Roborock S6 MaxV User manual

Roborock S6 Robotic Vacuum Cleaner Manual
Read this manual carefully before using the product and store it properly.

Product Introduction ...... 08
Safety Information ...... 01
Table of Faults ...... 06
Welcome ...... 07
Installation ...... 13
Instructions for Use ...... 17
Routine Maintenance ...... 21
Basic Parameters ...... 26
Troubleshooting ...... 27
FAQs ...... 29
EU Declaration of Conformity ...... 31
WEEE Information ...... 34
Warranty Information ...... 35

Safety Information
Restrictions
This product is designed for indoor floor cleaning only, do not use it outdoors
(such as on an open-ended terrace), on any surface other than the ground (such
as a sofa), or in any commercial or industrial environment.
Do not use this product on elevated surfaces without barriers such as the floor of
a lo, an open-ended terrace, or on top of furniture.
Do not use the product when the ambient temperature is higher than 104°F (40°C),
lower than 39°F (4°C), or if there are liquids or tacky substances on the floor.
Before using the product, move wires off the ground or place them to the side to
prevent them being pulled on by the cleaner.
To prevent blocking the product and to avoid damage to valuables, remove light-
weight items (such as plastic bags) and fragile objects (such as vases) from the
floor before cleaning.
Children should be supervised to ensure that they do not interfere with the product.
1

Safety Information
This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the pro-
duct by a person responsible for their safety (CB).
This product can be used by children aged from 8 years and above and persons
with reduced physical,sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the product in a safe way and understand the hazards involved. Children shall not
play with the product. Cleaning and user maintenance shall not be made by
children without supervision (EU).
Keep the main brush cleaning tools out of reach of children.
Do not place any object (including children and pets) on the product, whether it
is in operation or not.
Keep hair, loose clothing, fingers, and all parts of the body away from openings
and moving parts.
2

Safety Information
Do not use the product on burning objects (such as cigaree bus).
Do not use the product on high pile carpets (product effectiveness may also be
reduced on dark carpets).
Do not use the product to clean hard or sharp objects (such as decoration wastes,
glass and nails).
Do not carry the product using the laser scanner cap, main unit cover, or collision
buffer.
The product must be switched off and the plug must be removed from socket-outlet
before cleaning or maintaining the product.
Do not use wet cloth or liquids for cleaning the product.
Do not use the mopping module on carpets.
Use the product according to the manual. Any loss or damage caused from impro-
per use will be borne by the user.
This product contains baeries that are only replaceable by skilled persons.
3

Safety Information
Baery and Charging
WARNING
Do not charge non-rechargeable baeries.
For the purposes of recharging the baery, only use the detachable supply Unit
Roborock CDZ08RR or CDZ09RR provided with this product.
Do not dismantle, repair or modify the baery or charging dock.
Keep the charging dock away from heat (such as heating vents).
The baery must be removed before disposing the product.
The product must be disconnected from the supply mains when removing the
baery.
The baery must be disposed of safely. Do not discard waste baeries. Leave them
with a professional recycling organization.
Do not wipe or clean the charger prongs with wet cloth or wet hands.
If the power cord is damaged, stop using it immediately. It must be replaced by the
manufacturer, its service agent, or similarly qualified persons to avoid a hazard.
4

Safety Information
Make sure the product is powered off before shipment.
Use of the original packaging is advised.
If to be le unused for a long period of time, fully charge the product and switch
it off before storing it in a cool, dry place.
Charge it at least every three months to avoid over discharging the baery.
5

6
Table of Faults
Item
Main Unit
Charging dock Main unit does not charge.
Main brush, side brush, fan or main wheel issue.
Does not power on.
Functions do not work.
Power cable Charging dock has no power.
Fault
Table of Faults

Thank you for choosing a Roborock S6 Robotic Vacuum Cleaner.
This product is a sweeping and mopping robot equipped with a high-precision laser guided navigation system that
allows it to quickly and accurately create and store a map of every room of your home. Using this map, an advanced
dynamic route planning system plans out the most efficient path for cleaning each of your rooms as quickly as possible.
You can check this map, as well as the location of the product, and the progress of any clean, using the Xiaomi Home
App, which also lets you schedule cleans and take control remotely. If for any reason you can’t use your phone, you can
also control it using a variety of voice commands.
Through powerful sweeping and mopping systems inspired by nature, your floors are treated to a thorough clean and
deep dirt removal every time you clean. Aer a clean, it automatically drives back to the charging dock to recharge,
without out any help from you. Best of all, new noise reduction designs give you all the power with less of the noise so
you can any time in the day or night without disruption.
Roborock is dedicated to puing the most advanced technologies to work making your life easier. With your new
Roborock S6 product doing the hard work, you can focus on doing the things you truly enjoy.
Roborock
Welcome
7

