Roland MDX-40A User manual

User's Manual
Thank you very much for purchasing this product.
To ensure correct and safe usage with a full understanding of this product's performance, please
be sure to read through this manual completely and store it in a safe location.
Unauthorized copying or transferral, in whole or in part, of this manual is prohibited.
The contents of this operation manual and the specifications of this product are subject to
change without notice.
The operation manual and the product have been prepared and tested as much as possible. If
you nd any misprint or error, please inform us.
Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which
may occur through use of this product, regardless of any failure to perform on the part of this
product.
Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may
occur with respect to any article made using this product.

For the USA
FEDERAL COMMUNICATIONS COMMIS-
SION RADIO FREQUENCY INTERFER-
ENCE STATEMENT
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protec-
tion against harmful interference when the equipment
is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
Unauthorized changes or modication to this system
can void the users authority to operate this equipment.
When the equipment requires a usb cable, it must be
shielded type.
For Canada
CLASS A NOTICE
This Class A digital apparatus meets all requirements of
the Canadian Interference-Causing Equipment Regula-
tions.
CLASSE A AVIS
Cet appareil numérique de la classe A respecte toutes
les exigences du Règlement sur le matériel brouilleur
du Canada.
NOTICE Grounding Instructions
In the event of a malfunction or breakdown, grounding
provides a path of least resistance for electric current to
reduce the risk of electric shock. This tool is equipped
with an electric cord having an equipment-grounding
conductor and a grounding plug. The plug must be
plugged into a matching outlet that is properly installed
and grounded in accordance with all local codes and ordi-
nances.
Do not modify the plug provided - if it will not t the out-
let, have the proper outlet installed by a qualied electri-
cian.
Improper connection of the equipment-grounding conduc-
tor can result in a risk of electric shock. The conductor
with insulation having an outer surface that is green with
or without yellow stripes is the equipment-grounding
conductor. If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment-ground-
ing conductor to a live terminal.
Check with a qualied electrician or service personnel if
the grounding instructions are not completely understood,
or if in doubt as to whether the tool is properly grounded.
Use only 3-wire extension cords that have 3-prong
grounding plugs and 3-pole receptacles that accept the
tool's plug.
Repair or replace damaged or worn cord immediately.
WARNING
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
For EU Countries
For EU Countries
Manufacturer:
ROLAND DG CORPORATION
1-6-4 Shinmiyakoda, Kita-ku, Hamamatsu-shi, Shizuoka-ken, 431-2103 JAPAN
The authorized representative in the EU:
Roland DG Corporation, German Ofce Halskestr. 7, 47877 Willich, Germany
For California
WARNING
This product contains chemicals known to cause cancer,
birth defects and other reproductive harm, including lead.
Roland DG Corp. has licensed the MMP technology from the TPL Group.
1

