Rockwell Automation Allen-Bradley 2094-AC-M-S Series User manual

Kinetix Safe Torque-off Feature
Catalog Numbers 2094-ACxx-Mxx-S, 2094-BCxx-Mxx-S, 2094-AMxx-S, 2094-BMxx-S, 2099-BMxx-S
Safety Reference Manual
Original Instructions

Important User Information
Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety
Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from
your local Rockwell Automation® sales office or online at http://www.rockwellautomation.com/literature/) describes some
important differences between solid-state equipment and hard-wired electromechanical devices. Because of this difference,
and also because of the wide variety of uses for solid-state equipment, all persons responsible for applying this equipment
must satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the
use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or
software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation,
Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Allen-Bradley, GuardLogix, GuardPLC, Kinetix, Logix5000, RSLogix, TechConnect, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
IMPORTANT
Identifies information that is critical for successful application and understanding of the product.

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 3
Summary of Changes
This manual contains new and updated information.
New and Updated
Information
This revision includes changes for the Kinetix 6000 series C servo drives.
Topic Page
Updated references tosafe-off (SO) as safe torque-off (STO), per EN 61800-5-2. Throughout
this manual
Replaced references to EN 954-1 with EN ISO 13849-1.
Updated safe torque-off descriptive text, including certification, description of operation, and
PFD/PFH definitions and data. 9…12
Updated European Union Directives and moved from chapter 3 to chapter 1. 10
Updated Safe Torque-off Interface Cables table with 1202-C30, 3 m(9.8 ft) cable. 20
Added Safe Torque-off Headers table.
Added safe torque-off specifications for Kinetix 6000 (series C) drives. 30
Added EC Certifications appendix that includes examination certificate and declaration of conformity
for Kinetix 6000 and Kinetix 7000 drives. 43

4Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Summary of Changes
Notes:

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 5
Table of Contents
Preface
About This Publication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Terminology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 1
Safety Concept and Troubleshooting
Certification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Important Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Category 3 Requirements According to EN ISO 13849-1. . . . . . . . 10
Stop Category Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
European Union Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
EMC Directive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Low Voltage Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Description of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PFD and PFH Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PFD and PFH Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Understanding the Safe Torque-off Condition vs Drive Fault . . . . 13
Chapter 2
Safe Torque-off Connector Data
Safe Torque-off Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Safe Torque-off Header Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Safe Torque-off Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 3
Wiring Your Kinetix Safe Torque-off
Drive
Wire the Safe Torque-off Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safe Torque-off Wiring Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Safe Torque-off Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Safe Torque-off Feature Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Safe Torque-off Connection Examples . . . . . . . . . . . . . . . . . . . . . . . . . 24
Safe Torque-off Wiring Examples for SIL 3 Applications . . . . . . . . 27
Appendix A
Specifications
Safe Torque-off Response Time Specifications. . . . . . . . . . . . . . . . . . . . . . 29
Safe Torque-off Signal Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Kinetix 6000 (series A and B) and Kinetix 7000 Servo Drives . . . . 29
Kinetix 6000 (series C) Servo Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Table of Contents
Appendix B
Kinetix Safe Torque-off Wiring
Diagrams
Kinetix Safe Torque-off/Safety Relay Configurations. . . . . . . . . . . . . . . . 32
Kinetix Safe Torque-off/GuardLogix Configurations. . . . . . . . . . . . . . . . 35
Kinetix Safe Torque-off/GuardPLC Configurations . . . . . . . . . . . . . . . . 39
Appendix C
EC Certifications
EC Type - Examination Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
EC Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Index

