Rockwell Automation Allen-Bradley VersaView 6300B User manual

User Manual Original Instructions
Machine Mount Box PC
Bulletin Number 6300B-MM

2Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Machine Mount Box PC User Manual
Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before
you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to
requirements of all applicable codes, laws, and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to be carried out by suitably
trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this
equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and requirements associated with
any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
These labels may also be on or inside the equipment to provide specific precautions.
The following icon may appear in the text of this document.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).
Identifies information that is useful and can help to make a process easier to do or easier to understand.

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 3
Table of Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
About This Publication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Download Associated Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Download UEFI and BIOS Firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Terminology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Machine Mount Box PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 1
Overview Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Approximate Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Peripheral Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 2
Prepare for Installation Unpack Your Box PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Environment and Enclosure Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
UL/cUL Mark Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
European Union Directive Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Site Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Placement Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Power Connection Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Tools and Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 3
Installation Determine Mounting Bracket Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Secure Your Box PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
For Wall-mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
For Shelf-mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connect the Box PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connect the Peripheral Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Grounding and Bonding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connect Network Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connect the AC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connect to the Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 4
Operate Operating Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Manual Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Restart Via the OS (preferred method). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Restart with the Reset Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Shut Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Table of Contents
Shut Down Via the OS (preferred method) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Shut Down with the AC Power Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chapter 5
Configure, Restore, and Update
System Settings
Use the Setup Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
About the Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
View and Modify Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Back Up or Restore the OS Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Initial Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Back Up the OS Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Restore the OS Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Update the UEFI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Step 1 — Verify FAT32 File Format of the USB Flash Drive . . . . . . . . . . . . . . . . . . . . 29
Step 2 — Download the Updated UEFI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Step 3 — Update the UEFI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Restore Factory Defaults through a DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Step 1 — Change the DIP Switch Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Step 2 — Reset to Factory Default using the UEFI Setup Utility . . . . . . . . . . . . . . . 31
Chapter 6
Maintenance and Service Clean Exterior Surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Remove/Reinstall the Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Remove the Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Reinstall the Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Add/Remove Hardware on the Motherboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Connect to the Internal USB Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Remove/Add RAM Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Add an Expansion Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Replace the Internal Battery Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Add an HDD/SSD Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 5
Preface
About This Publication This manual is a user guide providing procedures to install, connect, operate, and troubleshoot
your 6300B machine mount box PCs.
A general knowledge of automation technology is needed to understand and follow the
instructions in this publication.
Knowledge of personal computers and Microsoft® Windows® operating systems (OS) are
required to understand and follow the instructions in this publication.
Download Associated Files Download UEFI and BIOS Firmware
The Product Compatibility and Download Center, rok.auto/pcdc, may be accessed to download
various files, such as UEFI and BIOS firmware, and view product release notes associated with
your 6300B machine mount box PC. Registration is required before downloading files.
Terminology Machine Mount Box PC
Throughout this manual, the term “box PC” is used to refer to your 6300B machine mount box
PC bulletin number. This bulletin number is specified on the product label that is located on
the side of your box PC.
Additional Resources These documents contain additional information concerning related products from Rockwell
Automation. You can view or download publications at rok.auto/literature.
Resource Description
6300B Machine Mount Box PCs Installation Instructions, 6300B-IN003 Provides installation instructions for the 6300B machine mount box PCs.
6300B Industrial Computer and Monitor Specifications Technical Data, IC-TD003 Provides technical specifications about the 6300B machine mount box PCs.
American Standards, Configurations, and Ratings: Introduction to Motor Circuit
Design, IC-AT001
Provides an overview of American motor circuit design based on methods that are
outlined in the NEC.
CIP Security™ with Rockwell Automation Products Application Technique, 
SECURE-AT001
Provides information on CIP Security, including which Rockwell Automation products
support CIP Security.
EtherNet/IP™ Network Devices User Manual, ENET-UM006 Describes how to configure and use EtherNet/IP devices to communicate on the
EtherNet/IP network.
Ethernet Reference Manual, ENET-RM002 Describes basic Ethernet concepts, infrastructure components, and infrastructure
features.
FactoryTalk® Edge Gateway User Manual, 95055-UM006D-EN-P Provides information about how to use FactoryTalk Edge Gateway to connect
operational technology (OT) to information technology (IT) destination systems.
Industrial Automation Wiring and Grounding Guidelines, 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system.
Industrial Components Preventive Maintenance, Enclosures, and Contact Ratings
Specifications, IC-TD002
Provides a quick reference tool for Allen-Bradley® industrial automation controls and
assemblies.
Product Certifications website, rok.auto/certifications Provides declarations of conformity, certificates, and other certification details.
Safety Guidelines for the Application, Installation, and Maintenance of Solid-state
Control, SGI-1.1
Designed to harmonize with NEMA Standards Publication No. ICS 1.1-1987 and provides
general guidelines for the application, installation, and maintenance of solid-state
control in the form of individual devices or packaged assemblies incorporating solid-
state components.
System Security Design Guidelines Reference Manual, SECURE-RM001 Provides guidance on how to conduct security assessments, implement Rockwell
Automation products in a secure system, harden the control system, manage user
access, and dispose of equipment.
UL Standards Listing for Industrial Control Products, CMPNTS-SR002 Assists original equipment manufacturers (OEMs) with construction of panels, to help
confirm that they conform to the requirements of Underwriters Laboratories.

6Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Notes:

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 7
Chapter 1
Overview
Your box PC runs operations from small visual interface and maintenance applications to large
control and information applications. It comes standard with a selection of I/O ports for
peripheral connections and expansion slots.
Features Your box PC offers the following features:
• Available with the Microsoft® Windows® 10 Internet of Things (IoT) LTSC 2019 OS or
without an OS
• An Intel® Core™ i5 microprocessor
•A512GBsolid-statedrive(SSD)
• Two extractable bays on the front for 2.5-in. SATA III drives
• An internal USB port for activation dongles or other USB storage devices
• A cooling fan rated with a total power consumption between 10…20 W when using
expansion slots
• Wall-mount or shelf-mount installation using the supplied mounting kit
Approximate Dimensions The following figure provides important dimensions to plan the installation of your box PC.
Figure 1 - Approximate Dimensions [mm (in.)], No Brackets
8.0
(0.31)
430.0
(16.93)
438.0
(17.24)
305.0
(12.00)
175.0
(6.89)
Side View Front View
Bottom View

8Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 1 Overview
Peripheral Connections The following table identifies the I/O ports, buttons, and light-emitting diode (LED) status
indicators on the rear and front of your box PC.
Figure 2 - Rear View: I/O Ports and Buttons
Note No. Component/Cable Type
1 Power ON button
2 PS/2™ mouse port
3 PS/2™ keyboard port
44xUSB2.0ports
5 2 x Display Port ports
6 Serial COM port (DB9M)
7DVI-Dport
8 2 x 1 GB LAN ports
9 4 x USB 3.1 ports
10 Line-in jack
11 Line-out jack
12 Microphone-in jack
13 Functional ground screw
14 AC power input
15 AC power switch
16 7 x PCI/PCIe expansion slots
Figure 3 - Front View: I/O Ports, Buttons, and LED Status Indicators
Note No. Component/Cable Type
17 Power ON button
18 Reset button
19 Power ON LED
20 HDD activity LED
21 2 x USB 3.0 ports
22 2 x USB 2.0 ports
23 2 x external access SSD
Rear Panel
2
4
5
6 7
8 9
10
11
12
13 14 15
16
1
3
Front Panel
(shown with access door open)
17
19
21
22
20
23
18