Operating Instructions
KEEP GUARDS IN PLACE and in working order.
REMOVE ADJUSTING KEYS AND WRENCHES. Form
habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it on.
KEEP WORK AREA CLEAN. Cluttered areas and bench-
es invite accidents.
DON'T USE IN DANGEROUS ENVIRONMENT. Don't
use power tools in damp or wet locations, or expose them
to rain. Keep work area well lighted.
KEEP CHILDREN AWAY. All visitors should be kept safe
distance from work area.
MAKE WORKSHOP KID PROOF with padlocks, master
switches, or by removing starker keys.
DON'T FORCE TOOL. It will do the job better and safer
at the rate for which it was designed.
USE RIGHT TOOL. Don't force tool or attachment to do a
job for which it was not designed.
USE PROPER EXTENSION CORD. Make sure your
extension cord is in good condition. When using an exten-
sion cord, be sure to use one heavy enough to carry the
current your product will draw. An undersized cord will
cause a drop in line voltage resulting in loss of power and
overheating.
WEAR PROPER APPAREL. Do not wear loose clothing,
gloves, neckties, rings, bracelets, or other jewelry which
may get caught in moving parts. Nonslip footwear is rec-
ommended. Wear protective hair covering to contain long
hair.
USE SAFETY GLASSES, face or dust mask if cutting
or cleaning operation is dusty. Everyday eyeglasses only
have impact resistant lenses, they are NOT safety glasses.
SECURE WORK. Use clamps or a vise to hold work
when practical.
DON'T OVERREACH. Keep proper footing and balance
at all times.
MAINTAIN TOOLS WITH CARE. Keep tools sharp and
clean for best and safest performance. Follow instructions
for lubricating and changing accessories.
DISCONNECT TOOLS before servicing; when changing
accessories, such as blades, bits, cutters, and the like.
REDUCE THE RISK OF UNINTENTIONAL START-
ING. Make sure switch is in off position before plugging
in.
USE RECOMMENDED ACCESSORIES. Consult the
owner's manual for recommended accessories. The use of
improper accessories may cause risk of injury to persons.
NEVER STAND ON TOOL. Serious injury could occur
if the tool is tipped or if the cutting tool is unintentionally
contacted.
CHECK DAMAGED PARTS. Before further use of the
tool, a guard or other part that is damaged should be care-
fully checked to determine that it will operate properly
and perform its intended function - check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its
operation. A guard or other part that is damaged should be
properly repaired or replaced.
NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don't leave tool until it comes to a
complete stop.
USE POWER SUPPLY CORD WHICH IS ATTACHED
WITH PRODUCTS. Do not use other power supply cord.
2

3
Contents
To Ensure Safe Use......................................................................................6
Pour utiliser en toute sécurité...................................................................13
Important Notes on Handling and Use.............................................................20
About the Documentation for This Machine ...................................................21
Documentation Included with the Machine .................................................21
Installing the NC Code Reference MANUAL...............................................21
Viewing the NC Code Reference MANUAL................................................22
Chapter 1 Getting Started ................................................................................23
1-1 Machine Highlights...............................................................................24
Overview of the Unit.....................................................................................................................24
Operating the Machine ................................................................................................................24
1-2 Part Names and Functions ..................................................................25
Front....................................................................................................................................................25
Side......................................................................................................................................................26
VPanel.................................................................................................................................................27
Built-in Panel ....................................................................................................................................28
Chapter 2 Installation and Setup ..........................................................................29
2-1 Checking the Included Items................................................................30
2-2 Installation............................................................................................31
Installation Environment .............................................................................................................31
Installation Environment .............................................................................................................31
Removing and Storing the Retainers ......................................................................................33
2-3 Cable Connections...............................................................................34
Connecting the Power Cord.......................................................................................................34
Connecting to the Computer.....................................................................................................35
2-4 Installing and Setting Up the Software.................................................36
System Requirements...................................................................................................................36
The Software You Can Install and Set Up...............................................................................37
Installing the Windows-based Driver......................................................................................38
Installing VPanel and Other Softwares ...................................................................................39
Viewing the Documentation for the Softwares...................................................................40
Chapter 3 Basic Operation...............................................................................41
3-1 Types of Emergency Stops to Ensure Safety.......................................42
How to Perform an Emergency Stop.......................................................................................42
To Cancel an Emergency Stop ...................................................................................................42
Emergency Stop Due to Opening or Closing the Front Cover.......................................42
3-2 Starting and Quitting............................................................................43
How to Start the Machine ...........................................................................................................43
Shutdown..........................................................................................................................................45

