Epilog Laser Fusion User manual

X Axis Sensor Replacement
Step-By-Step for the
Epilog Fusion/Fusion M2

Replacing the X Axis sensor should be
done if:
•You cannot Jog left or right
•During boot up the head doesn’t go to the
left.
X Axis Sensor Replacement Fusion 2

Things You Will Need
•Phillips Screwdriver
•X-Y Limit Switch (2 total on each Axis)
X Axis Sensor Replacement Fusion 3

Remove X Axis Cover
Make sure Fusion is turned off and disconnected from
power source.
X Axis Sensor Replacement Fusion 4
Remove the top cover from the X-Axis assembly by using a Phillips
screwdriver to unscrew the Phillips screws at the front and the back
of the cover.

Locate and Remove Sensors on X-
Axis
Please see pictures for reference.
X Axis Sensor Replacement Fusion 5
Left Sensor Right Sensor
With a Phillips Screwdriver, unscrew the two Philips screws that are holding the black
sensor and the silver housing.

Flip the X Axis. Cut the zip tie that holds the harness in place. Then Disconnect the
black connector.
X Axis Sensor Replacement Fusion 6
Locate and Remove Sensors on X-
Axis
The right sensor will have an additional white clip that you will need
to unscrew.

Locate and Remove Sensors on X-
Axis
Now you can pull the Sensor out from the top through the opening.
X Axis Sensor Replacement Fusion 7

Install New Sensor
Laser Alignment, Epilog 8000 Series 8
Reverse these steps to install the new sensors.
Be sure to put the X Axis cover back on before running the machine more. For
further questions contact Epilog Tech Support.