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 7
Preface
About This Publication This manual provides detailed installation instructions for wiring and
troubleshooting your Kinetix 6000 and Kinetix 7000 safe torque-off drives.
Included are interconnect diagrams with Allen-Bradley safety relays, GuardLogix
controllers, and GuardPLC controllers.
Audience This manual is intended for engineers or technicians directly involved in the
installation and wiring of the Kinetix 6000 and Kinetix 7000 drives, and
programmers directly involved in the operation, field maintenance, and
integration of the Kinetix 6000 and Kinetix 7000 drives in a safe torque-off
application.
If you do not have a basic understanding of the Kinetix 6000 and Kinetix 7000
drives, contact your local Rockwell Automation sales representative for
information on available training courses.
Conventions Used in This
Manual
The following conventions are used throughout this manual:
•Bulleted lists such as this one provide information, not procedural steps.
•Numbered lists provide sequential steps or hierarchical information.
•Bo
ldtype is used for emphasis.
Terminology This table defines acronyms used throughout this manual.
Acronym Full Term Definition
EN European Norm European Standards (EN specifications) developed by the European Committee for
Standardization for the European Union.
ISO International Organization for
Standardization Voluntary organization whose members are recognized authorities on standards, each one representing a different country.
IEC International Electrotechnical
Commission
Non-profit, non-governmental international standards organization that prepares and
publishes international standards for all electrical, electronic, and related technologies,
collectively known as electrotechnology.
PL Performance Level EN ISO 13849-1 safety rating.
SIL Safety Integrity Level The measure of a products ability to lower the risk that a dangerous failure could occur.
PFD Probability of Failure on Demand The average probability of a system to fail to perform its design function on demand.
PFH Probability of Failure per Hour The probability of a system to have a dangerous failure occur per hour.
HFT Hardware Fault Tolerance Equals N, where N+1 faults could cause the loss of the safety function. A hardware fault
tolerance of 1 means that 2 faults are required before safety is lost.
STO Safe Torque-off Functional safety feature that complies with IEC 61800-5-2.
IGBT Insulated Gate Bi-polar Transistors Typical power switch used to control main current.

8Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Preface
Additional Resources These documents contain additional information concerning related Rockwell
Automation products.
You can view or download publications at
http://literature.rockwellautomation.com. To order paper copies of technical
documentation, contact your local Rockwell Automation distributor or sales
representative.
Resource Description
Kinetix 6000 Multi-axis Servo Drive User Manual, publication 2094-UM001
Detailed mounting, wiring, setup with RSLogix 5000 software, applying
power, and troubleshooting information, with appendices to support
firmware upgrades, common bus applications, and Bulletin 2090 resistive
brake module (RBM) applications.
Kinetix 7000 High Power Servo Drive User Manual, publication 2099-UM001 Detailed mounting, wiring, setupwith RSLogix 5000 software, applying power, and troubleshooting information, with an appendix to support
firmware upgrades.
DeviceNet Modules in Logix5000 Control Systems User Manual,
publication DNET-UM004 Information on controlling devices on the DeviceNet network.
DeviceNet Safety User Manual, publication 1791DS-UM001 Information on installing and configuring the 1791DS Series modules.
System Design for Control of Electrical Noise Reference Manual,
publication GMC-RM001 Information, examples, and techniques designed to minimize system failures
caused by electrical noise.
EMC Noise Management DVD, GMC-SP004
Rockwell Automation Configuration and Selection Tools website,
website http://ab.com/e-tools Online product selection and system configuration tools, including AutoCAD
(DXF) drawings.
Rockwell Automation Product Certification,
website http://rockwellautomation.com/products/certification For declarations of conformity (DoC) currently available from Rockwell Automation.
Safety Products Catalog, website http://ab.com/catalogs Information regarding Allen-Bradley safety products.
Application Considerations for Solid-State Controls, publication SGI-1.1 A description of important differences between solid-state programmable
controller products and hard-wired electromechanical devices.
Safety of Machinery - Safety Related Parts of Control Systems,standard EN 954-1 Safety requirements and guidance on the principles for the design of safety
related parts of control systems.
Functional Safety of Electrical/Electronic/Programmable Electronic Safety-related Systems, standard
IEC 61508 Aspects to be considered when electrical/electronic/programmable electronic systems are used to carry out safety functions.
National Electrical Code, published by the National Fire Protection Association of Boston, MA An article on wire sizes and types for grounding electrical equipment.
Rockwell Automation Industrial Automation Glossary, publication AG-7.1 A glossary of industrial automation terms and abbreviations.

