Rockwell Automation Micro800 2080-MEMBAK-RTC User manual

Wiring Diagrams
Micro800 Memory Backup and High Accuracy
RTC Plug-In Module
Catalog Numbers 2080-MEMBAK-RTC, 2080-MEMBAK-RTC2
http://literature.rockwellautomation.com
FR Cette publication est disponible en français sous forme électronique (fichier PDF).
Pour la télécharger, rendez-vous sur la page Internet indiquée ci-dessus.
IT Questa pubblicazione è disponibile in Italiano in formato PDF. Per scaricarla
collegarsi al sito Web indicato sopra.
DE Diese Publikation ist als PDF auf Deutsch verfügbar. Gehen Sie auf die oben
genannte Web-Adresse, um nach der Publikation zu suchen und sie
herunterzuladen.
ES Esta publicación está disponible en español como PDF. Diríjase a la dirección web
indicada arriba para buscar y descarga esta publicación.
PT Esta publicação está disponível em portugués como PDF. Vá ao endereço web que
aparece acima para encontrar e fazer download da publicação.
ZH
ZC
KO

2 Micro800 Memory Backup and High Accuracy RTC Plug-In Module
Rockwell Automation Publication 2080-WD007C-EN-P - March 2018
Environment and Enclosure
Preventing Electrostatic Discharge
ATTENTION: This equipment is intended for use in a Pollution Degree 2
industrial environment, in overvoltage Category II applications (as defined
in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This
equipment is considered Group 1, Class A industrial equipment according
to IEC/CISPR 11. Without appropriate precautions, there may be
difficulties with electromagnetic compatibility in residential and other
environments due to conducted and radiated disturbances.
This equipment is supplied as open-type equipment. It must be mounted
within an enclosure that is suitably designed for those specific environmental
conditions that will be present and appropriately designed to prevent personal
injury resulting from accessibility to live parts. The enclosure must have
suitable flame-retardant properties to prevent or minimize the spread of flame,
complying with a flame spread rating of 5V A, V2, V1, V0 (or equivalent) if
non-metallic. The interior of the enclosure must be accessible only by the use
of a tool. Subsequent sections of this publication may contain additional
information regarding specific enclosure type ratings that are required to
comply with certain product safety certifications.
In addition to this publication, see:
• Industrial Automation Wiring and Grounding Guidelines, Rockwell
Automation publication 1770-4.1, for additional installation
requirements.
• NEMA Standard 250 and IEC 60529, as applicable, for explanations of
the degrees of protection provided by different types of enclosure.
ATTENTION: This equipment is sensitive to electrostatic discharge, which
can cause internal damage and affect normal operation. Follow these
guidelines when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• Use a static-safe workstation, if available.
• Store the equipment in appropriate static-safe packaging when not in use.

Micro800 Memory Backup and High Accuracy RTC Plug-In Module 3
Rockwell Automation Publication 2080-WD007C-EN-P - March 2018
North American Hazardous Location Approval
The following module is North American Hazardous Location approved:
2080-MEMBAK-RTC, 2080-MEMBAK-RTC2
The following information applies
when operating this equipment in
hazardous locations:
Informations sur l’utilisation de cet
équipement en environnements
dangereux:
Products marked "CL I, DIV 2, GP A, B, C, D" are
suitable for use in Class I Division 2 Groups A, B,
C, D, Hazardous Locations and nonhazardous
locations only. Each product is supplied with
markings on the rating nameplate indicating the
hazardous location temperature code. When
combining products within a system, the most
adverse temperature code (lowest "T" number)
may be used to help determine the overall
temperature code of the system. Combinations of
equipment in your system are subject to
investigation by the local Authority Having
Jurisdiction at the time of installation.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne
conviennent qu'à une utilisation en environnements de
Classe I Division 2 Groupes A, B, C, D dangereux et
non dangereux. Chaque produit est livré avec des
marquages sur sa plaque d'identification qui indiquent
le code de température pour les environnements
dangereux. Lorsque plusieurs produits sont combinés
dans un système, le code de température le plus
défavorable (code de température le plus faible) peut
être utilisé pour déterminer le code de température
global du système. Les combinaisons d'équipements
dans le système sont sujettes à inspection par les
autorités locales qualifiées au moment de
l'installation.
WARNING:
EXPLOSION HAZARD
• Do not disconnect equipment
unless power has been
removed or the area is known
to be nonhazardous.
• Do not disconnect connections
to this equipment unless power
has been removed or the area
is known to be nonhazardous.
Secure any external
connections that mate to this
equipment by using screws,
sliding latches, threaded
connectors, or other means
provided with this product.
• Substitution of any component
may impair suitability for Class
I, Division 2.
• If this product contains
batteries, they must only be
changed in an area known to
be nonhazardous.
AVERTISSEMENT:
RISQUE D’EXPLOSION
• Couper le courant ou s'assurer que
l'environnement est classé non
dangereux avant de débrancher
l'équipement.
• Couper le courant ou s'assurer que
l'environnement est classé non
dangereux avant de débrancher les
connecteurs. Fixer tous les
connecteurs externes reliés à cet
équipement à l'aide de vis, loquets
coulissants, connecteurs filetés ou
autres moyens fournis avec ce
produit.
• La substitution de tout composant
peut rendre cet équipement
inadapté à une utilisation en
environnement de Classe I,
Division 2.
• S'assurer que l'environnement est
classé non dangereux avant de
changer les piles.

