EASY SPRING WAND
INSTALLATION MANUAL
April 2018

Page 1 Easy spring WAND Assembly Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
CONTENTS
April 2018
This manual is to be read in conjunction with the Product Specifications & Assembly manual
SECTION
NO
.
DESCRIPTION
PAGE NO.
SECTION 1 − ITEMS REQUIRED 1.1
SECTION 2 − INSTALLATION 2.1
PART A – PREPARING INSTALLATION SPACE 2.1
PART B – MOUNTING BRACKET AND SHADE INSTALLATION 2.1
PART C – PRETENSION CHECKS 2.3
PART D – SET LIMITS 2.6
SECTION 3 − TROUBLESHOOTING 3.1
DISCLAIMER
INTRODUCTION
This Installation manual has been produced by Rollease Acmeda to supply the necessary information for safe and correct installation of this system.
INSTALLERS RESPONSIBILITY
Before installing, please read & ensure you understand the safety information and installation instructions as defined in this installation manual.
•If you do not fully understand these instructions, contact Rollease Acmeda for clarification before installing.
•The Installer is responsible to ensure that all installation personnel have been adequately trained on the safe & correct installation and operation.
•The Installer is responsible to ensure that a Job Safety Analysis or Safe Work Method Statement is completed prior to installation to identify hazards, to determine
appropriate risk control measures and to implement the control measures.
•The Installer is responsible to ensure that supporting structures are sound and can adequately support the load.
•The Installer is responsible to ensure that the devises used to anchor the product to the supporting structure are suitable for the application.
•The fasteners provided are intended for fastener to timber. The installer is responsible for selecting fasteners that are suitable for other substrates
SAFETY INFORMATION
•Ensure Job Safety Analysis/Safe Work Method Statement is completed and actions to reduce risks are implemented.
•Ensure that electrical works are done only by a LICENSED ELECTRICIAN.
•DO NOT modify any of the components of this system.
PERSONNEL REQUIREMENTS
Only suitably trained/qualified personnel should undertake installation.
DISCLAIMER
Rollease Acmeda has used reasonable care in preparing the information included in this document, but makes no representations or warranties as to the completeness or
accuracy of the information. Information is supplied upon the condition that the persons receiving the information will make their own determination as to its suitability
for their purposes prior to use. Rollease Acmeda assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the
information included herein. Rollease Acmeda reserves the right to make changes without further notice to any products to improve reliability, function or design.
COPYRIGHT
COPYRIGHT ROLLEASE ACMEDA 2018
All rights reserved. No part of this document may be reproduced or utilized in any means, by any means, electronic or mechanical including photocopying, recordings, or
by any information storage or retrieval system, without the express permission from Rollease Acmeda.

Page 1.1 Easy Spring Wand Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
SECTION 1 − ITEMS REQUIRED
TOOLS REQUIRED
•Drill
•Drill Bits
•Measuring Tape
•Pencil
•Screw Driver - Flat Head
•5mm Socket
•Ratchet
SHADE
ITEMS REQUIRED
Check you have all items required to complete installation;
1. Shade Assembly
2. 2 x Bracket Covers
3. 2 Mounting Brackets
4. Appropriate Fasteners

Page 2.1 Easy Spring Wand Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
SECTION 2 − INSTALLATION
PART A
–
PREPARING
INSTALLATION SPACE
STEP 1 – ENSURE TOP OF INSTALLATION SPACE IS LEVEL
PART B
–
MOUNTING
BRACKET
AND
SHADE
INSTALLATION
STEP 1 – INSTALL BRACKETS TO WALL / CEILING USING APPORPRIATE FASTENERS TO SUIT APPLICATION
INSTALL BRACKETS AS PER INSTALLATION REQUIREMENTS
NOTE: Install additional Easy-Link bracket if required

Page 2.2 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
STEP 2 – INSTALL SHADE ONTO MOUNTING BRACKETS
Note: Insert limiter end into bracket first
Ensure Control End is fully engaged with the top bracket tongue

Page 2.3 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
PART C
–
PRETENSION
CHECKS
STEP 1 – CHECK FUNCTIONALITY OF PRE TENSIONED SHADE
i) PULL Bottom Rail
down to bottom
location
ii) Shade will raise within range
indicated below to be locked and
provide a 'Release Allowance'
(for raising the shade)
iii) TUG Bottom Rail
(Shade will automatically
rise)
NOTE: As limits are not set,
ensure Bottom Rail is
controlled so Shade doesn't
Crash into structure and
damage fabric
If Bottom Rail raises at the
desired speed, the correct
number of pre-turns have been
assigned
If Shade stops midway or slows significantly, insufficient pre-turns
have been applied.
Pre-turns to be added
If Shade operates too fast, too many pre-turns have been
applied.
Pre-turns to be removed
PROCEED TO PART D
MAX 33mm (1.3”)
PULL
← Limit Position