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 9
Chapter 2
Prepare for Installation
Unpack Your Box PC Before you unpack your box PC, inspect the shipping carton for damage. If damage is visible,
immediately contact the shipper and request assistance. Otherwise, proceed with unpacking.
Your box PC ships with the following items.
Installation Precautions Read and follow these precautions before you install your box PC.
Environment and Enclosure Information
Keep the original packing material in case you must return your box PC for repair
or transport it to another location.
See the label on the side of your box PC to identify its catalog number (cat. no.).
Record this cat. no. for future reference.
Table 1 - Parts List
Item Description
Hardware
• Mounting bracket kit:
– L-shaped wall-mount brackets, quantity 2
– Z-shaped brackets, quantity 2
– M4x8 screws, eight washers, quantity 8
– Self-locking hexagonal nuts, quantity 8
– Shock absorbers, quantity 4
• Extraction key and 6.5 cm (2.5 in.) height adapter for optional SSD installation
• For U.S. installation only: 1.8 m (5.9 ft) ≤ 125V rated AC power cord, quantity 1
Document • 6300B Machine Mount Box PC Installation Instructions, publication 6300B-IN003
ATTENTION: This equipment is:
• intended for use in a Pollution Degree 2 industrial environment, in overvoltage
Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m
(6561 ft) without derating.
• considered Group 1, Class A industrial equipment according to
IEC/EN 61326-1. Without appropriate precautions, there can be potential
difficulties with electromagnetic compatibility in other environments due to
conducted as well as radiated disturbance.
• considered open equipment, which means it must be mounted in an enclosure
where the equipment can be operated from the front panel.
The enclosure in which this equipment is installed must be accessed only with
a key or tool, and only by trained and authorized personnel.
In addition to this publication, see the following:
• Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1,
for more installation requirements
• UL 50, CSA C22.2 No. 94.1, and IEC 60529, as applicable, for explanations of the
degrees of protection provided by enclosures

10 Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 2 Prepare for Installation
UL/cUL Mark Compliance
Equipment with the UL/cUL mark complies with the requirements of UL 61010-1, UL 61010-2-
201, CSA C22.2 No. 61010-1, and CSA C22.2 No. 61010-2-201. A copy of the certificate of
compliance is available at rok.auto/certifications.
This equipment is not suitable for use in locations where children are likely to be present.
European Union Directive Compliance
This box PC meets the European Union Directive requirements when installed within the
European Union or EEA regions and have the CE marking. A copy of the declaration of the
conformity is available at rok.auto/certifications.
Installation Requirements Site Requirements
Your box PC can be installed in various installation sites, including mounting cabinets, control
cabinets, switch boards, or consoles. To make sure that your box PC provides service with
excellent reliability, the installation site must:
• have sufficient power,
• be indoors in an industrial or control room environment that uses some form of power
isolation from the public, low voltage mains,
• be stored in a surrounding air temperature range of -20…+60 °C
(-4…+140 °F).
• be kept away from direct sunlight, and
• operate in a surrounding air temperature of 0…50 °C (32…122 °F) with the relative
humidity of the ambient air 10…90% noncondensing.
Placement Requirements The placement of your box PC must:
• be at a suitable height,
• be attached to a flat, level surface (such as a shelf or against a wall),
- holes are provided on both sides of the box PC for side mounting installation and on
the bottom for an upright installation
• use the supplied mounting kit, and
ATTENTION: This equipment is intended to operate in an industrial or control
room environment, which uses some form of power isolation from the public
low-voltage mains.
Obtain permission from the local power authority before you connect any
computer configuration that draws more than 75 W of AC power directly from
the public mains.
All I/O cables must be used only indoors.
IMPORTANT Your box PC must not be exposed to a surrounding air
temperature above 50 °C (122 °F), especially when the PC is
mounted in an enclosure.
IMPORTANT When you use expansion cards, the factory-installed cooling fan
requires a maximum total power consumption of 20 W,
accounting for their power consumption.

