Rocket Fish RF-RBREC User manual

RF-RBREC Wireless Amplied Audio Receiver
QUICK SETUP GUIDE
Package contents
Remote
control
Establishing communication
All Rocketboost devices must be“joined”or wirelessly connected to your Rocketboost hub device so
that audio can be sent between them. The following steps describe how to join Rocketboost devices.
For additional information, see the Rocketboost network notes on the right.
1If you are setting up your network for the rst time, choose one of your Rocketboost senders to
be your hub device by setting the Hub Status switch to Enable.
For example, if you want the RF-RBAUX sender/receiver to be the hub, set the Hub Status
switch on the sender/receiver to Enable.
The sender/receiver power indicator lights green if the sender/receiver Hub Status switch is
enabled, or lights blue if the sender/receiver Hub Status switch is disabled.
2If possible, bring your Rocketboost hub device, and the RF-RBREC wireless receiver which you’d
like to join to the hub, into the same room.
3Press the on the Rocketboost hub device to turn it on.
4Press the on the RF-RBREC wireless receiver to turn it on.
5Press and hold the on the Rocketboost hub device for more than three seconds to put it
into joining mode. The power indicator starts blinking rapidly and the unit will stay in joining
mode for 30 seconds.
6Press and hold the on the RF-RBREC wireless receiver for more than three seconds to put it
into joining mode.
• When successfully joined, the power indicator LEDs on both products will stop blinking and
stay on.
• If joining fails after 30 seconds, the power indicator LEDs will begin ashing at a slower rate.
If this occurs, repeat the above steps.
• Repeat steps 2-6 for each additional Rocketboost device you are adding to your network.
For additional information, see your User Guide.
Using your wireless receiver
1Make sure the volume is turned up on the audio device connected to your Rocketboost sender.
2Play music from the audio device connected to your Rocketboost sender.
3Adjust the volume level on the wireless receiver.
If you have multiple audio sources in your Rocketboost network, press the Source button on
the wireless receiver to hear the next audio source. Press the Source button again to cycle
through all available audio sources.
Rocketboost network notes:
Every Rocketboost network must contain
one hub device, which helps devices join
the network. The network can have only
one hub, which you can enable using the
hub switch on the back of all Rocketboost
senders and sender/receivers. If this is your
rst Rocketboost product, you should
make this device the hub, if you already
have Rocketboost products, you should
disable hub mode on this device.
Important: Hub devices must always have
power for your network to operate. The
hub device can be in standby (power-
saving) mode, but must stay plugged in.
© 2010 BBY Solutions, Inc., All Rights Reserved. Distributed by Best Buy Purchasing, LLC, 7601 Penn Avenue South, Richeld, MN USA 55423-3645
ENGLISH 10-0176
AC power cable
Cable spool
Speaker cable (2)
3 ft (91.5 cm)
Wireless receiver
Initial setup
1 Unpack the package contents
2 Enable the remote control battery
Remove the tab from the bottom of
the remote control.
Rocketboost technology can connect all audio
devices throughout your home to form a home
audio network. Rocketboost products include
“senders,”which send audio streams, and“receiv-
ers,”which receive the audio. This lets you listen to
music from your sender in other rooms, using your
receiver.
The RF-RBREC is a Rocketboost wireless receiver
that includes a built-in audio amplier. So once you
connect your speakers to the RF-RBREC you can
listen to audio from your Rocketboost senders.
Rocketboost is expandable. Each Rocketboost
receiver can select the audio from any sender in
your Rocketboost audio network. You can set up
your network to meet your specic needs. The
illustration on the right shows an example
Rocketboost network.
Connecting the speakers to the wireless receiver
• Connect the right speaker to the right speaker-out connectors on the wireless receiver. Use a
red speaker wire to connect the red (+) speaker-out connector and a black speaker wire to
connect the black (-) speaker-out connector. Repeat this step to connect the left speaker.
Connecting the wireless receiver to an AC power outlet
• Connect one end of the AC power cord to the AC IN connector on the back of the wireless
receiver.
Then, plug the other end of the AC power cable into an AC power outlet. The Standby indicator
turns on.
SPEAKER-OUT (4-8 Ohm)
R
L
AC IN
Right (rear)
speaker
Left (rear)
speaker
Receiver back
To AC power
outlet
Cable notch
RF-RBAUX
(sender)
RF-RBREC
(receiver)
RF-RBWS02
(receiver)
RF-RBAUX
(receiver)
