Rockwell Automation Allen-Bradley 6180P-12KSXP User manual

Integrated Display Industrial Computers with Keypad
Catalog Numbers 6180P-12KSXP, 6180P-12BSXP, 6180P-12BPXP, 6180P-12BPXPDC, 6180P-12KPXP,
6180P-15KSXP, 6180P-15BSXP, 6180P-15BPXP, 6180P-15KPXP, 6180P-15BPXPDC
User Manual

Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to
familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws,
and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required
to be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the
use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or
software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation,
Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT
Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 3
Summary of Changes
This manual contains new and updated information. Changes throughout this
revision are marked by change bars, as shown to the right of this paragraph.
New and Updated
Information
This table contains the changes made to this revision.
Topic Page
Added title and updated ‘Preface Objectives’ section 9
Added ‘Abbreviations’ section 10
Updated ‘Chapter Objectives’ section
11, 17, 29, 33, 47
Added link to Rockwell Automation Product Compatibility and Download Center (PCDC) website 11, 49, 57, 59
Removed ‘Multilingual User-interface CD Pack’ section 12
Reduced what compact discs (CDs) are shipped with computer in ‘Parts List’ section 12
Moved existing information into ‘Installation Precautions’ section 18
Revised title and added information to ‘Installation Guidelines’ section 19
Moved existing information into ‘Mounting Clearance Requirements’ section 20
Moved existing installation and mounting information into ‘Install the Computer’ section 22
Added steps in ‘Mount the Display Computer in a Panel’ section 23
Moved existing AC and DC power information into ‘Connect Power’ section 25
Added Attention table in ‘Connect Power’ section 25
Updated IEC number for power cord in ‘Connect AC Power’ section 26
Changed Attention table to Shock Hazard table in ‘Connect AC Power’ section 26
Revised and added steps in ‘Connect DC Power’ section 27
Added information in ‘Functional Ground Screw’ section 27
Moved ‘Operator Access’ section into ‘Operating Guidelines’ section 29
Added information in ‘Operating Guidelines’ section 29
Added information in ‘Start the Computer’ section 30
Added information in ‘Restart the Computer’ section 31
Added information in ‘Shut Down the Computer’ section 32
Updated link to Rockwell Automation Computers and Operators Interface website 33, 53
Updated step 4 in ‘Post-configuration’ section 35
Added step 4 in ‘Remove the Cover’ section 36
Added information in ‘Reinstall the Cover’ section 36
Added ‘Drive Precautions’ section 37
Added ‘Hardware Monitoring’ section 47
Added Tip table in ‘Troubleshooting’ section 48
Revised opening paragraph for ‘Troubleshooting Checklists’ section 48
Replaced ‘Diagnostic Utility’ section with ‘Load the System Defaults’ section 51
Added ‘Clear the CMOS’ section 51
Added ‘Ship or Transport the Computer’ section 52
Added Turkey RoHS statement in Certifications table 55
Revised information in ‘Upgrade the BIOS from the CD Drive’ section 59
Revised information in ‘Upgrade the BIOS from an External Floppy Disk Drive’ section 61

4Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Summary of Changes
Notes:

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 5
Table of Contents
Preface Preface Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Purpose of This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Abbreviations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 1
Features
Chapter Objectives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Computer Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Computer Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 2
Installation
Chapter Objectives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installation Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Environment and Enclosure Information. . . . . . . . . . . . . . . . . . . . . . . 18
European Union Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installation Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Mounting Clearance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Computer Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Install the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Panel Mounting Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Panel Cutout Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Mount the Display Computer in a Panel . . . . . . . . . . . . . . . . . . . . . . . 23
Connect Peripherals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Connect Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Connect AC Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Connect DC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Functional Ground Screw. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connect to a Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 3
Operation
Chapter Objectives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Operating Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Keypad Function Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Start the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Restart the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Shut Down the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Table of Contents
Chapter 4
Component Replacement
Chapter Objectives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Accessories and Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Voltage Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Electrostatic Discharge Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Pre-configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Post-configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Remove the Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Reinstall the Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Drive Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replace or Install a Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replace the Existing HDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Install a Second HDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Install an Add-in Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Replace or Add Memory Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Memory Configuration Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Replace or Add a Memory Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Replace the RTC Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Backlight Assembly Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Chapter 5
System Troubleshooting
Chapter Objectives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Hardware Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Troubleshooting Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Issues during Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Issues after Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Issues Running New Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Issues with the Add-in Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Issues with the Integrated Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Issues with an External Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Diagnostic Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Load the System Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Clear the CMOS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Ship or Transport the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Appendix A
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Appendix B
Use a Touchscreen
Touchscreen Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Driver Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Resistive Touchscreen Technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Calibrate the Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 7
Table of Contents
Appendix C
Upgrade to a New BIOS
BIOS Upgrade Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Upgrade the BIOS from the CD Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Upgrade the BIOS from an External Floppy Disk Drive . . . . . . . . . . . . . 61
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

8Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Table of Contents
Notes:

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 9
Preface
Preface Objectives This preface covers the following topics:
•Purpose of This Manual
•Additional Resources
•Abbreviations
Purpose of This Manual This manual is a user guide for integrated display industrial computers with
keypad. It provides procedures to the following:
•Install the computer.
•Make computer connections.
•Operate the computer.
•Troubleshoot the computer.
Additional Resources These documents contain additional information to related products from
Rockwell Automation.
You can view or download publications at http://www.rockwellautomation.com/
literature. To order paper copies of technical documentation, contact your local
Allen-Bradley distributor or Rockwell Automation sales representative.
Resource Description
Integrated Display Computer with Keypad
Installation Instructions, publication
6180P-IN001
Provides procedures on how to install the computer and make
connections to the workstation.
Cloning Utility for Rockwell Automation
Industrial Computers Technical Data,
publication 6000-TD002
Provides information on how to create and restore a back-up image of
your computer’s hard disk drive.
Industrial Automation Wiring and
Grounding Guidelines, publication
1770-4.1
Provides general guidelines for installing a Rockwell Automation®
industrial system.

10 Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Preface
Abbreviations This publication can use the following abbreviations.
Abbr Meaning Abbr Meaning
ACPI Advanced configuration (and) power
interface
PCB Printed circuit board
AHCI Advanced host controller interface PCDC Product Compatibility and Download Center
AMI American Megatrends, Inc. PCH Platform control hub
AMT Active management technology PCI Peripheral component interconnect
BIOS Basic input/output system PCIe Peripheral component interconnect express
CF CompactFlash PEG PCI express graphics
CPU Central processing unit PELV Protective extra-low voltage
CMOS Complementary metal oxide semiconductor PERR PCI parity error
COM Communication (serial port interface) POST Power on self test
CRC Cyclic redundancy clock PSU Power supply unit
DDR Double data rate (RAM) PXE Pre-boot execution environment
DIMM Dual in-line memory module RAID Redundant array (of) independent disks
DVI Digital video interface RAM Random access memory
DVMT Dynamic video memory technology RIUP Remove or insert under power
ECC Error correcting code RMS Root-mean-square
EEA European Environment Agency RTC Real-time clock
EMC Electromagnetic compatibility SAS Serial attached SCSI
EOS Embedded operating system SATA Serial advanced technology attachment
ESD Electrostatic discharge SCSI Small computer system interface
EWF Enhanced write filter SELV Safety extra-low voltage
FAT File allocation table SERR PCI signal error
HDD Hard disk drive SPD Serial presence detect
HORM Hibernate once, resume many SSD Solid-state drive
IDE Integrated device electronics TFT Thin film transistor
IEC International Engineering Consortium UEFI Universal extensible firmware interface
IGD Intel graphics driver USB Universal serial bus
KVM Keyboard video mouse UPS Uninterruptible power source
LAN Local area network VBAT Voltage (battery)
NEMA
National Electrical Manufacturers Association VDDR Voltage (DDR RAM)
ODD
Optical disk drive VGA Video graphics array

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 11
Chapter 1
Features
Chapter Objectives This chapter provides information on the following topics:
•Computer Overview
•Operating Systems
•Computer Options
•Before You Begin
•Parts List
•Hardware Features
Computer Overview The integrated display computers with keypad feature an integrated 12- or 15-
inch display panel. These panel mount devices feature 36 or 44 programmable
function keys, a full alphanumeric keypad, and a resistive, anti-glare touch screen
option. With these features, the computers can function as an industrial
computer or an operator input station. It can be used to run visual interface,
maintenance, control, and basic information applications from one machine. The
absence of external display cables and separate component mounting
requirements allows for simple integration.
These computers are available with standard and performance features. They
come standard with a selection of I/O ports for peripheral connections; ISA and
PCI slots for expansion options; and LAN ports for communication.
Operating Systems The computers are shipped with Microsoft-licensed Windows XP Professional,
Service Pack 3 operating system installed and configured. No operating system
updates have been applied to the factory image beyond the service packs.
The I386 source directory for Microsoft Windows is on the system drive of your
computer off the root directory, C:\I386. This allows for easy removal and
addition of Windows components.
Computers with HDDs include a recovery partition with the original factory
image. Refer to the Cloning Utility for Rockwell Automation Industrial
Computers Technical Data, publication 6000-TD002, for instructions.
To obtain a copy of a factory system image, contact your local technical support
center or access the Rockwell Automation Product Compatibility and Download
Center (PCDC) at http://www.rockwellautomation.com/support/pcdc.page.

