rollease acmeda AUTOMATE AX30 User manual

AUTOMATE™
AX30/AX50 EXTERNAL SHADE MOTOR
433 MHZ
BI-DIRECTIONAL
ELECTRONIC
LIMIT
FAVORITE
POSITION
IMPACT
DETECTION
AUTOMATE | AX30/AX50 External Shade Motor combine the simple, intuitive features of
ARC “Automate Radio Communication” with the higher lifting capacity of an AC motor for
larger shade applications.
INSTR.AX30/AX50 v0.5 JUL 2020

2 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
CONTENTS
1 ASSEMBLY 6
2 WIRING 7
2.1 EU/AU Motor 7
2.2 US Motor 7
3 P1 BUTTON FUNCTIONS 8
3.1 Motor state test 8
3.2 Motor configuration options 8
4 NONCASSETTE OPEN MODE 9
4.1 Initial Setup 9
4.1.1 Pair motor with controller 9
4.1.2 Check motor direction 9
4.2 Set Limits 10
4.3 Adjust Upper Limit 11
4.4 Adjust lower limit 11
4.5 Delete Upper/Lower Limits 12
5 CASSETTE MODE 13
5.1 Initial Setup 13
5.1.1 Pair motor with controller 13
5.1.2 Check motor direction 13
5.2 Select Motor Mode 14
5.3 Set Limits 14
5.4 Delete Upper/Lower Limits 15
5.4.1 Activate/Deactivate Upper Limit Fabric Tension 15
5.4.2 Activate/Deactivate Lower limit Fabric Tension 16
6 VERTICAL DROP MODE 17
6.1 Initial Setup 17
6.1.1 Pair motor with controller 17
6.1.2 Check motor direction 17
6.2 Select Motor Mode 18
6.3 Set Limits 18
6.3.1 Adjust upper limit 19
6.3.2 Adjust lower limit 19
6.3.3 Delete Upper/Lower Limits 20

3 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
CONTENTS
6.4 FT Mode Overview 20
6.4.1 Switching FT Lock Mode 21
6.4.2 Auto Mode Operation 22
6.4.3 Manual Mode Operation 22
6.5 Impact Detection (Only available with Zipscreen) 23
6.5.1 Active/Deactivate Impact Detection Mode 23
7 ADD CONTROLLER AND CHANNEL 24
7.1 Using P2 Button on existing controller to add a new controller or channel 24
7.2 Using a pre-existing controller to add or delete a controller or channel 24
8 FAVORITE POSITIONING 25
8.1 Set a favorite position 25
8.2 Send shade to favorite position 25
8.3 Delete favorite position 25
9 SLEEP MODE 26
10 WIND SENSOR FUNCTION 26
10.1 Wind Sensor Prioritize Function 26
11 TROUBLE SHOOTING 27

4 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
SAFETY INSTRUCTIONS
WARNING: Important safety instructions to be read before installation.
Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
• Do not expose to water, moisture, humid and damp environments or extreme temperatures
• Persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge
should not be allowed to use this product.
• Keep away from children.
• Use or modification outside the scope of this instruction manual will void warranty.
• Installation and programming to be performed by a suitably qualified installer.
• For use with motorized shading devices.
• Ensure correct crown and drive adapters are used for the intended system.
• Keep antenna straight and clear from metal objects
• Do not cut the antenna.
• Follow Rollease Acmeda installation instructions.
• Before installation, remove any unnecessary cords and disable any equipment not needed for powered operation.
• Ensure torque and operating time is compatible with end application.
• Motor is to be installed in horizontal application only.
• The routing of cable through walls shall be protected by isolating bushes or grommets.
• Ensure power cable and aerial is clear and protected from moving parts.
• If cable or power connector is damaged do not use.
• Route motor cable to create a drip loop
• Frequently inspect for improper operation. Do not use if repair or adjustment is necessary.
• Keep motor away from acid and alkali.
• Do not force the motor drive.
• Keep clear when in operation.
It is important for the safety of persons to follow the enclosed instructions. Save these instructions for future
reference
Rollease Acmeda declares this equipment is in compliance with the essential requirements and other relevant provisions of
R&TT EC Directive 1999/5/EC

5 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
SAFETY INSTRUCTIONS
Do not dispose of in general waste.
Please recycle batteries and damaged
electrical products appropriately.
Statement Regarding FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
Statement Regarding IC Compliance
1. This device complies with Industry Canada RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
-French:
Leprésent appareil est conforme aux CNR d’Industrie Canada applicable aux appareils radio
Exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement.”
CAN ICES-3 (B)/NMB-3(B)

