Roland WM-1 User manual

01
Owner’s Manual

2
Panel Descriptions............................... 3
WM-1 .......................................... 3
Installing the Batteries ............................ 3
Turning the WM-1 On ............................. 3
WM-1D ......................................... 3
Turning the WM-1D On ............................ 3
Overview of the WM-1/WM-1D .................... 4
WM-1 (Connected to MIDI Connector) ........................ 4
Connections .................................... 4
WM-1D (Connect to USB Port) ............................ 4
Connections .................................... 4
Setting the Communication Mode ................. 5
About the Two Communication Modes ................ 5
Switching the Communication Mode.................. 5
About the MODE Indicator.......................... 5
Registering the MIDI Device to Use (Pairing) ........... 6
Using STANDARD (Host) Mode (Indicator Is Red) ............. 6
Connecting the WM-1 with iPhone ................... 6
Connecting the WM-1 with Mac ..................... 6
Connecting the WM-1 with a Windows Computer (WM-1D) ... 7
Using FAST Mode (Indicator Is Orange) ..................... 7
Advanced Features .............................. 8
Switching Between STANDARD (Host) Mode and STANDARD
(Remote) mode .................................. 8
Connecting Three Devices to One WM-1 (Multi Connection)..... 8
Initializing the Unit’s Connection Settings ........... 9
Limitations ..................................... 9
Main Specications .............................. 10
Contents
Before using this unit, carefully read “USING THE UNIT SAFELY” and “IMPORTANT NOTES”(the leaet “USING THE UNIT SAFELY”). After reading, keep
the document(s) where it will be available for immediate reference.
© 2020 Roland Corporation

3
WM-1
1
3
4
2
1
CONNECT TO MIDI OUT jack
Connect this to your MIDI device’s MIDI OUT connector.
2 CONNECT TO MIDI IN jack
Connect this to your MIDI device’s MIDI IN connector.
3 [MODE] switch (MODE indicator)
Switches the WM-1’s mode.
The color of the indicator changes depending on the mode.
&“About the Two Communication Modes” (p. 5)
At the time of purchase, the WM-1 is set to “STANDARD (Host)
mode.”
4 Battery
Install one AAA battery.
Installing the Batteries
AAA battery
Battery cover
WM-1
(CONNECT TO MIDI IN side)
1. Remove the battery cover.
2. Taking care to observe the correct orientation of the
batteries, insert the batteries into the battery case.
3. Close the battery cover.
* If you handle batteries improperly, you risk explosion and uid
leakage. Make sure that you carefully observe all of the items
related to batteries that are listed in “USING THE UNIT SAFELY”and
“IMPORTANT NOTES”(leaet“USING THE UNIT SAFELY”).
Battery replacement indicator
* When the battery is nearly worn out, the MODE indicator blinks
red. Replace the new battery as soon as possible.
Turning the WM-1 On
1. Connect the WM-1 to your MIDI device, and power-
on the connected device.
The power of the WM-1 turns on in tandem with the MIDI device.
Turning O the Power
1. Turn o the power of the connected MIDI device.
The power of the WM-1 turns o in tandem with the MIDI device.
WM-1D
1
2
3
1 USB port
Connect this to your computer’s USB port.
2 [MODE] switch
Switches the mode of the WM-1D.
&“About the Two Communication Modes” (p. 5)
At the time of purchase, the WM-1D is set to “STANDARD
(Remote) mode” (p. 8).
3 MODE indicator
The color of the indicator changes depending on the mode.
&“About the Two Communication Modes” (p. 5)
Viewing the MODE indicator
View the indicator at a 45-degree angle from the USB
connector of the WM-1D.
* If you view the indicator from directly above, it
might be dicult to determine the color.
Turning the WM-1D On
1. Connect the WM-1D to your computer.
The unit powers-on, is detected as a general-purpose USB MIDI
device, and the driver is installed automatically.
Turning O the Power
1. Disconnect the WM-1D from your computer.
Panel Descriptions

