Ronbow E032439-WH Assembly instructions

INSTALLATION AND CARE GUIDE
SINK
Sinktop

REV. 160811ronbow.eu | ronbow.comINSTALLATION SHEET
1
SINK Sinktop Without Overflow
Model : E012427
E012428
E032439
E042431
E042447
E052431
E052463
E062730
E072435
E072443
E082520
E092830
E092842
Tools Required
PRE-INSTALLATION
MATERIALS REQUIRED
1 drain

REV. 160811ronbow.eu | ronbow.comINSTALLATION SHEET
2
SINK Sinktop Without Overflow
Model : E012427
E012428
E032439
E042431
E042447
E052431
E052463
E062730
E072435
E072443
E082520
E092830
E092842
Figure 1.
Figure 2.
Figure 3.
Step 2: Place a generous portion of plumbers’
putty under drain cap and insert
whole drain body inside the bowl and
through the countertop.
Step 3:
Step 4:
From under the drain, insert the
thick rubber washer, screw on and
tighten the metal nut. Romove excess
plumbers’ putty.
Attach p-trap to tailpiece.
Place adhesive around top of cabinet.
See Figure 1.
See Figure 2.
See Figure 3.
Step 1:
INSTALLATION
adhesive caulking
Drain Cap
Overflow hole
Metal Nut
Thick rubber
washer
Tailpiece
Drain
sinktop
Drain Nut
Tailpiece
Thick rubber
washer
P-trap

REV. 160811ronbow.eu | ronbow.comINSTALLATION SHEET
3
SINK Sinktop Without Overflow
Model : E012427
E012428
E032439
E042431
E042447
E052431
E052463
E062730
E072435
E072443
E082520
E092830
E092842
Ceramic Sinks
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Bar Keeper’s Friend
• Household Vinegar
• Propietary Bathroom Cleaning Products
DISCLAIMERS: Eectiveness of cleaning your Ronbow products is dependent on various factors that include: water temperature, concentration and/or
amounts of cleansers. Because of these many dierent conditions, Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at [phone].

REV. 160811ronbow.eu | ronbow.comINSTALLATION SHEET
4
SINK Sinktop Without Overflow
Model : E012427
E012428
E032439
E042431
E042447
E052431
E052463
E062730
E072435
E072443
E082520
E092830
E092842
Recommended Products
Solid Surface Sinks
• Propietary Bathroom Cleaning Products
DISCLAIMERS: Eectiveness of cleaning your Ronbow products is dependent on various factors that include: water temperature, concentration and/or
amounts of cleansers. Because of these many dierent conditions, Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• After applying recommended cleaning products, wipe surfaces clean and rinse completely with water
immediately
• Use mild cleaning solution only, Strong, abrasive cleaners are not recommended, and can damage surface.
Do not allow cleaner to soak.
• Use a soft, dampened sponge or cloth. Never use an abrasive materials such as a brushed or scouring pad
to clean surface.
• Always test your cleaning solution on a inconspicuous area before apply to the entire surface.
• Hot pans, electric frying pans, waffle irons, crock-pots, and other heat-generating appliances can damage
the surface. To prevent heat damager, always use a trivet with rubber feet between the appliance and the
countertop.
• Avoid exposing solid surface to strong chemicals, such as paint removers, oven cleaner, ect. If contact
occurs, quickly flush the surface with water.
• Remove nail polish with a non-acetone-based nail polish remover and flush with water.
• Do not cut directly on your solid surface countertop. Cutting directly on it will damage the surface.
• Run cold water when pouring boiling water into sinks
• Soapy water and a sponge will remove most stains. Do not use 409 or Fantastik.
• For more stubborn stains use a blue scotch-brite pad and Soft-Scrub.

160811
40650 Encyclopedia Circle
Fremont, CA 94538
T 510.713.1188
F 510.657.9388 ronbow.eu | ronbow.com

INSTALLATION AND CARE GUIDE
SINK
Above Counter

REV. 160810ronbow.eu | ronbow.comINSTALLATION SHEET
1
SINK Above Counter Without Overflow
Model : E012001
E012002
E012003
E012005
E012006
E022002
E022003
E022004
E032001
E032002
E092001
Tools Required
PRE-INSTALLATION
MATERIALS REQUIRED
1 drain

REV. 160810ronbow.eu | ronbow.comINSTALLATION SHEET
2
SINK Above Counter Without Overflow
Model : E012001
E012002
E012003
E012005
E012006
E022002
E022003
E022004
E032001
E032002
E092001
Figure 1.
Figure 2.
Figure 3.
Step 2: Place a generous portion of plumbers’
putty under drain cap and insert
whole drain body inside the bowl and
through the countertop.
Step 3:
Step 4:
From under the drain, insert the
thick rubber washer, screw on and
tighten the metal nut. Romove excess
plumbers’ putty.
Attach p-trap to tailpiece.
Position countertop opening to ensure
clearance between the lavatory, faucet
and backsplash. Cut 1-3/4” hole for
drain in countertop.
See Figure 1.
See Figure 2.
See Figure 3.
Step 1:
INSTALLATION
Drain Cap
Metal Nut
Thick rubber
washer
Tailpiece
Drain
Drain Nut
Tailpiece
Thick rubber
washer
P-trap

REV. 160810ronbow.eu | ronbow.comINSTALLATION SHEET
3
SINK Above Counter Without Overflow
Model : E012001
E012002
E012003
E012005
E012006
E022002
E022003
E022004
E032001
E032002
E092001
Ceramic Sinks
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Bar Keeper’s Friend
• Household Vinegar
• Propietary Bathroom Cleaning Products
DISCLAIMERS: Eectiveness of cleaning your Ronbow products is dependent on various factors that include: water temperature, concentration and/or
amounts of cleansers. Because of these many dierent conditions, Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at [phone].

REV. 160810ronbow.eu | ronbow.comINSTALLATION SHEET
4
SINK Above Counter Without Overflow
Model : E012001
E012002
E012003
E012005
E012006
E022002
E022003
E022004
E032001
E032002
E092001
Recommended Products
Solid Surface Sinks
• Propietary Bathroom Cleaning Products
DISCLAIMERS: Eectiveness of cleaning your Ronbow products is dependent on various factors that include: water temperature, concentration and/or
amounts of cleansers. Because of these many dierent conditions, Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• After applying recommended cleaning products, wipe surfaces clean and rinse completely with water
immediately
• Use mild cleaning solution only, Strong, abrasive cleaners are not recommended, and can damage surface.
Do not allow cleaner to soak.
• Use a soft, dampened sponge or cloth. Never use an abrasive materials such as a brushed or scouring pad
to clean surface.
• Always test your cleaning solution on a inconspicuous area before apply to the entire surface.
• Hot pans, electric frying pans, waffle irons, crock-pots, and other heat-generating appliances can damage
the surface. To prevent heat damager, always use a trivet with rubber feet between the appliance and the
countertop.
• Avoid exposing solid surface to strong chemicals, such as paint removers, oven cleaner, ect. If contact
occurs, quickly flush the surface with water.
• Remove nail polish with a non-acetone-based nail polish remover and flush with water.
• Do not cut directly on your solid surface countertop. Cutting directly on it will damage the surface.
• Run cold water when pouring boiling water into sinks
• Soapy water and a sponge will remove most stains. Do not use 409 or Fantastik.
• For more stubborn stains use a blue scotch-brite pad and Soft-Scrub.

160810
40650 Encyclopedia Circle
Fremont, CA 94538
T 510.713.1188
F 510.657.9388 ronbow.eu | ronbow.com
