Connect the other end of the Component (RGB) and RCA Audio cables
to the matching coloured ports on the back of your HDTV.
With your TV turned off and your Rogers
remote pointing towards the digital box, press
the CBL then PWR buttons on the remote.
AConnect The Digital Box To Your TV
BAuthorize The Digital Box
Confirm the digital box is authorized.
1. Turn on the digital box by pressing PWR on the
Rogers remote.
2. Change the channel to 03 by pressing 0 -0- 3
on your Rogers remote.
Is Channel 03 being displayed?
Yes: Continue to Section C , below.
No: Channel 03 is “Not Authorized”.
Call 1 866 894 9962 to have the digital box
authorized. You will be asked for the phone
number associated with your account.
Installing your Rogers digital box is as easy as A - B - C.
AConnect The Digital Box To Your TV
BAuthorize The Digital Box
CProgram Your Rogers Remote And Additional Options
From Digital Box
High Definition
Easy Installation Guide
Connect the end of the Coaxial cable coming from your wall to the
CABLE IN port. Connect one end of the Component (RGB) and RCA
Audio cables to the matching coloured ports.
Note: Be sure to securely finger tighten all cable connections.
CProgram Your Rogers Remote And Additional Options
Component Connection: This connection uses the Component (RGB) Video and RCA Audio cables, provided by
Rogers.
Note: Remember the name of the Component port you selected, ex. COMP 1,
RGB 1, etc. You will need this for Step 7.
Connect one end of the power cord to the
back of the digital box and the other end to
the wall outlet.
Note: To ensure the digital box remains author-
ized and updated, keep the power cord
and Coaxial cable connected at all times.
Wait for the time to appear on the digital
box.
Turn your HDTV on and set it to the input used in Step 3.
Most TVs can be connected
to multiple video sources
like DVD players and
VCRs. To view
programming from your
digital box, your HDTV
must be set to the input
selected in Step 3.
Change your HDTV input by
pressing the Input or Source button on the front
of the TV or by using your TV's remote control.
Note:
Your Rogers remote can-
not be used to change
the HDTV input until it
has been programmed to
control your TV.
Are you installing the digital box
yourself?
Yes: I am installing the digital box
myself. Continue to Step 2.
No: A technician installed my digital box
for me. Go to Section C below.
In addition to operating the digital box, the Rogers remote is capable of controlling basic commands on your
TV, VCR and other devices. To enable these features, the Rogers remote must be programmed for your
particular home entertainment components.
Program the Rogers remote for your TV.
Since the Rogers remote control is a universal remote, you can program it to control other components by
repeating the steps and substituting the TV button with the respective device button (VCR, DVD, etc.).
1. Turn your TV on.
2. Press the TV button on the Rogers remote.
3. Press and hold SETUP until the TV button flashes twice.
4. Press 9- 9- 1, the TV button flashes twice.
5. Point the remote towards your TV and press PWR.
6. Repeatedly press and release the CH+ button until your TV turns off. The remote will
cycle through all possible codes until a match is found.
Note: You may need to press the CH+ button dozens of times before finding a
match.
7. Once the TV turns off, press the SETUP button to lock the code. The TV button will
flash twice.
8. Confirm the correct code was locked by pressing the PWR button to turn on your TV.
What if this did not work?
Your remote should have come with a small guide that contains specific codes for programming popular
components. Consult that guide for futher instructions.

Important Information About Your TV
• Some televisions can experience image “Burn-In” if fixed images are displayed for extended periods of time. Consult your TV manufacturer’s docu-
mentation for more information.
• Always keep the digital box plugged in to the power outlet and connected to the cable outlet. Do not disconnect it when not in use. Updates are
sent periodically to the digital box and if the box is not connected and plugged in, you may miss an update. Also, if the box is disconnected for a
long period of time, your channels may become unauthorized when it is reconnected.
PTV Easy Installation Guide - ATL HD v4.0 07/09 ©2009 Rogers Cable Communications Inc.
OPTIONAL Connect Additional Equipment To Your TV
The order in which you connect your other components like a VCR and DVD player to the TV is very important. Below is the recommended connection order for High
Definition TVs. Any additional cables that may be required are sold separately.
With this connection you can:
• Watch TV programming, DVDs and VCR videos on your HDTV.
• Watch HDTV programming on your HDTV.
• Listen to TV shows and movies from the digital box on your stereo or home
theatre.
• Record the show you are watching on the digital box to your VCR.
Note:
This hookup will not allow you to record one program on your VCR while
watching another.
For other hookup options visit: www.rogershelp.com/hookups
Setting your PIN will prevent people in your household who shouldn’t be able to view certain programming and/or purchase On Demand or Pay Per View content
from doing so.
For further instructions refer to Your PersonalTV User Guide or www.rogershelp.com/PIN
How Do I Order Rogers On Demand?
Why Should I Set My PIN?
1. Tune to channel 100. An On Demand splash screen appears.
2. Use the UP/DOWN/LEFT/RIGHT and SELECT buttons on your remote to navigate
through the menus.
3. Scroll up/down to see the different On Demand services available.
4. To select a category, highlight it and press the SELECT button.
5. Highlight a title to see the price, running time and cast information.
6. Press INFO to view the movie synopsis.
7. Press Bto purchase the title.
8. Press PLAY to begin playback of your purchased title.
9. Use the VCR buttons to control the playback of your Rogers On Demand selection.
TIP: Find out what titles are premiering this month by visiting rogers.com/rod
Where Can I Get More Information/Help With The PersonalTV Service?
Help with common problems can be found in the troubleshooting section of Your PersonalTV User Guide:
No picture on any channel (Just a black screen) No sound Remote control does not work
“Not Authorized” messages on channels I should be receiving Changing the PIN Can’t view High Definition programming
Before calling Rogers for Technical Support . . .
Most common problems can be fixed by rebooting the digital box. To reboot the box:
1. Unplug the power cord and wait 10 seconds. 3. Press the PWR button on the Rogers remote.
2. Plug the power cord back in and wait 10 minutes. 4. Ensure your TV is on and is set to the input used in Step 3.
How Do I Solve Common Problems?
To help you get the most out of your PersonalTV service, and to solve potential problems, Rogers provides you with a wide range of support options.
Use the information below to choose the support option that best meets your needs.
Your PersonalTV User Guide Online Support Email Phone
Your PersonalTV User Guide is a com-
prehensive user guide designed to help
you resolve the most common trou-
bleshooting issues.
Save time by following the quick and
easy steps detailed in the guide included
with your digital box.
Visit us at:
www.rogershelp.com for additional
PersonalTV information.
View a selection of How To Videos at:
rogershelp.com/video
Email us at:
[email protected]
for technical support.
Call us at 1 888 ROGERS1
(1 888 764 3771) and follow
the prompts.