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 9
Chapter 1
Safety Concept and Troubleshooting
This chapter introduces you to how the safe torque-off feature meets the
requirements of Performance Level e (PLe) and safety category 3 (CAT 3) per
EN ISO 13849-1 and SIL 3 per IEC 61508, EN 61800-5-2 and EN 62061.
This chapter also provides a troubleshooting table and flowchart for
understanding the Safe Torque-off mode.
Certification The TÜV Rheinland group has approved the Kinetix 6000 and Kinetix 7000
servo drives for use in safety-related applications up to EN ISO 13849-1
Performance Level e (PLe) and category 3, SIL 3 per IEC 61508, EN 61800-5-2
and EN 62061, in which removing the motion-producing power is considered to
be the safe state.
To view the certificate, refer to EC Type - Examination Certificate on page 43.
Important Safety Considerations
You are responsible for the following:
•Validation of any sensors or actuators connected to the system
•Completing a machine-level risk assessment
•Certification of the machine to the desired EN ISO 13849-1 performance
level or EN 62061 SIL level
•Project management and proof testing
Topic Page
Certification 9
European Union Directives 10
Description of Operation 11
PFD and PFH Specifications 11
Troubleshooting 12

10 Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Chapter 1 Safety Concept and Troubleshooting
Category 3 Requirements According to EN ISO 13849-1
Safety-related parts are designed with these attributes:
•A single fault in any of these parts does not lead to the loss of the safety
function.
•A single fault is detected whenever reasonably practicable.
•Accumulation of undetected faults can lead to the loss of the safety
function, which results in failure to remove motion-producing power from
the motor.
Stop Category Definition
Stop category 0 as defined in EN 60204 or Safe Off as defined by EN 61800-5-2
is achieved with immediate removal of motion-producing power to the actuator.
European Union Directives If this product is installed within the European Union or EEC regions and has
the CE mark, the following regulations apply.
CE Conformity
Conformity with the Low Voltage Directive and Electromagnetic Compatibility
(EMC) Directive is demonstrated by using harmonized European Norm (EN)
standards published in the Official Journal of the European Communities. The
safe torque-off circuit complies with the EN standards when installed according
instructions found in this manual.
EMC Directive
This unit is tested to meet Council Directive 2004/108/EC Electromagnetic
Compatibility (EMC) by using these standards, in whole or in part:
•EN 61800-3 - Adjustable Speed Electrical Power Drive Systems,
Part 3 - EMC Product Standard including specific test methods
•EN 61326-3-1 EMC - Immunity requirements for safety-related systems
The product described in this manual is intended for use in an industrial
environment.
CE Declarations of Conformity are available online at
http://www.rockwellautomation.com/products/certification and in EC
Declaration of Conformity on page 178.
IMPORTANT
In the event of a malfunction, the most likely stop category is category 0. When
designing the machine application, timing and distance should be considered
for a coast-to-stop. For more information regarding stop categories, refer to
EN 60204-1.

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 11
Safety Concept and Troubleshooting Chapter1
Low Voltage Directive
These units are tested to meet Council Directive 2006/95/EC Low Voltage
Directive. The EN 60204-1 Safety of Machinery-Electrical Equipment of
Machines, Part 1-Specification for General Requirements standard applies in
whole or in part. Additionally, the standard EN 61800-5-1 Electronic
Equipment for use in Power Installations apply in whole or in part.
Refer to the Kinetix Servo Drives Specifications Technical Data, publication
GMC-TD003, for environmental and mechanical specifications.
Description of Operation The safe torque-off feature provides a method, with sufficiently low probability
of failure, to force the power-transistor control signals to a disabled state. When
disabled, or any time power is removed from the safety enable inputs, all of the
drive output-power transistors are released from the On-state. This results in a
condition where the drive is coasting (stop category 0). Disabling the power
transistor output does not provide mechanical isolation of the electrical output,
which may be required for some applications.
Under normal operation, the safe torque-off inputs are energized. If either of the
safety-enable inputs are de-energized, then all of the output power transistors will
turn off. The safe torque-off response time is less than 25 ms.
PFD and PFH Specifications Safety-related systems can be classified as operating in either a Low Demand
mode, or in a High Demand/Continuous mode:
•Low Demand mode: where the frequency of demands for operation made
on a safety-related system is no greater than one per year or no greater than
twice the proof-test frequency.
•High Demand/Continuous mode: where the frequency of demands for
operation made on a safety-related system is greater than once per year.
The SIL value for a low demand safety-related system is directly related to order-
of-magnitude ranges of its average probability of failure to satisfactorily perform
its safety function on demand or, simply, average probability of failure on demand
(PFD). The SIL value for a High Demand/Continuous mode safety-related
system is directly related to the probability of a dangerous failure occurring per
hour (PFH).
ATTENTION: Permanent magnet motors can, in the event of two simultaneous
faults in the IGBT circuit, result in a rotation of up to 180 electrical degrees.

