Ronbow Contempo Leonie 034723-F08 Assembly instructions

Installation Sheet
www.ronbow.com
Step 1 :
Step 2 :
Ronbow Corporation, All Rights Reserved.
Sink : Countertop : Model : 200555
218023
307023
367023
Step 3 :
Apply adhesive caulking around the
topside of rim near the edge, Carefully
raise sink in place, align, and press firmly
See Figure 1.
Attach 4 undermount-clips to hold
lavatory in place
See Figure 2.
Secure top & back splash to cabinet by
using adhesive caulk
See Figure 3.
Figure 1.
Undermount Clip
Figure 2.
Figure 3.
LEONIE 23”
Contempo Collection
034723-F08
034723-H01
For installing under counter sink and top
Countertop
adhesive caulking
silicon pad silicon pad
Stone Counter
to be continue on next page

www.ronbow.com Ronbow Corporation, All Rights Reserved.
Step 5 :
Step 6 :
From under the drain, insert the thick
rubber washer and screw on and tighten
the metal nut. Remove excess plumbers’
putty.
See Figure 5.
Attach p-trap to tailpiece.
Drain Nut
Tailpiece
Thick rubber
washer
P-trap
Drain
Figure 4.
Figure 5.
Drain Cap
Overflow hole
Metal Nut
Thick rubber
washer
Tailpiece
Step 4 : Place a generous portion of plumbers’
putty under drain cap and insert whole
drain body inside the bowl and through
the coutertop
(there maybe a small beveled rubber washer
packaged with your drain, please discard this
and use plumbers’ putty instead)
See Figure 4.
Installation Sheet
Sink : Countertop :
Model : 200555
218023
307023
367023
LEONIE 23”
Contempo Collection
034723-F08
034723-H01
to be continue on next page

Installation Sheet
www.ronbow.com Ronbow Corporation, All Rights Reserved.
LEONIE 23”
Model: 034723-F08
034723-H01
Contempo Collection
Step 1 :
Step 2 :
Step 3 :
Step 4 :
Step 5 :
Unpack glass shelf from styrofoam
packaging
See Figure 1.
Unscrew flat head setscrews in flass
shelf mounts (3) located inside cabinet
Turn Phillips head mount post screw
clockwise 90oor til tight
See Figure 2.
Insert glass shelf into mounts
See Figure 3.
Clamp glass shelf into mounts by
tightening setscrews
Becareful not to overtighten.
Figure 1
Figure 2
Figure 3
Glass shelf
Mount
Cabinet
Mount Post Screw
To Tighen 90° Clockwise
Set Screw
Mount
Plastic
Glass shelf
Mount Post Screw
Set Screw Mount
