BLOOD GLUCOSE MONITORING SYSTEM
User’s Manual
for
Acoustic Mode
AA
CCU-
CCU-
CHEK
HEK
®
Compact Plus
008
8
ACCU-CHEK and SOFTCLIX
are trademarks of Roche.
Made in Ireland for export to:
Roche Diagnostics
201 Boul.Armand-Frappier
Laval, Québec
CANADA, H7V 4A2
Accu-Chek Customer Care:
Montreal area: [phone]
Outside Montreal (toll free): 1-800-363-7949
www.accu-chek.ca
Roche Diagnostics GmbH
D-68298 Mannheim, Germany
www.accu-chek.com

1
IVD
008
8
On the packaging, on the type plate of the meter and on the lancing
device you may encounter the following symbols shown here with
their meaning:
Please consult User’s Manual
Catalogue number
For in vitro diagnostic use
Use by/ Expiry date
Lot number
Blood glucose meter and test strips:These products
fulfil the requirements of Directive 98/79/EC on in vitro
diagnostic medical devices.
Lancing device and lancets:These products fulfil
the requirements of Directive 93/42/EEC on medical
devices.
Manufacturer
Caution (refer to accompanying documents). Please
refer to safety-related notes in the User’s Manual
accompanying this instrument.
For single use only
Sterilized using irradiation
Last update: March 2005
This user’s manual for the acoustic mode features three symbols that
draw your attention to important information.
This symbol indicates a possible risk of injury or of damage to
your health.
This symbol draws attention to actions that could result in
damage to meter or lancing device.
iThis symbol draws your attention to other important information.

23
The acoustic mode is intended for people who are visually impaired.
When the acoustic mode is turned on,the meter will guide the user
through the testing process using beep tones; it will also announce the
results as a series of beeps.
Visually impaired people need a sighted person to instruct them
in the use of the meter and to assist them with all aspects of its
operation.Visually impaired persons must not test their blood
glucose without the assistance of a sighted person.
A person without visual impairment must set up the meter.All the
necessary information for this is contained in the User’s Manual for the
meter.
This user’s manual for the acoustic mode is intended for sighted per-
sons instructing visually impaired people on how to use the Accu-Chek
Compact Plus meter and supporting them in its use.
The user’s manual for the acoustic mode contains separate descriptions
of how to use the meter and the lancing device.These are provided to
support a sighted person,who is instructing a visually impaired person
on how to use the meter and supporting them in its use. Only those
activities,which are to be performed by a visually impaired person
with simultaneous support from a sighted person,are described in this
manual.These activities are:
 Inserting and replacing the batteries
 Inserting and replacing the test strip drum
 Obtaining a blood
 Testing blood glucose
 Retrieving the results of the best
Descriptions are also given of different acoustic signals which indicate
warnings and error messages.
The user’s manual for the meter covers all the steps involved in
operating the meter as well as warnings and other information.
The user‘s manual for the acoustic mode in spoken form is also avail-
able in a CD format.You can receive this CD by calling the Accu-Chek
customer care line.Details are given at the end of this user’s manual.
The user’s manual for the acoustic mode was created in collaboration
with the Centre for Blind andVisually Impaired Students at Fachhoch-
schule Gießen-Friedberg,Germany.

45
Contents
The user’s manual for the acoustic mode does not replace the
user’s manual for the Accu-Chek Compact Plus meter.Please
study the user‘s manual carefully and completely before using
the meter in acoustic mode.It will provide you with all the infor-
mation you need to operate and care for the meter and to deal
with any errors that might arise.
If you have any questions, please contact theAccu-Chek customer care
line.Contact details are given at the end of this user’s manual.
Contents
1 Description of the meter ............................................................ 6
1.1 The front ............................................................................. 6
1.2 The back ............................................................................. 7
1.3 The lancing device .............................................................. 8
2 Turning on the acoustic mode ................................................. 10
3 Inserting or replacing batteries ............................................... 11
4 Inserting or replacing the test strip drum ............................... 14
5 Preparing the lancing device ................................................... 16
6 Testing your blood glucose ...................................................... 19
7 Announcement of the results as beeps .................................. 22
8 Ejecting the test strip ............................................................... 24
9 Ejecting the lancet ................................................................... 25
10 Retrieving the results from memory ....................................... 26
11 Warnings and error messages ................................................ 28
12 Local customer support and service ....................................... 30
12.1 Information and repair ....................................................... 30
12.2 Contact us ........................................................................ 31

