* Troubleshooting
The following form lists the common operating system with problem and solutions. Please read the
form carefully and follow
it.
M1
.'f):JHIUMlf
any
of
the following symptoms appears during your operating, stop using the tool
immediately, or serious personal injury could result. Only a qualified persons
or
an authorized service center
can perform repairs or replacement
of
tool.
Disconnect tool from air supply before attempting repair or adjustment. When replacing 0-rings or
Cylinder, lubricate with air tool oil before assembly.
SYMPTOM
PROBLEM
SOLUTIONS
Air leak near top
of
tool or 1.0-ring in trigger valve are damage. l .Cbeck and replace 0-ring.
in trigger area 2.Trigger valve head are damage. 2.Check and replace.
3.Trigger valve stem ,seal or 0-ring are 3.Check and replace trigger valve
damaged. seal or 0-ring
Air leak near bottom
of
tool. I. Loose screws. I.Tighten screws.
stem,
2.
Worn
or damaged 0-rings or bumper. 2.Check and replace 0-rings or bumper.
Air leak between body and I. Loose screws. I.Tighten screw.
cylinder cap.
2.
Worn
or damaged 0-rings or seals. 2.Check and replace 0-rings or bumper.
Blade driving fastener too
1.
Worn
bumper. I.Replace bumper.
deep.
2.
Air pressure
is
too high. 2.Adjust the air pressure.
Tool does not operate well:
1.
Inadequate air supply. I.Verify adequate air supply.
can not drive fastener or
2.
Inadequate lubrication. 2.Place 2 or 6 drops
of
oil into air inlet.
operate sluggishly.
3.
Worn
or damaged 0-rings or seals. 3.Check and replace 0-rings or seal.
4.Exhaust port in cylinder head
is
4.Replace damaged internal parts.
blocked.
Tool skips fasteners. I.Worn bumper or damaged spring. l .Repalce bumper orpusher spring.
2.Dirt in front plate. 2.Clean drive charmel on front plate.
3.Dirt or damage prevents fasteners from 3.Magazine needs to be cleaned.
moving freely
in
magazine.
4.Worn or dry 0-ring on piston or lack
of
4.0-ringneed to be replaced.
lubrication. And lubricate.
5.Cylinder cover seal leaking. 5.Replace Sealing washer.
Tool jams. I.Incorrect or damaged fasteners. I.Change and use correct fastener.
2.Damaged
or
worn driver gnide. 2.Check and replace the driver.
3.Magazine
or
nose screw loose. 3.Tighten the magazine.
4.Magazine
is
dirty. 4.Clean the magazine.
-5-
