Roberts MessageR User manual

Please read this manual before use
ROBERTS
DAB / FM RDS Digital Clock Radio
Enjoy Listening

MessageR digital radio features..........................................2
Display icons .......................................................................2
Controls ........................................................................... 3-5
Battery operation .................................................................6
Using the radio for the first time...........................................7
Operating your digital radio .................................................8
Selecting a station - DAB.....................................................9
Secondary services - DAB.................................................10
Display options - DAB.................................................. 10-12
Finding new stations - DAB ...............................................12
Manual tuning - DAB .........................................................13
Signal strength display - DAB............................................13
Dynamic Range Control (DRC) - DAB...............................14
Operating your radio - FM auto-tune .................................15
Manual tuning - FM............................................................16
Display options - FM.................................................... 17-18
Stereo / mono setting - FM (headphones only) .................18
Presetting stations.............................................................19
Recalling a preset station ..................................................20
Favourite stations ..............................................................21
Recording a voice message ..............................................22
Playing back a voice message ..........................................22
Contents
Setting the alarm times................................................ 23-25
Cancelling alarms..............................................................25
To view the alarm settings .................................................26
Snooze function.................................................................26
Setting the clock format.....................................................27
Setting the date format ......................................................28
Sleep function....................................................................29
Nap timer...........................................................................30
Display backlight dimmer...................................................31
Moon light feature..............................................................31
Display backlight................................................................32
Key tone adjustment..........................................................32
Software version................................................................33
System reset......................................................................34
Headphone socket.............................................................35
Auxiliary input socket.........................................................36
USB socket (for software upgrades)..................................36
Cautions ............................................................................37
Specifications ....................................................................37
Circuit features ..................................................................37
Guarantee..........................................................................38
1

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 2
MessageR digital radio features
The Roberts MessageR digital radio provides the following range of features
in an attractive compact unit:-
• Radio for DAB and FM (with RDS) broadcasts.
• 20 station presets (10 for DAB and 10 for FM).
• 8 favourite station memories (4 for DAB and 4 for FM).
• 2 voice message memories with up to 10 seconds record duration.
• Two alarm timers with snooze feature to wake you to either buzzer,
radio alarm or voice message.
• Nap timer to set your radio to wake you after a predetermined interval
(up to 2 hours).
• Adjustable sleep timer which can be set to turn the radio off after
between 15 and 120 minutes.
• Clock display with time when in standby.
• A 3.5mm Auxiliary input socket for playing audio from MP3 players,
iPod devices or other audio equipment.
• A standard 3.5mm headphone socket for private listening.
Display icons
a. Battery capacity indicator
b. Alarm 1 indicator
c. Alarm 2 indicator
d. DAB indicator
e. FM indicator
f. Nap timer indicator
g. Sleep / Snooze indicator
h. Signal strength indicator
i. Clock digits
a b c d e f g h
i

3
Controls (Top)
1. Sleep button
2. Backlight button
3. Alarm / Menu button
4. On / Off button
5. DAB / FM button
6. Auto Tune button
7. Favourite station buttons 1- 4
8. Nap timer button
9. Message 2 button with LED
10. Message 1 button with LED
11. Advanced / Info button
12. Memo button
12 3 4
6
5
7
8910
11
12

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
Controls (front)
13. Microphone
14. LCD display
15. Tuning / Select control
16. Volume control
17. Loudspeaker
18. Moon light
4
13
14
15
16
17
18

5
0.8A
Controls (rear)
19. Buzzer volume control
20. Battery compartment
21. USB socket (for software upgrades)
22. Wire DAB / FM aerial socket
23. Auxiliary input socket
24. DC input socket
25. Headphone socket
21
19
20
25 24 23 22