4
Overview of the WM-1/WM-1D
WM-1 (Connected to MIDI Connector)
The WM-1 is a wireless MIDI adaptor.
It is used by connecting it to a device that is equipped with MIDI
connectors.
5Direct connection between hardware products
5Stable synchronization with multiple connections
5Low 3 ms latency
MEMO
The WM-1D is required for wireless MIDI communication with a
Windows computer that does not support BLE MIDI.
Connections
Connect the WM-1 to your MIDI device’s MIDI connectors (IN, OUT).
WM-1D (Connect to USB Port)
The WM-1D is a wireless MIDI dongle.
To use it, connect it to your computer.
Other than its connectors and power supply, it has the same
performance as the WM-1 (WM-1 + USB MIDI interface).
5Direct connection between hardware products
5Stable synchronization with multiple connections
5Low 3 ms latency
5Operates on USB bus power
Connections
Connect the WM-1D to a USB port of your computer.
The WM-1/WM-1D transmits and receives MIDI messages wirelessly.
Using the WM-1/WM-1D allows wireless MIDI communication with your MIDI device, computer, tablet, or smartphone.
By using the WM-1D with a Windows computer that does not support BLE MIDI, you can also use a wireless MIDI connection on a Windows system.
What is BLE MIDI?
This is technology that uses Bluetooth LE to transmit and receive MIDI messages wirelessly.
It is ocially known as “MIDI over Bluetooth Low Energy.”

5
Setting the Communication Mode
About the Two Communication Modes
STANDARD Mode (BLE MIDI)
In STANDARD mode, you can connect to a Mac or smartphone
that supports BLE MIDI, or connect to the WM-1D connected to a
computer.
Up to three BLE MIDI devices can be connected to a WM-1 unit that is
in STANDARD mode. You can connect not only the WM-1D, but also a
Mac or smartphone.
STANDARD mode has two modes: STANDARD (Host) and STANDARD
(Remote).
&“Advanced Features” (p. 8)
FAST mode
In FAST mode, you can connect with a lower latency than STANDARD
mode.
One WM-1/WM-1D unit can be connected to a WM-1/WM-1D that is in
FAST mode.
NOTE
5A smartphone can’t be connected in FAST mode.
5If you’re using a Mac with FAST mode, connect using the WM-1D.
Switching the Communication Mode
Here’s how to switch between STANDARD mode and FAST mode.
1. Hold down the [MODE] switch for two seconds.
The [MODE] switches each time you long-press the switch.
WM-1 : “STANDARD (Host) ” #“FAST”
WM-1D : “STANDARD (Remote)” #“FAST”
For details on the mode and indicator color, refer to “About the
MODE Indicator” (p. 5).
About the MODE Indicator
The MODE indicator shows the state of the WM-1/WM-1D in each communication mode, as described below.
STANDARD (Host) mode STANDARD (Remote) mode
(p. 8) FAST mode
MIDI communication is
occurring (other than realtime
messages)
Briey blinks red when a message
is received.
Receiving MIDI messages
Briey blinks green when a
message is received.
Receiving MIDI messages
Briey blinks orange when a
message is received.
Receiving MIDI messages
While pairing
Briey lit red once,
then unlit for one second.
Blinks every second
Briey lit green twice,
then unlit for one second.
Blinks every second
Briey lit orange three times,
then unlit for one second.
Blinks every second
When pairing is completed Rapidly blinks red. Rapidly blinks green. Rapidly blinks orange.
While connected via MIDI Slowly blinks red. Slowly blinks green. Slowly blinks orange.
When multi-connected and
one or more remote devices
are not found
While slowly blinking red, blinks
briey in the intervals. –- –-
When the battery runs low
(Low battery)
Briey lit red four times,
then unlit for two seconds.
Blinks every two seconds
While initializing this unit’s
connection settings (Factory-
reset)
Blinks orange.