Contents
4
3-3 Selecting the Command Set................................................................46
What is Command Set? ................................................................................................................46
Selecting Command Set ..............................................................................................................46
3-4 Moving the Tool....................................................................................48
Manual Feed.....................................................................................................................................48
About the Displayed Tool Position...........................................................................................49
Moving to a Specic Position.....................................................................................................51
Moving to the VIEW Position......................................................................................................51
3-5 Starting and Stopping Spindle Rotation...............................................52
Starting or Stopping the Spindle..............................................................................................52
3-6 Pausing/Resuming/Quitting of Cutting.................................................53
Pausing and Resuming of Cutting by Operation of the Machine.................................53
Quitting Cutting by Operation of the Machine...................................................................54
Quitting Cutting by Operating from the VPanel .................................................................55
Chapter 4 Getting Ready for and Performing Cutting...................................57
4-1 Cutting Area.........................................................................................58
Workpiece Size and Location Where Secured in Place .....................................................58
Actual Size That Can Be Cut ........................................................................................................58
4-2 Installing a Tool ....................................................................................59
Tool Selection ..................................................................................................................................59
Features of the Tools......................................................................................................................59
Installing a Tool (End mill) ...........................................................................................................59
4-3 Starting Cutting....................................................................................61
About Origin Point.........................................................................................................................61
Setting Origin Point.......................................................................................................................61
Start Cutting (Output to the machine directly form the application).........................64
Start Cutting (Output via VPanel) .............................................................................................65
Recovery of Operation from Emergency Stop or Emergency Shutdown..................67
4-4 Override...............................................................................................68
What's an Override?.......................................................................................................................68
How to Make the Settings for Overrides................................................................................68
Chapter 5 Appendix..........................................................................................69
5-1 Using the Z0 Sensor............................................................................70
What’s a Z0 Sensor .........................................................................................................................70
Setting the Z Origin Using the Z0 Sensor..............................................................................70
Setting the Thickness of the Z0 Sensor ..................................................................................72
5-2 Using the Engraving Cutter..................................................................73
Installing the Engraving Cutter and Setting the Origin Point ........................................73
5-3 Maintenance ........................................................................................76
Cleaning.............................................................................................................................................76
Maintenance of the Spindle Unit..............................................................................................77
5-4 What to Do If........................................................................................78
The Power Does Not Come On..................................................................................................78
Initialization is Not Performed or Initialization Fails. .........................................................78
VPanel Doesn't Start Correctly...................................................................................................78

Contents
5
Operations are Ignored. ...............................................................................................................78
The Spindle Doesn't Rotate. .......................................................................................................79
Abnormal Cutting is Performed................................................................................................79
The Origin is Misaligned...............................................................................................................79
The Feed Rate or Spindle Speed is Wrong.............................................................................79
The Cutting Results are Not Attractive. ..................................................................................79
What to Do If a Flashing Error Is Displayed ...........................................................................80
Installation is Impossible .............................................................................................................80
Uninstalling the Driver .................................................................................................................81
5-5 Responding to an Error Message........................................................83
For Connection of Equipment ...................................................................................................83
Detection Failure ............................................................................................................................83
Pause...................................................................................................................................................83
Emergency Stop..............................................................................................................................84
5-6 Power Rating and Serial Number Locations........................................86
5-7 NC Code Specications .......................................................................87
Settings for NC Codes...................................................................................................................87
Items Related to the Mechanical Specications .................................................................87
Interpretation of Omitted NC Codes.......................................................................................88
Word List............................................................................................................................................89
5-8 Specications.......................................................................................91
Expansion Connector....................................................................................................................91
External View....................................................................................................................................92
Dimensional Drawings of the Table Area...............................................................................93
Main Specications........................................................................................................................94
System Requirements for USB Connection...........................................................................95
http://www.rolanddg.com/
Copyright © 2009 Roland DG Corporation
Company names and product names are trademarks or registered trademarks of their respective holders.

6
To Ensure Safe Use
Improper handling or operation of this machine may result in injury or damage to prop-
erty. Points which must be observed to prevent such injury or damage are described as
follows.
About WARNING and CAUTION Notices
WARNING Used for instructions intended to alert the user to the risk of death
or severe injury should the unit be used improperly.
CAUTION
Used for instructions intended to alert the user to the risk of injury
or material damage should the unit be used improperly.
Note: Material damage refers to damage or other adverse
eects caused with respect to the home and all its furnishings, as
well to domestic animals or pets.
About the Symbols
The symbol alerts the user to important instructions or warnings. The
specific meaning of the symbol is determined by the design contained
within the triangle. The symbol at left means "danger of electrocution."
The symbol alerts the user to items that must never be carried out (are
forbidden). The specific thing that must not be done is indicated by the
design contained within the circle. The symbol at left means the unit must
never be disassembled.
The symbol alerts the user to things that must be carried out. The specic
thing that must be done is indicated by the design contained within the
circle. The symbol at left means the power-cord plug must be unplugged
from the outlet.

