Rollplay W487AC-R Assembly instructions

Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colors may vary. Do not return to store. Call 1-888-982-9309 for assistance and
replacement parts.
IMPORTANT:
Save this manual with your sales receipt.
Owner’s Manual and Assembly Instructions
Model #: W487AC-R, W487AC-B, W487AC-ROB, W487AC-BOB, W487AC
Volkswagen type 2 (T1)
Products Co., Ltd. (Goodbaby Group). Trademark “VW-in-circle logo”, associated design patents and copyrights are
used with the approval of the owner Volkswagen AG.

Introduction
Thank you for purchasing this RollPlay vehicle from Aria Child. We hope
the rider enjoys it for miles to come. Please read this instruction guide
carefully before assembling and operating the vehicle. Please have your
model number and serial number ready before calling. Please have proof of
purchase. Keep your sales receipt or register your product at
www.rollplay.net.
Please contact Aria Child Customer Service with any questions.
Hours: 9 AM - 5 PM (CST), Monday - Friday
Phone: [phone]
Email: [email protected]
Web: www.rollplay.net
Specifications:
BATTERY 6V 7AH
MOTOR 6V 15W
AGE 3 Years and Up
MAX WEIGHT 35 kg (77 lbs)
PRODUCT SIZE 107 x 54 x 55 cm (42.2 x 21.2 x 21.6 in)
SPEED 4 km/h (2.5 MPH)
RECHARGE TIME 8-12 Hours
TYPICAL RUN TIME 1-2 Hours
CHARGER OUTPUT DC 7.0V

IMPORTANT!
YOU MUST CHARGE THE BATTERY
FOR 24 HOURS BEFORE FIRST USE!
Charge the battery after each use.
Charge the battery at least once a month, even if the vehicle is not in use.
DO NOT RETURN THIS ITEM
TO THE STORE!
Call Customer Service if you need assistance or replacement parts. Please
have your model number and serial number ready before calling. Please
have proof of purchase. Keep your sales receipt or register your product at
www.rollplay.net as we may require proof of purchase.
1-888-982-9309
Read this entire manual to ensure
proper assembly and safe operation
of the vehicle.

This page is intentionally left blank.

5
Table of Contents
Safety..........................................................6
Parts ..........................................................8
Charging Instructions ...............................9
Assemble the Front Wheels....................10
Assemble the Steering Wheel
................
11Assemble the Rear Wheels .....................
13
Attach the Mirrors ...................................14
Attach the Seat ........................................15
Operation Instructions ............................16
Battery Removal ......................................17
Maintenance ............................................18
General Care ............................................19
Troubleshooting Guide............................20
FCC Information ......................................22
Service and Repairs ...............................23
Warranty ...................................................24
Product Registration ...............................26

6Safety
WARNING: SAFETY RIDING RULES
The user must follow all safety rules and guidelines, or serious injury or death may
occur to the user.
• Always use common sense and safe practices when using the vehicle. The user
must be at least 3 years old and weigh no more than 35 kg (77 lbs).
• This product contains small parts that are for adult assembly only. Keep small
children away when assembling. Remove and dispose of all protective material
and plastic bags before assembly.
• Riders must always wear a tted helmet that complies with U.S. Consumer
Product Safety Commission (CPSC) Standard 16CFR 1203.
• Only sit on the seat in the vehicle.
• Do not allow more than one rider.
• Do not overload the vehicle. Do not remove the weight restriction decals.
• Do not pull the vehicle with another vehicle or similar device.
• Keep body parts such as hands, legs, hair and clothing away from moving parts.
Moving parts can cause serious injury.
• Always wear shoes in the vehicle.
• Do not operate near streets or motor vehicles.
• Do not operate near drop-offs such as steps, steep inclines or hills. Operate on
relatively level ground.
• Do not operate near water, swimming pools or other uids.
• Do not operate in dangerous weather conditions such as rain or snow.
• Do not operate near loose dirt, mud, sand or ne gravel.
• Do not operate near ammable vapors (gasoline, paint thinner, acetone, etc.).
• Always use the vehicle in a safe, secure environment with adult supervision.
PREVENT INJURIES AND DEATHS:
NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when child is in
vehicle. Direct adult supervision is REQUIRED.
NEVER use in roadways, near cars, on or near steep inclines or steps, swimming
pools or other bodies of water.
ALWAYS wear shoes
ALWAYS sit on the seat
RISK OF FIRE. Do not bypass.