6
Registering the MIDI Device to Use (Pairing)
“Pairing” is the procedure of registering the MIDI device that you
want to use with the WM-1/WM-1D (authenticating the devices with
each other).
Here’s how to make settings so that MIDI data can be transmitted and
received between the WM-1/WM-1D and your MIDI device.
MEMO
5Once pairing has been completed between this unit and the
WM-1/WM-1D, the connection occurs automatically (memorized),
and there is no need to perform pairing again. In the case of Mac or
iPhone, the pairing operation is required each time.
5If you initialize an already-paired WM-1/WM-1D, you must initialize
the other WM-1/WM-1D unit (on Mac or a smartphone, remove the
device) and perform pairing again.
5When you switch the mode, pairing is cancelled.
Using STANDARD (Host) Mode (Indicator Is
Red)
Connecting the WM-1 with iPhone
WM-1 iPhone
1. Connect the WM-1 to your MIDI device.
The system begins searching for a target, and the MODE indicator
blinks red for a certain length of time.
MODE indicator
The MODE indicator blinks every second
...
2. From your iPhone app, directly select the WM-1.
When pairing is completed, the indicator changes from blinking
rapidly to slow blinking.
MODE indicator
Connecting the WM-1 with Mac
WM-1 Mac
1. Connect the WM-1 to your MIDI device.
The system begins searching for a target, and the MODE indicator
blinks red for a certain length of time.
MODE indicator
The MODE indicator blinks every second
...
2. On the Mac, start Audio MIDI settings.
3. From the [MIDI Studio] menu, select [Open
Bluetooth Conguration] to access [Bluetooth
Conguration].
4. Make sure that the WM-1 is shown, and then click
the [Connect] button.
If it not shown, once again briey press the WM-1’s [MODE] switch
to make the MODE indicator blink red.
MODE indicator
When pairing is completed, the indicator changes from blinking
rapidly to slow blinking.

7
Registering the MIDI Device to Use (Pairing)
Connecting the WM-1 with a Windows
Computer (WM-1D)
WM-1 Windows computer + WM-1D
1. Connect the WM-1 to your MIDI device.
The system begins searching for a target, and the MODE indicator
blinks red for a certain length of time.
WM-1’s MODE indicator
The MODE indicator blinks every second
...
2. Briey press the WM-1D’s [MODE] switch.
The system begins searching for a target, and the MODE indicator
blinks green for a certain length of time.
The WM-1D’s MODE indicator
The MODE indicator blinks every second
...
When pairing is completed, the indicator changes from blinking
rapidly to slow blinking.
WM-1’s MODE indicator
The WM-1D’s MODE indicator
* Pairing is not possible if both the WM-1 and the WM-1D are in
STANDARD (Host) mode. Set one or the other to STANDARD
(Remote) mode.
* Pairing is not possible if both the WM-1 and the WM-1D are in
STANDARD (Remote) mode. Set one or the other to STANDARD
(Host) mode.
Using FAST Mode (Indicator Is Orange)
WM-1 WM-1D
1. Set both of the WM-1/WM-1D units to be paired to
FAST mode.
&“Switching the Communication Mode” (p. 5)
The system begins searching for a target, and the MODE indicator
blinks orange for a certain length of time.
The MODE indicator blinks every second
...
When pairing is completed, the indicator changes from blinking
rapidly to slow blinking.
MODE indicator
If no target is found, the MODE indicator goes dark. In this case,
briey press the [MODE] switch to resume pairing.
NOTE
5A smartphone cannot be paired using FAST mode.
5To use FAST mode with a Mac, connect using a WM-1D.

8
A maximum of three BLE MIDI devices can be connected to a
WM-1/WM-1D in STANDARD (Host) mode (multi connection). The
following BLE MIDI devices can be connected: iPhone or other iOS
device, Mac, or a WM-1/WM-1D that is set to STANDARD (Remote)
mode.
For details on how to set the WM-1/WM-1D to STANDARD (Remote)
mode, refer to “Switching Between STANDARD (Host) Mode and
STANDARD (Remote) mode” (p. 8).
MEMO
5When pairing two WM-1 units in STANDARD mode, one of them
must be in STANDARD (Remote) mode.
5When using multi connection, only one unit of the same device
(iPhone, Mac) can be connected.
&“Limitations” (p. 9)
WM-1D
(STANDARD (Host) mode)
WM-1 (STANDARD (Remote) mode)
Mac
iPhone
Switching Between STANDARD (Host)
Mode and STANDARD (Remote) mode
1. Rapidly press the [MODE] switch twice.
The mode changes each time you press rapidly the [MODE] switch
twice.
“STANDARD (Host) ” #“STANDARD (Remote)”
For details on the mode and the color of the indicator, refer to
“About the MODE Indicator” (p. 5).
MEMO
When in FAST mode, pressing rapidly the [MODE] switch twice
changes to STANDARD (Host) mode.
Connecting Three Devices to One WM-1
(Multi Connection)
1. Briey press the [MODE] switch of the STANDARD
(Host) mode WM-1D and the STANDARD (Remote)
mode WM-1.
WM-1D
(STANDARD (Host) mode)
WM-1 (STANDARD (Remote) mode)
Mac
iPhone
The system begins searching for a target, and the MODE indicator
blinks for a certain length of time (the color of the indicator
depends on the mode).
The WM-1D’s MODE indicator
The MODE indicator blinks every second
...
The WM-1’s MODE indicator
The MODE indicator blinks every second
...
When pairing is completed, the indicator changes from blinking
rapidly to slow blinking.
The WM-1D’s MODE indicator
The WM-1’s MODE indicator
If no target is found, the MODE indicator goes dark. In this case,
briey press the [MODE] switch to resume pairing.
MEMO
If you’re using an iPhone or Mac, that device will have BLE MIDI
settings. In its screen, select the WM-1.
For an iOS device, select the WM-1 directly from the app.
2. In the same way for the second device, press the
[MODE] switch briey to pair.
WM-1D
WM-1
Mac
iPhone
3. In the same way for the third device, press the
[MODE] switch briey to pair.
WM-1D
WM-1
Mac
iPhone
Advanced Features

