Romus RED HOT VARIO User manual

1. The product description:
This product is a fan-type electric heaters, room heating is achieved through fan
forced cooling, this product can only be used in household or factory. A built-in
physical expansion type thermostat and self-reset overheat thermal cut-out adjust the
temperature and provide protection. At ambient temperature 0 ° man can adjust the
temperature of the thermostat in a range of 0-40 °C to control the air inlet
temperature; the self-reset thermal cut-out controls the appliance body temperature,
so that to avoid the overheating caused by wrong operation and provide the user a
safety and secure operation. The cooling fan is not controlled by thermostat and still
works when the heating element was power-off. The Product can be adjusted
upwards with an angle up to 10-degree, it’s user-friendly for heating with different air-
outlet angles; a built-in anti-overturn switch shuts off the heater when it was tipped
over 50-degree or above and the product stopped working.
GENERAL SECURITY :
This device is not intended for use by persons (including children) with physical, sensory or
mental disability, or persons lacking experience or knowledge, unless supervised by a person
responsible for their safety, supervision or instruction concerning use of the device.
You must watch children to make sure they do not play with the apparatus.
HEATING « RED HOT VARIO »
Ref 93477
User’s Manual - GB

-This device may be used by children aged 8 years or older and by persons with reduced
physical, sensory or mental capacities or lack of experience or knowledge if they are properly
supervised) S or if instructions for the safe use of the device have been given and the risks
involved have been taken into account. Children should not play with the appliance. Cleaning
and maintenance by the user should not be carried out by unattended children.
-Children under 3 years of age should be kept at a distance, unless they are under continuous
supervision. Children between the ages of 3 and 8 must only switch the appliance on or off,
provided that the appliance has been placed or installed in a normal position and that these
children are supervised or have received Instructions on how to use the device safely and
understand the potential hazards. Children between the ages of 3 years and 8 years must not
connect, adjust or clean the appliance, or perform maintenance on the appliance.
-It is compulsory not to dispose of the appliance with unsorted municipal waste and to collect
the appliance separately.
-CAUTION - Parts of this product may become very hot and cause burns. Particular attention
must be paid to the presence of children and vulnerable persons.
-CAUTION: To avoid overheating, do not cover the heater.
-The heater must not be placed directly below a power outlet.
-Do not use this heater near a bathtub, shower or swimming pool "(Mobile heating
appliances)
-WARNING: This heater is not equipped with a device for controlling the ambient
temperature. Do not use this heater in small rooms when they are occupied by persons
unable to leave the room alone unless constant monitoring is provided "(space heating
appliances without integrated room thermostat Or without thermal control device limiting
the ambient temperature).
-If the power cable is damaged, it must be replaced by the manufacturer, its after-sales
service or persons of similar qualification in order to avoid danger "
2. Technical specifications：
Model
form
Description
Rated voltage /
frequency
power
Product dimension
Weight
gross
Weight
net
Additional
function
ref 93477
steel frame
AC230V/50Hz
3KW
382㎜×325㎜×445㎜
6.7 KG
5.8 KG
ref 93477
steel frame
AC230V/50Hz
3KW
382㎜×325㎜×445㎜
6.7KG
5.8 KG
with a delay
function
Fuse: capacity must be more than 16A
Portable appliance

Electric connection: through coupler and plug
2. Product description and operation:
⑴ handle ⑵ switch knob ⑶ thermostat ⑷ front cover ⑸ steel frame ⑹
angle orientation plate ⑺adjustment knob ⑻ rear cover ⑼ motor
Control Panel

Rotary switch with 3 levels and 4 positions, the first level is ventilator only, the second level is 2KW heating
power，and the third level is highest power 3KW。
0～40C adjustable thermostat to control the room temperature，the thermostat button can
be turned from 0 to 270 degree.
THERMOSTAT INSTRUCTIONS
At first turn the thermostat to “Max” and let the heater operate with full power input. When the
room temperature reaches the required value, turn the thermostat to left until it switches off.
The thermostat will then switch on and off automatic to control the room temperature
according to the preset value and keep the room temperature constant.
When using the heater for the first time, you may notice a slight emission of smoke. This is
quite normal and it stops after a short time. The heating element is made of steel and was
coated with a layer of protection oil by production. The smoke is caused by the left oil when
heated.
After the use turn the thermostat to OFF position and turn the selector switch to Fan level, let
the appliance cool down for two minutes. For appliances with time delay stopping function,
even the power switch is off, the delay circuit may turn on the appliance if the inner
temperature reached the preset function value. The delay time depends on the ambient
temperature. For 20 C ambient it is ca. 3-4 minutes. If the ambient temperature keeps being
more than 27C so the delay device cannot cool down, the delay time may be very long or
the delay circuit doesn’t open，hereby the user can only disconnect the appliance from the
power supply by pulling out the plug.
3. Angle adjustment description:

During the operation the user can increase the air out-let angle, the biggest
adjustment is 14 degrees. Firstly tighten the adjustment knob at both ends of steel-
pipe rack then gently press the tail top of the product with hand, the heater will be
tilted. Adjust the hot air direction to the user needed angle, now the heater blows hot
air up, if the user needs the direction of air to be horizontal blown out, gently press
the control box top at the front part of product.
SAFETY INSTRUCTIONS:
Warning: In order to avoid overheating, do not cover the heater.
When using electrical appliances basic precautions should always be followed, including the
following:
1) Do not connect the appliance to the mains power socket if the voltage given on the rating
plate differs from the mains voltage.
2) Children should be supervised to ensure that they do not play with the appliance. If the
appliance is damaged, do not use it any more.
3) The heating device shall not be installed below a socket-outlets.
4) Do not use outdoors or in humid place. Never use the heater in the bathroom, shower or
near a swimming pool etc.
5) Do not place the appliance on moving vehicles or somewhere easy to be tipped over.
6) When you don’t use the appliance for a long time, unplug the appliance. Don’t leave the
heater for a considerable amount of time when in use. Pull the plug straight out, never
remove the plug by pulling on the cord.
7) Use the appliance in places with good air ventilation, do not position it near a wall or
corner.
8) When the appliance is in use, keep it far from combustible, explosive articles or
explosive, corrosive gas. Keep the heater far from curtain or places where the air inlet
can easily be blocked.
9) It is recommended that a separate circuit serving only this appliance be provided，keep
the power cord far enough from the hot air outlet；
10) Do not use this heater with a programmer, timer or any other device that switches the
heater on automatically,；
11) The power coupler is waterproof when not in use. In order to prevent possible electric
shock or leakage current, never use the appliance with wet hand or operate the
appliance when there is water on the power cord.
12) If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
13) Heater is not located immediately below a socket-outlet.
14) Do not use this heater in the immediate surroundings of a bath, a shower or a swimming
pool.
15) Do not throw the appliance in dustbin with wheels. Do not dispose of electrical
appliances as unsorted municipal waste, use separate collection facilities. Contact you
local government for information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being. When
replacing old appliances with new ones, the retailer is legally obligated to take back your
old appliance for disposals at least free of charge.
16) This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
17) Children should be supervised to ensure that they do not play with the appliance.
Cleaning and maintenance
Before cleaning the appliance, disconnect it from the socket and let it cool down.
The enclosure is easily to get dirty, wipe it often with soft sponge. For very dirty parts, wipe
with a sponge dipped in < 50°C water and mild detergent, then dry the heater enclosure with
clean cloth. Be careful not to let the water enter the appliance inner.
Don’t splash water onto the heater，never use solvent like gasoline, isoamyl acetate, toluene
etc. to clean the heater, in order to protect the enclosure.
Clean the coupler, dry and pack it in a plastic bag.
When you store the heater, let it cool down first, keep it dry. Then cover it with a plastic bag,
put in the packing box and store it in a dry, ventilated place.
Warranty Information
The manufacturer provides warranty in accordance with the legislation of the
customer's own country of residence, with a minimum of 1 year (Germany: 2 years),
starting from the date on which the appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service centre.
When making a claim under the warranty, the original bill of purchase (with purchase
date) must be submitted.
The warranty will not apply in cases of:
Normal wear and tear
Incorrect use, e.g. overloading of the appliance, use of non-approved
accessories
Use of force, damage caused by external influences
Damage caused by non-observance of the user manual, e.g. connection to an
unsuitable mains supply or non-compliance with the installation instructions
Partially or completely dismantled appliances
Correct Disposal of this product

This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for environmental safe
recycling.