To Ensure Safe Use
7
Incorrect operation may cause injury.
WARNING
Be sure to follow the operation pro-
ceduresdescribed in thisdocumenta-
tion. Never allow anyone unfamiliar
with the usage or handling of the
machine to touch it.
Incorrect usage or handling may lead to
an accident.
Keep children away from the ma-
chine.
Themachine includesareasandcompo-
nentsthatpose ahazardto childrenand
may result in injury, blindness, choking,
or other serious accident.
Never operate the machine while
tired or after ingesting alcohol or any
medication.
Operation requires unimpaired judg-
ment. Impaired judgment may result in
an accident.
Conduct operations in a clean, bright-
ly lit location.
Working in a location that is dark or clut-
tered may lead to an accident, such as
becoming caught in the machine as the
result of an inadvertent stumble.
Never use the machine for any pur-
pose for which it is not intended, or
use the machine in an undue manner
that exceeds its capacity.
Doing so may result in injury or re.
Never use a cutting tool that has
become dull. Perform frequent main-
tenance to keep and use the machine
in good working order.
Unreasonable usage may result in re
or injury.
WARNING
For accessories (optional and con-
sumable items, power cord, and the
like), use only genuine articles com-
patible with this machine.
Incompatible items may lead to an ac-
cident.
Before attempting cleaning, mainte-
nance, or attachment or detachment
of optional items, disconnect the
power cord.
Attempting such operations while the
machineisconnectedto apowersource
may result in injury or electrical shock.
Never attempt to disassemble, repair,
or modify the machine.
Doing so may result in re, electrical
shock, or injury. Entrust repairs to a
trained service technician.
CAUTION
Never climb or lean on the machine.
The machine is not made to support
a person. Climbing or leaning on the
machinemaydislodge components and
cause a slip or fall, resulting in injury.
Never operate if a front cover is
cracked or broken.
Doing so may result in injury. If the front
coveriscracked,contactyourauthorized
Roland DG Corp. dealer.

To Ensure Safe Use
8
This machine weighs 65 kg (144 lb.)
CAUTION
Unloading and emplacement are op-
erations that must be performed by 4
persons or more.
Tasks that require undue effort when
performedby asmallnumberof persons
may result in physical injury. Also, if
dropped, such items may cause injury.
Install in a location that is level and
stable.
Installation in an unsuitable location
may cause an accident, including a fall
or tipover.
The cutting waste or workpiece may catch re or pose a health hazard.
WARNING
Never attempt to cut magnesium or
any other such ammable material.
Fire may occur during cutting.
Keep open ame away from the work
area.
Cuttingwaste mayignite.Powdered ma-
terial is extremely ammable, and even
metal material may catch re.
When using a vacuum cleaner to take
up cutting waste, exercise caution to
prevent re or dust explosion.
Taking up ne cuttings using an ordinary
vacuum cleaner may cause danger of
re or explosion. Check with the manu-
facturer of the vacuum cleaner. When
the safety of use cannot be determined,
clean using a brush or the like, without
using the vacuum cleaner.
CAUTION
Wear dust goggles and a mask. Wash
away any cutting waste remaining on
the hands.
Accidentally swallowing or inhaling
cutting waste may be hazardous to the
health.

