rollease acmeda AUTOMATE Installation manual

AUTOMATE™
AC MECHANICAL LIMIT TUBULAR MOTOR
MECHANICAL
LIMIT
QUIET
OPERATION
FEATURES:
• Line Voltage (available for both 100V-120V & 220V-240V applications)
• “Slim Head” design minimizes light gap
• Low Operating Noise Levels.
• Mechanical Limits
AUTOMATE™| mechanical limit AC motors come in 35mm and 45mm diameters with
various torque and speeds, including models with Quiet Operation. A “Slim Head” design
minimizes light gap.
INSTR. MTACML_Automate_AC V1.0 FEB 2017

2 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
NOTES

3 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
CONTENTS
1 ASSEMBLY 5
2 WIRING 6
2.1 Power options 6
3 ADJUSTING LIMITS: FRONT ROLL, LEFT MOUNT 7
3.1 Adjusting Upper Limit 7
3.2 Adjusting Lower Limit 7
4 ADJUSTING LIMITS: FRONT ROLL, RIGHT MOUNT 8
4.1 Adjusting Upper Limit 8
4.2 Adjusting Lower Limit 8
5 ADJUSTING LIMITS: REVERSE ROLL, LEFT MOUNT 9
5.1 Adjusting Upper Limit 9
5.2 Adjusting Lower Limit 9
6 ADJUSTING LIMITS: REVERSE ROLL, RIGHT MOUNT 10
6.1 Adjust Upper Limit 10
6.2 Adjust lower limit 10
7 TROUBLESHOOTING 11

4 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
SAFTEY INSTRUCTIONS
WARNING: Important safety instructions to be read before installation.
Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
CAUTION
• Do not expose to moisture or extreme temperatures.
• Do not allow children to play with this device.
• Use or modification outside the scope of this instruction manual will void warranty.
• Installation and programming to be performed by a suitably qualified installer.
• For use within tubular blinds.
• Ensure correct crown and drive adaptors are used for the intended system.
• Keep antenna straight and clear from metal objects
• Do not cut the antenna.
• Use only Rollease Acmeda hardware.
• Before installation, remove any unnecessary cords and disable any equipment not needed for powered operation.
• Ensure torque and operating time is compatible with end application.
• Do not expose the motor to water or install in humid or damp environments.
• Motor is to be installed in horizontal application only.
• Do not drill into motor body.
• The routing of cable through walls shall be protected by isolating bushes or grommets.
• Ensure power cable and aerial is clear and protected from moving parts.
• If cable or power connector is damaged do not use.
Important safety instructions to be read prior to operation.
• It is important for the safety of persons to follow the enclosed instructions. Save these instructions for future reference.
• Persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge
should not be allowed to use this product.
• Keep remote controls away from children.
• Frequently inspect for improper operation. Do not use if repair or adjustment is necessary.
• Keep motor away from acid and alkali.
• Do not force the motor drive.
• Keep clear when in operation.
5005833

5 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
1 ASSEMBLY
Step 1. Cut roller tube to required length.
Step 2. Ensure roller tube is clean and free from burrs.
Step 3. Fit required crown, drive and bracket adapters.
Tube must be close fitting with chosen crown
and drive adapters. Refer to Rollease Acmeda
System Assembly Manual for recommended
crown, drive, and bracket adapter kits.
Step 4. Slide Motor into tube.
Insert by aligning keyway in crown and
drive wheel to the tube.
Step 5. Mount motorized tube onto brackets.
Refer to Rollease Acmeda System
Assembly Manual for recommended crown,
drive, and bracket adapter kits.
Please refer to Rollease Acmeda System Assembly Manual for full assembly instructions relevant to the hardware system being used.
Crown
Drive
Retaining
Clip
Motor Head
Adapter
Bracket

6 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
2 WIRING
2.1 Power options
Ensure cable is kept clear of fabric.
Cut off the mains power supply
• Connect the motor according to the information in the table below.
Range Neutral Live 1 Live 2 Earth
220-240V Blue Brown Black Yellow / Green
100-120V White Black Red Green

7 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
To raise the limit, turn bottom adjuster
countercockwise towards the “+”.
To lower the limit, turn lower adjuster clockwise
towards the “-”.
Motor Response Motor Response
Lower limit will raise. Lower limit will become lower.
3.1 Adjusting Upper Limit
3.2 Adjusting Lower Limit
To raise the limit, turn bottom adjuster
counterclockwise towards the “+”.
To lower the limit, turn lower adjuster
clockwise towards the “-”.
Motor Response Motor Response
Upper limit will raise. Upper limit will lower.
3 ADJUSTING LIMITS: FRONT ROLL, LEFT MOUNT

8 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
4 ADJUSTING LIMITS: FRONT ROLL, RIGHT MOUNT
4.1 Adjusting Upper Limit
4.2 Adjusting Lower Limit
To raise the limit, turn upper adjuster
clockwise towards the “-”. To lower the limit, turn upper adjuster
counterclockwise towards the “+”.
Motor Reponse Motor Reponse
Lower limit will raise. Lower limit will become lower.
To raise the limit, turn bottom adjuster
countercockwise towards the “+”.
To lower the limit, turn lower adjuster clockwise
towards the “-”.
Motor Response Motor Response
Upper limit will raise. Upper limit will lower.

9 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
5 ADJUSTING LIMITS: REVERSE ROLL, LEFT MOUNT
5.1 Adjusting Upper Limit
5.2 Adjusting Lower Limit
To raise the limit, turn upper adjuster
counterclockwise towards the “+”.
To lower the limit, turn upper adjuster
clockwise towards the “-”.
Motor Response Motor Response
Upper limit will raise. Upper limit will lower.
To raise the limit, turn upper adjuster
counterclockwise towards the “+”.
To lower the limit, turn upper adjuster
clockwise towards the “-”.
Motor Response Motor Response
Lower limit will raise Lower limit will become lower.

10 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
6 ADJUSTING LIMITS: REVERSE ROLL, RIGHT MOUNT
6.1 Adjust Upper Limit
6.2 Adjust lower limit
To raise the limit, turn upper adjuster
counterclockwise towards the “+”..
To lower the limit, turn upper adjuster
clockwise towards the “-”.
Motor Response Motor Response
Upper limit will raise. Upper limit will lower.
To raise the limit, turn upper adjuster
counterclockwise towards the “+”.
To lower the limit, turn upper adjuster
clockwise towards the “-”.
Motor Response Motor Response
Lower limit will raise. Lower limit will become lower.

11 | Automate™Programming Instructions | AC Mechanical ROLLEASE ACMEDA
7 TROUBLESHOOTING
Problem Cause Remedy
Motor is not responding Incorrect wiring
Check that wiring is connected
correctly (refer to motor
installation instructions)