6 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
.
Crown
Bracket
Drive
Adapter
Retaining Clip
Motor Head
Step 1. Cut roller tube to required length.
Please refer to Rollease Acmeda System Assembly Manual for full assembly instructions relevant to the
hardware system being used, including recommended crown, drive and bracket adapter kits.
Step 2. Ensure roller tube is clean and free from burrs.
Step 3. Fit required crown, drive and bracket adapters.
Step 4. Slide Motor into tube.
Insert by aligning key-way in crown and drive
wheel into the tube.
Step 5. Mount motorized tube onto brackets.
1 ASSEMBLY
Tube must be close fitting with chosen crown
and drive adapters.
Impact detection does not require a 2 piece drive set. The use of a standard 1 part
drive adapter is compatible. Zipscreen is needed to let the impact transmit to the top
during downward movement. The top tube must be able to freely rotate ~ 5 degrees
after installation.
IMPORTANT

7 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
1
2
3
Disconnect the mains power supply.
Connect the motor according to the information in the table below.
Ensure cable is kept clear of fabric.
Ensure antenna is kept straight and away from metal objects.
Ensure cable is kept clear of fabric.
Ensure antenna is kept straight and away from metal objects.
Power OFF
Water proof connector
Power Cord
2 WIRING
MOTOR POWER NEUTRAL LIVE EARTH REGION
MT01-1145-069014 230V AC 50Hz
Blue Brown Yellow/Green
EU
MT01-1145-069016
MT01-1145-069013 240V AC 50Hz AU
MT01-1145-069015
DO N OT REM OV E THIS LABEL
WARNING
E L E C TRICAL HAZARD !
Power shall only be supplied to this
cable once male & female
connectors are correctly coupled.
Isolate power prior to connecting or
disconnecting this motor.
This connector must not be acces-
sible to the end user. It shall be
placed within a pelmet box or within
a housing in accordance to
AS/NZS 60335.1:2011 or
(BS) EN 60335-1:2012
Failure to do so could compromise
personal safety.
DO N OT REMOVE THIS LABEL
WARNING
ELE C TRIC A L H AZARD !
Power shall only be supplied to this
cable once male & female
connectors are correctly coupled.
Isolate power prior to connecting or
disconnecting this motor.
This connector must not be acces-
sible to the end user. It shall be
placed within a pelmet box or within
a housing in accordance to
AS/NZS 60335.1:2011 or
(BS) EN 60335-1:2012
Failure to do so could compromise
personal safety.
MOTOR POWER CORD LENGTH POWER NEUTRAL LIVE EARTH
MT01-1145-069017 240in. (6096mm) 120V AC 60Hz White Black Green
MT01-1145-069018
P1 button on motor head
P1 button on motor head
3
2
1
2.2 US Motor
2.1 EU/AU Motor

8 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
3 P1 BUTTON FUNCTIONS
This table describes the function of a short P1 Button press/release (<2 seconds) depending on current motor
configuration.
The P1 Button is utilized to administer motor configurations as described below.
Activate Pairing Mode
Approx.
Approx.
Approx.
Sleep Mode
Reverse Direction
Approx.
Reset To Factory Settings
Approx.
Approx.
P1
Press Condition Function Achieved
Visual
Feedback
Audible
Feedback Function Described
Short
Press
If limit is NOT set None No Action None No Action
If limits are set
Operational
control of motor,
run to limit. Stop
if running
Motor Runs None
Operational control
of motor after pairing
and limit setting is
completed first time
If motor is in
“Sleep Mode” &
limits are set
Wake and control
Motor wakes
and runs in a
direction
None
Motor is restored from
Sleep Mode and RF
control is active
Hold P1 button on motor head.
Approx.
Approx.
Approx.
Approx.
3.1 Motor state test
3.2 Motor configuration options
8
P1 button on motor head

9 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
4 NONCASSETTE OPEN MODE
For Cassette Mode refer to section 5 and for Vertical Drop Mode refer to section 6.
4.1 Initial Setup
.
4.1.1 Pair motor with controller
4.1.2 Check motor direction
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT IMPORTANT
IMPORTANT
Note: Ensure Motor is in factory default setting.

10 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
4.2 Set Limits
SECS
5
Cycle shade up and down prior to setting limits to settle fabric
After setting limits, motor will automatically exit from initial
set-up mode.
Move shade to the desired highest or lowest
position by pressing the UP or DOWN buttons
on controller.
To save upper limit, hold UP and STOP.
To save lower limit, hold DOWN and STOP.
Motor Response
IMPORTANT
IMPORTANT
Approx.