12 Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Chapter 1 Safety Concept and Troubleshooting
PFD and PFH Data
These PFD and PFH calculations are based on the equations from IEC 61508
and show worst-case values. Ta ble 1 provides test data and demonstrates the
worst-case effect of various configuration changes on the data.
Table 1 - PFD and PFH Proof Test Interval
Determination of safety parameters is based on the assumption that the system
operates in High Demand mode and that the safety function is requested at least
once a year.
PFH and PFD determination was performed without considering external wiring
failure modes, as described in EN ISO 13849-2. Depending on the application,
consider taking measures to exclude these failure modes.
To proof test the safe torque-off function, you must interrupt power to the safe
torque-off function inputs (STO-5 and STO-7) and verify the drive is in the
disabled state. Refer to the Safe Torque-off Connector Pinout on page 15, for
signal descriptions and pinouts.
Troubleshooting The safe-off fault (E49) is detected upon demand of the safe-off function.
Table 2 - Kinetix 6000 and Kinetix 7000 Safe Torque-off Troubleshooting
Attribute Kinetix 6000 Drives Kinetix 7000 Drives
PFH 0.26 (e-9) 0.38 (e-9)
PFD 0.045 (e-3) 0.027 (e-3)
Proof test interval (years) 20 15
Error
Code
Fault Message RSLogix
(HIM) Problem or Symptom Potential Cause Possible Resolution
E49 DriveHardFault
(Safe-off HW Flt)
Safe-off function mismatch.
Drive will not allow motion.
·Loose wiring at safe torque-off (STO) connector.
·Cable/header not seated properly in safe
torque-off (STO) connector.
·Safe-off circuit missing +24V DC.
·Verify wire terminations, cable/header
connections, and +24V.
·Reset error and run proof test.
·If error persists,return the drive to Rockwell
Automation.
ATTENTION: After troubleshooting, a proof test must be performed to verify
correct operation.

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 13
Safety Concept and Troubleshooting Chapter1
Understanding the Safe Torque-off Condition vs Drive Fault
When both inputs de-energize within 100 ms, a fault does not occur (E49 is not
displayed), however, a safe torque-off state is entered within the 25 ms response
time. The safe torque-off condition occurs through normal drive operation.
A mismatch occurs when one input is de-energized while the other input is
energized after 100 ms. This causes the E49 error code to display and the drive
begins a shutdown sequence. Causes for a mismatch include:
•wiring anomalies at the Safe Torque-off (STO) connector, pins STO-5 and
STO-7, or the external monitoring relay.
•input anomalies associated with the Safe Torque-off (STO) connector,
pins STO-5 and STO-7.
•sequencing errors in the program.
•EMI interference.
To determine if you have a safe torque-off fault or condition, you must examine
the Axis_Servo_Drive status bit in RSLogix 5000 software.
•If bit status is 0, then no safe torque-off condition or fault exists.
•If bit status is 1, then a safe torque-off condition or fault does exist.
Figure 1 - RSLogix 5000 Software, Version 15 Safe Torque-off Status Bit
In the RSLogix 5000, version 15 example, the axis.DriveStatus.14 bit is set to 0,
indicating the drive is not in Safe Torque-off mode. No safe torque-off condition
or fault exists.
Figure 2 - RSLogix 5000 Software, Version 16 (or later) Safe Torque-off Status Bit
In the RSLogix 5000, version 16 example, the axis.SafeOffModeActiveStatus bit
is set to 0, indicating the drive is not in Safe Torque-off mode. No safe torque-off
condition or fault exists.

