Roborock H6M1A User manual

Roborock handheld cordless vacuum cleaner
instruction manual

01
Safety Information
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
• READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE).
• Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
WARNING
To reduce the risk of fire, electric shock or injury：
• Do not use on wet surfaces. Do not expose to rain. Store indoors.
• Do not allow to be used as a toy. Close attention is necessary when used by or near children, pets or plants.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors,
or dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not
run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle Power Supply, including Power Supply plug, and Power Supply terminals with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that
may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not use without dust bag.
• Prevent unintentional starting. Ensure the switch is in the off-position before picking up or carrying the appliance. Carrying
the appliance with your finger on the switch or energizing appliance that have the switch on invites accidents.
• Recharge only with the Power Supply specified by the manufacturer. A Power Supply that is suitable for one type of battery
pack may create a risk of fire when used with another battery pack.
• Use appliances only with specifically designated battery packs. Use of any other battery packs may create a risk of injury
and fire.

02
SAVE THESE INSTRUCTIONS
Safety Information
• When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
• Do not use a battery pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit unpredictable
behavior resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above 130°C may
cause explosion.
• Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range specified in
the instructions. Charging improperly or at temperatures outside of the specified range may damage the battery and increase
the risk of fire.
• Have servicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of
the product is maintained.
• Do not modify or attempt to repair the appliance or the battery pack except as indicated in the instructions for use and care.
• Always turn off this appliance before connecting or disconnecting motorized nozzle.
Household use only.

03
Safety Information
IMPORTANT SAFETY INSTRUCTIONS
L’utilisation d’un appareil électrique demande certaines précautions:
• LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CET APPAREIL).
• Le non-respect des mises en garde et des instructions peut causer des chocs électriques, des incendies et/ou des
blessures graves.
AVERTISSEMENT.
Pour réduire les risques d’incendie, de choc électrique ou de blessure:
• Ne pas aspirer des déchets humides. Ne pas exposer à la pluie. Ranger à l’intérieur.
• Ne pas permettre aux enfants de jouer avec l’appareil. Une attention particulière est nécessaire lorsque l’appareil est utilize par des
enfants ou à proximité de ces derniers.
• N’utiliser que conformément à cette notice avec les accessories recommandés par le fabricant.
• Ne pas utiliser si le cordon ou la fiche est endommagé. Retourner l’appareil à un atelier de reparation s’il ne fonctionne pas bien, s’il est
tombé ou s’il a été endommagé, oublié à l’extérieur ou immergé.
• Ne pas tirer soulever ni trainer l’appareil par le cordon. Ne pas utiliser le cordon comme une poignée, le coincer dans l’embrasure d’une
porte ou l’appuyer contre des arêtes vives ou des coins. Ne pas faire rouler l’appareil sur le cordon. Garder le cordonà l’écart des
surfaces chaudes.
• Ne pas débrancher en tyrant sur le cordon. Tirer plutôt la fiche.
• Ne pas manipuler le chargeur, y compris la prise du chargeur, et les bornes du chargeur avec les mains mouillées
• N’insérer aucun objet dans les ouvertures. Ne pas utiliser l’appareil lorsqu’une ouverture est bloquée. S’assurer que de la poussière, de
la peluche, des cheveux ou d’autres matières ne réduisent pas le debit d’air.
• Maintenir les cheveux, les vêtements amples, les doigts et toutes les parties du corps à l’écart des ouvertures et des pieces mobiles.
• User de prudence lors du nettoyage des escaliers.
• Ne pas aspirer des liquids inflammables ou combustibles, comme de l’essence, et ne pas faire fonctionner dans des endroits où
peuvent se trouver de tells liquides.
• Ne pas aspirer de matières en combustion ou qui dégagent de la fumée, comme des cigarettes, des allumettes ou des cendres chaudes.