11 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
4.3 Adjust Upper Limit
SEC
SEC
S
S5
5
4.4 Adjust lower limit
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the DOWN button.
Move shade to the desired
highest position by pressing
the UP button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
SEC SECS S
5 5
Approx. Approx.

12 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
4.5 Delete Upper/Lower Limits
Press P2 on controller Press DOWN on controller Press P2 on controller
Motor Response Motor Response Motor Response

13 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
5 CASSETTE MODE
For Non-Cassette Open Mode refer to section 4 and for Vertical Drop Mode refer to section 6.
5.1 Initial Setup
.
5.1.1 Pair motor with controller
5.1.2 Check motor direction
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT IMPORTANT
IMPORTANT
Note: Ensure Motor is in factory default setting.

14 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
5.2 Select Motor Mode
Press P2 on controller. Press UP on controller. Press UP on controller.
Cassette Mode:
Motor Response
SET UPPER LIMIT IN CASSETTE MODE
Move shade to the highest position by pressing the UP button on controller. Upper limit will be automatically
set when motor stops.*
Note:
*On condition that lower limit has been set prior.
Move shade to the desired lowest
position by pressing the UP or DOWN
buttons on controller.
To save lower limit, hold DOWN and STOP.
+
Motor Response
OR
SECSSECS
55
SET LOWER LIMIT IN CASSETTE MODE
5.3 Set Limits
Now set the motor to cassette mode.

15 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
5.4 Delete Upper/Lower Limits
Press P2 on controller Press DOWN on controller Press P2 on controller
Motor Response Motor Response Motor Response
Move shade to Upper/Lower Limits
5.4.1 Activate/Deactivate Upper Limit Fabric Tension
Press P2 on controller Press STOP on controller Press UP on controller
ACTIVATE:
Motor Response Motor Response Motor Response
DEACTIVATE:
Upper limit fabric tension is deactivated by default.

16 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
5.4.2 Activate/Deactivate Lower limit Fabric Tension
Press P2 on controller Press STOP on controller Press DOWN on controller
ACTIVATE:
Motor Response Motor Response Motor Response
DEACTIVATE:
Lower limit fabric tension is deactivated by default.

17 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
6 VERTICAL DROP MODE
For Non-Cassette Open Mode refer to Section 4 and for Cassette Mode refer to section 5.
6.1 Initial Setup
.
6.1.1 Pair motor with controller
6.1.2 Check motor direction
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT IMPORTANT
IMPORTANT
Note: Ensure Motor is in factory default setting.

18 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
6.3 Set Limits
For Ultralock application, see Zipscreen Manual for further info
SECS
5
Cycle shade up and down prior to setting limits to settle fabric
After setting limits, motor will automatically exit from initial
set-up mode.
Move shade to the desired highest or lowest
position by pressing the UP or DOWN buttons
on controller.
To save upper limit, hold UP and STOP.
To save lower limit, hold DOWN and STOP.
Motor Response
IMPORTANT
Initial set-up is not complete
IMPORTANT
Approx.
6.2 Select Motor Mode
Press P2 on controller. Press UP on controller. Press UP on controller.
Perform sequence 2Times - Motor will Jog/Beep at the end of each sequence.
Vertical Drop Mode:
Motor Response at the end of x2 sequence
Now set vertical drop mode.

19 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
6.3.1 Adjust upper limit
SEC
SEC
S
S5
5
Hold UP and STOP on
controller.
Move shade to the desired
highest position by pressing
the UP button.
To save upper limit, hold UP
and STOP.
Approx.
Approx.
Motor Response Motor Response
6.3.2 Adjust lower limit
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the DOWN button.
To save lower limit, hold
DOWN and STOP.
Motor Response Motor Response
SEC SECS S
5 5
Approx. Approx.

20 | Automate™Programming Instructions | AX30/AX50 External Shade Motor ROLLEASE ACMEDA
6.3.3 Delete Upper/Lower Limits
Press P2 on controller Press DOWN on controller Press P2 on controller
Motor Response Motor Response Motor Response
Move shade to Upper/Lower Limits.
6.4 FT Mode Overview
MODE OVERVIEW
Top limit
Bottom limit
TENSION
UNLOCK
MODE 2
FT MODE Automatic Lock
MODE 3
FT MODE Manual Lock
LEGEND
END OF CYCLE
CYCLE PAUSE
MODE 1
E-Type (DEFAULT)
