ROOMS TO GO HMIS F1823-04 HUTCH User manual

1 OF 2
MADE IN VIETNAM
Step 1
This product is manufactured by HMIS for
4
A
B
B
A
Step 2
Hardware Pack Location(s):
HMIS F1823-04 HUTCH, SKU# : 26818231
3
5
4
4
2
3
5
5
1
Step 3
Assembly Instructions
HMIS F1823-04 HUTCH SKU #: 26818231
1Pc
Code
1
2
3
Table Top
PARTS LIST
2pcs
4
Middle Sheft
Right Middle Table Base
Side Table Base
2pcs
5
Credenza
(Sold Separately) 1Pc
Left Middle Table Base
6
1Pc
1Pc
***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people
are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly.
Hardware List
Step
1+2+3
5
Code
A
Allen Bolt - Ø1/4x20x19mm
Lock washer - Ø1/4"
1Pc
Allen Key - 4mm
Flat washer - Ø1/4x16x1.5mm
B
20Pcs
Step 1 :Assembly the Side Table Base(4), Middle Table Base
(2,3) with the Middle Sheft(5) using the bolts (A) and tighten
them through by Allen Key (B) provided.
Do not fully tighten all bolts until the assembly is completed.
Step 2 + Step 3: Assembly Table Base(2), Middle Table Base
(3) with the Table top(1) using the bolts (A) and tighten them
through by Allen Key (B) provided.
Do not fully tighten all bolts until the assembly is completed.
2Pcs
Iron -plate - 94 x 20 x 2mm
C5
20Pcs
20Pcs
TOOLS REQUIRED (NOT PROVIDED)
Phillips screwdriver
Description Sketch

***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people
are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly.
2 OF 2
MADE IN VIETNAM
This product is manufactured by HMIS for
C
C
Wall
Step 4
Step 5
Step 6
Assembly Instructions
HMIS F1823-04 HUTCH SKU #: 26818231
Step 4 :Put the Hutch on the Credenza (6) carefully.
Step 5 :Use the iron plate (C) to connect the Hutch with Credenza
(6) , using the bolts (A) and tighten them through by Allen Key
(B) provided. Tighten all the bolts. Assembly completed.
RECOMMNED: Install the anti-tipping kit of the Credenza (6).
(RECOMMEND)
6
C
B
A
