Reach Drive Pump Control Kit
Instruction Manual D2-3563
Reach Drive Pump Control Kit Recommended Order of Assembly
Recommended Order of Assembly
!
ATTENTION: To prevent electrical shock, disconnect from power source before installing or
servicing. Failure to observe this precaution could result in severe bodily injury or loss of life.
Number Part Description
1DinRail
2 M4 Washer
3M4Screw*
4 End Anchors
5 Fuse Block
6 Contactor
7 Overload Contactor
8 Panel Mount Adapter
4
1
2
3
5
7
8
6
*The recommended torque for the Din Rail Screws is 17 in/lbs.

Publication D2-3563 November 2006
www.rockwellautomation.com
A
mericas: Rockwell Automation, 1201 South Second Street, Milwaukee, WI 53204-2496 USA, Tel: [phone], Fax: [phone]
E
urope/Middle East/Africa: Rockwell Automation, Vorstlaan/Boulevard du Souverain 36, 1170 Brussels, Belgium, Tel: [phone], Fax: [phone]
0
A
sia Pacific: Rockwell Automation, Level 14, Core F, Cyberport 3, 100 Cyberport Road, Hong Kong, Tel: [phone], Fax: [phone]
Power, Control and Information Solutions Headquarters
P/N 338889-P01
Assembled Pump Control Kit
