Rockwell Automation Allen-Bradley DeviceNet 193-DNCT User manual

DeviceNet™ Configuration Terminal
Catalog Numbers 193-DNCT
User Manual

™ Configuration Terminal

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 iii
Important User Information
Because of the variety of uses for the products described in this publication, those responsible for the application and use of
this control equipment must satisfy themselves that all necessary steps have been taken to assure that each application and
use meets all performance and safety requirements, including any applicable laws, regulations, codes and standards.
The illustrations, charts, sample programs and layout examples shown in this guide are intended solely for purposes of
example. Since there are many variables and requirements associated with any particular installation, Rockwell Automation
does not assume responsibility or liability (to include intellectual property liability) for actual use based upon the examples
shown in this publication.
Allen-Bradley publication SGI-1.1, Safety Guidelines for the Application, Installation and Maintenance of Solid-State
Control (available from your local Allen-Bradley distributor), describes some important differences between solid-state
equipment and electromechanical devices that should be taken into consideration when applying products such as those
described in this publication.
Reproduction of the contents of this copyrighted publication, in whole or part, without written permission of Rockwell
Automation, is prohibited.
Throughout this manual we use notes to make you aware of safety considerations:
Attention statements help you to:
•identify a hazard
•avoid a hazard
•recognize the consequences
European Communities (EC) Directive Compliance
If this product has the CE mark, it is approved for installation within the European Union and EEA regions. It has been
designed and tested to meet the following directives.
•EMC Directive
•This product is tested per EN61000-6-4:2001 and EN61000-6-2:2005.
Allen-Bradley is a trademark of Rockwell Automation. DeviceNet™ is a trademark of the Open DeviceNet™ Vendors
Association (ODVA). All other trademarks and/or registered trademarks are the property of their respective owners.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage or economic loss
IMPORTANT
Identifies information that is critical for successful application and understanding of the product.

iv Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Manual Objectives
The purpose of this manual is to provide you with the information necessary to apply the DeviceNet™ Configuration
Terminal. Described in this manual are methods for installing, configuring, and troubleshooting the DeviceNet™
Configuration Terminal.
Who Should Use This Manual
This manual is intended for qualified personnel responsible for setting up and servicing DeviceNet™ devices. You must have
previous experience with and a basic understanding of communications terminology, configuration procedures, required
equipment, and safety precautions.
You should understand DeviceNet™ network operations, including how devices operate on the network.
Vocabulary
In this manual we refer to the:
Bulletin 193 DeviceNet™ Configuration Terminal as 193-DNCT, DNCT, terminal, Configuration Terminal, or HIM
(Human Interface Module)
Programmable Logic Controller as a Programmable Controller, PLC controller, SLC controller, ControlLogix Controller,
or PLC
DeviceNet™ as DNet or DNET
Reference Manuals
DeviceNet™ Media Design and Installation Guide
•Publication DNET-UM072_-EN-P
Copies of this and all other reference publications are available at http://www.rockwellautomation.com/literature/.
IMPORTANT
Read this manual in its entirety before installing, operating, servicing, or initializing the DeviceNet™
Configuration Terminal.
IMPORTANT
Read the DeviceNet™ Media Design and Installation Guide (Publication DNET-UM072_-EN-P)
in its entirety before planning and installing a DeviceNet™ system. If the network is not installed
according to this document, unexpected operation and intermittent failures may occur.