To Ensure Safe Use
9
Danger of pinching, entanglement, and burns.
WARNING
Neverattemptoperationwhilewearing
anecktie,necklace,looseclothing,or
gloves. Bind long hair securely.
Such items may become caught in the
machine, resulting in injury.
Securely fasten the cutting tool and
workpiece in place. After securing
in place, make sure no wrenches or
otherarticleshaveinadvertentlybeen
left behind.
Otherwise such articles may be thrown
from the machine with force, posing a
risk of injury.
WARNING
Exercise caution to avoid being
pinched or becoming caught.
Inadvertent contact with certain areas
may cause the hand or ngers to be
pinched or become caught. Use care
when performing operations.
Caution: cutting tool.
The cutting tool is sharp. To avoid injury,
exercise caution.
Caution: high temperatures.
The cutting tool and spindle motor be-
come hot. Exercise caution to avoid re
or burns.
Danger of electrical short, shock, electrocution, or re
WARNING
Do not use with any electrical power
supply that does not meet the ratings
displayed on the unit.
Use with any other power supply may
lead to re or electrocution.
WARNING
Never use out of doors or in any loca-
tion where exposure to water or high
humiditymayoccur. Nevertouch with
wet hands.
Doing so may result in re or electrical
shock.
Never allow any foreign object to get
inside. Never expose to liquid spills.
Inserting objects such as coins or
matches or allowing beverages to be
spilled into the ventilation ports may re-
sult in re or electrical shock. If anything
gets inside, immediately disconnect the
power cord and contact your authorized
Roland DG Corp. dealer.

To Ensure Safe Use
10
WARNING
Never place any flammable object
nearby. Never use a combustible
aerosol spray nearby. Never use in
any location where gases can ac-
cumulate.
Combustion or explosion may be a
danger.
Handle the power cord, plug, and
electrical outlet correctly and with
care. Never use any article that is
damaged.
Using a damaged article may result in
re or electrical shock.
When using an extension cord or
power strip, use one that adequately
satises the machine’s ratings (for
voltage, frequency, and current).
Use of multiple electrical loads on a
single electrical outlet or of a lengthy
extension cord may cause re.
When the machine will be out of use
for a prolonged period, disconnect
the power cord.
This can prevent accidents in the
event of current leakage or unintended
startup.
Connect to ground.
This can prevent re or electrical shock
due to current leakage in the event of
malfunction.
Position so that the power plug is
within immediate reach at all times.
This is to enable quick disconnection
of the power plug in the event of an
emergency. Install the machine next to
anelectricaloutlet.Also,provideenough
empty space to allow immediate access
to the electrical outlet.
WARNING
Never use cutting oil.
This machine is not designed for the
ow of cutting oil. Oil may get inside
the machine and cause re or electrical
shock.
Never use a pneumatic blower.
This machine is not compatible with a
pneumatic blower. Cutting waste may
get inside the machine and cause re
or electrical shock.
If sparking, smoke, burning odor,
unusual sound, or abnormal opera-
tion occurs, immediately unplug the
power cord. Never use if any compo-
nent is damaged.
Continuing to use the machine may
result in re, electrical shock, or injury.
Contact your authorized Roland DG
Corp. dealer.

To Ensure Safe Use
11
Important notes about the power cord, plug, and electrical outlet
Never place any object on top or subject to
damage.
Never bend or twist with undue force.
Never pull with undue force.
Never bundle, bind, or roll up.
Never allow to get wet.
Never make hot.
Dust may cause re.

To Ensure Safe Use
12
Warning Labels
Warning labels are afxed to make areas of danger immediately clear. The meanings of
these labels are as follows. Be sure to heed their warnings.
Also, never remove the labels or allow them to become obscured.
Caution: Sharp Tool
Inadvertent contact
may cause injury.
Caution:High Tem-
perature
Never touch imme-
diately after cutting
operation.
Front
Rear
Caution: Pinching Hazard
Be careful not to allow the n-
gers to become pinched when
closing the cover.
Never use a pneumatic
blower.
This machine is not com-
patible with a pneumatic
blower. Cutting waste may
get inside the machine
and cause re or electrical
shock.
Caution: High Voltage
Cover removal may
pose hazard of shock or
electrocution due to high
voltage.