12 Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Chapter 1 Features
Computer Options This table summarizes the options available for the integrated display industrial
computers with keypad. A comparative summary of features for the computers is
in Appendix A, Specifications on page 87.
Before You Begin Before unpacking the computer, inspect the shipping carton for damage. If
damage is visible, immediately contact the shipper and request assistance.
Otherwise, proceed with unpacking.
Keep the original packing material in case you need to return the computer for
repair or transport it to another location. Use both inner and outer packing
cartons to provide adequate protection for a computer returned for service.
Parts List The computers ship with the following items.
Cat. No. Display Size (in.) Touchscreen Power Package
6180P-12KSXP 12 Keypad AC Standard
6180P-12BSXP Keypad and Touchscreen
6180P-12BPXP Performance
6180P-12KPXP Keypad
6180P-12BPXPDC Keypad and Touchscreen DC
6180P-15KSXP 15 Keypad AC Standard
6180P-15BSXP Keypad and touchscreen
6180P-15BPXP Performance
6180P-15KPXP Keypad
6180P-15BPXPDC Keypad and touchscreen DC
Item Description
Hardware •Power cord for AC power models
•Mounting clips
•Keys for front access cover lock
•Assembly screw bag
•Industrial Computer System Cloning Utility CD (red)
•CD with CD/DVD burning software(1)
(1) Shipped only with Performance models; see the table in Computer Options on page 12 for more information.
Documents •Integrated Display Industrial Computers with Keypad Installation Instructions,
publication 6180P-IN001
•Shipped Compact Discs (CDs) Update Release Note, publication 6000-RN009
•China RoHS hazardous material table insert
•Production test report

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 13
Features Chapter 1
Hardware Features The illustrations in this section show the hardware features of each computer:
•Exterior views
–Front panel
–Side panel
–Rear panel
•Interior view
•Motherboard
Figure 1 - Front Panel
Item Icon Component
1LCDpanel
2 Power/standby indicator shows the computer’s power status.
•Green: Powered on and running
•Flashing orange: Standby mode
•Off: Powered off
3 HDD/ODD activity indicator shows the drive’s status.
•Flashing red: Ongoing drive activity
•Off: No hard drive activity
4 NumLock indicator lights up green when the NumLock function is enabled.
5 CapsLock indicator lights up green when the CapsLock function is enabled.
6Alphanumerickeypad
7 Brightness control keys / Display auto adjust
8 Front access cover - Protects the front USB ports and power switch from
unauthorized access.
9Functionkeys
•1200P - 36 function keys
•1500P - 44 function keys
12345
6
7
8
9

14 Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Chapter 1 Features
Figure 2 - Side Panel
Item Component Item Component
1 Parallel port 9 Power switch
2 Microphone-in jack 10 LAN port 2
3 Line-out jack 11 LAN port 1
4 Line-in jack 12 Power supply fan
5 DVI port 13 Power input, AC
6 COM 2 14 Functional ground screw
7 COM 1 15 Ventilation slots
8 USB ports (4) 16 Expansion slot covers
16
14
15
1
23
4
5
6
7
8
91011
12 13

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 15
Features Chapter 1
Figure 3 - Rear Panel
Figure 4 - Interior View
Item Component Item Component
1 ODD eject button 5 HDD 1 bay
2 ODD mechanical eject hole 6 HDD 2 bay(1)
(1) HDD bay shipped empty for optional, second HDD.
3 ODD activity indicator 7 HDD 2 bay captive thumbscrews
4 HDD 1 captive thumbscrews
Item Component Item Component
1 Expansion board hold-down clamps 5 Power supply unit
2 System board 6 Expansion board hold-down bar
3Systemfans 7Chassiscentersupportbar
4Systemdrivecage
1
2
3
467
5
12
3
4
6
57

16 Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Chapter 1 Features
Figure 5 - Motherboard
Item Component Item Component
1 LGA775 processor socket 11 Power switch cable connector
2 Reserved for USB port connector 12 DIMM 1 slot
3 ATX12V power connector 13 DIMM 2 slot
4 Heat sink fan connector 14 RTC battery socket
5 System fan connector 15 Clear CMOS jumper
6 ODD cable connector 16 Parallel port cable connector
7 Keypad cable connector 17 PCI 3 expansion slot
8 SATA 2 cable connector 18 PCI 2 expansion slot
9 SATA 1 cable connector 19 PCI 1 expansion slot
10 ATX power connector 20 ISA expansion slot
1
2
3
7
6
5
4
89
10
111213
14
15
16
17
18
19
20

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 17
Chapter 2
Installation
Chapter Objectives This chapter provides information on the following topics:
•Installation Precautions
•Installation Guidelines
•Mounting Clearance Requirements
•Computer Dimensions
•Required Tools
•Install the Computer
•Connect Peripherals
•Connect Power
•Functional Ground Screw
•Connect to a Network
Review each mounting type and computer dimensions before installing.