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 1
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
European Communities (EC) Directive Compliance. . . . . . . . . . . . . . . . . iii
Manual Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Who Should Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Vocabulary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Reference Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Chapter 1
Product Overview
Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Bill of Material. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 2
Installation and Wiring
Installation and Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
193-CB1 Physical Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
193-CM1 Physical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
193-DNCT-BZ1 Physical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Powering the 193-DNCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3
Physical Features
Physical Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Communication Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Key Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Shifted Key Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 4
Quick Start
Powerup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Terminal Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Network Who Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Device Choices Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parameter Monitoring and Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
DeviceNet™ Configuration Terminal Setup Menus. . . . . . . . . . . . . . . . . . 15
Port Object And Routing Sub Nets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Who Menu Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chapter 5
Device Choices Menu
Device Choices Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Standard Device Status Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fault/Warning Choice Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fault Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Warning Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Table of Contents
Chapter 6
Parameter Choices Menu
Parameter Choices Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Groups Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Num List Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Parameter Edit Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Numeric Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Accessing a Different Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Changing a Parameter Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Enumerated Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Floating Point Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Search for Changed Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Parameter Display-Value Enumerated. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 7
Copy Cat Menu
Copy Cat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Copy Cat Uploading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Copy Cat Downloading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Copy Cat Downloading and Product Revisions . . . . . . . . . . . . . . . . . . . . . 33
Copy Cat Downloading and Product Current Ratings. . . . . . . . . . . . . . . 34
Deleting Copy Cat Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Copy Cat Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
DeviceLogix™ Library 5 Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Chapter 8
Tools Menu
Tools Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Node Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Class Instance Attribute Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Graph Setup Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Graph View Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Assembly Consumed/Produced Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Chapter 9
Advanced Functions Menu
Advanced Functions Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Chapter 10
HeartBeat Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Chapter 11
I/O Message Monitoring
I/O Message Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 3
Table of Contents
Chapter 12
DeviceLogix™ Functionality
DeviceLogix™ Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
DeviceLogix™ Choices Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
DeviceLogix™ Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Boolean Gates: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Bistable Latches: RS Latch and SR Latch . . . . . . . . . . . . . . . . . . . . . . . 50
Counters: Up Counter and Up/Down Counter . . . . . . . . . . . . . . . . 50
Timers: On Delay, Off Delay and Pulse Timer . . . . . . . . . . . . . . . . . . 51
Discrete Output Points (DOPs): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Produced Network Bits (PNBs):. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
DeviceLogix™ Editor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Creating a New Function Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Function Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Assigning Source Bits to Function Block Inputs . . . . . . . . . . . . . . . . . . . . 53
Chapter 13
Discrete I/O Status
Discrete I/O Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Chapter 14
Zone Interlock Protocol (ZIP)
Zone Interlock Protocol (ZIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
ZIP Consumed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Mapping Consumed ZIP Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
ZIP Produced Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
ZIP Data Table Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Chapter 15
DeviceNet™ Scanner Menu
DeviceNet™ Scanner Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Scanner Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
AutoScan Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
ScanList Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Node Activation Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Chapter 16
Terminal Choices Menu
Terminal Choices Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Version Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Offline Connection Set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Offline Change Address Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
DeviceNet™ Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Network Statistics Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

4Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Table of Contents
Chapter 17
Terminal Setup Menu
Terminal Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Communication Setup Screen (HIM Comm) . . . . . . . . . . . . . . . . . . . . . . 69
Password Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Password Setup (Primary) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Password Setup (Secondary) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Entering a Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Resetting Forgotten Passwords. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Auto Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
AutoDisplay Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
AutoDisplay Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Programmable User Function Key Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Function Key Setup Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
LCD Contrast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Chapter 18
Copy and Paste Feature
Copy and Paste Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Chapter 19
Menu Help Feature
Menu Help Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Chapter 20
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Specifications
Appendix A
DeviceNet™ Objects
Identity Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Message Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
DeviceNet™ Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Connection Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 5
Chapter 1
Product Overview
Product Overview The 193-DNCT product is a handheld device that can be used to commission,
configure, program, and monitor other devices on a DeviceNet™ network. In
addition, the 193-DNCT can be used to upload, store, and later download
complete device configurations for DeviceNet™ devices via the network. The
193-DNCT also has the capability to present DeviceNet™ physical layer
diagnostics and network bandwidth statistics to the user.
Bill of Material The 193-DNCT product package includes the following items:
Accessories
Item Description Quantity
193-DNCT DeviceNet™ Configuration Terminal 1
193-CB1 1 m DNCT Cable with color-coded bare leads 1
193-QR002_-EN-P DeviceNet™ Configuration Terminal Quick Reference 1
Description Catalog No.
1 m DNCT Cable with color-coded bare lead 193-CB1
1 m DNCT Cable with microconnector (male) 193-CM1
Door mount bezel kit 193-DNCT-BZ1
Mini-Mini-Micro Tee for connection to ArmorStart 1485P-P1R5-MN5R1
5-pin connector 1787-PLUG10R
ATTENTION: The Bulletin 193 DeviceNet™ Configuration Terminal
should only be used on a DeviceNet™ network.

6Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Chapter 1 Product Overview
Notes:

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 7
Chapter 2
Installation and Wiring
Installation and Wiring The DNCT ships complete with a 1 m cable (193-CB1) for connection to a
DeviceNet™ network. This cable has a plug connection to the terminal on one
end, and color coded bare leads on the other end. Alternately, a 1 m cable (193-
CM1) can be ordered that has a plug connection to the terminal on one end, and
a DeviceNet™ male micro style connector on the other end. A bezel mounting kit
(193-DNCT-BZ1) is available for mounting the terminal to a panel door.
193-CB1 Physical Connections
The 193-CB1 cable that ships with the Configuration Terminal has a plug
connection to the terminal on one end, and color coded bare leads on the other
end. The cable’s bare leads are wired to a DeviceNet™ connector according to the
following table:
193-CM1 Physical Connections
The optional Cat. No.193-CM1 has a plug connection to the terminal on one
end and a DeviceNet™ male micro-style connector on the other end. The cable’s
micro connector pin-out is shown in Figure 1 -
Figure 1 - Cat. No. 193-CM1 Pinout
Signal Function Color
V- Common Black
Can_L Signal Low Blue
Drain Shield Non-insulated
Can_H Signal High White
V+ Power Supply Red
Drain
Can_L
Can_H
V+
V-

8Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Chapter 2 Installation and Wiring
193-DNCT-BZ1 Physical Connections
The optional Cat. No. 193-DNCT-BZ1 connects to the DeviceNet™ network via
an attached cable that has color coded bare leads. The cable’s bare leads are wired
to a DeviceNet™ connector according to the following table:
Powering the 193-DNCT The DNCT must be powered from an external 24V DC source through the
communication cable. The 24V DC connections should be made to the V+ and
V- pins/wires in the above cable pinout/wire definitions.
ATTENTION: When mounting in a door or panel-mounted bezel kit,
only the Cat. No. 193-DNCT-BZ1 DeviceNet™ Bezel Kit should be used
with the Bulletin 193-DNCT DeviceNet™ Configuration Terminal.
Signal Function Color
V- Common Black
Can_L Signal Low Blue
Drain Shield Non-insulated
Can_H Signal High White
V+ Power Supply Red
ATTENTION: Before physically connecting the DNCT to a target device,
verify that the external power supply has adequate capacity to power all
devices on the network.

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 9
Chapter 3
Physical Features
Physical Features Figure 1 - Cat. No. 193-DNCT Physical Features
Communication Port The communication port is used to connect the DNCT to a DeviceNet™
network through use of a communication cable or bezel mount kit (Cat. No. 193-
DNCT-BZ1). Additionally, 24V DC power is provided to the DNCT at the
communication port.
8-Line, 21-Character,
Backlit LCD Display
Function Keys
Numeric Entry Keys
Navigation Keys
Communication
Port
Reset Key