14 Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Chapter 1 Safety Concept and Troubleshooting
Figure 3 - Advanced Safe Torque-off Troubleshooting Flowchart
(1) This is a safe torque-off condition because the safe torque-off status bit is set to 1 without an E49 error code. After the condition is
fixed, the motion planner must be signaled that the position loop has opened in the condition state with a Motion Servo Off (MSF)
instruction before the next Motion Servo On (MSO) instruction can take place. The MSF instruction is necessary because the drive is
enabled and running.
(2) This is also a safe torque-off condition (the safe torque-off status bit is set to 1 without an E49 error code). The safe torque-off
condition must be resolved, but because the drive is not enabled and running the MSF instruction is not necessary.
10
Go to RSLogix 5000 software>Motion Group>
Axis_Servo_Drive tag name>Monitor Axis tag>
Axis_Servo_Drive.SafeOffModeActiveStatus GUI.
Go to RSLogix 5000 software>Motion Group>
Axis_Servo_Drive tag name>Monitor Axis tag>
Axis_Servo_Drive.DriveStatus bit 14.
Refer to user manual for
troubleshooting Bulletin 2094
drives without safe torque-off.
Start
Bulletin 2099 or
Bulletin 2094 with safe
torque-off (-S) drive?
RSLogix 5000
software
v15 or v16?
Yes No
Yes No 2
Yes No
Yes
No 1
Safe Torque-off fault exists.
Mismatch occurred outside
of the 100 ms responsetime.
Drive Status Indicator = Steady Red.
DriveHardFault and Axis Shutdown
in RSLogix 5000 software.
Safe Torque-off
status bit
1 or 0?
Was the axis
enabled prior to
reading bit?
No safe torque-off fault or condition.
Both inputs energized within 100 ms.
Was error code
E49 displayed?
Was error code
E49 displayed?
Safe Torque-off condition exists through
normal operation. Both inputs de-energized
within 100 ms of each other.
Resolve safe torque-off condition.
Safe Torque-off condition exists through
normal operation. Both inputs de-energized
within 100 ms of each other.
Resolve safe torque-off condition.
Complete MSF 1 instruction.
Complete MASR instruction.
Resolve safe torque-off fault.
MSO instruction or
next program step.
Finish
v15 v16 (or later)

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 15
Chapter 2
Safe Torque-off Connector Data
This chapter provides safe torque-off (STO) connector, header, and interface
cable information for the Kinetix 6000 and Kinetix 7000 safe torque-off drives.
Safe Torque-off Connector
Pinout
Headers are available to extend the 9-pin safe torque-off (STO) connector
signals for use in wiring single and multiple safe torque-off drive configurations,
or to defeat (not use) the safe torque-off function.
Table 3 - 9-pin Safe Torque-off (STO) Connector
Topic Page
Safe Torque-off Connector Pinout 15
Safe Torque-off Header Configurations 17
Safe Torque-off Accessories 20
Safe Torque-off
(STO) Connector Pin
Also Applies to These
STO Connector Headers
Description Signal
1
•Wiring plug header used in
single-drive applications
•First-drive wiring header
(2090-XNSM-W) used in
multiple-drive applications
One side of the normally-closed monitoring contact of relay 2 FDBK2+
2 Other side of the normally-closed monitoring contact of relay 2 FDBK2-
3 One side of the normally-closed monitoring contact of relay 1 FDBK1+
4 Other side of the normally-closed monitoring contact of relay 1 FDBK1-
5 Safety enable 2 input SAFETY ENABLE2+
6 Return for safety enable power (both inputs) SAFETY ENABLE-
7 Safety enable 1 input SAFETY ENABLE1+
8•Wiring plug header
•Motion-allowed jumper
Output power for continuous enable of the safety function, 500 mA, max 24V+
9 Output power return used for continuous enable of safety function 24V_COM
IMPORTANT
Pins STO-8 (internal 24V+ supply) and STO-9 (24V_COM) are used only by the
motion-allowed jumper to defeat the safe torque-off function. When the safe
torque-off function is in operation, the 24V supply must come from an external
source.