18 Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Chapter 2 Installation
Installation Precautions Read and follow these precautions before installing the computer.
Environment and Enclosure Information
European Union Compliance
This computer meets the European Union Directive requirements when installed
within the European Union or EEA regions and have the CE mark. A copy of the
declaration of the conformity is available at http://www.rockwellautomation.com/
certification .
ATTENTION: This equipment is intended for use in a Pollution Degree 2
environment, in overvoltage Category II applications (as defined in IEC 60664-1),
at altitudes up to 2000 m (6562 ft) without derating. The enclosure door must
be closed.
This equipment is considered Group 1, Class A equipment according to IEC/CISPR 11.
Without appropriate precautions, there can be potential difficulties ensuring
electromagnetic compatibility in other environments due to conducted as well as
radiated disturbance.
This equipment can be mounted in an enclosure that is suitably designed to
prevent personal injury resulting from accessibility to live parts. If not mounted
inside another enclosure, the mounting method must limit the tilt of the computer
to +/- 30° from vertical. Examples include articulated arm, table-top stand, wall
mount, or other means having sufficient mechanical stability. The mounting
means must be firmly attached to the supporting surface using screws bolts, or
clamps so the computer cannot tip.
In addition to this publication, see the following:
•Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1,
for additional installation requirements
•NEMA 250 and IEC 60529, as applicable, for explanations of the degrees of
protection provided by different types of enclosure
ATTENTION: This computer is intended to operate in an industrial or control
room environment, which uses some form of power isolation from the public
low–voltage mains. Some computer configurations cannot comply with the
EN 61000-3-2 Harmonic Emissions standard as specified by the EMC Directive of
the European Union. Obtain permission from the local power authority before
connecting any computer configuration that draws more than 75 W of AC power
directly from the public mains.
To comply with EN 55024, the Ethernet port LAN cable 30 m (98.42 ft), only used
indoors, and not exit the building at any point. All other I/O cables must be less
than 3 m (9.84 ft) and only used indoors.

Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014 19
Installation Chapter 2
Installation Guidelines
Follow these guidelines to make sure your computer provides safe and reliable service:
•The installation site must have sufficient power.
•In dry environments, static charges can build up easily. Proper grounding
of the computer helps to reduce static discharges, which can cause shock
and damage electronic components.
•The enclosure must allow sufficient space around air inlets and outlets to
provide the circulation necessary for cooling. See Mounting Clearance
Requirements on page 20 for further information. Never allow air passages
to become obstructed.
•The ambient air temperature must not exceed the maximum operating
temperature specified in Tab le 4 on pa g e 4 8 . Consider a user-supplied fan,
heat exchanger, or air conditioner for heat generated by other devices in
the enclosure.
•The humidity of the ambient air must not exceed limits specified in
Ta b le 4 o n p a g e 4 8 and must avoid condensation.
•
The enclosure or cover must remain in place at all times during operation. The
cover provides protection against high voltages inside the computer and
inhibits radio-frequency emissions that can interfere with other equipment.
• When mounted, the computer cannot be tilted more than 30° from vertical.
ATTENTION: To maintain an electrically safe installation, AC powered
computers must be plugged into a grounded outlet.
TIP
Hot air rises. The temperature at the top of the enclosure is often
higher than the temperature in other parts of the enclosure, especially
if air is not circulating.
IMPORTANT
The computer can operate at a range of extremes. However, the life
span of any electronic device is shortened if you continuously operate
the computer at its highest rated temperature.
Acceptable Unacceptable
≤30°
from Vertical
≤30°
from Vertical

20 Rockwell Automation Publication 6180P-UM001C-EN-P - February 2014
Chapter 2 Installation
Mounting Clearance
Requirements
Figure 6 - Minimum Clearances
IMPORTANT
Because of self-heating, do not operate the computer in an enclosure with the
minimum clearances unless adequate ventilation or other cooling methods are
used to lower the temperature within the enclosure.
Allow enough clearance to easily install or remove peripheral components, such
as internal drives.
1
2
3
4
5
Item Description Value
1 Top 50 mm (2 in.)
2Left 50mm(2in.)
3Rear
Air flow
ODD
HDD access
25 mm (1 in.)
140 mm (5.5 in.)
178 mm (7 in.)
4Right
I/O port access and
ventilation
76.2 mm (3 in.)
5 Bottom 102 mm (4 in.)
Right and left are based on facing the front of the
computer.