13
Pour utiliser en toute sécurité
La manipulation ou l'utilisation inadéquates de cet appareil peuvent causer des blessures
ou des dommages matériels. Les précautions à prendre pour prévenir les blessures ou les
dommages sont décrites ci-dessous.
Avis sur les avertissements
ATTENTION Utilisé pour avertir l'utilisateur d'un risque de décès ou de blessure
grave en cas de mauvaise utilisation de l'appareil.
PRUDENCE
Utilisé pour avertir l'utilisateur d'un risque de blessure ou de
dommage matériel en cas de mauvaise utilisation de l'appareil.
* Par dommage matériel, il est entendu dommage ou tout autre
effet indésirable sur la maison, tous les meubles et même les
animaux domestiques.
À propos des symboles
Le symbole attire l'attention de l'utilisateur sur les instructions
importantes ou les avertissements. Le sens précis du symbole est déterminé
par le dessin à l'intérieur du triangle. Le symbole à gauche signie "danger
d'électrocution."
Le symbole avertit l'utilisateur de ce qu'il ne doit pas faire, ce qui est
interdit. La chose spécifique à ne pas faire est indiquée par le dessin à
l'intérieur du cercle. Le symbole à gauche signifie que l'appareil ne doit
jamais être démonté.
Le symbole prévient l'utilisateur sur ce qu'il doit faire. La chose spécique
à faire est indiquée par le dessin à l'intérieur du cercle. Le symbole à gauche
signie que le l électrique doit être débranché de la prise.

L’utilisation incorrecte peut causer des blessures
ATTENTION
S’assurer de suivre les procédures
d’utilisation décrites dans la docu-
mentation. Ne jamais permettre à
quiconque ne connaît pas le fonc-
tionnement ou la manutention de
l’appareil de le toucher.
L’utilisation ou la manutention incor-
rectes peuvent causer un accident.
Garder les enfants loin de l’appareil.
L’appareil comporte des zones et des
composants qui présentent un danger
pourlesenfantsetquipourraientcauser
desblessures,lacécité,lasuffocationou
d’autres accidents graves.
Ne jamais faire fonctionner l’appareil
après avoir consommé de l’alcool ou
des médicaments, ou dans un état
de fatigue.
L’utilisation de l’appareil exige un juge-
ment sans faille. L’utilisation avec les
facultés affaiblies pourrait entraîner un
accident.
Utiliser l’appareil dans un endroit
propre et bien éclairé.
Travailler dans un endroit sombre ou
encombré peut causer un accident;
l’utilisateur risque, par exemple, de tré-
bucher malencontreusement et d’être
coincé par une partie de l’appareil.
Ne jamais utiliser l’appareil à des ns
autres que celles pour lesquelles il
est conçu. Ne jamais l’utiliser de
manière abusive ou d’une manière
qui dépasse sa capacité.
Le non-respect de cette consigne peut
causer des blessures ou un incendie.
PRUDENCE
Ne jamais grimper ni s’appuyer sur
la machine.
La machine n’est pas conçue pour sup-
porterlepoids d’une personne. Grimper
ou s’appuyer sur la machine peut dé-
placer des éléments et causer un faux
pas ou une chute, ce qui causerait des
blessures.
Ne pas utiliser si un couvercle avant
estssuré ou brisé.
Si le couvercle transparent à l'avant
ou sur lecôté de l'appareil est ssuré,
communiquer avecle revendeur ou le
centre de service autorisésde la société
Roland DG.
ATTENTION
Ne jamais utiliser un outil de coupe
émoussé. Procéder fréquemment
aux travaux d’entretien pour garder
l’appareil en bon état de fonction-
nement.
L’usage abusif peut causer un incendie
ou des blessures.
Débrancher le câble d’alimentation
avant de procéder au nettoyage ou à
l’entretien de l’appareil, et avant d’y
xer ou d’en retirer des accessoires
en option.
Tenter ces opérations pendant que
l’appareil est branché à une source
d’alimentationpeutcauserdesblessures
ou un choc électrique.
Ne jamais tenter de démonter, de ré-
parer ou de modier l’appareil.
Le non-respect de cette consigne ris-
que de provoquer un incendie, un choc
électrique ou des blessures. Confier
les réparations à un technicien ayant la
formation requise.
Pour utiliser en toute sécurité
14