16 Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Chapter 2 Safe Torque-off Connector Data
Figure 4 - 9-pin Safe Torque-off (STO) Connector - Kinetix 6000 Drive
Figure 5 - 9-pin Safe Torque-off (STO) Connector - Kinetix 7000 Drive
BAUD
RATE
TX
RX
W
V
U
MBRK -
MBRK +
COM
PWR
DBRK -
DBRK +
1 2 3 4
1 2 3 4 5 6
1 2 3 4 5 6 7 8 9
BAUD
RATE
TX
RX
DPI
DC-
DC+
L3
L2
L1
CONT EN-
CONT EN+
W
V
U
MBRK -
MBRK +
COM
PWR
DBRK -
DBRK +
CTRL 2
CTRL 1
1 2 3 4
1 2 3 4 5 6
1 2 1 2 3 4 5 6 1 2
Axis Module (AM), Top View
(2094-BMP5-S is shown)
Safe Torque-off
(STO) Connector
Integrated Axis Module (IAM), Top View
(2094-BC01-MP5-S is shown)
1 2 3 4 5 6 7 8 9
Safe Torque-off
(STO) Connector
Kinetix 7000 Drive Module, Top View
(2099-BM06-S is shown)

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 17
Safe Torque-off Connector Data Chapter2
Safe Torque-off Header
Configurations
The safe torque-off function can be implemented in a single-drive or extended in
up to eight drives in a multiple safety-drive configuration. The connector can also
be jumpered to effectively remove the safe torque-off function.
In this example, the Kinetix 6000 axis module is shown with the motion-allowed
jumper installed in the wiring plug header. This header/jumper combination
(default configuration) ships with each Kinetix 6000 and Kinetix 7000 drive and
enables drive operation without external safety-circuit connections.
Figure 6 - Motion-allowed Jumper
In this example, the Kinetix 6000 axis module is shown with a wiring plug header.
The motion-allowed jumper has been removed. Use the wiring plug header alone
for wiring Kinetix 6000 and Kinetix 7000 single drive safe torque-off
applications.
Figure 7 - Single Drive Wiring Header
1
1 2 3 4 5 6 7 8 9
Kinetix 6000 or Kinetix 7000 Drive
(Kinetix 6000 axis module is shown)
Motion-allowed Jumper
Wiring Plug Header
Safe Torque-off
(STO) Connector
1 2 3 4 5 6 7 8 9
Kinetix 6000 or Kinetix 7000 Drive
(Kinetix 6000 axis module is shown) Safe Torque-off terminals for
input wiring (STO-1…STO-7).
Wiring Plug Header

18 Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Chapter 2 Safe Torque-off Connector Data
In this example, the Kinetix 6000 axis module is shown with a first-drive wiring
header (catalog number 2090-XNSM-W). Kinetix 6000 and Kinetix 7000 first-
drive modules use this header in multiple safe torque-off drive configurations for
wiring to a safety control circuit and extending the safe torque-off circuitry to
another drive.
Figure 8 - First-drive Wiring Header (2090-XNSM-W)
Figure 9 - First-drive Wiring Header Pin Assignment
Kinetix 6000 or Kinetix 7000 Drive
(Kinetix 6000 axis module is shown)
Safe Torque-off terminals for
input wiring (STO-1…STO-7).
Cable connector to second
drive in safety circuit.
IMPORTANT
Do not use the first-drive (2090-XNSM-W) wiring header in single-drive
applications.
SO-1 2 3 4 5 6 7

