Rola CRM19-2 User manual

2, RME17-2-91MRC:rebmuNedoCtcudorP
Maximum Carrying Capacity: 80 kg
532 Issue C
Sheet 1 of 2 19/11/09
STEP 2: Placement Of Locking Straps
A. Locate Anchor points on vehicle roof (Fig. 2.a).
Unscrew existing button head bolts with the Red Key
supplied, to reveal threaded Anchor points.
B. Locate the Rubber Washer and Retaining Strap over
the Anchor Point.
C. Use the M8x20mm Button head bolts and Spring
Washers supplied to secure Retaining Strap to each
Anchor Point (Fig.2.b). Tighten Bolts with Red key
provided, to secure Retaining Strap to vehicle.
A firm hand tightness is adequate.
Anchor Points are indicated by arrows
Front of Vehicle
Fig 2b
Fig 2a
Retaining Strap
Front Rear
Arrow Direction
indicates centre
of Vehicle
www.rola.com.au
M8 x 20mm Button head Bolt
Rubber Washer
VOLKSWAGEN
CADDY VAN
3/05 ON
REMOVABLE MOUNT
ROOF RACKS
Strap
Cage nut
Strap
Cage nut
Fig.1a. Fig.1b.
End Support
Bottom Slug
M8 Bolt
Flat Washer
Spring Washer
Security
Bolt
RE Global Bar
End Cap
Buffer Strip
Under Cover Strip
RE Global
Cross Bar
End Support
Bottom Slug
M8 Bolt
Flat Washer
Spring Washer
Commercial Buffer Strip
Under Cover Strip
Security
Bolt
Commercial
Cross Bar
Commercial Bar
End Cap
COMMERCIAL SERIES SPORTS SERIES
STEP 1:Fitting End
Support to Cross-bar
A. Insert End Support into
Cross-bar.
B. Insert Nut into Bottom Slug
and then slide both
components into the
cross-bar.
C. Loosely fasten using Bolt,
Spring Washer and Flat
Washer.
Assemble as shown in Fig.1
D. Fit End Cap to each end
of cross-bar.
NOTE: Your purchased kit contains
either the “Commercial Series” parts or
the “Sports Series” parts. Please refer to
diagrams on the right.

VOLKSWAGEN
CADDY VAN
3/05 ON
ProductCodeNumber: CRM19-2
Maximum Carrying Capacity: 80kg
REMOVABLE MOUNT
ROOF RACKS
STEP 3: Fitting Cross Bar to Vehicle
Cross Bar
Assembly
End Support
Retaining
Strap
Security Key
M6/20 Security
Bolt
Fig. 3a.
Fig. 4
Fig. 5.a
Cross Bar
End Support
Undercover Strip
Push up and
press firmly
Cross Bar Assembly
Undercover Strip fitted to
one side of Cross Bar.
Undercover Strip fitted
and secure to Cross Bar.
Fig. 5.b
Cage Nut
A. Place Cross Bar Assembly onto appropriate Retaining
Straps and align end supports. Loosely fit M6x20mm
Security Bolts through End Support and engage Cage
Nut. Tighten two or three turns with Security Key
provided. Go to other side of the Vehicle and fit other
End Support the same (Fig.3.a).
B. Measure overhang of Cross Bar past end support and
adjust Cross Bar till it equally overhangs on either
End Support. Tighten End Support M8 Hex head Bolts.
Ensure all other bolts have been adequately tightened.
STEP 4: Measuring Undercover Strip
STEP 5: Fitting Undercover Strip
A. Using a tape measure, obtain a
size for Dimension X (Fig.4).
B. With the Undercover Strip on a flat
surface, mark and cut the length
obtained in StepA; using strong
scissors.
Note: Caution should be taken
when using sharp blades.
A. Place one side of the Undercover Strip
into the position under the Cross Bar as shown
(Fig.5.a)
B. Apply pressure along the opposite edge of the
Undercover Strip until the whole length is clipped
securely into position (Fig.5.b).
Dimension X
(Measured between End Supports)
End Support
532 Issue C
Sheet 2 of 2 19/11/09
www.rola.com.au