Cover latch
Power light
White: baery level ≥ 20%
Red: baery level ＜ 20%
Slow flashing: Charging or starting up
Red flashing: Error
Clean/On and Off
Press to start cleaning
Press and hold to power on or off
Spot cleaning
Press to start spot cleaning
Note: Press any buon to pause cleaning,
recharging or spot cleaning.
Recharge
Press to start recharging
Reset WIFI
Press and hold and for 3 seconds.
Product Introduction
Main Unit
8

Product Introduction
Part list
9
Power cable
Water filter
Charging dock
Air filter
Mop clothAdjustable water tank
Damp-proof mat
Mounting plate –
disposable mop cloth
Disposable mop cloth

Product Introduction
Dustbin Main Unit
10
WIFI indicator
Off: WIFI is disabled
Slow flashing:
Waiting for connection
Fast flashing: Connecting
Stable light:
WIFI is connected
System reset buon
Speaker
Air outlet
Main brush cleaning tool
Air filter
Dustbin latch
Dustbin cover

Product Introduction
Main Unit and sensor
11
Bumper
Recharge sensor
Laser distance sensor Height sensor
Wall sensor
Side brush
Omni-directional
wheel
Charging contacts
Main brush
Main brush
latch
Main wheel
Cliff sensor
Cliff sensor

Product Introduction
Mopping module
Charging Dock
12
Water tank
Water control switch
Water tank latch
Water tank
latch
Mopping cloth slot
Water tank cover
Water filters
Mop cloth
Aachment
point
Contact point
Transmission zone
Charging dock
indicator
Contact point
Cable slot opening
Power connector
Cable slot
Rear cover

Installation
Setup
13
1. Clip the damp-proof mat onto the charging dock using the
guiding grooves.
2. Place the charging dock against a wall on a level floor and
plug it in. Hide any excess cable in the cable slot.
More than 1.7 (0.5m)
More than 1.7 (0.5m)
More than 5 (1.5m)
Notes:
Keep at least 1.7 (0.5m) on either side and 5 (1.5m) in front of the charging
dock clear.
If the power cable is le hanging vertically, it may get caught as the main unit
cleans, causing it to loosen or unplug.
The charging dock indicator will be lit when the dock is plugged in, and off
when the main unit is charging.
3. Power on and charge.
Press and hold the buon to power on, wait until the
ring light turns on, and then place the main unit onto the
charging dock to charge. The high-performance lithium-ion
rechargeable baery pack inside must be charged regularly
to maintain optimum baery performance.
Power light color indicates
baery level
White: Baery level ≥ 20%
Red: Baery level ＜ 20%
Note: The product will not power on if the baery is low. Place the main unit
directly onto the charging dock to recharge.
4. Connect with Xiaomi Home App. (Optional)

Installation
This product works with Xiaomi Home app . Control your device, and interact it and other smart home devices
with Xiaomi Home app.
Quick Setup
Note: The version of the app might have been updated, please follow the instructions based on the current app version.
WIFI connection only supports networks in the 2.4 GHz band, not the 5 GHz band.
Note: If a mobile phone has never been connected to the product, or if there is a
problem with the connection, reset the WIFI before aempting connection.
Note: For specific connection instructions, visit the Roborock website and download guidelines for iOS and Android devices.
Download Xiaomi Home app
1
Scan the QR code to download and install the app. You will be directed to the connection setup page if the app is installed
already. Or search "Xiaomi Home" in the app Store to download and install it.
Add Device
Open Xiaomi Home app, tap "+" on the upper right, and then follow prompts to add your device.
The app is referred to as Xiaomi Home app in Europe (except for Russia). The name of the app displayed on your device should be taken as the default.
*
2
Off: WIFI is disabled
Slow flashing:
Waiting for connection
Fast flashing: Connecting
Stable light:
WIFI is connected
WIFI indicator
Reset WIFI
If you experience any WIFI problems, reset the WIFI to defaults.
Open the top cover to expose the WIFI indicator then press and
hold the buon and the buon until you hear the "Reset
WIFI" voice prompt. Reset is complete when the WIFI indicator
flashes slowly. The product will then wait for a connection.
3
14