Le poids de cet appareil est de 65 kg (144 lb.)
PRUDENCE
Le déchargement et la mise en place
doivent être faits par au moins 4
personnes.
Les tâches qui exigent un effort trop
grand si elles sont exécutées par un
petitnombrede personnespeuvent être
cause de blessures. La chute d’articles
très lourds peut aussi causer des bles-
sures.
PRUDENCE
Installer l’appareil à un endroit stable
et plat.
Installer l’appareil à un endroit inappro-
prié peut provoquer un accident grave
comme le renversement ou la chute.
ATTENTION
Ne jamais tenter de couper du mag-
nésium ni aucun autre matériau
inammable.
Unincendiepourraitseproduirependant
la coupe.
Ne pas approcher une amme nue de
l’espace de travail.
Les rognures de coupe peuvent
s’enammer. Les matériaux pulvérisés
sont extrêmement inflammables et
même le métal peut s’enammer.
ATTENTION
Si un aspirateur est utilisé pour ra-
masser les rognures de coupe, faire
preuve de prudence pour empêcher
que la poussière s’enflamme ou
explose.
Ramasser des rognures nes à l’aide
d’un aspirateur ordinaire peut créer un
risque d’incendie ou d’explosion. Vérier
auprèsdufabricantdel’aspirateur.Dans
les cas où il est impossible de déter-
miner si un aspirateur peut être utilisé
sans danger, se servir d’une brosse ou
d’un article semblable plutôt que d’un
aspirateur.
PRUDENCE
Porter des lunettes de protection et
un masque. Rincer toutes les rog-
nures de coupe qui pourraient rester
collées aux mains.
Avaler ou respirer accidentellement des
rognures de coupe peut être dangereux
pour la santé.
Les débris de coupe peuvent s ’enammer ou présenter un
risque pour la santé.
Pour utiliser en toute sécurité
15

ATTENTION
Ne p as u til is er av ec u ne
sourced'alimentation électrique non
conformeà la norme indiquée sur
l'appareil.
Utiliser l'appareil avec une autre
sourced'alimentation risque de pro-
voquer un incendieou de causer une
électrocution.
Risque de décharge ou de choc électrique, d’électrocution ou d’incendie
ATTENTION
Ne jamais utiliser à l'extérieur ni à
un endroit où l'appareil risque d'être
exposé à de l'eau ou à une humidité
élevée. Ne jamais toucher l'appareil
avec des mains mouillées.
Lenon-respectdecetteconsignerisque
de provoquer un incendie ou un choc
électrique.
Certains éléments peuvent présenter un risque de
pincement, d’emmêlement, de brûlure ou d’autres dangers.
ATTENTION
Ne jamais faire fonctionner l’appareil
si on porte une cravate, un collier ou
des vêtements amples. Bien attacher
les cheveux longs.
Ces vêtements ou ces objets peuvent
être coincés dans l’appareil, ce qui
causerait des blessures.
Fixer solidement l’outil de coupe et la
pièce à travailler. Une fois qu’ils sont
xés solidement, s’assurer qu’aucun
outil ni aucun autre objet n’a été
laissé en place.
Si tel était le cas, ces objets pourraient
êtreprojetésavecforcehorsdel’appareil
et causer des blessures.
ATTENTION
Faire preuve de prudence pour éviter
l’écrasement ou le coincement.
La main ou les doigts peuvent être
écrasés ou coincés s’ils entrent en
contact avec certaines surfaces par
inadvertance.Fairepreuvede prudence
pendant l’utilisation de l’appareil.
Attention : outil de coupe.
L’outil de coupe est acéré. Faire preuve
de prudence pour éviter les blessures.
Attention : températures élevées.
L’outil de coupe et le moteur chauffent.
Fairepreuve deprudence pouréviter un
incendie ou des brûlures.
Pour utiliser en toute sécurité
16