6Description of the meter 7
Description of the meter
1
1 Description of the meter
The meter is supplied with a lancing device docked onto it.
1.1 The front
Display and buttons
Hold the meter so that the lancing device is located to the right.The two
short ends of the meter have different contours.The smooth end (with-
out projections or depressions) should be pointing away from you.The
other end has a depression and a corner which is rounded off.This end
should be pointing towards you, so the rounded end and lancing device
are on the right.The display and buttons are on the top half of the meter.
In the centre of the meter is theTest button.This can be identified
through its curved ridge.To the left of theTest button is the M button
and to the right of theTest button is the S button.Above the buttons is
the display.
Drum compartment cover
Below the buttons is the drum compartment cover and, underneath it,
the drum compartment.The hinge attaching the drum compartment
cover to the meter is located below the buttons.At the lower end of the
drum compartment cover is a flat depression which continues around
onto the end of the meter nearest to you.
Test strip guide
Below the depression in the drum compartment cover, i.e.at the short
end of the meter nearest to you,is the test strip guide.This is where the
test strip will emerge.
Drum compartment
To the right of the test strip guide is a small projection that is part of the
drum compartment cover.By pulling this projection upwards, you can
open the drum compartment.When the drum compartment is open, a
button (the red drum release button) is situated at its lower right-hand
corner.
1.2 The back
Turn the meter over and lay it down face downwards so the lancing
device is now situated on the left.
Sliding button for undocking the lancing device
At the top left is an oval,ribbed button that slides towards you.This is
the sliding button that releases the lancing device.
Battery compartment
To the right of the sliding button is the battery compartment that
occupies approximately the upper half of the meter. Roughly at the
centre of the meter (i.e.at the lower end of the battery compartment
cover) is a ribbed surface.You push this forward to open the battery
compartment.

8Description of the meter 9
Description of the meter
1
1.3 The lancing device
When the buttons are facing upwards,the lancing device is located on
the right side of the meter.It is docked in a recess in the meter.The
shape of the lancing device is that of a fat ballpoint pen.At its lower
end,adjacent to the end of the meter with the test strip guide, is the
cap. Underneathe the cap is the lancet holder.The cap rotates and is
used to set the penetration depth. Just above the cap,inset into the
lancing device,is a semi-circular arch that has a light-coloured border.
This indicates the chosen penetration depth.The cap is removed to al-
low a new lancet to be inserted or to eject a used one.At the upper end
of the lancing device is the plunger,which is used to prime, trigger and
eject the lancet.
Undocking and docking the lancing device
씰Hold the meter so the back is facing upwards,with the lancing
device on the left.
씰Search for the ribbed sliding button at the top left corner of the
meter.
씰Slide this button downwards and hold it there.
This releases the lancing device.
씰Withdraw the lancing device by pulling it forward towards you.
The lancing device is not round like a ballpoint pen,but has four sides
that are different, and have rounded edges.On the two narrow sides of
the lancing device are two narrow grooves that start below the plunger
and run along the lancing device.Along the edges of the recess in the
meter into which the lancing device is docked are the corresponding
guides.These guides must engage with the grooves when the lancing
device is docked onto the meter.
Of the two broad sides one is flat and the other curved.When the
lancing device is docked onto the meter,the curved side faces
outwards.
씰Slide the lancing device from below,plunger first, into the recess.
The flat, broad side of the lancing device must be facing the meter
and be in contact with the walls of the recess.The guides then glide
into the grooves.The lancing device docks into place with an audi-
ble CLICK.

10 Turning on Acoustic Mode
2
11
Inserting or replacing batteries
3
2 Turning on Acoustic Mode
씰With the meter turned off,press the right-hand
S
button
(S button).
The meter turns on without advancing a test strip.
씰Press the left-hand Mbutton (M button) repeatedly until it beeps
and On2 flashes in the display.The acoustic mode is now turned on.
씰Press the middle button (Test button) to turn the meter off.
iYou cannot set a hypo warning if you have the acoustic mode
turned on (On2).This is to prevent it from being confused with
other beep tones.If you have already set a threshold, the hypo
warning is automatically turned off when you subsequently turn
acoustic mode on.
3 Inserting or replacing batteries
When the batteries are low,the meter emits three double beeps (2 short
beeps three times in quick succession) when you turn it on.
You can now perform about 50 more tests.Continue testing until all the
test strips in your current test strip drum have been used up.Then re-
place the batteries and the test strip drum.
씰If the meter is on,press the middle button (Test button) to turn
it off.
씰Hold the meter so the back is facing upwards,with the lancing
device on the left.
The battery compartment is located at the top right and extends to
approximately the middle of the meter.At the lower end of the battery
compartment cover is a ribbed area.
씰Push the ribbed area forward as far as it will go (about 3 mm).
씰This unlocks the battery compartment and you can remove the
cover.
You may turn the meter over if you wish,so the battery compart-
ment cover drops off.Turn the meter over again so the battery
compartment is again at the top right.
씰Remove the used batteries.