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 6
0.8A
Battery operation
1. Remove the battery cover on the back of the unit by pushing up the
tab and lifting the cover out of its locating slots.
2. Insert four LR14 (C size) batteries into the spaces in the compartment.
Take care to ensure all batteries are inserted with the correct polarity
as shown inside the battery compartment. Replace the battery cover.
3. The low battery indicator flashing, reduced power, distortion and
a ‘stuttering’ sound are all signs that the batteries may need replacing.
4. If the radio is not to be used for any extended period of time it is
recommended that the batteries are removed from the radio.
We would recommend for economy that the radio is used via the AC
adaptor whenever possible with battery operation for occasional use
only.
IMPORTANT: The batteries should not be exposed to excessive heat
such as sunshine, fire or the like.After use, disposable batteries should
if possible be taken to a suitable recycling centre. On no account
should batteries be disposed of by incineration.
1

7
Using the radio for the first time
1. Place your radio on a flat surface.
2. Plug the wire DAB / FM aerial into the aerial socket on the rear of the
unit. Fully extend the wire aerial and place the aerial so that it is as
straight as possible extending either above or below the radio.
3. Insert the adaptor plug into the DC socket located on the rear of your
radio. Plug the adaptor into a standard 13 amp mains socket outlet.
The display will show 'ROBERTS' for a few seconds and will then
show 'NO CLOCK' and the unit will enter the standby mode. During
this time the radio is scanning to find a DAB radio signal. After a short
time the current time will appear on the display.
Note: that during this time the display will not show any scanning
message for this initial scan.
4. If no signal is found, 'NO CLOCK' will be displayed. It may be necessary
to relocate your radio to a position giving better reception. You should
then carry out a scan to find stations as described on page 12.
IMPORTANT: The mains adaptor is used as the means of connecting
the radio to the mains supply. The mains socket used for the radio must
remain accessible during normal use. In order to disconnect the radio
from the mains completely, the mains adaptor should be removed from
the mains socket outlet completely.
0.8A
2

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 8
Operating your digital radio
1. Press the On / Off button to switch on your radio.
When first switched on, the radio will be in DAB mode. After each use
the radio will remember the mode used and then switch on in that
mode the next time that it is used.
2. If the radio has been used before, the last used station will be selected.
3. If this is the first time that the radio has been used a quick scan of
the Band III DAB channels will be carried out. During the scanning
process the display will show the progress of the station search. The
number on the right of the display is the number of stations that have
been found.
4. When the scan is completed the first station (in numeric-alpha order
0...9, A...Z will be selected. The first station in the list of stations found
during scanning will be played. The display will show the station name.
5. If no signals are found then 'OFF AIR' will be displayed and it may be
necessary to relocate your radio to a position giving better reception.
You should then carry out a scan to find stations as described on page
12.
• Your radio has an indicator on the display to indicate the strength
of the DAB radio signal being received.
1

9
Selecting a station - DAB
1. Press the On / Off button to switch on your radio.
2. Press and release the DAB / FM button until the DAB mode is selected.
The display will show the name of the radio station currently selected.
3. Rotate the Tuning / Select control to step through the list of available
stations.
4. When the desired station name appears on the display, press and
release the Tuning / Select control to select the station. The display
will show 'TUNING' while your radio finds the new station.
5. Adjust the Volume control to the required setting.
Note: If after selecting a station the display shows 'OFF AIR' it may be
necessary to relocate your radio to a position giving better reception.
1
2
3,4
5

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 10
Secondary services - DAB
1. Certain radio stations have one or more secondary services associated
with them. If a station has a secondary service associated with it then
the secondary service will then appear immediately after the primary
service as you rotate the Tuning / Select control.
2. To tune to the secondary service, press and release the Tuning /
Select control. Most secondary services do not broadcast continually
and if the selected service is not available, the radio will re-tune to the
associated primary service.
Display options - DAB
Your radio has a range of display options when in DAB mode:-
1. Press and release the Info button to cycle through the various options.
All display options except the text display will revert to the clock display
after about 10 seconds.
a. Station name Displays the station name being
listened to.
b. Scrolling text Displays scrolling text messages such
as artist/track name, phone in number,
etc.
a
1,2
b
1

11
c. Programme type Displays the type of station being
listened to e.g. Pop, Classic, News, etc.
d. Multiplex Name Displays the name of the DAB multiplex
to which the current station belongs.
e. Time Displays the current time.
f. Date Displays the current date.
c
d
e
f