ATTENTION
Ne jamais insérer d’objet étranger
dans l’appareil. Ne jamais exposer
l’appareil aux déversements de liq-
uides.
L’insertion d’objets comme des pièces
de monnaie ou des allumettes, ou le
déversement de liquides dans les ori-
ces de ventilation peuvent causer un
incendieouun chocélectrique. Siunob-
jet ou du liquide s’inltre dans l’appareil,
débrancher immédiatement le câble
d’alimentation et communiquer avec le
représentant Roland DG autorisé.
Ne jamais placer d’objet inflam-
mable à proximité de l’appareil. Ne
jamais utiliser de produit inflam-
mable en aérosol à proximité de
l’appareil. Ne jamais utiliser l’appareil
dans un endroit où des gaz peuvent
s’accumuler.
Unecombustionouune explosion pour-
raient se produire.
Mise à la terre.
La mise à la terre peut prévenir un in-
cendie ou un choc électrique dus à une
fuite de courant en cas de défaillance.
Manipuler le câble d’alimentation, la
che et la prise électrique correcte-
ment et avec soin.
Nejamaisutiliserunarticleendommagé,
car cela pourrait causer un incendie ou
un choc électrique.
Si une rallonge ou une bande
d’alimentation électrique sont utili-
sées, s’assurer qu’elles correspon-
dent aux caractéristiques de l’appareil
(tension, fréquence et courant).
L’utilisation de plusieurs charges élec-
triques sur une prise unique ou une
longue rallonge peut causer un in-
cendie.
ATTENTION
Si l’appareil doit rester inutilisé pen-
dant une longue période, débrancher
le câble d’alimentation.
Cela peut prévenir les accidents en cas
de fuite de courant ou de démarrage
accidentel.
Placer l’appareil de façon à ce que
la che soit facile d’accès en tout
temps.
Ainsi, l’appareil pourra être débranché
rapidement en cas d’urgence. Installer
l’appareil près d’une prise électrique.
En outre, prévoir sufsamment d’espace
pour que la prise électrique soit facile
d’accès.
Ne jamais utiliser d’huile de coupe.
Cet appareil n’est pas conçu pour traiter
l’huile de coupe. L’huile peut s’inltrer à
l’intérieur et causer un incendie ou un
choc électrique.
Ne jamais utiliser d’air sous pres-
sion.
Cet appareil n’est pas conçu pour être
nettoyé à l’aide d’un appareil soufant.
Des rognures de coupe peuvent s’inltrer
à l’intérieur et causer un incendie ou un
choc électrique.
S’il se produit des étincelles, de la
fumée, une odeur de brûlé, un bruit
inhabituel ou un fonctionnement
anormal, débrancher immédiatement
le câble d’alimentation. Ne jamais
utiliser si un composant est endom-
magé.
Continueràutiliserl’appareilpeutcauser
un incendie, un choc électrique ou
des blessures. Communiquer avec le
représentant Roland DG Autorisé.
Pour utiliser en toute sécurité
17

Remarques importantes à propos du câble d'alimentation, de la che et de la prise
électrique
Ne jamais déposer aucun objet sur le câble,
sur la che ou sur la prise car cela risque de
les endommager.
Ne jamais plier ni tordre le câble avec une
force excessive.
Ne jamais tirer sur le câble ou la che avec
une force excessive.
Ne jamais plier ni enrouler le câble.
Ne jamais laisser l'eau toucher le câble, la
che ou la prise.
Ne jamais chauffer le câble, la che ou la
prise.
La poussière peut causer un incendie.
Pour utiliser en toute sécurité
18