04
• Ne pas utiliser l’appareil si le sac à poussière ou le filter n’est pas en place.
• Emêcher une mise en marche accidentelle. S’assurer que l’interrupteur est à la position arrêt avant de lever ou de
déplacer l’appareil. Transporter l’appareil en gardant un doigt sur l’interrupteur, ou mettre sous tension un appareil
dont l’interrupteur est à la position marche peut causer un accident.
• Recharger uniquement avec le chargeur prescrit par le fabricant. Un chargeur convenant à un type de batterie peut
présenter un risque d’incendie lorsqu’il est utilisé avec une autre batterie.
• Utiliser uniquement les batteries recommandées pour l’appareil. L’utilisation d’autres types de batteries peut
présenter un risque de blessure ou d’incendie.
• Lorsque l’appareil n’est pas utilisé, tenir la batterie loin d’objets métalliques comme des trombones, des pièces de
monnaie, des clés, des clous, des vis ou autres petits objets qui pourraient établir une liaison entre les bornes. Un
courtcircuit des bornes des batteries peut causer des brûlures ou un incendie.
• En condition d’usage abusif, du liquide peut s’échapper de la batterie ; éviter tout contact avec ce liquide. En cas de
contact accidentel, rincer abondamment avec de l’eau. En cas de contact avec les yeux, consulter également un
médecin. Le liquide projeté peut causer des irritations ou des brûlures.
• Ne pas utiliser une batterie ou un appareil endommagé ou qui a été modifié. Des batteries endommagées ou modifies
peuvent avoir un comportement imprévisible pouvant causer un incendie, une explosion ou un risque de blessure.
• Ne pas exposer une batterie ou un appareil à la flamme ou à des températures excessives. L’exposition à une flamme
ou à des températures supérieures à 130 °C peut causer une explosion.
• Respecter toutes les instructions de chargement et ne pas charger la batterie ou l’appareil à des températures qui ne
sont pas incluses dans la gamme de températures indiquées dans la notice d’instructions. Un chargement mal effctué.
• Confier les réparations à une personne qualifiée qui utilisera uniquement des pièces de remplacement identiques.
Cette façon de faire garantira la sécurité du produit.
• Ne pas modifier ni tenter de réparer l’appareil ou la batterie sauf comme il est indiqué dans les instructions d’utilisa-
tion et d’entretien.
• Toujours mettre l’interrupteur de l’appareil à la position ARRÊT avant de connecter ou d’enlever la brosse à moteur.
Safety Information

05
Safety Information
CONSERVER CES INSTRUCTIONS
Battery and Charging
Usage Domestique seulement
• Please keep the power supply and docking station away from heat (such as heating plates).
• For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper configuration for the
power outlet, if needed.
• The battery must be removed from the appliance before it is scrapped.
• The appliance must be disconnected from the supply mains when removing the battery.
• The battery is to be disposed of safely. Please do not discard waste batteries. Leave them to a professional
recycling organization.
• Do not wipe or clean the power supply or docking station shrapnel with a piece of wet cloth or wet hands.
• Please make sure the cleaner is powered off in shipment and original packaging is advised.
• If left unused for a long period, please store the cleaner in a cool and dry place afer having it fully charged and
switched off, charge it at least every three months to avoid the battery being over discharged.
• Please do not use the product when the temperature is higher than 40°C or lower than 4°C , or there is any liquid
or sticky substance on the floor.
Battery pack charging temperature
Battery pack using temperature
4°C ~ 40°C
4°C ~ 40°C
Battery pack
storage
temperature
Storage(within 3 months) -20°C ~ 45°C
@Less than 75% RH
Long Storage(3months) 25+/- 3°C
@Less than 75% RH

Batterie et chargement
• Conservez l'alimentation électrique et la station de chargement à l'écart de toutes sources de chaleur (des
plaques chauffantes, par exemple).
• Pour un branchement à une alimentation à l'extérieur des États-Unis, utilisez un adaptateur de fiche de branche-
ment d'une configuration adéquate à la prise d'alimentation.
• La batterie doit être retirée de l'appareil avant d'être mise au rebut.
• Lorsqu'on retire la batterie, l'appareil doit avoir été débranché de toute alimentation électrique.
• La batterie doit être mise au rebut de manière sécurisée. Ne mettez pas au rebut les batteries usagées.
Confiez-les à un organisme professionnel de recyclage.
• N'essuyez pas et ne nettoyez pas le chargeur ou la station de chargement avec un tissu humide ou avec les mains
mouillées.
• Si vous renvoyez l'aspirateur, assurez-vous que celui-ci est bien éteint et, de préférence, retournez-le dans son
emballage d'origine.
• Si l'appareil doit rester inutilisé pendant une période prolongée, rangez-le dans un endroit frais et sec après
l'avoir totalement chargé et éteint. Chargez-le au moins tous les trois mois pour éviter que la batterie ne se
décharge complètement.
• N'utilisez pas le produit lorsqu'il fait plus de 40°C ou moins de 4°C, ou lorsqu'il y a du liquide ou une substance
collante sur le sol.
Température de chargement du bloc de batterie
Température d'utilisation du bloc de batterie
4°C ~ 40°C
4°C ~ 40°C
Température de
stockage du bloc
de batterie
Stockage (dans les 3mois) -20°C ~ 45°C
À moins de 75% d'humidité relative
Stockage pour une longue
période (3mois)
25+/-3°C
À moins de 75% d'humidité relative
06