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 11
Chapter 2 Prepare for Installation
• have at least 7.62 cm (3 in.) of clearance at the front and rear of your box PC. See
Approximate Dimensions on page 7 to determine this minimum clearance.
Power Connection
Guidelines
Follow these power connection guidelines for your box PC.
• Power cord guidelines are dependent upon your geographical location.
- For applications in North America: use the AC power cord provided, which is an IEC
60320 C14 receptacle with a NEMA 5-15P three-prong plug.
- For all other international applications: any IEC 60320 C13 power cord can be used.
• Supply your box PC circuit with its own disconnecting means.
• Use an uninterruptible power supply (UPS) (not supplied) to help protect against
unexpected power failure or power surges.
Tools and Hardware The following tools and hardware are required for your box PC installation.
IMPORTANT The required minimum clearance of 7.62 cm (3.00 in.) provides
adequate ventilation and adequate space to install and remove
peripheral cables and components (such as storage drives).
IMPORTANT Your box PC generates heat. Do not operate your box PC in an
enclosure without the minimum clearances unless adequate
ventilation or other cooling methods are used to lower the
temperature within the enclosure.
IMPORTANT The power supply input accepts 100…240V AC power to your box PC.
For ease of installation, you need two people to mount your box PC; one person
holds the box PC while the second person secures it to a wall or shelf.
IMPORTANT To comply with EN 61326-1, all I/0 peripheral cables must be shielded
and be rated for indoor use only. All USB cables must be less than
9.84 ft. (3.00 m) in length.
IMPORTANT The supplied AC power cord cannot be used if the power source is
greater than 125V. You must supply an AC power cord with a suitable
rating.
Table 2 - Tools and Hardware List
Supplied
For All Installations
• For U.S. only: 1.80 m (5.90 ft) ≤ 125V rated AC power cord , quantity of 1
• Extraction key and 6.5 cm (2.5 in.) height adapter for optional SSD
installation
For Shelf-mount or
Wall-mount Installation
• Mounting bracket kit:
– L-shaped wall-mount brackets, quantity of 2
– Z-shaped brackets, quantity of 2
– M4x8 screws, eight washers, quantity of 8
– Self-locking hexagonal nuts, quantity of 8
• Shock absorbers, quantity of 4
Not Supplied
For All Installations
• For countries outside of the U.S.: properly rated power cord
– see Power Connection Guidelines for specifications
• I/O peripheral cables
• Cutting tool and cable tie for optional internal USB port installation
• Torx 7 and Torx 2.5 mm screwdriver for optional SSD installation
• External display, keyboard with numeric keypad, and mouse for initial
operation and maintenance
For Shelf-mount or
Wall-mount Installation
• M6 or four M3 screws, quantity of 4
• Internal toothed washers, quantity of 4
• Carpenter Square
•Level
• Drill motor and drill bits
•Pencil

12 Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 2 Prepare for Installation
Notes:

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 13
Chapter 3
Installation
You can place your box PC on any flat, level surface in environments where vibration is present
or can be secured with mounting brackets and screws (supplied) in environments where
vibration is present.
Determine Mounting
Bracket Placement The placement of the mounting brackets depends upon your choice of wall or shelf mounting.
Figure 4 - Wall or Shelf-mount Installation: Bracket Secured to Side of Box PC
If your box PC is placed on a level surface where vibration is not present, mounting
brackets are not required. In this instance, proceed to Connect the Box PC on
page 17.
To ease installation, add internal devices to the motherboard before you secure
your box PC. See Add/Remove Hardware on the Motherboard on page 34 for
instructions.
2.0
(0.09)
2.0
(0.09)
11.0
(0.43)
7.0
(0.28)
31.0
(1.22)
Ø 6.5
(0.26)
26.5
(1.04)
18.50
(0.73) 260.0
(10.24)
430.0
(16.93)
448.0
(17.64) 392.0
(15.43)
305.0
(12.01)
205.0
(8.07)
175.0
(6.89)
217.0
(8.54)
Side View
Front View
Bottom View
Front View