4 Micro800 Memory Backup and High Accuracy RTC Plug-In Module
Rockwell Automation Publication 2080-WD007C-EN-P - March 2018
Parts List
Your package contains one memory plug-in module.
WARNING:
• If you insert or remove the module while power is on, an electrical arc can
occur. This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous
before proceeding.
• When used in a Class I, Division 2, hazardous location, this equipment must
be mounted in a suitable enclosure with proper wiring method that
complies with the governing electrical codes.
ATTENTION: This equipment is considered Group 1, Class A industrial
equipment according to IEC/CISPR 11. Without appropriate precautions,
there may be difficulties with electromagnetic compatibility in residential
and other environments due to conducted and radiated disturbance.
WARNING: At the end of its life, the used battery should be
collected separately from any unsorted municipal waste
and recycled.
45065

Micro800 Memory Backup and High Accuracy RTC Plug-In Module 5
Rockwell Automation Publication 2080-WD007C-EN-P - March 2018
Insert Module into Controller
Follow the instructions to insert and secure the plug-in module to the controller.
1. Position the plug-in module as shown.
2. Snap the module only into slot 1 of the module bay.
3. Using a screwdriver, tighten the 10…12 mm (0.39…0.47 in.) M3
self-tapping screw to torque specifications.
ATTENTION:
• The 2080-MEMBAK-RTC plug-in module is only compatible with
Micro830®and Micro850®controllers.
• The 2080-MEMBACK-RTC2 plug-in module is only compatible with
Micro870™ controllers.
• You can insert or remove the module while power is applied, but only in
nonhazardous locations.
45066

6 Micro800 Memory Backup and High Accuracy RTC Plug-In Module
Rockwell Automation Publication 2080-WD007C-EN-P - March 2018
Status Indicator
Specifications
State Description
Solid red (2 s) Startup cycle test in progress.
Flashing red Back up in progress
Solid red (continuous) Battery low
General and Environmental Specifications
Attribute Value
Mounting torque 0.2 Nm (1.48 lb-in.)
Terminal screw torque 0.22....0.25 Nm (1.95…2.21 lb-in.)
using a 2.5 mm (0.10 in.) flat-blade screwdriver.
Temperature, operating IEC60068-2-1 (Test Ad, Operating Cold),
IEC60068-2-2, (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...65 °C (-4…149 °F)
Temperature, surrounding air, max 65 °C (149 °F)
Temperature, non-operating IEC60068-2-1 (Test Ad, Operating Cold),
IEC60068-2-2, (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-40...85 °C (-40…185 °F)
North American temp code T4

Micro800 Memory Backup and High Accuracy RTC Plug-In Module 7
Rockwell Automation Publication 2080-WD007C-EN-P - March 2018
Certifications
Certification (when
product is marked)(1)
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada.
See UL File E322657.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,
certified for U.S. and Canada. See UL File E334470.
CE European Union 2014/30/EU EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
RCM Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for
Declarations of Conformity, Certificates, and other certification details.

Rockwell Automation Support
Rockwell Automation provides technical information on the Web to assist you in using its products. At
http://www.rockwellautomation.com/support/, you can find technical manuals, a knowledge base of FAQs,
technical and application notes, sample code and links to software service packs, and a MySupport feature
that you can customize to make the best use of these tools.
For an additional level of technical phone support for installation, configuration and troubleshooting, we
offer TechConnect support programs. For more information, contact your local distributor or Rockwell
Automation representative, or visit http://www.rockwellautomation.com/support/.
Installation Assistance
If you experience a problem within the first 24 hours of installation, please review the information that's
contained in this manual. You can also contact a special Customer Support number for initial help in getting
your product up and running.
New Product Satisfaction Return
Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from
the manufacturing facility. However, if your product is not functioning and needs to be returned, follow
these procedures.
Documentation Feedback
Your comments will help us serve your documentation needs better. If you have any suggestions on how to
improve this document, complete this form, publication RA-DU002, available at
http://www.rockwellautomation.com/literature/.
United States or Canada 1.440.646.3434
Outside United States or
Canada Use the Worldwide Locator at
http://www.rockwellautomation.com/support/americas/phone_en.html, or
contact your local Rockwell Automation representative.
United States Contact your distributor. You must provide a Customer Support case number
(call the phone number above to obtain one) to your distributor to complete
the return process.
Outside United States Please contact your local Rockwell Automation representative for the return
procedure.
Allen-Bradley, Rockwell Automation, Micro800, Micro830, Micro850, and Micro870 and TechConnect are trademarks of Rockwell
Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Publication 2080-WD007C-EN-P - March 2018 PN-476637
Supersedes Publication 2080-WD007B-EN-P - March 2014 Copyright © 2018 Rockwell Automation, Inc. All rights reserved. Printed in Singapore.
Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: [phone]
Rockwell Automation maintains current product environmental information on its website at
http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page.
