Ronin MR400 User manual

MEASURE
PRODUCT LIST:
1 hard case with wheels and extensible handle.
1 Ronin MR400 Ascender
1 Battery
1 Charger
1 Charger cable type A, C, G
RONIN MR400 ASCENDER W
HARD CASE
PRESENTS
ART. NR. 40002
MR400 – A battery operated Power Ascender out
of the ordinary.
The ascender is delivered in a protective Hard Case together
with a battery and a charger.
MR 400 means Multiple Ropes – 400 lbs (181 kg).
The ascender can handle different ropes with a diameter of
between 10 mm-13 mm and is certified to handle 181 kg.
To reach an optimal use of the machine CE EN1891/
EN564-classed Kernmantelropes with low
elasticity should be used.
The ascender is supplied with a battery and charger, contained
in a Mr Ronin Hard Case.
a:
b:
c:
Weight incl. the Li:
Strengths:
450 mm (17.7 in)
585 mm (23 in)
265 mm (10.4 in)
20 kg (44 lbs)
Robust, Gas- and Waterproof (IP 68)
b
a
c

DESCRIPTION
A Ronin ascender supplied in a well thought-out case.
The machine is the lightest in the market with that capacity.
It weighs only 9 kg (11 kg with battery). It is quick and easy to
use. The batteries are exchanged easily and safely also during
use a height.
The Ascender is certified for a maximum weight of 400
lbs/181 kg, but with the right rope it can li250 kg e.g. in a
rescue situation. As a safety measure, there is an automatic
overheating device which stops the motor if it is overheated.
Aer a short rest it can be run again. We recommend, however,
that during regular conditions, you work in accordance with
the certification of the ascender – maximum 400 lbs/181 kg –
so as not to damage it.
The throttle lever for going up or down, a continuous scroll
switch, is adjusted with your thumb. Controlled lowering
without the help of the motor can be done manually with a
mechanical friction brake.
A Ronin ascender grabs hold of the rope through letting it be
wound 2,5 times around a driving axis. This means that a Ronin
ascender can limore weight than others throughout time
when using muddy ropes. Other ascenders grab rope with the
help of blade wheels. It is not unusual that ropes full of e.g.
concrete dust, wear these blade wheels down, which results
in high costs for service and spare parts. Those using a Ronin
ascender will not have to experience that.
ROPES TO BE USED IN THE ASCENDER:
EN 1891 and EN 564
Aramid or core jacket ropes
2-3 % elasticity is recommended (the lower the better).
As the rope passes through the ascender with its end at start-up
there are certain demands. The end of the rope should be roun-
ded and without shrink-wrap marking or tape. The end of the rope
should be similar to a tip of an index finger.
This product contains an ascender with battery and battery char-
ger, safely stored in a protective case. This Hard Case makes it eas-
ier not only for transportation between workplaces, but also when
your equipment should be sent somewhere else with an external
forwarder. Negligible risk of external influence during transport.
PRODUCT DESCRIPTION
*1 hard case with wheels and extensible handle.
*Cut out foam with room for:
1 Ronin MR400
2 batteries
1 battery charger
1 Petzl ASAP
1 Petzl Absorber complete with carbines
6 or 8 carbines (depends on whether you have Absorber with
carbines in your case).
In the lid of the case there is a storage box for directions for use
and other manuals

SPECIFICATIONS
METRIC SYSTEM:
Rope Diameters
Rope Type
Ropes Specs
Rope Elongation (elasticet)
Ascender Capacity
Ascent Speed
Descent Method
Descent Speed
Weight Li
Ingress Protection (IP)
Product Approvals
Battery Weight
Battery Re-Charge time
Operating Temp.
Battery Life Ascent Temp Range 20C - 40C
(91 kg)
(181 kg)
Battery Life Ascent Temp Range 0C - 20C
(91 kg)
(181 kg)
Battery Life Ascent Temp Range -20C - 0C
(91 kg)
(181 kg)
IMPERIAL SYSTEM:
Rope Diameters
Rope Type
Ropes Specs
Rope Elongation (elasticet)
Ascender Capacity
Ascent Speed
Descent Method
Descent Speed
Weight Li
Ingress Protection (IP)
Product Approvals
Battery Weight
Battery Re-Charge time
Operating Temp.
Battery Life Ascent Temp Range 20C - 40C
(200 lbs)
(400 lbs)
Battery Life Ascent Temp Range 0C - 20C
(200 lbs)
(400 lbs)
Battery Life Ascent Temp Range -20C - 0C
(200 lbs)
(400 lbs)
10 – 13 mm
Aramid or Kernmantle Sheath
EN1891 or EN564
2 - 3,3%
181 kg
Variable 0.3 – 0.75 m/s
Gravity Feed with manual brake
2.4 m/sec max @ 181 kg
9 kg
IP54
CE and ANSI
2.9 kg
2.5 hour
-15 C - 57 C
259 m
137 m
152 m
76 m
76 m
54 m
10 – 13 mm
Aramid or Kernmantle Sheath
EN1891 or EN564
2 - 3,3%
400 lbs
Variable (1.0 – 2.5 ./sec)
Gravity Feed with manual brake
8.0 ./sec max @ 400 lbs
Approx 20 lbs
IP54
CE and ANSI
6.5 lbs
2.5 hour
5 F - 135 F
849 
449 
498 
249 
249 
177 
