ROOMS TO GO 18565703 Setup guide

SETUP AND OPERATION GUIDE
TRIPLE PWR RECLINER
SKU: 18565703/ 18565715/ 18565727
Vendor Code: MVLC

Note:
Page 1
·
TABLE OF CONTENTS
When placing the furniture on non-carpeted flooring, it is recommended to use
some type of floor protection such as an area rug or furniture pads under the
chair glides. Area rugs and padding are not included with purchase.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that
may cause undesired operation of the device. Modifications not approved by
the party responsible for compliance could void user's authority to operate
the equipment.
This power furniture is not intended for use by persons(including children)with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction regarding
the use of this item by a party responsible for their safety.
Children should be supervised to ensure that they do not play with or mishandle
any part of the operating system of this item.
Assembly of Your Lift Chair or Recliner
Cord and Transformer Connections
2
3
4
5
5
Hidden Cup Holders with Wireless Charging
Operating Instructions For Triple Power Sku’s
6
Installation of Back-up Batteries
6
Troubleshooting
Important Safety Instructions
Chair Assembly

Page 2
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING.
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons:
DANGER: To reduce the risk of electric shock-Always unplug this furnishing from
the electrical outlet before cleaning.
Unplug from outlet before putting on or taking off parts.
Close supervision is necessary when used by or near children, or disabled people.
Use this furnishing only for its intended use as described in these instructions.
Do not use attachments not recommended by the manufacturer.
Never operate this furnishing if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water.
Keep the cord away from heated surfaces.
Never drop or insert any object into any opening.
Do not use outdoors. Just for household indoor use only.
To disconnect, turn all controls to the off position, the remove plug from outlet.
WARNING: Risk of injury - Keep children away from extended foot support.
WARNING: Risk of injury to Persons – do not use this furnishing to support video
equipment such as televisions or computer monitors.
When not in use, it is recommended that the wand be stored securely in the
pocket on the outside of the arm.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
SAVE THESE INSTRUCITONS.
In a double-insulated product, two systems of insulation are provided instead
of grounding. No grounding. No grounding means is provided on a double-in-
sulated product, nor is a means for grounding to be added to the product.
Servicing a double-Insulated Product requires extreme care and knowledge of
the system, and is to be done only by qualified service personnel. Replace-
ment parts for a double-insulated product must be identical to the parts they
replace.
SERVIVING OF DOUBLE- INSULATED PRODUCTS.

Page 3
Connect the Headrest and Lumbar cable plugs (Figure C). Headrest-only
modelshave only one set of cables.
Figure C
Lumbar
Headrest
Slide inside back receivers onto the steel mechanism posts in the base of the
chair. (Figure A)
To remove the back from the base, use a screwdriver pressing outward on
the black tab in the metal receivers on both sides of the chair back and lift the
back from the base of the chair to release. (Figure B)
ATTACHING THE CHAIR WINGS TO
THE CHAIR BACK *
Slide the wings down until they are
completely set on the backs metal
sleeves.
Metal Sleeves
Metal Inserts
Wing
Chair Back
Back Receivers
Steel
Mechanism
Post
Figure A
Figure B
Screwdriver required (not included)
CAUTION: PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING ASSEMBLY
PROCESS. IT IS RECOMMENDED TO USE TWO PEOPLE WHEN ASSEMBLING AND
REMOVING THE INSIDE BACKS TO AND FROM THE BASE OF THE FURNITURE.
Press both sides of the back firmly into place until the back automatically
locks into track.
STEP1:
STEP2:
STEP3:
STEP4:
STEP1:
STEP2:
Slide the metal inserts on the chair’s
wings into the metal sleeves on the
side of the chair back.
CHAIR ASSEMBLY
ATTACHING THE CHAIR BACK TO THE CHAIR BASE

1.
2.
3.
4.
5.
6.
7.
Side Switch Control or Remote
Transformer
and Cord
Power Transformer and Cord
Page 4
CORD AND TRANSFORMER CONNECTIONS
Once the box has been removed from around the chair, you’ll notice the back
is laying on top of the seat. There are a couple items to remove from the seat
portion of the chair first. Follow the steps below:
Remove the zip tie holding the foam bag with the Power Transformer and its
cord on the left.
You can find a remote in the pocket Panel of the chair.
Take out the remote from the side pocket of the chair. Remove the remote
from the plastic bag and connect it to the female plug located in the outside
pocket of the chair.
Connect the Power Transformer to the plug coming from the chair.
Connect the Power Cord into the Power Transformer.
Connect the Power Cord into an electrical outlet near where the chair will be
positioned.
Connect the heat pad from the back to the seat.
Power
Transformer
Power
Cord
HEAT
BACK
HEAT
HEAT
HEADREST
Lumbar
Back
Seat

Page 5
OPERATING INSTRUCTIONS FOR TRIPLE POWER SKU’S
Hidden Cup Holders with Wireless Charging
Charging your Smartphone on the Wireless Charger
Open the front of the arm to use the hidden cup holders.
WARNING! Your smartphone may shift or fall out of the charger when the chair is raised. Remove
your smartphone from the wireless charger prior to elevating your chair above a seated position.
Failure to do so may result in personal injury and/or property damage.
Headrest
Headrest Down Headrest Up
USB
Lower lift Chair
Close All and Lift
Red light - Stronge HEAT
HEAT (ON/OFF)
Green Light - Soft HEAT
Lumbar
Lumbar In Lumbar Out
Product Protected By Following Patents:
Patented Articulating Power Headrest & Lumbar
US Patent: 10,736,423

00474 REV A
Page 6
(Not Included)
2 - 9 Volt back-up batteries will lift the chair from the reclined position to the
seating position one cycle in case of a
power failure. If a power failure occurs
and the chair is cycled, the 2 - 9 Volts
batteries will need to be replaced.
1. Removed the sliding door on the
side of the transformer to locate the
2 - 9 Volt batteries.
2. Pull out the 2 - 9 Volts batteries and
replace with new batteries.
3. Replace door on the transformer.
4. Batteries not included.
INSTALLATION OF BACK-UP BATTERIES
Confirm the wire from
chair to transformer is
firmly connected
Chair doesn't recliner or lift
Headrest or lumbar motor
wires may not be
connected well inside back
flap of chair
Check the headrest
and lumbar motor
wires have been
correctly connected
Headrest or Lumbar doesn’t
work
Headrest and lumbar
motor plug have been
cross connected
Check the headrest and
lumbar motor wires
(labeled) have been
correctly connected
Headrest and lumbar work
oppositely
Remote may not be
connected well
Check the remote cord
has been correctly
connected to plug
The remote doesn’t work
Transformer may not be
connected well
Check the power supply
has been correctly
connected to
transformer and socket

•NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
by the party responsible for compliance could void user's authority to operate the equipment.
Customer Service
If you have any questions regarding the use of this unit,or find that your unit needs service, please
contact your retailer.