7
Safety (Continued)
WARNING: BATTERY SAFETY
• Battery posts, terminals and related accessories contain lead and lead compound
(asic) chemicals known to the state of California to cause cancer, reproductive
harm, and are toxic and corrosive. DO NOT open the battery.
• Contact exposure to battery leakage (lead acid) may cause serious injury.
Immediately contact your doctor if exposure occurs. If the chemical is on the skin,
ush immediately with cool water for 15 minutes. If the chemical is swallowed,
immediately give the person water or milk. Do not give water or milk if the person
is vomiting or has decreased alertness. Do not induce vomiting.
• Tampering with or modifying the electric circuit system may cause shock, re or
explosion. It could permanently damage the system. Keep the charger housing
closed to prevent exposed wiring, which may cause electric shock.
IMPORTANT: Before using the vehicle for the rst time, the battery must be
charged for a full 24 hours (no more than 30 hours).
WARNING: ADULT SUPERVISION
REQUIRED
• Before using the vehicle, the rider must understand the vehicle controls and safety
issues.
• It is the responsibility of the adult to educate the child and to determine if the child
is capable of understanding the vehicle controls.
• An adult must ALWAYS directly supervise the use of this vehicle.
• NEVER leave a child unsupervised in the vehicle.

8Parts
1. Car Body
2. Seat
3. Steering Wheel
4. Rear Wheel (2)
5. Front Wheel (2)
6. Wheel Rim (4)
7. Hubcap (4)
8. Steering Wheel Screw
9. Steering Wheel Nut
10. Mirrors (2)
11. Battery Charger
12. Snap Pin (4)
13. Small Washer (4)
14. Large Washer (3)
15. Inner Wheel Spacer
16. MP3 Cable
rPhillips screwdriver
rPliers
Not Included:
Helpful Tip:
Parts 8-9 and 12-16 are located in
the blister pack
Spare Parts:
Snap Pin (2)
Small Washer (1)
Large Washer (1)

9
Charging Instructions
ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER.
To Charge the Battery:
1. Ensure the vehicle is stopped and turned
off.
2. Unlock and remove the seat.
3. Located the red battery connector (A)
that attaches directly to the battery.
4. Connect the red battery connector to the
red battery charger connector (B).
5. Plug into a 120 V outlet.
To Reconnect the Battery:
6. Unplug the battery charger from the
outlet.
7. Unplug the red battery connector from
the red charger connector (B).
8. Connect the red battery connector (A) to
the red engine connector (C).
9. Replace the seat and tighten lock.
Note: It is not necessary to remove the
battery for charging. However, if the
battery does not reach the outlet, it can be
removed for charging. For Battery Removal
instructions, see Page 17.
YOU MUST CHARGE THE BATTERY FOR 24 HOURS
BEFORE THE FIRST USE!
A
A
B
Helpful Tip:
1. Ensure the red battery connector
is connected to the red engine
connector
2. Ensure the white gear box connector
is connected to the white engine
connector
3. NEVER connect a red connector to a
white connector
C

10 Assemble the Front Wheels
1. Located the washers and snap pins from the blister box.
2. Slide the small washer (13) onto the front axle.
3. Slide the front wheel (5) onto the axle. Ensure that the side of the wheel with the
slots is facing out.
4. Slide the small washer (13) onto the axle.
5. Insert the straight sdie of the snap pin (12) through the hole at the end of the axle
to keep the wheel in place.
6. Position the wheel rim (6) over the holes on the wheel and snap into place.
7. Position the hubcap (7) over the holes on the wheel rim, and snap the hubcap into
place.
8. Repeat steps 1-7 for the other front wheel.

11
Assemble the Rear Wheels
Left Rear Wheel
1. Locate the washers (14), snap pins (12) and inner wheel spacer (15)
from the blister box
2. Locate the rear axle (pre-installed).
3. Slide the rear axle toward the right side of the car with the motor so that
1’’ of the axle is visible on the non-motor side.
4. Slide the large washer (14) onto the axle.
5. Slide the inner wheel spacer (15) onto the axle.
6. Align the rear wheel (4) with the hole in the inner wheel spacer and slide
the axle all the way through the wheel.
7. Slide the large washer (14) onto the axle.
8. Insert the straight side of the snap pin (12) through the hole at the end
of the axle to keep the wheel in place.

12
Right Rear Wheel
1. Slide the axle away from the motor so that 1’’ of the axle is visible on
the motor side.
2. Slide the rear wheel (4) onto the axle with the gear teeth facing inward.
Ensure that the gear teeth connect with the motor that is pre-installed
on the axle.
3. Slide the axle toward the motor until it stops against the left rear wheel.
4. Slide the washer (14) onto the axle.
5. Insert the straight side of the snap pin (12) through the hole at the end
of the axle to keep the wheel in place.
Rims and Hub Caps
1. Position the wheel rim (6) over the holes on the wheels, and snap into
place.
2. Position the hubcap (7) over the holes on the wheel rim, and snap the
hubcap into place.
6 7
Assemble the Rear Wheels

13
Assemble the Steering Wheel
B
2. Plug the steering wheel connector (A) into the dashboard connector (B).
1. Located the steering wheel screw (8) and nut (9) from the blister box.
3. Slide the steering wheel (3) onto the steering rod.
4. Align the holes on the steering wheel with the holes on the steering rod.
5. Slide the steering wheel screw (8) through the round hole on the steering wheel
and steering rod.
6. Fasten the nut (9) on the end of the screw on the square hole and tighten the
screw with a screwdriver.
Helpful Tip:
1. Check that the steering rod is pushed up
all the way before installing the steering
wheel. Flip the car on its side and push
up on the steering rod from underneath
the car body.
2. Make sure the steering rod stays in
place as the steering wheel is installed.