14 Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 3 Installation
Figure 5 - Shelf-mount Installation Only: Brackets Secured to Side of Box PC
1. Determine whether your box PC will be a wall-mount or shelf-mount installation.
• For wall-mount installation: The Z-shaped mounting bracket can only be attached
to the side of your box PC.
• For shelf-mount installation: The Z-shaped mounting bracket can be secured to
either the side or bottom of your box PC.
2. Be sure the placement provides adequate space to connect and reconnect I/O
peripheral cables and allow adequate airflow. See Placement Requirements on page 10.
3. See Table 3 to determine the mounting holes and screw size (not provided) for your
selected installation type.
Table 3 - Determine Mounting Hole and Screw Size for L-shaped Mounting Brackets [mm (in.)]
Mounting Holes Screw Size Suggested Torque Description
A
M6
(1/4-20)
4 Qty
5 N•m
(44.25 lb•in)
Use A Mounting Holes when:
• Shock and vibration are not environmental elements
• Suitable for shelf mounting applications only
B
M3
(4-40)
4 Qty
1.2 N•m
(10.62 lb•in)
Use B Mounting Holes when:
• Shock and vibration are environmental elements
• For all wall mounting applications
Ø 4.0
(0.16)
Ø 7.0
(0.28)
Ø 10.0
(0.39)
20.0
(0.79)
28.5
(1.12)
30.0
(1.81)
30.0
(1.81)
2.0
(0.09)
240.0
(9.45)
192.0
(7.56)
212.0
(8.35)
175.0
(6.89)
180.0
(7.09)
305.0
(12.01)
430.0
(16.93)
460.0
(18.11)
480.0
(18.90)
Side View Front View
Bottom View
Ø8
(0.31)
A
B
4x Ø4
(0.16)
4x Ø7
(0.28)
A4x Ø4
(0.16)
4x 20
(0.79)

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 15
Chapter 3 Installation
Secure Your Box PC Follow the instructions below for your selected installation type.
For Wall-mount Installation
1. Attach the Z-shaped brackets to the side of your box PC.
a. Secure two shock absorbers (supplied) to the lower bracket with two self-locking
hexagonal nuts (supplied).
b. Tighten the self-locking hexagonal nuts to a torque of 2 N•m (17.71 lb•in).
c. Fasten the Z-shaped brackets to the side of your box PC with the washers and
screws (supplied).
d. Tighten the screws to a torque of to 2 N•m (17.71 lb•in).
2. Attach the L-shaped brackets to the wall.
a. Secure the remaining two shock absorbers (supplied) to the upper bracket with two
self-locking hexagonal nuts (supplied).
b. Tighten the self-locking hexagonal nuts to a torque of 2 N•m (17.71 lb•in).
c. Place the L-shaped mounting brackets against the wall. See Figure 4 on page 13 to
determine the location of the mounting holes.
d. With the L-shaped mounting brackets level, mark the mounting hole locations that
you selected in Table 3 on page 14.
e. Drill at the marked mounting hole locations.
f. Align the holes of L-shaped mounting brackets to the drilled mounting holes in the
wall.
g. Secure the L-shaped mounting brackets to the wall with four internal toothed
washers (not supplied) and four screws (not supplied).
h. Tighten the screws the suggested torque to the value shown in Table 3 on page 14.
For ease of installation, you need two people to mount your box PC; one person
holds the box PC while the second person secures it to the wall.
IMPORTANT To meet the shock and vibration specification, the shock absorbers
must be attached and secured to your box PC with the self-locking
hexagonal nuts.
Step aand b
Step d
Step a…b
Step c…h

16 Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 3 Installation
3. Place your box PC onto the L-shaped mounting brackets.
4. Attach the four self-locking hexagonal nuts (supplied) to the shock absorbers to the L-
shaped mounting brackets.
5. Tighten the self-locking hexagonal nuts to a torque of 2 N•m (17.71 lb•in).
For Shelf-mount Installation
1. Prepare the shelf.
a. Be sure that the shelf is level.
b. Use a carpenter square to position the Z-shaped brackets on the shelf. See Figure 4
on page 13 or Figure 5 on page 14 to determine the location of the mounting holes.
c. Mark the mounting hole locations determined in Table 3 on page 14.
d. Drill at the marked mounting hole locations.
2. Attach the four shock absorbers.
a. Insert four shock absorbers (supplied) through the drilled mounting holes in the
shelf.
b. Secure each shock absorber with a self-locking hexagonal nut (supplied).
c. Tighten the self-locking hexagonal nuts to a torque of 2 N•m (17.71 lb•in)..
IMPORTANT To meet the shock and vibration specification, the shock absorbers
must be attached and secured to your box PC with the self-locking
hexagonal nuts.