12 Inserting or replacing batteries 13
Inserting or replacing batteries
3
씰Insert new batteries.
Ensure that the flat, smooth end of the right-hand battery (minus
end) is pointing downwards and the end with the rounded projection
(plus end) is pointing upwards.The left-hand battery must be insert-
ed the other way round,with the smooth, flat end pointing upwards
and the end with the rounded projection pointing downwards.
씰Place the battery compartment cover loosely back on the battery
compartment.
The battery compartment cover has slots along three edges of the
battery compartment.The three prongs projecting from the cover
must engage in the slots.The battery compartment cover is properly
located over the battery compartment when the cover is loosely
attached and is lying flush with the back of the meter.
씰Slide the battery compartment cover downwards towards you. It
locks with an audible CLICK.
iWhen you replace the batteries, the year,time and date settings
only remain saved as long as
you do not take longer than two minutes to change the
batteries,
you do not press any button while there are no batteries in
the meter and
you do not open the drum compartment while there are no
batteries inserted.
After replacing the batteries, therefore,ask a sighted person to check
and,if necessary,adjust the settings.
If the year,time and date are not correctly entered,your future results
will be displayed and saved without the time and date, in which case
they will be sequentially numbered instead.Statistical calculations (e.g.
of average values) and downloading of results to a computer can only
be performed for results that have been saved together with the year,
time and date.

14 Inserting or replacing the test strip drum 15
Inserting or replacing the test strip drum
4
4 Inserting or replacing the test strip drum
The test strip drum is a short cylinder that resembles a full spool of
thread.One end of the test strip drum has a hole in the middle, the other
end has a central,ring-shaped ridge.With the exception of the hole and
the ridge,both ends of the drum are sealed with aluminium foil. On a
new test strip drum this foil must be smooth,a sign that it is undam-
aged.
씰Hold the meter so the buttons and the display screen are facing up-
wards with the test strip guide pointing towards you.
To the right of the test strip guide is a small projection that is part of the
drum compartment cover.
씰Lift the projection upwards to open the drum compartment cover.
씰Fold the drum compartment cover up as far as it will go.
The drum compartment is a rectangular chamber.At the lower, right-
hand corner of this chamber is a red button,the drum release button.
씰Press the red button.
If there is a test strip drum in the meter:
씰Keeping hold of the drum compartment cover turn over the meter so
the drum compartment is pointing downwards.
The test strip drum drops out.
씰Turn the meter back over so that the buttons are facing up.
씰Take a new test strip drum from its container.
씰Place the test strip drum in the drum compartment.
Ensure that the end with the ring-shaped ridge is pointing in the di-
rection of the test strip guide.The lower edge of the test drum com-
partment has a rectangular groove at its centre into which the ridge
of the drum fits.When inserting the test strip drum, hold it so the
two aluminium ends are vertical and the cylindrical body is parallel
to the sides of the drum compartment.
The test strip drum will only fit into the drum compartment when it
is correctly aligned.
씰Fold the drum compartment cover down and press it closed.
It locks with an audible CLICK.
The meter will rotate the test strip drum in order to read the barcode.
You will hear the motor running.The meter then turns itself off.

16 Preparing the lancing device 17
Preparing the lancing device
5
5 Preparing the lancing device
When the lancing device is docked onto the meter,the cap is at the end
of the meter where the test strip guide is also located.At the upper end
of the lancing device is the plunger which is used to prime,trigger and
eject the lancet.
씰Pull the cap off downwards and remove it from the lancing device.
Beneath the cap is a narrow cylinder,the lancet holder.
If there is a lancet in the lancing device,only the lancet needle
protrudes from the lancet holder.To avoid injuring yourself, do not
grasp the lancet holder from the front.
If there is a lancet in the lancing device:
씰Hold the lancing device upright above a waste bin.
씰Press the plunger in as far as it will go.
The lancet drops out.
If the lancet does not drop out,a sighted person must remove it. For de-
tails refer to the User’s Manual for the meter (chapter entitled“Ejecting
the used lancet”).
Make sure the lancet has dropped out.Inadvertently leaving the
lancet in the lancing device may result in personal injury.
The lancet is a small rectangle with a flat and a rounded end.The
rounded end is the protective cap that is attached to the lancet needle.
씰Slide a new lancet,flat end first,into the lancing device as far as it
will go.When you hold the meter horizontally,a narrow side of the
lancet (no matter which) must be facing upwards.
The lancet will snap into place with an audible CLICK.
씰Twist off the rounded end to expose the lancet needle.
씰Press the cap back onto the lancing device.
There is only one position in which the cap can be properly attached
to the lancing device.To find it, lightly hold the cap against the lanc-
ing device and rotate it until you notice the cap slide over the lancet
holder.Press the cap on tight.The cap is properly fitted when it
locks into place with an audible CLICK.