07
International symbols explanation
FCC Statement
Compliance Information
Correspondence of the responsible party in USA
Product Name Handheld Vacuum Cleaner with Power Supplyr
Company Roborock Technology Co.
Email suppor[email protected]
Address 108 West 13th Street, Wilmington, Delaware 19801.
Compliance Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including inter-
ference that may cause undesired operation.
Produce Model Handheld Vacuum Cleaner Model: H6M1A
Power Supply Model: BTC03RR
– ON-OFF (push-push) symbol [symbol IEC 60417-5010 (2009-02)]
– ALTERNATING CURRENT symbol [symbol IEC 60417-5032 (2009-02)]
– DIRECT CURRENT symbol [symbol IEC 60417-5031 (2009-02)]

08
Warning
FCC Statement
Any changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

09
IC Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploita-
tion est autorisée aux deux conditions suivantes :
(1)L’appareil ne doit pas produire de brouillage;
(2)L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
CAN ICES-3 (B)/NMB-3(B)

10
Vacuum
Product introduction
Rear Filter
Dustbin
Dustbin Removal Latch Charging Contacts
Charging Port
Emptying Latch
Mode Button
Screen
•Press the Mode button to change vacuum
mode
* In MAX mode, the fan will run at full speed. Battery life
will shorten and hot air may be emitted.
Sustain Button
•Squeeze the Trigger to start vacuuming. Press
the Sustain button with the Trigger squeezed to
enter Sustain mode.
* Pressing the Sustain button for 2 seconds in any mode will
stop the vacuum.
•Press the Emptying Latch down to empty the
dustbin. The dustbin should be emptied
aftereach use.
Trigger
• Squeeze to turn on
•Release to turn off.

11
Parts List
Baton Flex Tube
Dusting Brush
Power Supply Crevice Tool
Motorized Mini-BrushCarpet Brush

12
Standby and operating modes
Error
If an error occurs while the vacuum is in operation, the screen will show an error message. See Troubleshooting for details.
Charging
When the battery is charging, a charging animation will show alongside the current battery level. The screen will turn off
automatically after 1minuteof inactivity.
Notes:
1. The run time indicator will appear after several seconds of use.
2. Remaining run time is for reference only and may be different to actual run time.
Screen display
This Roborock cordless vacuum is equipped with a 1.3-inch OLED display that shows relevant information in real-time.
Displays the remaining power when in standby mode
Active Standby
Displays the remaining run time for current mode when in use
Remaining battery indicator
Mode
Sustain mode indicator
Eco
Standard
MAX

13
Buttons
Sustain Button
Press the Sustain button to enter Sustain mode. The Sustain icon will appear on screen. Squeeze the trigger while in Sustain
mode to start the vacuum and enable it to run continuously. In Sustain mode, the vacuum will not stop when the trigger is
released. Press the Sustain button again to disengage Sustain mode and stop vacuuming.
You can also enable the vacuum to run continuously by first pressing the trigger then pressing the Sustain button.
Notes:
1. Squeezing the trigger while the vacuum is already running continuously in Sustain mode will have no effect.
2. Pressing the Sustain button for 2 seconds in any active mode will stop the vacuum.
Mode Switch button
When the vacuum is on, press the Mode button to switch between Eco, Standard, or MAX modes. The respective icon will be
highlightedon-screen.
Note:
The vacuum will return to Standard mode after turning off or when charging.
Trigger
Squeeze the trigger to start vacuuming.
* Press the Sustain button while the vacuum is running continuously to disengage Sustain mode.
Releasing the trigger will stop the vacuum and enter it into Standby mode, unless it is in Sustain mode. The screen will turn off
automatically after 30 seconds of inactivity and the vacuum will automatically turn off after 1 minute of inactivity.
Notes:
1. The vacuum will stop running when charging.
2. Insufficient power or other errors may cause the vacuum to fail. See Troubleshooting for details.

14
Vacuum and accessories setup
Installation
ClickClick
To disconnect,
press the lock
Click
Option 1 Connect the Baton to the vacuum, then attach an accessory.
Option 2 Connect the vacuum directly to an accessory
Click Click
Option 3 Connect the flex tube to the vacuum, then attach
an accessory.
* Motorized accessories such as the motorized mini-brush or Carpet brush cannot be
used with the flex tube.