Page 2.4 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
BEFORE ADDING OR REMOVING PRE TURNS
IF ADJUSTING PRETENSION WHILE SHADE IS INSTALLED:
Ensure the shade is raised fully at the top limit position before
making any adjustments.
IF ADJUSTING PRETENSION WITH SHADE REMOVED FROM
BRACKETS:
Before removing the shade, ensure the shade is lowered
slightly in its locked position. Shade must not be resting on
top limit. This is to prevent the spring from loosing the
pretension when removing the shade from brackets.
← Limit Position
← Locked Position
← Limit Position
← Locked Position

Page 2.5 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
PRE TENSION ADJUSTMENT – SHADE INSTALLED
Insert Socket Ratchet onto adjusting shaft and rotate in
counter clockwise to increase pre-turns as required.
NOTE: If there is insufficient space to rotate Socket Ratchet
within installation, Shade will need to be removed from the
bracket to undertake process.
Re-check functionality of blind as per process i, ii & iii outlined
above in this step.
(Pretension direction is reversed for LH control)
Insert Socket Ratchet onto adjusting shaft and rotate in a
clockwise direction to decrease pre-turns as required.
NOTE: If there is insufficient space to rotate Socket Ratchet
within installation, Shade will need to be removed from the
bracket to undertake process.
Re-check functionality of blind as per process i, ii & iii outlined
above in this step.
(Pretension direction is reversed for LH control)
PRE TENSION ADJUSTMENT – SHADE REMOVED
Hold the shade and use the Socket Ratchet
to rotate the adjusting shaft (and wand
control head) in an anti-clock wise
direction enough to release the booster
lock. The ratchet will move back under the
spring tension.
While holding the shade, grip the
wand control head and also prevent
both from turning. To add tension,
rotate the Socket Ratchet for the
number of turns desired in a counter
clockwise. (Note, to remove tension
allow the spring to unwind in the
clockwise direction)
To re-lock the booster and shade, while
holding the shade, release the wand
control and rotate the Socket Ratchet
enough to re-engage the lock (approx. ¼
turn). The ratchet should move back under
the booster tension to the locked position.

Page 2.6 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
PART D
–
SET LIMITS
STEP 1 – SET TOP LIMIT
Ensure Shade is fully raised
To lower the top limit position rotate limiter head so that the
Shade moves down.
To raise the top limit position rotate limiter head so that the
Shade raises.
NOTE: The shade must not be locked by the spring to allow the
bottom rail to move up
*Standard back roll shown, reverse for front roll
STEP 2 – TEST LIMITS & SHADE FUNCTIONALITY
Operate Shade up & down

Page 2.7 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
STEP 3 – SLIDE END CAP COVERS OVER BRACKETS

Page 3.1 Easy spring WAND Installation Manual | April 2018
Copyright 2018 | Rollease Acmeda Group
SECTION 3 − TROUBLESHOOTING
NO.
PROBLEM
CAUSE
SOLUTION
1 Cannot find limit Limit incorrectly Set a) Allow blind to raise fully
b) If the bottom rail is too high and contacting the brackets, then…
i. Wind limit adjustment wheel in the direction that would
lower the Shade *
ii. When the Shade starts to lower this indicates the limit has
been engaged
c) Use limit adjustment wheel to raise or lower limit as required
* Note : If limit wheel appears to require numerous turns, raise the Shade
to approximate top limit position, un-install the shade from mounting
brackets, remove the limiter from the tube, rotate and move limit nut to
appropriate stop position. Reassemble and re-install Shade to adjust top
limit. Refer to “Section 2, Part D”
2 Erratic Behaviour
Shade falls
Connector on wrong
end
Remove and re-install on other end (See Assembly Manual, Section 2,
Part C)
No Pre-Turns Add pretensions (See Section 2, Part C)
3 Shade rises too
quickly
Wrong Decelerator Remove and re-install correct Decelerator (See Assembly Manual, Section
2, Part B)
Too many preturns Remove pre-turns ( See Section 2, Part C )
4 Operation of the
wand does not
lower or release
shade
Incorrect hand Control Remove control and replace with correct hand control
Control is not fully
engaged with
Connector
Check deductions and/or bracket spacing are correct and according to the
specifications
5 Shade does not
raise
Incorrect hand Booster Remove control and re-orientate the booster (See Assembly Manual,
Section 2, Part C)
Control is not fully
engaged with Booster
Remove control and check with booster (See Assembly Manual, Section 2,
Part B)
Not enough pre-turns Add pretensions (See Section 2, Part C)