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 17
Chapter 3 Installation
3. Attach the Z-shaped brackets to the bottom of your box PC with the washers and
screws (supplied).
4. Tighten the screws to a torque of 2 N•m (17.71 lb•in).
5. Align the bracket holes with the posts of the shock absorbers and set your box PC on
the shelf.
6. Attach a self-locking nut onto each shock absorber to the underside of the shelf.
7. Check that the self-locking nuts on the shock absorbers are at a torque of
2 N•m (17.71 lb•in).
Connect the Box PC Connect the Peripheral Cables
1. See Peripheral Connections on page 8 for I/O port locations.
2. Connect peripheral cables (not supplied) to the front and/or back of your box PC.
IMPORTANT Do not connect the AC power cord to your box PC until instructed to do
so. See Connect the AC Power on page 18.
IMPORTANT Do not power on your box PC until instructed to do so.
IMPORTANT To comply with EN61326-1, all I/O cables must be shielded and
rated for indoor use only. USB cables must be less than
9.84 ft (3 m) in length. See Grounding and Bonding for guidance.

18 Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 3 Installation
Grounding and Bonding
Whenever two connected pieces of equipment are far apart, it is possible that their ground
connections could be at a different potential level.
To overcome possible grounding problems, the following bonding methods are recommended:
•Method 1: Connect the data cable shields to the equipotential bonding rail on both sides
before connecting the cable to the interfaces.
•Method 2: Use an equipotential bonding cable (16 mm2or AWG 6) to connect the
grounds between your monitor and your mbox PC.
Connect Network Cables
1. Locate the two 1 Gb LAN ports at the rear of your box PC.
See Peripheral Connections on page 8.
2. Insert one end of a CAT5 or CAT5e twisted-pair Ethernet cable with RJ45 connectors
(not supplied) into the LAN port.
3. Insert the other end of the Ethernet cable to your network.
Connect the AC Power
Use the Functional Ground Screw (optional)
Install the Ground Wire
To install the ground wire, perform the following steps.
1. Turn off the main power switch or breaker.
2. Remove the supplied nut, eyelet terminal, and washers from the ground screw located
at the rear panel of the box PC. See Peripheral Connections on page 8.
3. For earth ground, fasten a 1.5 mm2(16 AWG) or larger external wire to the eyelet
terminal.
4. Install the ground wire to the ground screw in the following sequence.
5. Tighten the ground screw.
IMPORTANT • To help prevent performance degradation of Ethernet communication,
do not subject the box PC or cables to extreme radiation or conducted
high-frequency noise.
• In industrial environments, proper cable routing and power conditioning
are required for Ethernet communication. We recommend that you
route all Ethernet cabling through dedicated metal conduits. For
improved performance, install ferrite bead filters at the cable ends.
The pre-installed functional ground screw is not required for safety or regulatory
compliance. If a supplemental ground is desired, use the functional ground screw
that is located on the rear panel of the box PC.
Use ground wire with an insulation color that is approved by your local
inspection authority.
Sequence No. Description
1 Toothed washer
2 Eyelet terminal
3Washer
4Lockwasher
5 Ground screw
12 345

Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022 19
Chapter 3 Installation
Connect to the Power Source
1. Connect the AC power cord to the AC power input located at the rear of your box PC. See
Peripheral Connections on page 8 to identify its location.
2. Connect the AC power cord to a power source with an earth ground.
3. Apply 100…240V AC power to your box PC.
SHOCK HAZARD: Failure to connect the AC power cord to a power
source with an earth ground can result in electrical shock.
ATTENTION: When you connect power to the box PC for the first time,
the following actions occur:
For box PCs with a Windows® OS: you must read and accept an End
User Setup procedure.
• Do not disconnect power from the system until after the setup
procedure is completed. If power is disconnected during this
procedure, it can result in a corrupted system image.
• Always shut down the Windows OS before you disconnect power to the
box PC to minimize performance degradation and OS failures.
For box PCs with another OS: the default universal extensible
firmware interface (UEFI) setting automatically starts the box PC after
it is plugged into a power source.

20 Rockwell Automation Publication 6300B-UM003A-EN-P - December 2022
Chapter 3 Installation
Notes:
