Roland Rg-3f User manual

The RG-1F is only 73cm (29") deep. With its SuperNATURAL Piano sound engine*

, PHA III Ivory Feel

keyboard*

, and Progressive Damper Action Pedal*

housed in its compact cabinet, the RG-1F offers the

beauty and quality of a grand piano. Its Satin Black nish adds class to any room and is easy to care for.

The control panel can be covered by the keyboard lid*

so you can concentrate on your performances

without being distracted by buttons and indicators. At only 75kg (166 lbs), the RG-1F is lightweight and

easy to move around. It offers a wide variety of built-in songs that you can use for background music and

play-along practice. A metronome and recorder are built in for practice sessions and skill evaluation.

*1 SuperNATURAL Piano sound engine [ P4] *2 PHA III Ivory Feel keyboard with Escapement [ P4] *3 Progressive Damper Action

Pedal [ P5] *4 Classic Position [ P5]

The grand piano, an object of aspiration for many,

is now more affordable, compact, and perfect for

smaller spaces such as living rooms

RG-1F

1,420mm

730mm

Visit us online at www.Roland.com Roland, V-Piano, and are either registered trademarks or trademarks of Roland

Corporation in the United States and/or other countries.

All specifications and appearances are subject to change without notice.

All trademarks used in this catalog are the property of their respective companies.

Printed in Japan Apr. 2010 RAM-4585 GR-UPR-SS AAC2

Options

USB Flash Memory

M-UF2G

USB CD Drive

CD-01A

Headphones

RH-A30

Headphones

RH-L20

Headphones

RH-5

Headphones

RH-300

The wood used to make our digital-piano

cabinets is imported from Indonesia. In

2008, Roland designated a 100-hectare

area for tree planting, where the company

has been planting trees for environmental

purposes. The area contains a mixture of

protected forest and trees designated

for digital-piano-cabinet production. This

forestation project is expected to offset

approximately 10,000 tons of CO2 over

a period of 20 years.

Ensuring high quality while protecting the environment:

Roland is ISO9001 and ISO14001 certified

At Roland, several group companies have obtained ISO9001 certification. In addition, in

January 1999, Roland also received ISO14001 international environmental management

system certification. We’re actively seeking ways to maintain harmony with the environment.

(ISO=International Standardization Organization: an organization for the promotion of

standardization of international units and terms. They provide

different categories of certification: ISO9001 Series certification

is a product quality certification for products that undergo a

certain level of quality control from the design stage to the after

service stage; ISO14001 Series certification is for environment-

related standards. Each member of the Roland Group is

striving to obtain certification.) ISO9001 ISO14001

Tree-planting project in Indonesia

RG-Series

ROLAND PIANO

DIGITAL

DIGITAL GRAND SERIES

*These figures were measured according to the method that is based on Roland’s technical standard.

In the interest of product improvement, the specifications and/or appearance of those units are subject to change without prior notice.

Specifications RG-3F/RG-1F

Keyboard

Keyboard 88 keys (PHA III Ivory Feel Keyboard with Escapement)

Touch Sensitivity Touch: 100 levels / Fixed Touch, Hammer Response: Off, 1–10

Keyboard Modes Whole, Dual (volume balance adjustable), Split (split point adjustable)

Sound Generator (Conforms to GM2 / GS / XG Lite)

Piano Sound SuperNATURAL Piano Sound

Max. Polyphony 128 voices

Tones 337 tones (including 8 drum sets, 1 SFX set)

Temperaments 8 types [Equal, Just (Major), Just (Minor), Arabic, Kirnberger, Meantone, Pythagorean,

Werckmeister], selectable temperament key

Stretched Tuning Off / Preset / User tuning (adjustable in individual notes)

Master Tuning 415.3 to 466.2 Hz (adjustable in increments of 0.1 Hz)

Transpose Key Transpose: -6 to +5 (in semitones)

Playback Transpose (with Audio CD / Audio File): -6 to +5 (in semitones)

Effects Reverb (Off, 1–10), [Only for Piano Tones] Key Off Resonance (Off, 1–10), String Resonance

(Off, 1–10), Damper Resonance (Off, 1–10), Cabinet Resonance (Off, 1–10), Open / close

lid (7 levels), Hammer Noise (5 levels), Damper Noise (Off, 1–10), Tone Character (-5 – +5),

Duplex Scale (Off, 1–10) [Only for Organ Tones] Rotary Speaker Effect (Slow/Fast)

Equalizer 4-band Digital Equalizer

User Program

Internal : 36, User Memory : Max. 99 User Program Sets , USB Memory : Max. 99 User Program Sets

Recorder

Tracks 1 track

Songs Recorder section: 1 song, Internal Memory: Max. 99 songs

Note Storage Approx. 30,000 notes

Controls Song Select, Play / Stop, Rec, Rewind to the top of the song, Rewinding, Fast-forwarding,

Track Mute, Mute Volume, Tempo, All Songs Play, Count-in

(only for Music files playback),

Song Volume, Center Cancel (only for audio playback)

Tempo Quarter note = 10 to 500, Audio Playback Speed: 75 – 125 %

Resolution 120 ticks per quarter note

Metronome Tempo: Quarter note = 10 to 500, Beat: 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8,

12/8, Volume: 11 levels

Internal Memory

Songs Max. 99 songs

Song Save Format Standard MIDI Files (Format 0)

External Memory

External Storage USB Flash Memory (sold separately)

Playable Song Format Standard MIDI Files (Format 0/1), Roland Original Format (i-Format),

Audio File (WAV 44.1 kHz / 16-bit Linear Format),

Audio CDs (CD-DA) (when using an optional CD drive)

Song Save Format Standard MIDI Files (format 0)

Other

Internal Songs 60 songs

Connectors AC inlet, Pedal Connector, Input jacks (1/4 inch phone type) (L/Mono, R), Input jacks (RCA

phono type) (L/Mono, R), Output jacks (1/4 inch phone type) (L/Mono, R), USB (MIDI)

connector, MIDI connectors (IN, OUT), Headphone jack (Stereo) x 2, External memory

connector (USB)

Rated Power Output [RG-3F] 60 W x 2 [RG-1F] 40 W x 2

Volume Level (SPL)* [RG-3F] 111dB [RG-1F] 108dB

Speakers 20 cm x 2, 5 cm x 2

Display 20 characters, 2 lines LCD

Controls Volume, Brilliance, LCD Contrast

Pedals Damper (Progressive Damper Action Pedal, capable of continuous detection), Soft (capable

of continuous detection, function assignable), Sostenuto (function assignable)

Other Functions Panel Lock, Playback Lock, V-LINK

Power Consumption [RG-3F] 140 W [RG-1F] 95 W

Cabinet [RG-3F] Polished Ebony [RG-1F] Satin Black

Accessories Owner’s Manual, Power Cord, Headphone Hook,

Maintenance Kit (RG-3F), Key Cover, Caster Caps (RG-3F), Brackets (RG-1F)

Dimensions RG-3F:

[with top opened]

1,490 (W) x 950 (D) x 1,540 (H) mm, 58-11/16 (W) x 37-7/16 (D) x 60-11/16 (H) inches

[with top closed] 1,490 (W) x 950 (D) x 920 (H) mm, 58-11/16 (W) x 37-7/16(D) x 36-1/4 (H) inches

RG-1F:

[with top opened] 1,420 (W) x 730 (D) x 1,270 (H) mm, 56 (W) x 29 (D) x 50 (H) inches

[with top closed] 1,420 (W) x 730 (D) x 890 (H) mm, 56 (W) x 29 (D) x 36 (H) inches

Weight [RG-3F] 110 kg / 243 lbs [RG-1F] 75 kg / 166 lbs

SuperNATURAL Piano sound engine provides the power and

expression of an acoustic grand

Both RG-3F and RG-1F are equipped with our newly developed

SuperNATURAL Piano sound engine, which was born by bringing together

V-Piano technology and 88-key stereo multisampling. This new sound

engine is the product of Roland’s deep research of the characteristics of

acoustic pianos, with the goal of faithfully reproducing the rich tone and true

expression of a concert grand piano. 128-voice polyphony ensures seamless

performance, even during the most dense and complex pieces.

Perfect touch and response in every key

Each note of a grand piano has its own character, due to the fact that the

strings are different sizes and lengths, use different materials, and are struck

by hammers of different sizes. These differences create variations in the

tonal color and resonance of each note. For the new SuperNATURAL Piano

sound engine, we sampled all 88 notes of a variety of world-class pianos

and used our unique digital technology to accurately reproduce the full, rich

tone and unique personality of these ne acoustic instruments.

True to the player’s touch

Pianos produce myriad differences not only in volume, but also in tone based

on how forcefully the key is struck. Our latest technology, the SuperNATURAL

Piano sound engine, delivers natural

and seamless changes in tonal color

in response to the player’s touch. The

expanded dynamic range supports the

most advanced and subtle techniques,

just as one would expect from an

acoustic grand piano.

Seamless note decay

The natural decay of notes and

beautiful lingering tones are essential

elements of a piano’s sound. The

decaying sound of an acoustic piano

not only decreases in volume, but

also gradually changes in color to a

softer tone. The SuperNATURAL Piano

sound engine replicates this natural

decay, just like an acoustic grand.

Volume

Time

Natural variations in tonal quality

Variation in tone color produced by the

SuperNATURAL Piano sound engine as the

tone decays.

*The graph and drawings are artistic illustrations

QUALIT Y

DESIGN

LESSONS &

ENTERTAINMENT

Inspiring creativity with Roland’s powerful technologies

Both RG-3F and RG-1F feature “Piano Resonance”, which faithfully

reproduces the sympathetic vibrations*1 between strings, as well as other

subtle nuances such as variations in lingering tones based on key-release

speed*2. It even replicates the resonance one hears while the damper pedal

is depressed and the dampers move off the strings*3. The RG-3F and RG-1F

also feature “Piano Designer”, which lets you customize all components of

the piano’s sound, even the position of the “virtual” grand piano lid.

*1 String Resonance *2 Key Off Resonance *3 Damper Resonance

display. Additionally, an I/O panel is located at the bottom front of the

instrument for easy connection to headphones, USB memory keys, and

CD drives. Safety features include a prop-lock mechanism (prevents

the piano lid’s propping rod from coming off) and anti-tip hardware*1

for preventing the unit from tipping

over, giving peace of mind to users

with small children. The RG-3F/1F’s

lightweight lid is easy to open and

close. The height of the lid can be

adjusted to two positions*2, and lid

locks are built-in to protect to the lid

from closing accidentally.

*1 RG-1F *2 RG-3F

The beauty of a grand piano in a space-saving cabinet

Physical grand-piano attributes, such as the elegant shape with

hinged lid, have been incorporated into the RG-series’ compact

cabinets. The RG-3F is available in a polished-ebony finish. The inner

side of the fallboard reflects the keyboard and performer’s fingers

to create a look that is true to acoustic grand pianos. The fallboard

closes slowly and safely when let go. With a satin-black finish that

blends well with any type of decor, the RG-1F has a keyboard lid that

can cover the control panel to create a clean, authentic appearance*.

Concentrate on your performances without being distracted by

buttons and indicators. With sets of three pedals, where the left and

right pedals curve outward, the RG-3F and RG-1F have been built to

provide a true piano experience.

* Classic Position

The design takes into account usability and safety as well

The number of buttons on the operation panel has been kept to a

minimum. The panel also features an easy-to-view LCD. You can check

the names of the playback songs as well as menu actions on this

The PHA III keyboard translate

the emotions of the player into sound

Its natural touch is not produced by springs, but by the hammer’s

weight and movement. Just as in an acoustic piano, the lower notes feel

slightly heavier and the higher notes feel lighter. The PHA III keyboard

also faithfully replicates the unique response of grand pianos, where

the keys move downward lightly when you play softly and give more

resistance when you play more forcefully.

The acclaimed PHA III keyboard

accurately responds to the player’s

touch, from the most subtle and

delicate to the most bombastic

technique. As the pianist’s emotion

and intention changes, so too does

the piano’s intonation. As the PHA

III keyboard drives our SuperNATURAL Piano sound engine, subtle

differences of articulation are faithfully reected in the tone for a true

grand-piano experience.

Simulated “escapement” replicates the feel and

response of a grand piano

Press a key slowly and you will feel the resistance increase gradually

and then become lighter again. This occurs on acoustic pianos when

the hammer releases or “escapes” from the key mechanism. By

replicating this, the PHA III keyboard further enhances the superb

response and expression of Roland pianos.

Roland pays attention to intricate, important details

such as these

The length of the hidden portion of

the keys has been lengthened as

much as possible so the fulcrum is

located farther back on the keys.

This reduces the difference in

touch response from the front to

the rear of the keys, replicating the

longer keys and superior response

of a grand piano.

The Ivory-Feel keyboard replicates

the texture of ivory and ebony

Modeled after high-end acoustic grand pianos, the white and black key

tops are made of a material that replicates the unique appearance and

texture of real ivory and ebony keys.

The white keys consist of a two-

piece “surface over base material”

construction to create the same

appearance you would nd on an

acoustic piano. It also reduces the

noise of ngernails tapping the keys.

Thanks to its moisture-absorbing

characteristics, the Ivory-Feel keyboard

feels better the more you play it.

RG-3F

Progressive Damper Action Pedal

The RG-3F and RG-1F feature Roland’s new Progressive Damper

Action pedal mechanism, which closely replicates the pedal

response of acoustic pianos. When you first start to press the

damper pedal it offers lighter resistance, but as you press it farther,

the resistance increases just as it does on an acoustic piano. This

new design enables more accurate pedaling response. The depth

of the damper pedal allows subtle control of tonal decay by letting

you easily find the point where the damper pedal effect starts

to work, and by continuous detection of the depth of the pedal.

The damper pedal can also accurately express the unique sound

decay when “half pedaling”. The sound immediately decays to a

certain degree of volume after key

release, and is then sustained with

rich resonances just as when the

damper pedal is fully depressed.

As a result, this pedal can

accurately convey the techniques

of even the most demanding

pianists.

Resistance change of the

damper pedal

Depressed resistance

of the pedal

Depressed depth of the pedal

Grand Piano

Progressive Damper

Action Pedal

The dampers

start to move

Damper Pedal : HALF

Damper Pedal : FULL

Sustaining

Time

Sustaining

Variation of decay depending on the

degree to which the damper pedal is

pressed

Key Off Point

VolumeVolumeVolume

Damper Pedal : OFF

Time

*The graph and drawings are artistic illustrations

Features only available in the digital realm help

expand your musical universe

The recorder function lets you easily record, play back, and save your

performances. This offers numerous benets for both performance and

practice. The ability to hear yourself privately on headphones has always been

a major advantage of digital instruments, since it allows you to play anytime,

day or night, without disturbing others.

Enjoy playing your favorite songs along with full

backing tracks

Both RG-3F and RG-1F come with a wide range of built-in songs, ranging

from classical to jazz. In addition, you can play commercially available SMF

music les or audio les stored on a standard USB ash memory device (sold

separately). With the optional Roland CD-01A CD Drive, you can even play

back and play along with songs directly from a standard audio CD. During

playback of the built-in songs or SMF music les from a USB memory key, you

can mute right-hand, left-hand and backing part individually. Since you can alter

both the key and tempo independently, you can slow down playback when

learning a new piece or nd a more comfortable key for a song with which you

want to sing along. During playback of

audio les from USB memory, you can

also alter key and tempo independently,

as well as minimize the lead vocal or

instrument via the “Center Cancel”

function. Both models also boast over

300 GM2/GS tones with layer and split

capability to support almost any musical

performance or study.

pp p mp mf fff

Variation in tone color produced by

the SuperNATURAL Piano sound

engine with heavier touch.

*The graph and drawings are artistic illustrations

A true grand-piano experience

The characteristics, nuance, and power of a grand piano in a compact body.

Natural and beautiful piano tone. Tone and touch that respond to the performer’s heart.

These models were designed to realize the richness and expression of an acoustic grand piano.

Enjoy the beauty and elegance of an acoustic grand, meticulously realized with the new RG-3F and RG-1F.

The mirror-nish cabinet in Polished Ebony houses the SuperNATURAL Piano sound engine*1, PHA

III Ivory Feel keyboard*2, and Progressive Damper Action pedal*3. From top to bottom, this top-line

model delivers the ultimate in tone, touch, and design. And because it’s only 95cm (37-7/16") deep,

the RG-3F can be placed in areas where it may be difcult to place traditional acoustic grand pianos,

such as living rooms, hotel lounges, or restaurants. The fallboard, which features a mirror-nish on

the inside, reects the keyboard and performer’s ngers just like a grand piano. It also comes with

educational features, including a built-in metronome and recorder.

*1 SuperNATURAL Piano sound engine [ P4] *2 PHA III Ivory Feel keyboard with Escapement [ P4] *3 Progressive Damper Action

Pedal [ P5]

Grand-piano sound and quality in a compact and

elegant body

*The graph and drawings are artistic illustrations

Natural touch

Fulcrum

Long

Key is the optimum length (PHA III)

Unnaturally heavy

Fulcrum

Short

Key is too short

Relationship between key length

and touch weight

1,490mm

950mm

1,540mm

920mm

Keyboard

Finger

moisture

Finger

moisture

Moisture

absorption

Moisture

absorption

A comfortable texture has been achieved thanks to

new materials with moisture-absorbing characteristics.

RG-3F

245
