 8758 0338 (Mon-Fri)