Installation
Using the mop
15
5. Install the mopping module.
Adjusting the water flow rate
Disposable mop cloth plate
Disposable mop cloth
1
2
Adjust the water flow rate according to your preferences.
High
Low
Install the mop cloth
a. Installing a reusable mopping cloth
Dampen the mop cloth and squeeze it dry. Slot it into the
mounting point and slide it along the groove on the water
tank then press it firmly in place.
Note: Use barrier tapes to create a border around carpets.
b. Installing a disposable mop cloth
b1. Installing the disposable mop cloth plate
Insert the disposable mop cloth plate from right to le along
the slot on the water tank as shown then press it firmly in
place.
b2. Securing a disposable mop cloth
Place the water tank on a flat surface with the disposable
mopping cloth fabric facing up. Align the cloth with the mop
cloth plate and press it down firmly. Press down on the various
locking points to secure the cloth onto the mop cloth plate.

Installation
Using the mop
16
Refill the water tank
3
Open the water tank, fill the tank with water, then reseal it
carefully.
Install the mopping module
4
Line the mopping module up with the alignment indicators
on the rear of the Main Unit then slot it in until you hear
a click.
Note: Some floor cleaners or disinfectants may block the water filters.
6. Start cleaning
When the power light changes from a slow white flash to a
steady light, charging is complete. Press the buon
or use the Xiaomi Home app to start cleaning.
7. Remove the mopping module
When a cleaning cycle is complete and the main unit has
returned to the charging dock, press the latches on either
side of the mopping module and pull backwards to remove it.
Notes:
Remove the mopping module if the product is to be le unused. Empty any water
le in the water tank and clean the mopping cloth to prevent mildew or odors.
If the charging dock is placed on a wood floor, always use the damp-proof mat
to avoid moisture leaking to the floor.

Instructions for Use
On / Off
17
Press and hold the buon to power on the main unit.
The power light will turn on and the main unit will enter standby
mode. When the main unit is idle, press and hold the
buon to power off and end the current cleaning cycle.
Note: The main unit cannot be shut down during charging.
Press the buon to start cleaning. When cleaning, the
product will plan an appropriate cleaning path based on the
generated map of the scanned area. It will clean along the edges
of a zone first and then plan a Z-shaped cleaning route to cover
the whole zone efficiently and quickly without missing a spot.
Start cleaning
Notes:
Cleaning cannot be started if the baery level is too low. Recharge baery
then restart cleaning.
Tidy away cables (including the charging dock power cable) from the floor
before cleaning to avoid power failure and to prevent damage resulting from
a dragged cable.
If a cleaning cycle is completed within 10 minutes, by default, cleaning will
repeat.
When the product is running, press any buon to pause it.
Press the buon to restart cleaning or the buon
to end the cleaning cycle and send the product back to the
charging dock.
Pause
Note: Docking the main unit to the charging dock when paused will stop the
current cleaning cycle.
If inactive for more than 10 minutes, the product will enter
sleep mode and its indicator light will flash slowly. Press any
buon to wake the product.
Sleep
Notes:
The product will not enter sleep mode when connected to the charging dock.
The product will automatically shut down if le in sleep mode for over 12 hours.
Zone 1 has
been cleaned.
Zone 2 has
been cleaned.
Zone 4 is
pending.
Zone 3 is
being cleaned.

Instructions for Use
18
If an error occurs, the power light will flash red quickly and
a voice prompt will sound. Refer to “Troubleshooting” for
solutions.
Errors
Charge
Auto mode: Aer cleaning, the main unit will automatically
return to the charging dock for charging.
Manual mode: In pause mode, press the buon to start
recharging.The power light flashes slowly when the robot is
being charged.
Notes:
The product will automatically enter sleep mode aer 10 minutes of inactivity
in an error state.
Docking the main unit to the charging dock in an error state will stop the current
cleaning cycle.
Note: If failing to find the dock charger, the main unit will automatically return to its
starting point. Manually place the main unit onto the charging dock for charging.
If your smartphone cannot connect to the product for any reason,
open the dustbin cover to view the WIFI indicator then press and
hold the buon and the buon until you hear the “Reset
WIFI” voice prompt. Reset is complete when the WIFI indicator
flashes slowly.
Reset WIFI
Note: WIFI will be automatically disabled if it takes over an hour to connect. If
you need to reconnect, reset the WIFI before proceeding.
In standby or pause mode, press the Spot Cleaning buon to
start spot cleaning. This mode cleans a 16.4 (1.5m) square
area centered on the product. Aer cleaning, it will return to
its starting point.
Spot cleaning
Note: Starting spot cleaning in pause mode will stop the current cleaning cycle.
16.4 (1.5m)
< <
16.4 (1.5m)
<
<