Rockwell Automation Publication GMC-RM002F-EN-P - June 2013 19
Safe Torque-off Connector Data Chapter2
In this example, the Kinetix 6000 axis module is shown with a drive-to-drive
middle header (catalog number 2090-XNSM-M). Kinetix 6000 and
Kinetix 7000 drive modules, in safe torque-off drive configurations of three or
more, use this header for making the safe torque-off connections between drives.
Figure 10 - Middle Drive Header (2090-XNSM-M)
In this example, the Kinetix 6000 axis module is shown with a last-drive
terminating header (catalog number 2090-XNSM-T). Kinetix 6000 and
Kinetix 7000 drive modules use this header in multiple safe torque-off drive
configurations for making safe torque-off connections to the last drive.
Figure 11 - Last Drive Header (2090-XNSM-T)
Kinetix 6000 or Kinetix 7000 Drive
(Kinetix 6000 axis moduleis shown)
Cable connectors to the next
and previous drive in safety circuit.
IMPORTANT
Next and previous drive cable connection to the middle header (catalog
number 2090-XNSM-M) is arbitrary. Input and output is not specified.
Kinetix 6000 or Kinetix 7000 Drive
(Kinetix 6000 axis module is shown)
Cable connector to last
drive in safety circuit.

20 Rockwell Automation Publication GMC-RM002F-EN-P - June 2013
Chapter 2 Safe Torque-off Connector Data
Safe Torque-off Accessories An assortment of headers, when wired and plugged into the safe torque-off
(STO) connector, make implementation possible, as described in this table.
Table 4 - Safe Torque-off Headers
Safe Torque-off interface cables are required for making connections with
2090-XNSM-W, 2090-XNSM-M, and 2090-XNSM-T safe torque-off headers.
Table 5 - Safe Torque-off Interface Cables
A replacement (STO) header with jumper is included in connector sets for the
Kinetix 6000 and Kinetix 7000 safe torque-off drives.
Table 6 - Replacement Connector Sets
Description Cat. No.
Safe Torque-off wiring header for the first drive in multiple safety drive configurations
(optional). 2090-XNSM-W
Safe Torque-off middle header for drive-to-drive connections in multiple safety drive
configurations with three or more drives (optional). 2090-XNSM-M
Safe Torque-off terminating header for the last drive in multiple safety drive configurations
(optional). 2090-XNSM-T
Cat. No. Description
1202-C02 Drive-to-drive safety cable, 200 mm (7.9 in.) for connecting single-wide Kinetix 6000 axis modules.
1202-C03 Drive-to-drive safety cable, 350 mm (13.8 in.) for connecting double-wide Kinetix 6000 axis modules.
1202-C10
Drive-to-drive safety cable, 1050 mm (41.3 in.) for connections between:
•Kinetix 6000 power rail and Kinetix 7000 drive.
•Two Kinetix 6000 power rails.
•Two Kinetix 7000 drives.
1202-C30 Drive-to-drive safety cable, 3 m (9.8 ft) for any connections requiring additional cable length within
the system enclosure.
IMPORTANT
Due to the current capacity limitation of the safe torque-off interface cable
connectors, multiple safe torque-off drive configurations must not exceed
eight Kinetix 6000 and Kinetix 7000 drive modules.
Cat. No. Drive Module Drive Cat. No. Description
2094-XNINV-1
Kinetix 6000 IAM and AM
Modules
2094-AC05-Mxx-S, 2094-AC09-M02-S,
2094-AMP5-S, 2094-AM01-S, 2094-AM02-S
Includes motor power (MP), motor/resistive brake (BC), and
safe torque-off (STO) replacement connectors for the IAM
(inverter) and AM modules.
2094-ANINV-2 2094-AC16-M03-S, 2094-AC32-M05-S, 2094-AM03-S,
2094-AM05-S, 2094-BC04-M03-S, 2094-BM03-S
2094-XNINV-1 2094-BC01-Mxx-S, 2094-BC02-M02-S,
2094-BMP5-S, 2094-BM01-S, 2094-BM02-S
2094-BNINV-2 2094-BC07-M05-S, 2094-BM05-S
2099-K7KCK-1 Kinetix 7000 High Power Drives 2099-BMxx-S
Includes safe torque-off (STO), general purpose I/O (GPIO),
general purpose relay (GPR), and control power (CP)
replacement connectors for Kinetix 7000 drives.