10 Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Chapter 3 Physical Features
Key Descriptions
Shifted Key Descriptions The following table describes the alternate functionality of each key when it is
pressed after the shift key.
Escape Key. Exit a menu or cancel a change.
Select key. Select a value, digit, or screen choice.
Increment key. Scroll through options, increase a value, or toggle a bit.
Decrement key. Scroll through options, decrease a value, or toggle a bit.
Enter key. Enter a menu, enter a mode, or enter a value.
Scroll left or right keys. Scroll left or right through a value.
Shift key. Small values (yellow text) on top of keys are entered when
pressed after the shift key.
Used to enter numbers.
Used to enter a decimal place for a number.
Used to negate a numeric value. Used to add a sign character when
editing a value.
Programmable function keys. See Chapter 16, Function Key Setup
Screen.
Programmable Reset key. See Chapter 16, Function Key Setup Screen.
…
Key
Combination
The letter A. Used to enter values in hexadecimal.
The letter B. Used to enter values in hexadecimal.
The letter C. Used to enter values in hexadecimal.
The letter D. Used to enter values in hexadecimal.
The letter E. Used to enter values in hexadecimal.
The letter F. Used to enter values in hexadecimal.
Copy function. Used to copy Class, Instance, and/or Attribute data to the clipboard. Available
on screens displaying a small “C” in the upper right corner.
Exponential function. Used to enter values in exponential notation.
Paste function. Used to paste Class, Instance, and/or Attribute data from the clipboard.
Available on screens displaying a small “P” in the upper right corner.
Help function. Invoke help information for the current screen.

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 11
Chapter 4
Quick Start
Powerup The DeviceNet™ Configuration Terminal is shipped so that when it is placed on
the network for the first time, it will automatically set its baud rate to that of the
traffic on the network, and then assign itself an unused network address. On
power up, the following screen is displayed:
Note that there is a 10-second powerup delay programmed at the factory. The
above screen will appear for at least 10 seconds on initial powerup. The powerup
delay can be modified in the Terminal Setup screen described in the following
section. Once the baud rate is determined and a network address has been set, the
terminal will display the Network Who screen, which displays a list of all devices
on the network.
Note: To go directly to the Terminal Setup screen, press and hold the ESC key
during powerup.
IMPORTANT
If the terminal fails to enter the Network Who screen
after approximately 20 seconds, it is because it could
not determine the network baud rate due to lack of
traffic on the network. Pressing the ESC key will allow
the user to enter the Terminal Setup screen so that a
fixed baud rate and network address can be set for the
terminal.
Baud = Fixed
baud rate
Auto =
AutoBauding
Actual baud
rate
Adrs = Fixed HIM
MacID
Auto = Auto
Addressing
Actual
terminal
address

12 Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Chapter 4 Quick Start
Terminal Setup
To scroll through the items on the screen, press the SEL key. To change the value
of a selected item, press the Increment or Decrement key. To commit the new
value for use, press the Enter (return arrow) key. To exit this screen, press the
ESC key.
Network Who Screen The terminal searches for all devices on the network and reports the devices it has
found on the Network Who screen. Use the Increment or Decrement key to
scroll through devices. Press Enter (return arrow) to invoke the Device Choices
menu.
Device Choices Menu This menu allows the user to choose what operation is to be performed for the
selected device. The terminal only displays choices that are appropriate for the
selected device. The Increment and Decrement keys allow the operator to scroll
through the selections. The Enter key will advance to the selected operation.
Powerup delay
in seconds
Fixed Address
setting OR the
starting address for
auto address
Enable = AutoBaud enabled
Disable = Use fixed Baud Rate
Fixed Baud
Rate setting
Enable = Auto addressing on power up
Disable = Use fixed network address
Searching at this address
Currently
selected device
Device address
“-“=Device is not faulted
“~” = Device is faulted
Currently selected operation

