Roger MCT12E User manual

MCTxxE Readers Installation Manual v1.0 fv1.0.2 Rev.A.doc 2017-05-04
Page 1of 2
Roger Access Control System
MCTxxE Readers Installation Manual
Firmware: 1.0.2 and higher
Hardware: v1.0
Revision: Rev. A
This document refers to:
MCT12E, MCT12E-IO, MCT12E-BK, MCT12E-IOBK, MCT32E-IO, MCT64E-IO, MCT66E-IO, MCT68ME-IO
This document contains minimum information that is necessary for
initial setup and installation of the device. The detailed description of
the reader functionality is described in MCTxxE Readers Operating
Manual available on the www.roger.pl website.
INTRODUCTION
The reader is designed to operate within RACS 5 system as a slave unit
connected to MC16 through RS485 bus. Factory new reader is
addressed to ID=100 and the rest of settings are default.
Before connecting to the controller reader requires an unique address.
Programming of other parameters depends on the individual installation
scenario requirements and is not obligatory. Addressing of the reader
can be done from PC by means of RogerVDM program or manually
through the Memory Reset procedure. Configuring of the reader by
RogerVDM requires RUD-1 interface (Fig. 1).
PROGRAMMING FROM PC
To perform this method reader has to be connected to PC via RUD-1
interface and programmed by means of RogerVDM software.
Fig. 1 Reader connection method to RUD-1 interface.
Programming procedure:
1. Connect reader to RUD-1 interface according to Fig. 1 (screw
terminals and wires description is in the Table 1).
2. In RogerVDM click: Device -> New.
3. Select proper device model, firmware version, communication
channel and serial port, on which RUD-1 is installed.
4. Click Connect, the software will establish connection with the reader
and automatically will proceed to Configuration tab, which enables
full configuration of the reader.
5. Set a proper RS485 address (in range of 100 to 115) and the rest
of configuration (depending of requirements).
6. Click Send to device –the software will send the configuration to
reader.
7. As an option, you can save the configuration in a file (Send to file
command). It allows you to restore the settings which has been
sent to device.
8. In RogerVDM click: Device -> Disconnect.
9. Disconnect reader from RUD-1 interface.
Note: Do not press keypad or read card when reader is under operation
with RogerVDM program .
MEMORY RESET PROCEDURE
Memory reset procedure restores factory settings of the reader and
allows to set the RS485 address manually.
To perform memory reset follow these steps:
1. Remove all connections from A, B, CLK and DTA lines.
2. Short CLK and DTA lines or put jumper on MEM contacts (in case of
MCT68ME-IO reader).
3. Restart the reader (switch power supply off and on or short RST
contacts for a while).
4. When LED STATUS (red), LED OPEN (green) and LED SYSTEM
(orange) will light up (for MCT68ME-IO the CONFIG RESET
inscription will appear) remove connection between CLK and DTA or
take off jumper from MEM contacts.
5. While LED SYSTEM is flashing enter three digits which will set the
RS485 address.
6. After entering the third digit reader will restart with new address
automatically.
Readers without keypad can be manually programmed by so called
multiple card reading method. In this method key pressing is emulated
by multiple card reading. In order to emulate key [N] read card N-
times and then wait for two beeps. Once you hear two beeps you can
proceed further with emulation of next digit. Digit 0 is emulated by 10-
times of card reading. Any EM 125 kHz UNIQUE card can be used for
multiple card reading method.
Example:
In order to program 101 address:
1. Read card 1 time and wait for double beep.
2. Read card 10 times and wait for double beep.
3. Read card 1 time and wait for double beep.
4. Wait until reader restarts with a new address and factory settings.
FIRMWARE UPGRADE
Firmware can be upgraded by means of RogerISP software and RUD-1
communication interface (Fig. 1). The file with latest firmware is
available at www.roger.pl
Firmware upgrade procedure:
1. Connect reader to RUD-1 interface according to Fig. 1.
2. Put jumper on FDM contacts (location of contacts is given on Fig.
2).
3. Restart the reader (switch power supply off and on or short RST
contacts for a while).
4. Run RogerISP software.
5. Select communication port where the RUD-1 interface has been
installed and choose programming through RS485.
6. Choose path to firmware file (*.hex).
7. Click Program and follow the instructions.
8. Remove jumper from FDM contacts and restart the reader.

MCTxxE Readers Installation Manual v1.0 fv1.0.2 Rev.A.doc 2017-05-04
Page 2of 2
DRAWINGS
Fig. 2 Location of service contacts.
Table 1: Connection screw terminals/wires description
Name
Wire colour
(MCTxxE-IO)
Wire colour
(MCTxxE)
Description
12V
Red
Red
Supply plus
GND
Black
Blue
Supply minus
IN1
Pink
IN1 input line
IN2
Blue
IN2 input line
IN3
White-yellow
IN3 input line
RS485 A
Brown
Brown
RS485 bus, A line
RS485 B
Green-white
White
RS485 bus, B line
CLK
White
Green
RACS CLK/DTA bus,
CLK line
DTA
Green
Yellow
RACS CLK/DTA bus,
DTA line
TMP
Yellow
Pink
Tamper Switch
TMP
Grey
Grey
Tamper Switch
IO1
Yellow-brown
IO1 output line
IO2
Green-brown
IO2 output line
REL1-NC
Grey-pink
REL1 relay output (NC)
REL1-
COM
Red-blue
REL1 common relay
terminal
REL1-NO
Violet
REL1 relay output (NO)
Table 2: Technical description
Supply voltage
10-15 VDC
Current consumption
(average)
MCT12E/MCT12E-IO: ~50 mA
MCT12E-BK/MCT12E-IOBK: ~40 mA
MCT64E-IO: ~50 mA
MCT66E-IO: ~40 mA
MCT68ME-IO: ~100 mA
Inputs
Three NO/NC inputs (IN1..IN3) internally
connected to the power supply plus through
a 15kΩ resistor, approx. 3.5V triggering
level
Relay outputs
Relay output (REL1) with single NO/NC
contact, 30V/1.5A DC/AC of max. load
Transistor outputs
Two transistor outputs (IO1, IO2), open
collector type, 15VDC/1A of max. load
Reading distance
up to 10 cm (for MCT66E)
up to 7 cm (for MCT12E, MCT64E,
MCT68ME-IO)
Anti-sabotage
protection (TAMPER)
Isolated contact, 50mA/24V, NC when
enclosure is closed
Proximity cards
EM 125 kHz Unique, EM4100/4102
compatible
Distances
Up to 1200 m of cable distance between
controller and reader
Ingress protection
IP65
Environmental class
(according to EN
50133-1)
Class IV, outdoor, temperature: -25°C –
+60°C, relative humidity: 10 to 95% (non-
condensing)
Dimensions H x W x D
MCT12E: 152,5 X 46 X 23(35) mm
MCT64E-IO: 115 X 80 X 35 mm
MCT66E-IO: 85 X 85 X 27 mm
MCT68ME-IO: 170 X 110 X 42 mm
Weight
MCT12/64/66E: approx. 150g
MCT68ME-IO: approx. 410g
Approvals
CE
Fig. 3 Readers and modules connection method to MC16.
The symbol of a crossed-through waste bin on wheels means
that the product must be disposed of at a separate collection
point. This also applies to the product and all accessories
marked with this symbol. Products labeled as such must not be
disposed of with normal household waste, but should be taken
to a collection point for recycling electrical and electronic
equipment. Recycling helps to reduce the consumption of raw
materials, thus protecting the environment. Weight of the
equipment is specified in the document.