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 12
g. Frequency and channel Displays frequency and channel number
for the currently tuned DAB station.
h. Bit rate Displays the digital audio bit rate for the
currently tuned DAB station.
i. Signal error Displays the bit error rate for the
currently tuned DAB station.
g
h
i
Finding new stations - DAB
From time to time, new DAB radio stations may become available. Or you
may have moved to a different part of the country. In this case you may
need to cause your radio to scan for new stations.
1. Press and release the Auto Tune button.
2. Your radio will perform a scan of the Band III DAB channels. As new
stations are found, the station counter on the right-hand side of the
display will increase and stations will be added to the list.
1

13
Manual tuning - DAB
Manual tuning allows you to tune your radio to a particular DAB frequency
in Band III. Any new stations found will be added to the station list. This
function can also be used to assist the positioning of the aerial or the radio
to optimise reception for a specific channel or frequency. Note that UK
DAB stations are located in the range of channels 11B to 12D.
1. Press and hold the Advanced / Info button so that the display shows
'MANUAL'. Press and release the Tuning / Select control to enter the
manual tuning mode.
2. Rotate the Tuning / Select control to select the desired DAB channel.
Press and release the Tuning / Select control to tune to the chosen
frequency.
3. If a signal is present, this will be indicated on a signal strength display.
The minimum signal marker ( ) shows the minimum signal strength
needed for good DAB reception. The signal indicator chevrons go up
or down showing the changing signal strength as you adjust the wire
aerial or your radio position. Press and release the Tuning / Select
control again to return to the normal DAB tuning mode.
Signal strength display - DAB
1. Press and release the Tuning / Select control to show the signal
strength display. The minimum signal marker ( ) shows the minimum
signal strength needed for good DAB reception. The signal indicator
chevrons increase or decrease showing the changing signal strength
as you adjust the wire aerial or your radio position.
2. Press and release the Tuning / Select control to return to the normal
radio display.
1
1-3
1,2

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 14
Dynamic Range Control (DRC) - DAB
The DRC facility can make quieter sounds easier to hear when your radio
is used in a noisy environment.
There are three levels of compression:
DRC 0 No compression applied. (default)
DRC 1/2 Medium compression applied.
DRC 1 Maximum compression applied.
1. Press the On / Off button to switch on your radio.
2. Press and release the DAB / FM button until the DAB band is selected.
3. Press and hold the Advanced / Info button.
4. Rotate the Tuning / Select control until 'DRC VAL' appears on the
display. Press and release the Tuning / Select control. The display
will show the current DRC value.
5. Rotate the Tuning / Select control to select the required DRC setting
(default is 0).
6. Press and release the Tuning / Select control to confirm the setting.
After several seconds the display will return to the normal radio display.
Note: Not all DAB broadcasts are able to use the DRC function. If the
broadcast does not support DRC, then the DRC setting in the radio will
have no effect.
3
4-6
2

15
Operating your radio - FM auto-tune
1. Fully extend the wire aerial located on the rear of your radio. Place
the wire antenna so that it is as straight as possible extending either
above or below the radio.
2. Press the On / Off button to switch on your radio.
3. Press and release the DAB / FM button until the FM band is selected.
4. Press and release the Auto Tune button to cause your radio to search
from low frequency to high frequency and to stop automatically when
it finds a station of sufficient strength.
5. After a few seconds the display will update. The display will show the
frequency of the signal found. If the signal is strong enough and there
is RDS data present then the radio may display the station name.
6. To find other stations press and release the Auto Tune button as
before.
7. Press and hold down the Auto Tune button for 2 - 3 seconds to cause
your radio to search from high frequency to low frequency and to stop
automatically when it finds a station of sufficient strength.
8. When the end of the waveband is reached your radio will recommence
tuning from the opposite end of the waveband.
9. Adjust the Volume to the required setting.
10. To switch off your radio, press the On / Off button.
4-7
3
2,10
9
Note:
If you find that FM reception is poor, try repositioning the wire aerial. Fully
extend the wire aerial located on the rear of your radio. Place the wire
antenna so that it is as straight as possible extending either above or
below the radio. If you find that an FM broadcast has a lot of background
hiss, this may often be reduced by setting the radio into Mono reception
mode for the current FM station. Please refer to the section "Stereo / Mono
setting - FM" on page 18 for further details.