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 13
Quick Start Chapter4
Ve r s i o n : Displays Version information for the selected device.
Params: Provides access to configuration and status parameters for the selected
device. Allows the operator to search for parameters that are not at factory
defaults.
Copy Cat: Upload and store complete device configurations, including
DeviceLogix™ programs to the programming terminal’s memory. Download
stored device configurations from the programming terminal memory to the
selected device.
To o l s : Provides access to Node Commissioning functions, the Class Instance
Attribute editor, and the real time graphing function.
Advanced: Provides access to the DeviceLogix™ editor, DeviceNet™ IO message
timing information, ZIP configuration, and local input and output status display.
Scanner: If the selected device is a DeviceNet™ scanner, provides access to simple
scanner configuration values and access to the scan list.
Parameter Monitoring and
Editing
Parameters can be accessed as either groups or as a numbered list of all
parameters. The Parameter Screen displays all information for a single parameter.
From the Parameter Screen, parameter values can be monitored or edited.
Scrolling through a parameter list is accomplished by pressing the Increment or
Decrement keys from the Parameter Screen. Parameters can also be accessed by
entering a parameter number with the numeric keys while in the Parameter
Screen. The parameter screen has the following format:
Parameter values are continuously updated.
Press Shift Copy to copy parameter Class,
Instance, Attribute info to the clipboard
Parameter
number
Parameter name
Paramete
r value Parameter units
A parameter help string, minimum value, maximum
value and default value are scrolled across the screen

14 Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Chapter 4 Quick Start
Change a parameter value by first pressing the SEL key and then modifying the
selected value.
Pressing the Enter key will write the new value to the selected device. When a
parameter value is selected, pressing the ESC key will deselect the parameter
value and allow movement within the parameter list or group.
Bit-enumerated parameters are displayed and modified as follows:
Pressing the Enter key will write the new value to the selected device. When a
parameter value is selected, pressing the ESC key will deselect the parameter
value and allow movement within the parameter list or group. Pressing the ESC
key will delete changes and revert to the previous settings for that parameter.
1) Press the SEL key to
select the value
2) The Increment and Decrement keys increment or decrement the value
when it is selected. An edit box will appear when a key is pressed.
OR
Enter a number from the numeric keypad. An edit box will appear when a
key is pressed.
1) Press the SEL key to select a bit to
change.The selected bit name is
displayed here
Press < (scroll left) or >(scroll right) to select the next
bit
2) Press the Increment (or 0) or Decrement (or 1) key or to toggle the bit value

Rockwell Automation Publication 193-UM009B-EN-P - February 2013 15
Quick Start Chapter4
DeviceNet™ Configuration
Terminal Setup Menus
The 193 DeviceNet™ Configuration Terminal often refers to itself as a HIM
(Human Interface Module). When This DNet HIM is chosen from the Network
Who screen, the following HIM Choices Menu appears:
The HIM Setup menu allows the user to configure many of the programming
terminal features.
Port Object And Routing Sub
Nets
The 193-DNCT has the capability to route down one DeviceNet™ sub net for
devices that support the Port Object. This allows the user to easily view devices
on the network display menu.
Displays version information
Allows the user to perform Faulted
Node Recovery for nodes that fail
the Dup Mac ID test
Displays and latches Network Diagnostic information such as Baud Rate,
Bus Voltages, Bus Loading characteristics and CAN errors
Displays the HIM Setup Menu
(shown below)
Displays a
DeviceNet™
communicatio
n error log
Invokes the Terminal Setup screen described
above
Sets up the 5 security
passwords:
1 primary and 4
secondary passwords.
Primary passwords
enable/disable all
editing functions
Secondary passwords
enable/disable editing
of the features
presented by the
terminal
Auto Display setup
enables the display of up
to 4 parameter values
from one or more devices
at powerup
Configures the
operation of the User
Adjust the
screen contrast

16 Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Chapter 4 Quick Start
Who Menu Display The Who Menu displays the device information for devices that support a
DeviceNet™ sub net.
When the +DeviceNet Subnet choice is selected and the Enter key is pressed,
the Subnet Who Menu will be displayed.
Selecting a device at the Subnet Who menu and pressing the Enter key will
display all of the menus available at the standard Who menu.