15
Charging
Use
Charge with the Power Supply
Charge with the charging stand
Charging Port
When the battery is charging, a charging animation will
show alongside the current battery level.
The screen will turn off automatically after 1minuteof
inactivity.
Notes:
1. When charging, the screen image faces the user for easy viewing.
2. When charging, the vacuum will enter Charging mode and stop all other functions.
3. The battery temperature will increase after continuous use in MAX mode. As a
result, recharging may take longer.
4. When battery levels are very low, the vacuum screen will only light up after a period
of charging.
Before using the vacuum, read the " Safety Instructions" in
this user manual
Note:
Make sure the Power Supply is firmly inserted into the power socket.

16
Use
Using the vacuum
1. When using the Carpet brush or motorized mini-brush on the vacuum cleaner, the surfaces of some fabrics may pill or be
difficult to vacuum. If this occurs, it is recommended that you use the dusting brush or crevice tool to vacuum these surfaces.
2. Before vacuuming shiny floors such as parquet or tiles, ensure there is no hard debris trapped the Carpet Brush to avoid
scratches.
3. Before using the vacuum, ensure that the Dustbin, Multi-Cyclone Assembly, and filters have been properly installed.
4. Do not block the exhaust outlet when vacuuming.
5. This vacuum is designed for domestic use. Flour and other fine dust should only be vacuumed in small amounts.
6. To avoid damage to the vacuum or the floor, do not use the vacuum to clean up hard or sharp objects such as toys and nails.
7. Be aware of your environment as you vacuum, especially around stairs and windows.
8. To avoid accidental fall damage, avoid placing the vacuum on raised surfaces such as desks and shelves, or leaning it against
other objects.
9. The rotation of the Carpet Brush may leave an unevenly polished floor. This can be resolved by wiping with a damp cloth or
polishing with floor wax.
Auto Shutoff
1. If any rotating parts get jammed, the vacuum will shut off automatically. Clear the jam to continue vacuuming.
2. If the motor gets too hot, the vacuum will automatically shut off. Wait until the temperature returns to normal before
continuing.
Keep the Brush Clear
1. Electric brushes will automatically stop if jammed by dirt or long fibers during use. If this occurs, clear them before continuing.
2. Detach the brush from the vacuum before cleaning. Avoid turning the vacuum on when no brush is attached.
Precautions:
1. Beware of sharp objects trapped in the roller.
2. If debris trapped in the roller cannot be easily extracted, see the "Clean Roller" section for details on removing the roller.

17
Brush Accessory Uses
Use
Tip:
The Dusting Brush can also be used on its own to dust the vacuum and other items
around the house.
1. Crevice Tool:
Narrow crevices, including skirting boards, corners, and
stairs.
2. Dusting Brush:
Dusting sofas, chairs, and other soft furnishings,and flat
surfaces such as desks and shelves.
3. Motorized Mini-Brush:
Cleaning dust from beds, sofas, and soft furnishings to
avoid mites.

18
Brush Accessory Uses
Use
4. Carpet Brush:
Connect to the Baton for cleaning short and medium-pile
carpets. Carpet Brush can also be used on easily scratched
floor surfaces.
Carpet Boost is automatically activated when the Carpet Brush
is installed. When a carpet is detected, suction automatically
increases to MAX for a deeper clean. It will return to the
previous mode when carpet is no longer detected.
Notes:
1. Carpet Boost will not activate when vacuuming in MAX mode.
2. Use the Carpet Brush for easily scratched floor surfaces.
5. Flex Tube:
Connect to Dusting Brush or Crevice Tool to clean small or
narrow spaces such as drawers and car interiors.

19
Maintenance
Product Warranty
1. Only use original parts. The use of non-original parts may
affect your eligibility for warranty services.
2. If the filter or accessory is jammed, the vacuum will start
and stop several times before shutting off. Clean the filters
and the accessory before further use.
3. If the vacuum is to be left unused for an extended period,
fully charge it and shut it down before storing it in a cool and
dry place. Do not place the vacuum in humid locations or in
direct sunlight. Charge the vacuum at least once every 3
months to prevent damage to the battery.
Emptying the dustbin
1. When the dustbin is full, suction will be reduced. Empty it
before continuing with vacuuming. Before cleaning the
dustbin, disconnect the vacuum from mains power and
keep it switched off.
Cleaning the vacuum
Use a soft dry cloth to wipe the vacuum.
2. To empty the dustbin, push the Dustbin Opener on the
front of the handle in the direction of the arrow to open it,
then empty it into a bin. The dustbin should be emptied at
least once a week.
Dustbin Release