14 Attach the Mirrors
1. Align the bottom of the mirror (10) with the hole on the car body.
2. Gently press the mirror down until it snaps into place.
3. Repeat for the other mirror.

15
Attach the Seat
1. Ensure the lock on the car seat is in the unlock position.
2. Align the two hooks on the back of the car seat (2) with the slots on the
back of the battery compartment.
3. Insert the hooks into the slots and push the seat down into place.
4. Use a at head screwdriver or a coin to turn the seat to the locked
position.

16 Operation Instructions
• Power: Push the power switch to turn on the car. Press the power
switch again to turn off the car.
• Pedal: Press the foot pedal down to go. Release the foot pedal to stop.
• Forward/Reverse: Push the forward switch to move forward. Push the
reverse switch to go in reverse.
• MP3: Turn on MP3 switch. Insert the MP3 cable into the MP3 jack and
connect to your device. The car must be turned on to use.
• Sounds: Press the in the middle of the steering wheel for sounds. The
car must be on for sounds to work.
• Battery power indicator: When the car is on, press the power
indicator button to check battery level.
• Green, Yellow, & Red Lights: Battery is fully charged. Yellow & Red
Lights: Battery level is low. Red Light: Battery power is lower than
5.5V, and the battery must be recharged

17
Battery Removal
1. Unlock and remove the seat.
2. Disconnect the red battery connector (A) from the red engine
connector (B).
3. Loosen and remove the screw from the battery strap using a Phillips
screwdriver.
4. Slide the battery strap out from the battery strap slot.
5. Remove the battery.
Note: It is not necessary to remove the battery for charging. However,
if the battery does not reach the outlet, then it can be removed for
charging.
Battery Strap

18 Maintenance
Important Battery and Charger Information
• Only an adult who has read and understands the safety warnings may
handle and operate the battery and battery charger. Keep away from
children.
• Charge the battery for 24 hours before using the vehicle for the rst
time.
• Recharge the battery immediately after each use. Charge for at least
8-12 hours, but no more than 20 hours.
• Charge the battery at least once a month, even if the vehicle is not used
or stored.
• Never leave the battery in a discharged condition.
• Connect the terminal of the battery and charger, then plug the charger
into a 120V AC outlet.
• It is normal for the charger to heat slightly. If the charger rises above
71°C / 160°F, disconnect the charger and call Customer Service for
assistance.
• Keep the charger away from water or excessive moisture to prevent
short-circuiting.
• Only use the charger specied with the original item. Do not charge the
battery with any other charger.
• Do not attempt to recharge non-rechargeable batteries with the original
charger.
• Do not replace the battery with any other battery, or the warranty
will be voided. If you need a replacement battery, see Page 23 for
replacement information.
• Remove damaged batteries from the car immediately. Recycle or
dispose of the used batteries responsibly.
• Do not short circuit the supply terminals.
• Do not leave the battery connected in the vehicle for extended periods
of time when the vehicle is not being used. Disconnect the battery
connector from the engine connector before storing.
• The vehicle is equipped with a thermal fuse to protect the electric
circuit. If the vehicle cuts out, turn the vehicle off and on to reset.

19
General Care
• Regularly inspect all vehicle parts to ensure they are in good working
condition.
• Regularly inspect the charger, cord, plug, and other related parts for
damage.
• Remove any damaged parts and immediately contact Customer Service
for replacement parts. See Service information on Page 23.
• DO NOT operate the vehicle if there are any damaged parts.
• Carefully clean the vehicle with a damp cloth and mild soap. Do not
get water in or near any electrical parts. Do not wash the vehicle with a
hose.
• Store the vehicle indoors or use a tarp to cover it. Keep away from
stoves, heaters, or other sources of heat.

20 Troubleshooting Guide
Problem Potential Cause Solution
Vehicle does not run Battery is low Recharge the battery
Thermal fuse tripped Reset fuse
Snap pins are loose Tighten snap pins
Loose wires or loose
connectors
Ensure the battery connectors
are securely attached. If wires
are loose, contact Customer
Service for repairs
Battery is dead Call Customer Service for
replacement battery
Electrical system is
damaged
Call Customer Service for
repairs
Motor is damaged Call Customer Service for
repairs
Vehicle only runs for a
short time
Undercharged battery Ensure a secure connection
when the battery is
recharging. Recharge for at
least 8-12 hours
Overcharged battery Never charge the battery for
more than 30 hours
Battery is old Replace battery
Vehicle runs slowly Battery is not fully
charged
Ensure a secure connection
when the battery is recharging
Battery is old Call Customer Service to
order replacement battery
Too much weight on
vehicle
Reduce weight on vehicle 35
kg / 77 lbs
Harsh conditions Operate the vehicle on level
ground and safe surfaces
Completely read through the manual and troubleshooting guide before
contacting Customer Service.