9
Initializing the Unit’s Connection Settings
1. Hold down the [MODE] switch for ten seconds.
The MODE indicator blinks orange.
When the operation is completed, the indicator goes dark.
&“About the MODE Indicator” (p. 5)
5This unit cannot be used in combination with a BLE MIDI device made by a dierent manufacturer.
5When using wireless communication via a multi connection, there might be cases in which tempo synchronization is not stable. In this case,
decrease the number of remote devices.
5When using a multi connection, only one unit of the same device (Mac or smartphone) can be connected.
First device can be connected.
First Mac
(can be connected)
First iPhone
(can be connected)
Communication is not stable for the second iPhone.
First Mac
(can be connected)
First iPhone
(can be connected)
Second iPhone
(communication is not stable)
Communication is not stable for the second Mac.
First Mac
(can be connected)
Second Mac
(communication is not stable)
Three WM-1/WM-1D units can be connected.
First WM-1D
(can be connected)
Second WM-1D
(can be connected)
Third WM-1D
(can be connected)
Limitations
5When using MIDI Sync, synchronization of the rst measure might not be stable depending on the DAW. In this case, insert an empty measure
at the beginning of the song to assist synchronization.
5When using this unit with a computer to which a USB 3.0 peripheral device is connected, interference might cause operation to be unstable. In
particular, instability is more likely if a USB ash drive or hard disk drive is connected. Create distance with the USB 3.0 peripheral when using
this unit.
Distancing the USB ports used by the peripheral and the WM-1D
USB 3.0
WM-1D
Using a USB extension cable (distancing the peripheral)
USB 3.0
WM-1D
USB extension cable

Roland WM-1
Wireless Format BLE and proprietary format
Wireless carrier
frequency 2. 4 GHz
Transmission Range 10 m (32 feet) line-of-sight (May vary due to local
conditions)
Latency (varies
depending on radio
conditions)
7.5–15 ms (STANDARD mode)
3 ms (FAST mode)
Connectors MIDI connectors (IN, OUT)
Power Supply Alkaline battery (AAA, LR03) x 1
Current Draw
14 mA
Battery life for continuous use (diers depending on
the conditions of use)
Alkaline battery (AAA, LR03): Approximately 60 hours
Dimensions
(Control side)
79 (W) x 17 (D) x 29 (H) mm
3-1/8 (W) x 11/16 (D) x 1-3/16 (H) inches
Dimensions
(Battery side)
80 (W) x 17 (D) x 29 (H) mm
3-3/16 (W) x 11/16 (D) x 1-3/16 (H) inches
Weight
(including battery) 46 g / 2 oz
Accessories Leaet “USING THE UNIT SAFELY”
Alkaline battery (AAA, LR03) x 1
Roland WM-1D
Wireless Format BLE and proprietary format
Wireless carrier
frequency 2. 4 GHz
Transmission Range 10 m (32 feet) line-of-sight (May vary due to local
conditions)
Latency (varies
depending on radio
conditions)
7.5–15 ms (STANDARD mode)
3 ms (FAST mode)
Connectors USB port : USB A type
Power Supply Supplied from the computer via USB
Current Draw 6 mA
Dimensions 43 (W) x 18 (D) x 9 (H) mm
1-3/4 (W) x 3/4 (D) x 3/8 (H) inches
Weight 6 g / 1 oz
Accessory Leaet“USING THE UNIT SAFELY”
Main Specications
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the
Roland website.