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 16
Manual tuning - FM
1. Fully extend the wire aerial located on the rear of your radio. Place
the wire antenna so that it is as straight as possible extending either
above or below the radio.
2. Press the On / Off button to switch on your radio.
3. Press and release the DAB / FM button until the FM band is selected.
4. Rotate the Tuning / Select control to tune to a station. The frequency
will change in steps of 50kHz.
If the radio is tuned to a station of sufficient signal strength with RDS
information present, then the display may change to show the station
name.
5. When the waveband end is reached the radio will recommence tuning
from the opposite waveband end.
6. Set the Volume to the desired setting.
7. To switch off your radio press the On / Off button.
Note:
If you find that FM reception is poor, try repositioning the wire aerial. Fully
extend the wire aerial located on the rear of your radio. Place the wire
antenna so that it is as straight as possible extending either above or
below the radio. If you find that an FM broadcast has a lot of background
hiss, this may often be reduced by setting the radio into Mono reception
mode for the current FM station. Please refer to the section "Stereo / Mono
setting - FM" on page 18 for further details.
3
2,7
6
4

17
Display options - FM
Your radio has a range of display options for FM mode:-
The Radio Data System (RDS) is a system in which inaudible digital
information is transmitted in addition to the normal FM radio programme.
RDS offers several useful features.The following are available on your radio.
1. Press and release the Info button to cycle through the various options.
All display options except the text display will revert to the clock display
after about 10 seconds.
a. Frequency Displays the frequency of the station being
listened to.
b. Station name Displays the name of the station being
listened to.
c. Programme type Displays type of station being listened to
e.g. Pop, Classic, News, etc.
d. Scrolling text Displays scrolling text messages such
as artist/track name, phone in number,
etc.
a
1
c
d
b

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 18
e. Time Displays the current time.
f. Date Displays the current date.
Note: If no RDS information is available, the radio will be unable to display
the station name, scrolling text and programme type information.
e
f
Stereo / Mono setting - FM (headphones only)
Your radio will play stereo FM broadcasts in stereo (via headphones)
provided that the received signal is of adequate strength. However, as
a stereo signal becomes weaker the audio signal will become poorer. It
may be preferable to force the radio to play the station in mono in order
to reduce the level of background hiss.
1. Press the On / Off button to switch on your radio.
2. Tune to the required FM radio station as previously described (see
pages 15, 16).
3. Press and release the Tuning / Select control so that the display
shows 'MONO'. The radio will play the current FM station in mono.
4. If you wish to cancel the Mono override while listening to the currently
tuned radio station, press and release the Tuning / Select control
so that the display shows 'AUTO'. The radio will play the current FM
station in stereo if the signal is sufficiently strong.
1
3,4

19
Presetting stations
You may store your preferred DAB and FM radio stations to the preset
station memories. There are 20 memory presets in your radio, 10 for
DAB and 10 for FM. Presets are remembered by your radio in the event
of a power failure.
The procedure for setting presets and using them to tune stations is the
same for FM and DAB modes, and is described below.
1. Press the On / Off button to switch on the radio.
2. Press the DAB / FM button to select the desired waveband DAB or
FM.
3. Tune to the required station as previously described.
4. Press and hold the Memo button. The display will show, for example,
'Empty 01' if no station has been stored to that preset.
5. Rotate the Tuning / Select control to select the desired preset station
number under which you wish to store the station.
6. Press and release the Tuning / Select control. The display shows,
for example, '01 SAVED'. The station will be stored under the chosen
preset. Repeat this procedure for the remaining presets.
7. Stations which have been stored in preset memories may be overwritten
by following the above procedure.
2
1
5,6
4
